Introduction
Q2 is a wireless display receiver that supports AirPlay mirroring for Apple iOS and Mac
systems and supports the Miracast standard protocol for Android and Windows systems to sync
images from mobile, tablet, and notebook displays to TV, Projector, car screen and other large
screen, enjoy the big screen fun; In addition, it also applies to home multimedia applications and
Streaming media player player DLNA . Q2 "screen sharing" concept for home entertainment,
gaming experience, business meetings, party sharing and other scenes, enjoy the experience of
sharing the beauty of large screen. This brochure will guide you using Q2 wifi display dongle.
Package Contents
Please check if the following items are included in the product box
Q2 Dongle
HD cable
AV cable
USB cable
User Manual
User Manual
x1
x1
x1
x1
x1
Advertisement
Table of Contents
Summary of Contents for Sinmax Q2
-
Page 1: User Manual
Streaming media player player DLNA . Q2 "screen sharing" concept for home entertainment, gaming experience, business meetings, party sharing and other scenes, enjoy the experience of sharing the beauty of large screen. This brochure will guide you using Q2 wifi display dongle. Package Contents... -
Page 2: Hardware Installation
Q2 for 2. 4G & 5G dual WiFi channel, it will be based on the home router channel to select the appropriate mode (default is 5G mode). - Page 3 2.2Open the phone settings "WI-FI, find the same device signal RENKCHIP- ******, enter the password 12345678 connected with the Q2 dongle. 2.3To ensure that the phone is connected with the Q2 dongle signal,open the browser in your phone, enter the dongle IP address 192.168.49.1 into the settings background, click on the first option WiFi, search the current available WiFi, enter the WIFI password, Connected to WIFI.
- Page 4 Airplay mirroring for IOS(iPhone/iPad) Mirror is the core function of Q2, suitable for IOS8.0 and above iphone and ipad. Because Q2 has two ways to connect to the network, the connection mode is different, with the screen mirror operation steps are some differences, please read carefully.
- Page 5 1. Macbook use Q2 please press the mode switch button in this UI interface. 2. Open the MACBOOK WiFi, find and connect the Q2 dongle signal RENKCHIP - ******, If Q2 is already connected to the router, MACBOOK can also connect the same router without the need to connect to Q2.
- Page 6 Miracast for Android The screen mirroring is the core function of Q2, suitable for Android4.4 and above and supports Miracast protocol mobile phone tablet. 1.Please confirm Q2 in Miracast mode. 2.Open Miracast on Android device. Common shortcut keys operation, such as Samsung Smartview, Huawei multi-screen interaction.
- Page 7 Expand the function Q2 can be used as a simple router. In the room where WiFi can not be covered, please power on Q2 and plug in the network cable. Tap the mode switch key to this UI interface,...
- Page 8 Q.Phone system has been upgraded, can not use Q2 A.Q2 for the phone version upgrade will be a new version of the firmware, only need to set Q2 connected to the available network, Q2 will automatically download the new firmware, and install.
