Summary of Contents for SAUNAKESKUS Duetto
- Page 1 Duetto Electric sauna infrared emitter Instructions for installation and use Made in Finland...
-
Page 2: Table Of Contents
Instructions for installation and use Electric sauna infrared emitter CONTENTS Delivery includes Technical details Symbol explanations Note before installation Infrared heater controls General safety precautions The amount and use of infrared heaters The need for infrared heaters Example of installation Placing an infrared heater Infrared heaters for stove sauna Joint use of infrared heaters and sauna stove... -
Page 3: Delivery Includes
Prompting symbol “Please read instructions for use, care and installation before installing or using the equipment” Prohibiting symbol ”The device must not be covered” ® Duetto infrared heater for stove sauna is certified Infrasauna heater is marked Unearthed electric device Safety instructions Do not touch the heater while it is switched on. -
Page 4: Note Before Installation
NOTE BEFORE INSTALLATION Infrared heater controls Duetto® -infrared heater can be used in the same space with a regular sauna stove. Please note the included instructions for use, care and installation. When adjusting the temperature, it is recommended to use a separate control unit. - Page 5 Instructions for installation and use Electric sauna infrared emitter INFRARED HEATER MUST NOT BE COVERED! Covering it causes a hazard of fire. Note danger of life: Never carry out repairs yourself. The device shall only be opened at the manufacturing factory. The device shall only be controlled by a control unit or timer suitable for controlling an infrared heater.
-
Page 6: The Amount And Use Of Infrared Heaters
Electric sauna infrared emitter THE QUANTITY AND USE OF INFRARED HEATERS ® The heat that Duetto -infrared heaters produce, makes you feel good. Placing the infrared heater close to the bigger muscles of the body gives a maximum benefit of the heaters. -
Page 7: Placing An Infrared Heater
Instructions for installation and use Electric sauna infrared emitter In a stove-heated sauna, the distance between a heater and sauna ceiling should be no less than 100 mm. In a stove-heated sauna you need three heaters for two bathers, for example, when using the regular stove at the same time. -
Page 8: Adjusting The Temperature
If the stove is on simultaneously with the infrared heaters the thermostat of the control unit is installed on the wall close to the heaters. ® If you use a timer to control Duetto –infra red heaters (with bipolar cut-off), the heaters do not need a room thermostat. -
Page 9: Installing Instructions
Instructions for installation and use Electric sauna infrared emitter INSTALLING INSTRUCTIONS Check the product in case of any damages from the transport. Attach the infrared heater following the instructions. Pay attention to installing the screws, covering plugs and casing the visible parts of the silicone cable. Perform the electric installations. -
Page 10: Installation Distances
Instructions for installation and use Electric sauna infrared emitter Installation distances Infrared heater can be mounted onto a wooden surface directly from its back and edges. The safety distance between hot front part of the infrared heater and flammable material is 5mm Infrared heater must not be covered. -
Page 11: Electric Wiring Of Infrared Heaters
Instructions for installation and use Electric sauna infrared emitter ELECTRIC WIRING OF INFRARED HEATERS When performing the electric wiring the infrared heaters can be connected in two different ways - either shunt or series. Shunt Series If two heaters are connected in series the fuse size needed is reduced. -
Page 12: Guarantee
Instructions for installation and use Electric sauna infrared emitter WARRANTY The warranty is consistent with currently existing specifications. Manufacturer’s guarantee This warranty clause is followed between Rauduspuu Oy (later “Manufacturer”) and the other party (later “Client”) considering the products provided by the Manufacturer, unless otherwise specifically agreed in writing in the agreement.
