Goodview L H7 Series Quick Start Manual

Quick Start Guide
Applicable for Model Series:LxxH7/PFxxH7 Series(Android Version) /MxxSA Series

RCU Instruction

Easy use, most operation can be
finished just by remote controller(RCU)
Button
POWER
MENU
SETUP
SOURCE
HDMI
VGA
YPbPr
Notice:
The buttons hasn't mentioned above are reserved
for work with other version in the future

Terminal Intro

1. AC Switch: Power Switch
2. AC IN: Power Cable In
3. WIFI: WIFI Antenna Port
4. LAN: Network connection Port
5. HDMI: HDMI Signal Input
6. VGA: VGA Signal Input
More instructions please ask for your supplier
Function
Power On/Off
Start Display Driver Menu
Start OSD Menu Setting
Start Signal Source Setting
Play/Confirmation
Move Up Cursor
Move Down Cursor
Move Left Cursor
Move Right Cursor
Provious Program
Next Program
Stop play&Retrun Main screen
Mute
Raise Volume
Lower Volume
Choose HDMI as Signal
Choose VGA as Signal
Choose YPbPr as Signal
More instructions please ask for your supplier
LxxH7
Remote Control window
7. Audio: Audio Signal Input
8. USB: Media Play Or System Upgrade
9. USB: Media Play Or System Upgrade
10. SIM: SIM Card Install Connector
11. TF: TF Card Extense Connector
PFxxH7
MxxSA
