Summary of Contents for Man Roland IPS.LBA-1
- Page 1 Operating Instructions IPS.LBA-1 Operating Instructions - IPS.LBA-1...
-
Page 2: Table Of Contents
Front View of Module Block Diagram Diagnostics LEDs 3.1. Subassemblies with Index A, B 3.2. Subassemblies from Index D onwards Pin Configuration 4.1. Connector Pin Assignment of X1 Remote In 4.2. Connector Pin Assignment of X2 Remote OUT Operating Instructions - IPS.LBA-1... -
Page 3: General
Subassemblies with Index C were never delivered. 1.2. Brief Description • The IPS.LBA-1 (INTERBUS-Based Press I/O System . Loop Bus Adapter - Type 1) is an I NTER remote bus node (bus terminal) and is for linking an INTERBUS loop spur. -
Page 4: Technical Data
Class 2, assessment criterion 3 61000-4-5 (Surge) • Immunity to interference according to IEC 10 V, assessment criterion 1 61000-4-6 (HF conductor) Supply for IPS.LBA-1 internal logic (+24V / 0V • Rating: 24 V DC • Permissible range: 20 .. 30 V (including ripple) •... -
Page 5: Technical Data Of Remote Bus Interfaces
Maximum line length between two loop nodes (see al- Index A, B: 12 m so: Allgemeine Information - Interbus Loop [General Index D onwards: 20 m; but MAN ROLAND Information on Interbus Loop]) specification: 12m Supply for loop subassemblies (output for loop connection, terminals 7 and 8) •... -
Page 6: Front View Of Module
24V supply and LOOP Terminal labelling IPS.LBA-1 16.86958-0022 A B C D E F Diagnosis LEDs Subassemblies LOOP BUS-ADAPTER labelling Ident Number : 4 Data Words Plug label Remote IN Remote OUT Plug connections for remote bus Operating Instructions - IPS.LBA-1... -
Page 7: Block Diagram
2. Block Diagram Loop Loop Bridge, module loop not necessary supply supply (out) (back) from Index D onwards ± Filter Filter Current limitation 28.5V Logic NTER Controller SUPI Remote Remote Operating Instructions - IPS.LBA-1... -
Page 8: Diagnostics Leds
Error red LED The master can set this LED if it localizes an error on the IPS.LBA-1 or the I/O modules that are connected to it. The box below shows the function of the LED that is located on the top edge of the subassembly. -
Page 9: Subassemblies From Index D Onwards
Error red LED The master can set this LED if it localizes an error on the IPS.LBA-1 or the I/O modules that are connected to it. The box below shows the functions of the four LEDs that are located on the top edge of the subassembly. -
Page 10: Pin Configuration
4.2. Connector Pin Assignment of X2 Remote OUT 9-pin Sub-D female connector for connecting the OUT two-wire remote bus Signal Meaning + Data out + Data in Reference con- ductor Logic voltage /DO2 - Data out /DI2 - Data in RBST RBST signal Operating Instructions - IPS.LBA-1... - Page 11 Data Receive + Data return path = Loop IN and outgoing loop voltage (Index A,B) or U OUT (Index D) Data Receive - respectively LBST Wire jumper; no longer necessary from subassemblies with Index D onwards. Operating Instructions - IPS.LBA-1...
