Page 1 GUARDIAN A6-6000 Dispensing System For use with non-flammable foam and polyurea. Not for use in explosive atmospheres. Important Safety Instructions Read all warnings and instructions in this manual. Save these instructions. U.S.A. CHINESE PATENT PATENT ZL 200630130159.1 D546,840...
Page 2: Table Of Contents
Table Of Contents Section 1 Installation Warnings ................................Introduction ................................ Standard Equipment ............................Equipment Assembly ............................Section 2 Operation Start-up Instructions ............................Shut–down Instructions ............................Daily Start-Up Instructions ..........................Section 3 General Information Assembly Drawings ............................. Sub Assembly Drawings ............................Maintenance ................................
Page 3: Warnings
Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclamation point symbol alerts you to a general warning and the hazard symbol refers to procedure-specific risk. Refer back to these warnings. Additional, product-specific warnings may be found throughout the body of this manual where applicable. WARNING ELECTRIC SHOCK HAZARD Improper grounding, setup, or usage of the system can cause electric shock.
Page 4 Warnings WARNING FIRE AND EXPLOSION HAZARD Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. To help pre- vent fire and explosion: • Use equipment only in well ventilated area. • Eliminate all ignition sources; such as pilot lights, cigarettes, portable electric lamps, and plastic drop cloths (potential static arc).
Page 5 Warnings Isocyanate Hazard To prevent exposing ISO to moisture: • Always use a sealed container with a desiccant dryer in the vent, or a nitrogen atmosphere. Never store ISO in an open container. • Keep the ISO lube pump reservoir filled with Graco Spraying materials containing isocyanates creates Throat Seal Liquid (TSL), Part 206995.
Page 6 Warnings Keep Components A and B Changing Materials Separate • When changing materials, flush the equipment mul- tiple times to ensure it is thoroughly clean. CAUTION • Always clean the fluid inlet strainers after flushing. To prevent corss-contamination of the equipment’s wet- •...
Page 7: Introduction
GlasCraft system, read and understand all of the relationship typical use. Each assembly should be technical and safety literature provided with GlasCraft directed by a GlasCraft distributor or made from the products. If you do not have the proper or related GlasCraft Assembly instructions provided.
Page 8: Standard Equipment
Section 1 - Installation: Standard Equipment Model - A-000 Part Description Number 23675- A6-6000 UNIT 23950-02 PROBLER P2 GUN 249588 HIGH PRESSURE HOSE ASSEMBLY 256626 WHIP HOSE ASSEMBLY 23473-00 HEATER REPAIR KIT GC-1398 USER MANUAL 59934-04 DIOCTYL PHTHALATE, 1 QT. 261821 REQUIRED TO COMPLETE THE HOSE ELECTRICAL CIRCUIT.
Page 9: Equipment Assembly
Depending on the electrical setup, it may be necessary to install an appropriate plug on the end of the cable. GlasCraft will not supply this plug, as we are unaware of which style will be needed. c. Consult the data sheet for the specific unit being installed to determine the proper breaker size needed.
Page 10 Section 1 - Installation: Equipment Assembly Remove the “red” plastic caps that cover the material Install a male quick disconnect fitting to air inlet of inlets on the bottom of the pumps, and the air inlets both pumps. Besure to use teflon tape on the threads. on the air motor portion of the pumps.
Page 11 Section 1 - Installation: Equipment Assembly Remove the 2 inch bung caps on both the A and B Remove the metal caps from the material pumps. side drums. Install the transfer pump collars into the bung holes, making sure to lubricate the threads with vaseline or grease, thus enabling easy removal when needed.
Page 12 Section 1 - Installation: Equipment Assembly Connect one end of each material hose to the inlet fittings located on the back of the machine. It is highly recommended that you label the (POLY) hose with BLUE tape and the (ISO) hose with RED tape to ensure that you don’t put the wrong transfer pump in the opposite material drum.
Page 13 Section 1 - Installation: Equipment Assembly a. Install the female quick-disconnect fittings p/n 22642-01 on to the ¼ in. air lines p/n 17798-10 that came in the transfer kit. Besure to use teflon tape on the threads. POLY Material Inlet Fitting b.
Page 14 Section 1 - Installation: Equipment Assembly If the optional scuff-jacket p/n FM-494 is being Connect the 1/4 in. air line on the hose assembly to used (highly recommended, sold separately) the air line whip hose one the front of the machine. install it over each individual section of hose before proceeding any further.
Page 15 Section 1 - Installation: Equipment Assembly If the wire is short of the ferrule end, adjust the strip To reach approximately 60 in.-lbs. (6.78 N•m), length accordingly. If bare is protruding from the complete 4.5 revolutions with the hex wrench ferrule, trim it flush to the end of the ferrule.
Page 16 Section 1 - Installation: Equipment Assembly Add extra hose lengths if necessary. Required Tools: Opened - end wrenches - 3/4 in. Lay hoses out straight. Couple hoses together with supplied union fittings and tighten finger-tight. • Hold crimp fitting hex (3/4 in.), and union fitting together, allowing the hose to hold its natural line.
Page 17 If you do not understand the electrical hook-up described above, consult your local GlasCraft distributor OR a qualified electrician. Electrical connections must be checked on a periodic basis.
Page 18: Start-Up Instructions
Section 2 - Operation: Start-Up Instructions Filling The System Never leave machine unattended while system power is on or system is running. Adjust Air Regulator to 20 PSI to fill system. Air System running is defined as: preheat cycle of the hose Motor will cycle slowly to fill Pumps, Heaters and heat, primary heaters, or any pump operation.
Page 19 Section 2 - Operation: Start-Up Instructions Place separate clean containers under each indi- Clean and lubricate Side Blocks and Seals thoroughly vidual side block. Slowly open material valves and re-assemble on Gun. Make certain that the side (black arrow forward) on each side block to allow block screws are tighten securely.
Page 20 Section 2 - Operation: Start-Up Instructions Turn on the ISO & POLY Heater control: Adjust Main Air Regulator to material suppliers a. Push in green power button. specifications. b. Press up or down arrow buttons on the controller until desired temperature setting is achieved.
Page 21: Shut-Down Instructions
Section 2 - Operation: Shut-Down Instructions Daily Shut-Down Procedure Reduce main air regulator pressure to zero. Turn off hose and heater controllers. Turn off main power switch. Visually inspect the entire system for leaks. Turn off main air supply and main power. Flip retract switch to the “retract position”...
Page 22 GlasCraft recommends that the retract switch to the “retract position” and trigger system should be stored with urethanes instead of the gun until the pumps are in the down position.
Page 23 Section 2 - Operation: Shut-Down Instructions Turn off main air supply and disconnect air line from Adjust main air regulator to 20 psi. the system. Adjust transfer pump regulators to approximately 40 psi. Generously coat the exposed transfer pump shafts with lithium grease.
Page 24 Section 2 - Operation: Shut-Down Instructions Open both side blocks simultaneously into separate containers and dispense approximately 1-1/2 - 2 Before performing any repairs on any part of the system, gallons of material from each side or until all plasticizer is purged from the system. Stop the PLACE ALL CONTROLS ON THE MACHINE AND THE pumps in the down position.
Page 25: Assembly Drawings
Section 3 - General Information: Assembly Drawings 235-XX Unit Assembly REVISION E...
Page 26 Section 3 - General Information: Assembly Drawings 235-XX Unit Assembly REVISION E...
Page 27 Section 3 - General Information: Assembly Drawings 235-XX Parts List Part Part Description Description Number Number RS-118 ISO DECAL 3800-03 WIRE RS-119 POLY DECAL 3800-08 WIRE RS-121 HOSE DECAL 7208-02 WIRE NUT RS-124-01 MAIN DECAL 7361-00 TERMINAL LUG RING RS-126 HOSE CURRENT DECAL 7486-05 WASHER...
Page 28 Section 3 - General Information: Assembly Drawings 235-XX Generic System Schematic REVISION E...
Page 29 Section 3 - General Information: Assembly Drawings 235-XX System Schematic 220V Single Phase REVISION E...
Page 30 Section 3 - General Information: Assembly Drawings 235-XX System Schematic 220V Three Phase REVISION E...
Page 31 Section 3 - General Information: Assembly Drawings 235-XX System Schematic 30V Three Phase REVISION E...
Page 32: Sub Assembly Drawings
Section 3 - General Information: Sub Assembly Drawings 23450-XX Hybrid Assembly REVISION D...
Page 33 Section 3 - General Information: Sub Assembly Drawings 23450-XX Hybrid Assembly Part Description Qty. Number RS-141-02 CORD GRIP T4-161-01 CONNECTOR 10009-19 ELBOW FITTING 17702-00 PILOT LAMP 18101-01 FITTING 19507-03 AIR HOSE 20188-12C SCREW 20226-00 SET SCREW 21119-00 TRANSFORMER 21145-01 VENT PLUG 21809-07 MATERIAL HOSE 21866-00...
Page 34 Section 3 - General Information: Sub Assembly Drawings 234-01 Control Panel Assembly Part Part Description Qty. Description Qty. Number Number 21112-00 COUNTER 23486-02 FEMALE PLUG 21164-00 1/2 AMP FUSE 23486-03 FEMALE PLUG 21164-02 2 AMP FUSE 23487-02 MALE PLUG 21356-02 CONTROL 23487-03 MALE MALE...
Page 35 Section 3 - General Information: Sub Assembly Drawings 234- Electrical Assembly 234-03 234-01 30 V Three Phase 220 V Single Phase 234-03 234-01 Part Part Description Description Number Number 21164-02 2 AMP FUSE 21164-02 2 AMP FUSE 21823-00 DIN RAIL 21823-00 DIN RAIL 21888-06...
Page 36 Section 3 - General Information: Sub Assembly Drawings 23445-XX ISO / 2344-XX POLY Heat Exchanger Assembly 23445-00 ISO / 2344-00 POLY Part Description Qty. Number 11021-23 PLUG 13076-18 O-RING 20653-00 FITTING 21068-06C SCREW 21074-00 THERMOCOUPLE 22019-00 FIRE ROD 22108-00 OVERTEMP SWITCH 22633-00 COMPRESSION SPRING 23442-00...
Page 37: Maintenance
Section 3 - General Information: Maintenance Daily Routine Maintenance Visually inspect the system for leaks. Check desiccant dryer beads to insure they are still purple and have not changed to pink. Check and lube top of the fluid section. Wipe off residual material and add a tablespoon of DOP,DBP Weekly Maintenance...
Page 38 Section 3 - General Information: Troubleshooting If a high pressure situation develops, the sensor will detect this and immediately engage the hold-in circuit. Do not place any part of the body in the path of the This will disengage power to the air motor and will also material spray.
Page 39: Troubleshooting
Mixing Chamber tip in the Gun. If you do not understand the electrical hook-up de scribed above, consult your local GlasCraft distributor b. If the missing material gauge reads LOWER than OR a qualified electrician.
Page 40 Section 3 - General Information: Troubleshooting A. MATERIAL DRUMS A. GUN 1. Material in drums? 1. Side Block Material Valve turned on? 2. Material temperature? 2. Bore hole of Mixing Chamber clean? a. If the material is to cold, especially at the 3.
Page 41: Options
Section 3 - General Information: Options 1-04 Diaphragm Transfer Pump Kit The transfer kit attaches the same way for both ISO & POLY side. Use teflon tape on NPT threads. REVISION A...
Page 42 Section 3 - General Information: Options 1-05 Transfer Kit The transfer kit attaches the same way for both ISO & POLY side. Use teflon tape on NPT threads. REVISION A...
Page 43: Notes
Section 4 - Safety Information: Notes...
Page 44: Technical Data
Section 4 - Warranty and Reference Information: Technical Data Material Ratio: 1:1 (Fixed) Material Viscosity: 200- 2000 Centipoise (Cps) @ AMBIENT Output: Pumps Rated: .042 Gallons Per Cycle .159 Liters Per Cycle Operating Temperatures: 32º F ( 0º C ) - 180º (82 º C ) Operating Psi: 22:1 RATIO 2200 PSI @ 100 PSI Air Max Working PSI 2420 PSI...
Page 45: Limited Warranty Policy
GlasCraft manufactured equipment and parts will conform to their published written specifications and be free of defects in workmanship and material for a period of one (1) year from the original date of installation. GlasCraft makes no warranty to anyone other than the original Purchaser.
Page 46: Technical Assistance
GlasCraft. * If your questions are not urgent, You can e-mail all correspondence to service@glascraft.com For Air Powered Systems: Model: _____________________________...
Page 47: For Your Reference
______________________________________________________ GlasCraft manufactures a complete line of polyurethane foam and polyurea coating spray systems. If your application is in-plant or a field contractor - GlasCraft has a system package to meet your requirements. GUARDIAN - AIR POWERED / A5 & A6 SERIES EQUIPMENT .
