  • Page 1 Ó...
  • Page 2 For the enthusiast user who wants to have insights, curiosities and detailed information about the characteristics and functions of the vehicle, Fiat gives the opportunity to consult a dedicated section which is available in electronic format. ONLINE VEHICLE OWNER HANDBOOK The following symbol ...
  • Page 3 In the attached Warranty Booklet you will also find a description of the Services that Fiat offers to its customers, the Warranty Certificate, the detail of the terms and conditions for maintaining its validity and the range of additional services available to Fiat Customers.

  • Page 4: Essential Information

    ESSENTIAL INFORMATION! REFUELLING Petrol engines: only refuel the vehicle with unleaded petrol with an octane rating (RON) not less than 95 conforming to the European specification EN228. Diesel engines: only refuel the vehicle with diesel fuel for motor vehicles conforming to the European specification EN590. The use of other products or mixtures may damage the engine beyond repair and consequently invalidate the warranty, due to the damage caused.
  • Page 5 ELECTRICAL ACCESSORIES If, after buying the vehicle, you decide to add electrical accessories (with the risk of gradually draining the battery), visit a Fiat Dealership. They can calculate the overall electrical requirement and check that the vehicle's electrical system can support the required load.
  • Page 6 USE OF THE OWNER HANDBOOK OPERATING INSTRUCTIONS Each time direction instructions (left/right or forwards/backwards) about the vehicle are given, these must be intended as regarding an occupant in the driver's seat. Special cases not complying with this rule will be specified as appropriate in the text. The figures in the Owner Handbook are provided by way of example only: this might imply that some details of the image do not correspond to the actual arrangement of your vehicle.
  • Page 7 This may also cause lapse of the warranty in relation to faults caused by the change or either directly or indirectly related to it. Fiat shall not be liable for damage caused by the installation of accessories either not supplied or recommended by...
  • Page 9 KNOWING YOUR VEHICLE KNOWING THE INSTRUMENT PANEL SAFETY STARTING AND DRIVING IN AN EMERGENCY SERVICING AND MAINTENANCE TECHNICAL SPECIFICATIONS MULTIMEDIA CONTENTS...

  • Page 11: Table Of Contents

    In-depth knowledge of your new THE KEYS........10 vehicle starts here. IGNITION DEVICE ......11 The handbook that you are reading THE FIAT CODE SYSTEM ..... 12 simply and directly explains how it is DOORS ........13 made and how it works. SEATS........17 That’s why we advise you to read it...

  • Page 12: The Keys

    THE KEYS To extract the metal insert, press Cargo versions fig. 2 button (B) fig. 2 - fig. 3. Button unlocks all the doors (including the tailgate, the rear swing To refit it proceed as follows: doors and the sliding side doors for hold down button B and turn the versions/markets where provided).

  • Page 13: Ignition Device

    The ignition device is fitted with an specified by law or by taking them to a remaining stuck inside the passenger Fiat Dealership, which will deal with their electronic safety system that requires compartment. disposal.

  • Page 14: The Fiat Code System

    THE FIAT CODE provided with the vehicle. Contact a 5) Always remove the key when you Fiat Dealership if you still cannot start leave your vehicle to prevent someone SYSTEM from accidentally operating the controls. the engine. Remember to engage the handbrake.

  • Page 15: Doors

    DOORS temporarily and double-flash the SLIDING SIDE DOORS direction indicators. Turn the key (for versions/markets, where provided) DOOR CENTRAL anticlockwise in the driver's door to On Cargo versions, the sliding side LOCKING/UNLOCKING unlock all the doors. door is fitted with a spring-loaded latch Locking from the outside that stops the door from opening any The doors will only be locked if all...

  • Page 16: Child Safety Device

    CHILD SAFETY DEVICE position 2: device not engaged (doors released) This system prevents the sliding side position 1: device engaged (door doors being opened from the inside. locked). The device is released and The device fig. 10 can be engaged only thus the doors can be opened as with the sliding side door open: follows: in the event that electrical...
  • Page 17 To open completely to 180° you need to intervene on the specific catch/release device (A) fig. 12 (one on each side). F0V0067 F0V0529 ° ° Using the key latch on the door, you Closing from 180 to 90 can do the following: Proceed as follows: for Cargo versions with wing door: close the door without intervening on...
  • Page 18 WARNING Pull handle (A) fig. 17 in the To release and lower the direction of the arrow only. crossmember, act, with rear doors open, on lever (D) fig. 20. F0V0518 Emergency opening of F0V0078 the first swing door F0V0526 from the inside FIXED WINDOW From inside, use device (A) fig.

  • Page 19: Seats

    14) When closing, shut the right hand Reclining backrest adjustment swing door fully before you close the left hand swing door. Never shut the two Lift lever (B) fig. 21 and, slightly doors at the same time. detaching the back from the backrest, accompany the movement of the backrest until it is in the desired IMPORTANT...
  • Page 20 Heated seats (for versions/markets, where provided) With the key turned to MAR, press button (A) fig. 23 to switch the function on/off. When the function is enabled, the LED on the button turns on. F0V0208 FOLDAWAY PASSENGER F0V0013 F0V0142 Backrest angle adjustment then push the backrest (B) fig.
  • Page 21 On some versions the seat can be folded into a table position. Completely retract the seat in table position for a total folding down avoiding interference with the dashboard. WARNING Move the seat only when there are no rear passengers. Seat folding F0V0143 F0V0145...
  • Page 22 3 rd ROW SEAT 3 rd ROW SEAT REMOVAL MOVEMENTS Proceed as follows: Proceed as follows: remove the rear seat head restraints; completely lower the rear seat head remove the rolling curtain from its restraints; housing; move the seat belt to the side, move the seat belt to the side, making sure that it is fully extended and making sure that it is fully extended and...
  • Page 23 WARNING Always disconnect the the left seat) or in the right side zone connection and fasten it to the seat (for the right seat) of the backrest; using the dedicated tape, to prevent it pull the elastic tape fig. 34 and from being damaged when moving the remove the electric connection from seat.
  • Page 24 the floor and that the lever (A) fig. 30 is tightened (red band not visible). FRONT BENCH (for versions/markets, where provided) Some versions feature a front bench with central and side passenger backrests that fold down to a table. To fold the backrests, pull the tabs (A) F0V0552 or (B) fig.

  • Page 25: Partitions

    SPLIT ROTATING 20) Close the dashboard console before PARTITION folding the front passenger seat to form a table to avoid damage. (for versions/markets, where provided) 21) While travelling, before using the third Should it be necessary to transport row seats, make sure that the second long, bulky loads, the passenger side row seats are in running position and well panel can be removed and fixed to the...
  • Page 26 fold the passenger seat away; from inside the load compartment, rotate the locking hook (A) fig. 47 90° anticlockwise; raise the panel, releasing it from the pins (B) fig. 47; arrange the panel, placing it over that on the driver side, aligning the holes (C) fig.

  • Page 27: Head Restraints

    HEAD RESTRAINTS 22) 23) FRONT REAR The head restraints are height- (for versions/markets, where provided) adjustable and lock into the desired To use them, lift them up. position automatically. To put the headrests away, press buttons (A)fig. 52 and push them down into the backrest.

  • Page 28: Steering Wheel

    neck, rests on them. Only in this case they WARNING can protect your head correctly. 23) To make the best use of the head 24) All adjustments must be carried out restraint's protective action, adjust the only with the vehicle stationary and the backrest so that you are sitting upright and engine off.

  • Page 29: Exterior Lights

    EXTERIOR LIGHTS move switch (A) to position (D) and manipulate it to adjust the right door mirror. IN BRIEF Once you have finished the adjustment, return switch (A) to intermediate locking The left stalk includes the controls for position (C). the exterior lights.

  • Page 30: Flashing The Headlights

    unstable position). The warning light switches on in the instrument panel. To turn the main beams off, pull the stalk towards the steering wheel again (dipped beams will turn on). FLASHING THE HEADLIGHTS Pull the stalk towards the steering wheel (1 st unstable position) regardless F0V0516 of the position of the ring.

  • Page 31: Rear Fog Lights

    Fiat Dealership. towards the steering wheel and move it within 2 minutes of the engine switching off.

  • Page 32: Interior Lights

    light (C) if pressed on the left side; WARNING light (D) if pressed on the right side. WARNING Before getting out of the 27) The daytime running lights are an vehicle, make sure both switches are in alternative to the dipped beam headlights the middle position;...

  • Page 33: Wipers

    WINDSCREEN / with the switch in the middle, the switch pushed down (position 2 - light is always off; AUTO OFF), bulb is always off. REAR WINDOW switch pushed up (position 1), light is WIPERS always on; TORCH FUNCTION switch pushed down (position 2 - (for Cargo versions where provided) IN BRIEF AUTO OFF), light is always off.

  • Page 34: Automatic Wiping

    AUTOMATIC WIPING With the windscreen wipers RAIN SENSOR operational, if reverse gear is engaged, (where provided) 5) 6) the rear window wiper is automatically Activation activated. 5) 6) The user can select automatic wiping This is a device located behind the by turning the ring-nut to AUTO fig.

  • Page 35: Rear Window Wiper

    IMPORTANT Make sure, when turning dashboard (rocking position) will engine), contact a Fiat Dealership. on the car, that the windscreen is free activate the rear window washer jet. 4) Do not operate the windscreen wiper...
  • Page 36 If operation is not restored, contact a Fiat Dealership. 8) The headlamp washer jet does not function when the level of fluid in the reservoir falls below 1.6 litres.

  • Page 37: Heating And Ventilation

    HEATING AND VENTILATION CONTROLS F0V0503 A. air temperature adjustment knob (hot/cold air mixing) B. fan activation knob C. air distribution knob. D. internal air recirculation on/off button E. heated rear window and mirror on/off switch (for versions/markets, where provided) delivers air from central and side vents warms the feet and keeps the face cool (bi-level function) warms up the passenger compartment faster;...

  • Page 38: Manual Climate Control System

    MANUAL CLIMATE CONTROL SYSTEM (for versions/markets, where provided) CONTROLS F0V0504 A. air temperature adjustment knob (hot/cold air mixing) B. fan activation knob C. air distribution knob. D. climate control compressor on/off button E. internal air recirculation on/off button F. heated rear window and mirror on/off switch (for versions/markets, where provided)
  • Page 39 When charging, only use the gas indicated on the dedicated plate in the engine compartment . The use of other coolants affects the efficiency and condition of the system. The lubricant used for the compressor is also strictly linked to the type of cooling gas, please refer to a Fiat Dealership.

  • Page 40: Automatic Climate Control System

    AUTOMATIC CLIMATE CONTROL SYSTEM (for versions/markets, where provided) CONTROLS F0V0505 A. AUTO button automatic control of all functions. B. Air distribution selection button. C. Display. D. MAX DEF function control button. E. System off button. F. Compressor enabling/disabling control button. G.
  • Page 41 When charging, only use the gas indicated on the dedicated plate in the engine compartment . The use of other coolants affects the efficiency and condition of the system. The lubricant used for the compressor is also strictly linked to the type of cooling gas, please refer to a Fiat Dealership.

  • Page 42: Electric Windows

    ELECTRIC WINDOWS Press button (A) or (B) again to stop the window in its current position. The electric windows are fitted with a security system (where provided) that ELECTRIC FRONT can detect the presence of an obstacle WINDOWS whilst the window is closing; when this (for versions/markets, where provided) happens, the system kicks in and the There are buttons on the driver side...

  • Page 43: Bonnet

    down but open it and repeat the WARNING procedure. 28) Improper use of the electric windows can be dangerous. Before and during their operation, ensure that any passengers are not at risk from the moving glass either by personal objects getting caught in the mechanism or by being hit by it directly.

  • Page 44: Luggage Compartment

    LUGGAGE The handle is enabled after pressing 32) Be careful working inside engine the third button on the remote control compartment when the engine is hot to COMPARTMENT avoid burning yourself. Do not place your or by operating the unlocking button hands near the engine fan as it may be from the interior of the vehicle.
  • Page 45 F0V0135 F0V0080 F0V0136 EMERGENCY OPENING REMOVING THE PARCEL OF THE SWING DOORS SHELF FROM THE INSIDE The parcel shelf consists of two parts. In the event of an emergency, you can To remove it completely, proceed as open the boot from inside the vehicle follows: as follows: open the rear wing door;...
  • Page 46 F0V0263 F0V0260 F0V0127 EXTENDING THE BOOT Versions with lever Proceed as follows: open the rear doors and remove the parcel shelf (as described previously); completely lower the rear seat head restraints; move the seat belt to the side, making sure that it is fully extended and F0V0262 F0V0202 not twisted;...
  • Page 47 Versions with tape Lift the tape (B) fig. 90 placed by the side of the cushion to release it; then lift the cushion manually and fold the seat and backrest all back fig. 89. Both systems will be present on vehicles with split rear seat.

  • Page 48: Headlights

    HEADLIGHTS secured, to avoid them from being thrown forward consequent to sudden braking and injuring your passengers. 37) You must not use the folded rear seat to carry luggage. The load could HEADLIGHT ALIGNMENT be thrown forward into the backrest of CORRECTOR the front seats, seriously injuring the This device works with the ignition key...

  • Page 49: Version With Methane System (Natural Power)

    22.1 kg. 10) 11) 12) from methane operation to petrol The amount of methane depends on operation and immediately go to a Fiat the outside temperature, the supply INTRODUCTION Dealership to have the vehicle checked pressure, the quality of the gas and The Fiat Doblò...
  • Page 50 Cylinder certification The methane cylinders are certified in accordance with ECE Regulation no. 110. The cylinders must be inspected, in accordance with ECE Regulation Procedure no. 110, every 4 years from the vehicle registration date or in accordance with specific regulations in individual countries.
  • Page 51 42) If gas is smelt, switch from methane -10°C, the switching times from Petrol operation to petrol operation and to Methane increase to allow the immediately go to a Fiat Dealerships to pressure regulator/reduction unit to have the vehicle checked and possible become warm enough.
  • Page 52 KNOWING THE INSTRUMENT PANEL This section of the handbook gives DASHBOARD AND INSTRUMENT you all the information you need to PANEL........51 understand, interpret and use the DIGITAL DISPLAY ......53 instrument panel correctly. MULTIFUNCTION DISPLAY ... 54 TRIP COMPUTER ......55 WARNING LIGHTS AND MESSAGES ........
  • Page 53 DASHBOARD AND INSTRUMENT PANEL Versions with digital display F0V0530 A. Speedometer; B. Fuel level gauge with reserve warning light; C. engine coolant temperature gauge with overheating warning light; D. Rev counter; E. Digital display...
  • Page 54 A. Speedometer; B. Fuel level gauge with reserve warning light; C. engine coolant temperature gauge with overheating warning light; D. Rev counter; E. Multifunction display IMPORTANT 13) If the needle for the engine coolant temperature reaches the red area, stop the engine immediately and contact a Fiat Dealership.

  • Page 55: Digital Display

    DIGITAL DISPLAY CONTROL BUTTONS SET-UP MENU The menu comprises a series of To scroll up through the screen functions arranged in a "circular way", and the related options or to increase which can be selected through the the displayed value. STANDARD SCREEN MENU Press briefly to access...

  • Page 56: Multifunction Display

    MULTIFUNCTION NOTE Buttons activate different functions according to the DISPLAY following situations: Adjusting the vehicle interior (for versions/markets, where provided) lighting The vehicle may be equipped with a – on the standard screen, they adjust multifunction display that gives the the brightness of the instrument panel driver useful information depending on and the radio.

  • Page 57: Trip Computer

    TRIP COMPUTER modes are different according to the Travel time B (driving time) characteristics of the option selected. Trip B reset The menu includes the following items: Natural Power versions LIGHTING NOTE The trip computer data IN BRIEF SPEED BUZZER concerning range, average TRIP B DATA consumption and instantaneous...
  • Page 58 "manual" resetting by the user, by IMPORTANT pressing the relevant button; "automatic" resetting, when the "trip 14) The "Trip B" function may be distance" reaches 9999.9 km or when disabled (see the "Activating Trip B" the "trip time" reaches 999:59 (999 paragraph).

  • Page 59: Warning Lights And Messages

    On certain versions, if the vehicle is moving an light has switched off. acoustic signal will also sound. If the warning light stays on, contact a Fiat Dealership. If the warning light comes on while driving, check that the handbrake is not on.
  • Page 60 What to do This failure in the brake servo does not affect the braking efficiency of the system, but the power assisted steering is reduced. Contact a Fiat Dealership to have Brake booster vacuum low the vehicle checked. The warning light switches on in the event of brake WARNING servo failure ;...
  • Page 61 When the key is turned to MAR, the warning light switches on but it should switch off after a few If the transmission is faulty, contact a Fiat Dealership as seconds. The warning light flashes (together with soon as possible to have the system checked.
  • Page 62 If, when restarting, the warning light switches on The warning light switches on when the ignition key again, contact a Fiat Dealership. If the vehicle is used is turned to MAR, but it should switch off after a few under demanding conditions (e.g. in high-performance seconds.
  • Page 63 (MultiJet versions with DPF only) The warning light starts to flash together with a message on the display (for versions/markets, where Contact a Fiat Dealership as soon as possible. provided) when the system detects that the engine oil 46) 47) has deteriorated.
  • Page 64 ; in this case, the airbags or pretensioners may not deploy in the event of an accident or, in a lower number of cases, they could deploy erroneously. Before continuing, contact a Fiat Dealership to have the system checked immediately.
  • Page 65 Continue the journey at moderate If the warning light flashes, it means that the catalytic speed, trying to avoid driving conditions that may cause converter may be damaged. further flashing and contact a Fiat Dealership as soon as possible.
  • Page 66 The warning light will blink to indicate a system fault. seconds. The warning light switches on when about 9 If this is the case, go to a Fiat Dealership to have the litres of fuel are left in the tank.
  • Page 67 Glow plug preheating failure The warning light flashes if there is a fault in the preheating system. Contact a Fiat Dealership as soon as possible. On some versions the display shows the dedicated message. WATER IN DIESEL FUEL FILTER...
  • Page 68 When the key is turned to MAR the warning light will flash only once and then switch off. If, with the ignition key at MAR, the warning light Contact a Fiat Dealership to have all the keys stored in stays on permanently, this indicates a possible failure the memory.
  • Page 69 (for versions/markets, where provided) The warning light comes on when the ignition key is In this case, contact a Fiat Dealership as soon as turned to MAR, but should go off after a few seconds; possible. The warning light will turn on when the Hill Holder system is faulty.
  • Page 70 The display will show a specific message. TPMS TPMS failure In this case, contact a Fiat Dealership as soon as The warning light flashes for about 75 seconds then possible. stays on constantly when a fault is detected in the amber TPMS.
  • Page 71 PARKING SENSOR FAILURE (for versions/markets, where provided) The warning light turns on when failure is detected in the parking sensors. In this case, contact a Fiat Dealership. On certain versions the warning light comes on amber instead.
  • Page 72 (on certain versions together with the message on the display), contact a Fiat Dealership as soon as possible. 17) The presence of water in the fuel supply circuit may cause severe damage to the injection system and irregular engine operation.
  • Page 73   Warning lights on panel What it means What to do DIPPED BEAM HEADLIGHTS The warning light switches on when the dipped beam headlights are turned on. FOLLOW ME HOME The warning light switches on (together with a green message shown on the display) when this device is in use (see "Follow me home device"...
  • Page 74 Warning lights on panel What it means What to do CRUISE CONTROL (for versions/markets, where provided) The digital warning light switches on in the display when the ignition key is turned to MAR, but it should switch off after a few seconds, if the Cruise Control is deactivated.
  • Page 75 Messages on display What it means What to do CNG SYSTEM FAILURE In this case, contact a Fiat Dealership as quickly as All Methane fuel levels disappear on the display and possible. the symbol appears with a dedicated message. PETROL OPERATION (Natural Power versions)
  • Page 76 Messages on display What it means What to do INDICATION OF DIESEL EMISSIONS ADDITIVE LOW LEVEL (UREA) When low UREA level is detected, a text message will appear on the instrument panel display, together with the symbol to indicate that UREA must be topped The symbol stays on until the tank is topped up with at least 5 litres of UREA.
  • Page 77 WARNING 49) When the UREA tank is empty and the engine is stopped it is no longer possible to restart it until the UREA tank is topped up with at least 5 litres of UREA.
  • Page 78 SAFETY The chapter that you are about to ACTIVE SAFETY SYSTEMS ... 77 read is very important: it describes the ABS ........... 77 safety systems with which the vehicle is ESC (Electronic Stability Control) equipped and provides instructions on SYSTEM ........78 how to use them correctly.
  • Page 79 ACTIVE SAFETY SYSTEM INTERVENTION swerve when braking sharply. Drive carefully to the nearest Fiat Dealership SYSTEMS The driver can feel that the ABS has to have the system checked. come into action because the brake The vehicle has the following active...

  • Page 80: System Activation

    The LED on the ASR OFF of tyre grip loss, helping to maintain imminently will be heard. button will also light up. Contact a Fiat directional control. Fault indications Dealership as soon as possible.
  • Page 81 In this case, contact The action of the ASR system is Whilst driving, the ASR can be the Fiat Service Network as soon as particularly helpful in the following switched off and subsequently possible. circumstances:...

  • Page 82: Seat Belts

    SEAT BELTS visibility and traffic. The driver is always 56) 57) responsible for road safety. USING THE SEAT BELTS 55) For the correct operation of the ESC and ASR systems it is vital that the tyres All vehicle seats are equipped with seat are the same make and the same type on belts with three anchor points and a all the wheels, in perfect condition and,...
  • Page 83 WARNING 56) Never press button (C) fig. 109 when travelling. 57) Remember that after a violent impact, rear-seat passengers who are not wearing their seat belts not only expose themselves to significant risk for injury, but also represent a danger to passengers occupying the front seats.

  • Page 84: Sbr System

    5 seconds, a buzzer sequence F0V0635 unfastened will start flashing red Contact a Fiat Dealership to deactivate will be started (front seats) consisting for approximately 30 seconds. An this acoustic warning permanently.
  • Page 85 The when the relevant seat belt is fastened a Fiat Dealership to have it replaced. maximum clearance should be kept again. The rear seat warning lights WARNING To obtain the highest...
  • Page 86 Contact a guaranteed if water does not get inside; Fiat Dealership for any assistance. replace the seat belt when it shows wear or cuts.

  • Page 87: Carrying Children Safely

    Lineaccessori Fiat offers child restraint long as possible (at least until 3-4 years systems for each weight group. These old), since this is the most protected devices are recommended having been position in the event of an impact.
  • Page 88 GROUP 2 GROUP 3 GROUP 1 Children from 15 to 25 kg may use For children between 22 kg and 36 kg, From 9 to 18 kg of weight, children the seat belts of the vehicle directly there are boosters which allow the seat may be carried forward facing fig.
  • Page 89 RESTRAINT SYSTEM USE The Fiat Doblò (only for vehicles designed to carry people), (homologation M1) complies with the new European Directive 2000/3/EC which governs the arrangement possibilities for child restraint systems on the seats of the vehicle as shown in the following table:  ...
  • Page 90 ISOFIX CHILD WARNING RESTRAINT SYSTEM SETUP 64) SERIOUS DANGER: When an active passenger airbag is fitted, DO NOT install (for versions/markets, where provided) rear facing child restraint systems on the Only for vehicles designed to carry front seat. Deployment of the airbag in an accident could cause fatal injuries to people, (M1 approval), provision has the child regardless of the severity of the...
  • Page 91 ECE R44 (R44/03 or superior) “Universal Isofix”. The Universal Isofix “Duo Plus” child restraint system and the special "G 0/1" one are available from Lineaccessori Fiat. Refer to the "instruction manual" provided with the child restraint system for any further details on installation/use.
  • Page 92 SUITABILITY OF PASSENGER SEATS FOR ISOFIX CHILD RESTRAINT SYSTEM USE The table below shows the different installation possibilities of Isofix child restraint systems on seats fitted with Isofix anchorages in compliance with European standard ECE 16.   Child restraint Rear central Rear side Isofix Weight group Isofix size class...
  • Page 93 i-Size CHILD RESTRAINT SYSTEMS These child restraint systems, built and type-approved according to the i-Size (ECE R129) standard, ensure better safety conditions to carry children on board a vehicle: the child must be transported rearward facing until 15 months; child restraint system protection F1B0124C is increased in the event of a side NOTE: See the table shown on the...
  • Page 94 The following table, according to European standard ECE 129, indicates the possibility of i-Size child restraint system installation.   i-Size POSITIONS ON THE VEHICLE Rear central Device Front passenger Rear side passengers passenger ISO/R2 i-Size child restraint systems ISO/F2 X: seat not suitable for Universal i-Size child restraint systems. This vehicle is not approved for use with i-Size child restraint systems.
  • Page 95 Child restraint system Type of child restraint system Child restraint system installation BeSafe iZi Go Modular Fiat order code: 71808564 Universal/i-Size child restraint system. It must be installed facing rearwards, Group 0+: from birth to 13 using the vehicle seat belts only, or the...
  • Page 96 It can only be fitted facing forwards, using the three-point seat belt and the ISOFIX Group 2: from 15 kg to 25 Britax Römer KidFix XP anchorages, if present. Fiat recommends (for versions/markets, where installing it using the ISOFIX anchor from 95 cm to 135 cm provided) points of the vehicle.
  • Page 97 Below is a summary of the main if the vehicle has been involved in on the passenger side sun visor (see the a road accident, replace the child safety rules to be followed when "Airbags" paragraph). 70) Do not move the front or rear seat if carrying children: restraint system with a new one.
  • Page 98 which should be worn at all times as The airbags are not deployed in the correctly. In a crash, the child could be specified by law in Europe and most event of minor frontal impacts (for seriously or fatally injured. non-European countries.

  • Page 99: Child Restraint Systems

    CHILD RESTRAINT approx. 8 seconds. If not, contact a pelvis, chest, shoulder SYSTEMS Fiat Dealership. and head protection During the first 8 seconds, the (for versions/markets, where provided) activation of the warning light does not Rearward-facing child restraint systems On Doblò...
  • Page 100 are protected, in addition to any side bags, only by their seat belts, which must therefore always be fastened. 81) In some versions, in the event of a failure of the LED (located on the front ceiling light), the warning light on the instrument panel turns on and the passenger side airbags are deactivated.
  • Page 101 PASSENGER'S FRONT AIRBAG AND CHILD RESTRAINT SYSTEMS: IMPORTANT F1A0387...
  • Page 102 SIDE BAGS from being thrown out of the vehicle by a very violent collision. (for versions/markets, where provided) On some versions, the vehicle may be SIDE BAG provided with side bags and window (for versions/markets, where provided) bags. It consists of an instantly inflating bag Side bags protect occupants from housed in the front seat backrest side-on crashes of medium/high...
  • Page 103 Fiat Dealership to have lips (pipe, pencils, etc.): they could cause possible injury during airbag inflation.

  • Page 104: Starting And Driving

    STARTING AND DRIVING Let’s get to the core of the vehicle: STARTING THE ENGINE ..... 103 seeing how you can exploit all of its WHEN PARKED ......104 potential to the full. USING THE GEARBOX ....105 We’ll look at how to drive it safely in any COMFORT-MATIC/ DUALOGIC situation, so that it can be a welcome TRANSMISSION ......

  • Page 105: Starting The Engine

    Release car. If you still cannot start the engine, to start, see the paragraph “The Fiat contact a Fiat Dealership. the key as soon as the engine starts.
  • Page 106 Use the vehicle normally if the gear to disappear from the display engine starts, but contact a Fiat Dealership before releasing the brake pedal. as soon as possible. WARNING NEVER leave the vehicle...

  • Page 107: Using The Gearbox

    92) The vehicle should be secured then release the brake and accelerate after several clicks of the lever. If it is gently; not, contact a Fiat Dealership to have it during prolonged stops with the adjusted. 93) Never leave children unattended in the engine running, it is advisable to keep vehicle.

  • Page 108: Automatic Mode

    COMFORT-MATIC/ Press the brake pedal. WARNING Start the engine. DUALOGIC Push the transmission lever towards TRANSMISSION 95) Press the clutch pedal fully to shift + fig. 134 to engage the first gear (if it gears correctly. It is therefore essential that is coming from N or R, simply place there is nothing under the pedals: make the lever in the middle position) or in R...

  • Page 109: Operating Mode

    With the vehicle stationary, the engine Auto/Manual mode. stops with the gearbox in neutral and 27) If the warning light (together with the the clutch pedal released. F0V0323 message in the display) continues to remain on in the panel, contact a Fiat Dealership.
  • Page 110 WITH ROBOTISED GEARBOX WITH ROBOTISED GEARBOX The engine cuts out if the vehicle stops If the gear lever is in position N, place it with the brake pedal pressed. in any other gear, otherwise release the brake pedal or move the gear lever to This condition can be maintained even if the brake pedal is not depressed, if (+), (–) or R.
  • Page 111 WARNING 96) If the battery needs to be replaced, always contact a Fiat Dealership. Replace the battery with a new one of the same type and specifications. 97) Before opening the bonnet, make sure that the vehicle is switched off and the key is in the OFF position.
  • Page 112 TPMS (Tyre pressure value printed on the side of WARNING Monitoring and maintaining the tyre. the correct pressure in all four tyres are Pressure particularly important. NOTE Monitoring System) Tyre pressure monitoring system The TPMS does not replace the (for versions/markets, where provided) low pressure warning normal tyre maintenance service and does not indicate any fault in a tyre.
  • Page 113 To activate/deactivate this function, warm tyres, do not reduce pressure even dry roads (e.g. motorways) with few contact a Fiat Dealership. though it is higher than the prescribed driving changes (e.g. motorway Following the operation, a sticker will...
  • Page 114 110) 111) by moving the stalk downwards Storing vehicle speed (-) until the new speed, which will automatically remain memorised, is Proceed as follows: reached. turn ring nut (A) fig. 143 to the ON Each movement of the stalk will position and press the accelerator correspond to a slight reduction in pedal so that the vehicle reaches the...

  • Page 115: Parking Sensors

    111) In the event of device faults or deactivated and it is reactivated again obstacles behind the vehicle. failures, turn knob (A) to OFF and contact when the speed is below 50 km/h. a Fiat Dealership. F0V0575 Traction Plus operation The system is deactivated when F0V0077 starting.
  • Page 116 (e.g. truck to contact a Fiat Dealership for the shampoo if necessary. When using special pneumatic brakes or pneumatic drills) washing equipment such as high pressure...
  • Page 117 gear lever in P (Park - versions concerned. The parking sensors are used with automatic transmission, where to assist the driver, who must never allow his attention to lapse during potentially provided); dangerous manoeuvres, even those ignition device in the STOP position. executed at low speeds.

  • Page 118: Refuelling The Vehicle

    provide an accurate image of the area 32) To prevent damage to the vehicle, WARNING behind the vehicle. The image will the driver should proceed as slowly as possible when parking to be able to stop appear on the display together with a 114) Parking and other potentially promptly if necessary.

  • Page 119: Fuel Tank Cap

    DURANCE DIESEL ART additive in the and wait for the UREA to return to proportions shown on the container liquid state before topping up. with the fuel. Pour the additive into the Proceed as follows: tank before the fuel. park the vehicle on ground level; When using or parking the vehicle for stop the engine by turning the a long time in the mountains or cold...
  • Page 120 "Refuelling a Fiat Dealership. before pouring the content of the bottle " paragraph in the "Technical Do not add additives or other into the AdBlue®...
  • Page 121 Follow the instructions on the label of In some European countries adapters E5: Unleaded petrol containing up to the container. are considered ILLEGAL (e.g. in 2.7% (m/m) oxygen and with maximum Germany). 5.0% (V/V) ethanol compliant with EN228 For service stations with cubic metre (m 3 ) nozzles (pressure differential) the E10: Unleaded petrol containing up to NATURAL POWER...

  • Page 122: Towing Trailers

    ADDITIVE FOR TOWING TRAILERS CNG: Automotive methane and bio- methane compliant with EN16723 DIESEL EMISSIONS IMPORTANT NOTES AdBlue (UREA) The vehicle must be equipped with a IMPORTANT type-approved tow hook and adequate The vehicle is equipped with an UREA electrical system to tow trailers. fuel injection system and a Selective Installation should be carried out by 33) For diesel engines, use only diesel fuel...
  • Page 123 115) 116) WARNING 115) The ABS with which the vehicle may be equipped will not control the trailer's braking system. Particular caution is required on slippery roads. 116) Never modify the braking system of the vehicle to control the trailer brake. The trailer braking system must be fully independent from the hydraulic system of the vehicle.

  • Page 124: In An Emergency

    Warranty Booklet. EMERGENCY STARTING .... 141 It is also possible to call the 00 800 FUEL CUT-OFF SYSTEM .... 142 3428 0000 freephone number to search the nearest Fiat Dealership. LIFTING THE VEHICLE....142 TOWING THE VEHICLE ....142...

  • Page 125: Hazard Warning Lights

    (for versions/markets, where provided) indicates infiltration of water. Contact a D Halogen bulbs: to remove the In the event of emergency braking Fiat Dealership. bulb, release the clip holding the bulb in the hazard warning lights come on place. automatically, as do the...
  • Page 126 38) Where possible, it is advisable to have bulbs changed at a Fiat Dealership. The correct operation and direction of the external lights are absolutely essential for the safety of the car and of compliance...

  • Page 127: Light Bulbs

    Light bulbs   Type Power Ref. Figure Main beams Dipped headlights Daytime running lights / side lights W21W Front direction indicators WY21W Side turn light WY5W Rear direction indicators PY21W Rear fog light W16W Reverse gear W16W Rear side lights P21/5W Stop P21W...
  • Page 128 REPLACING AN remove the protective cover headlight, pressing to engage it with the side clips (A)fig. 157; then (C)fig. 155; EXTERIOR BULB turn the bulb holder (A)fig. 156 reconnect the electrical connector; For the type of bulb and relevant power correctly refit the protective cover anticlockwise and extract it;...
  • Page 129 WARNING Go to a Fiat Dealership to have bulbs for the side direction (for versions/markets, where provided) indicators replaced, because they are WARNING Go to a Fiat Dealership to located inside the door mirror. have the front fog light bulbs replaced. MAIN BEAM HEADLIGHTS...
  • Page 130 NUMBER PLATE for versions with wing doors, remove LIGHTS (for hatchback the rubber caps (B)fig. 163 and versions) manoeuvre the holding tabs (C), then remove the unit; To replace the bulbs (A) fig. 165, proceed as follows: F0V0164 for versions with high roof and swing doors, remove the pressure-fit plastic guard (A)fig.
  • Page 131 REPLACING NUMBER PLATE LIGHTS (for versions with wing INTERIOR BULBS doors) For the type of bulb and relevant power To replace the bulbs (A) fig. 167, rating, see “Changing a bulb”. proceed as follows: FRONT/REAR CEILING LIGHT Ceiling light with movable lens To replace the bulbs, proceed as F0V0071 follows:...

  • Page 132: Replacing Fuses

    PASSENGER The CNG system components are COMPARTMENT protected by specific fuses. Contact a FUSEBOXES Fiat Dealership for replacement. To access the fuses, remove snap- fitted protective cover (A) fig. 174. ENGINE COMPARTMENT FUSEBOX The fusebox fig. 175 is located on the right-hand side of the engine, next to the battery.
  • Page 133 F0V0089 F0V0563...
  • Page 134 Engine compartment fusebox fig. 173 - fig. 175   PROTECTED DEVICE FUSE AMPERE Remote control switch for opening swing door (Cargo version) Single tone horn Main beams Heated rear window Fog lights Rear power socket Passenger compartment power socket...
  • Page 135 Passenger compartment fuseboxes fig. 174 - fig. 176   PROTECTED DEVICE FUSE AMPERE Door locking/unlocking motors, dead lock actuator motors, tailgate unlocking motor Supply + battery for EOBD diagnosis socket, radio, tyre pressure monitoring control unit Windscreen/rear window washer pump Window winder motor for front door passenger side Left low beam, headlight corrector Window winder motor for front door driver's side...
  • Page 136 121) Contact Fiat Dealership if a safety 122) 123) 124) 125) Note for one-way tyres system (airbags, brakes), engine system safely. The ground must be flat and...
  • Page 137 unscrew knob (D) fig. 181 and release the rim from bracket (E), removing it from the hole of the rim; F0V0149 for Doblò/Doblò Combi versions fig. 178: open the rear doors, inside the compartment on the rear right side, F0V0193 take the tool bag, unhooking the elastic For Cargo Natural Power versions band from the buckle, and take it next...
  • Page 138 F0V0249 F0V0153 F0V0155 for versions with alloy rims, remove operate the jack using the knob operate the jack with the knob to the press-fitted hub cap; (release the handle from the clip and open it until the groove (A) fig. 188 loosen the fixing bolts of the wheel to the hole on the nut) in order to open it of the jack is correctly inserted in the...
  • Page 139 ensure that it rotates freely in order to turn the jack handle to lower the for vehicles with alloy rims take the avoid grazing your hands against the vehicle, and remove the jack; adapter (D) fig. 192 and fit the plastic ground.
  • Page 140 fix the wheel to the adaptor, using the the lifted vehicle to fall. Do not use the jack WARNING socket wrench for the wheel nuts (G) for loads higher than the one shown on its label. fig. 194. 122) The space-saver wheel (for 125) Incorrect hub cap assembly may Tighten the screws with the wheel versions/markets, where provided) is...
  • Page 141 wear the reflective safety jacket before getting out of the car (anyway comply with the laws in force in the country you are driving in); insert the sealant cartridge (1) into the corresponding compressor compartment (2)and press it down hard fig. 195. Remove the speed limit sticker (3)and apply it in a clearly visible position fig.
  • Page 142 and restore pressure using the black WARNING inflation tube (9) fig. 200. If the pressure shown is higher than 1.8 126) The information required by the bar / 26 psi, restore the pressure and applicable regulation is indicated on the carefully drive to a Dealership in the Fix&Go kit package label.

  • Page 143: Jump Starting

    EMERGENCY required to use the brake pedal or turn the steering wheel. STARTING Go to a Fiat Dealership immediately if WARNING warning light comes on steady on the instrument panel. 128) This starting procedure must be performed by expert personnel because...

  • Page 144: Lifting The Vehicle

    If the vehicle needs to be lifted, go to a activate the left direction indicator; causing: Fiat Dealership which is equipped with deactivate the left direction indicator; the arm hoist or workshop lift. the interruption of the fuel supply with turn the ignition key to STOP.
  • Page 145 Fiat Dealership. code (a rigid bar), to move the vehicle on the road in readiness for towing or transport via a breakdown vehicle. Tow...
  • Page 146 SERVICING AND MAINTENANCE Correct maintenance permits the SCHEDULED SERVICING ... 145 performance of the vehicle to be SERVICE SCHEDULE ....146 maintained over time, as well as limited REGULAR CHECKS ....154 running costs and safeguarding the DEMANDING VEHICLE USE ..154 efficiency of the safety systems.

  • Page 147: Scheduled Servicing

    This is why Fiat has planned a series of checks and services every 30,000/35,000 km (depending on the version). It is, however, important to remember...

  • Page 148: Service Schedule

    SERVICE SCHEDULE PETROL / NATURAL POWER VERSIONS WARNING Once you have carried out the last intervention in the table, continue with the scheduled servicing, maintaining the frequency indicated in the plan by marking each operation with a dot or dedicated note. Warning: simply restarting the maintenance from the start of the plan may cause the allowed interval to be exceeded for some operations!  ...
  • Page 149 Thousands of miles Thousands of kilometres Years Check cleanliness of sliding side door lower guides (or every 6 months) Check handbrake lever travel and adjust, if necessary Check and adjust clutch pedal, if required Check condition and wear of front disc brake pads and operation of pad wear indicator Check rear drum brake lining condition and wear Visually inspect condition of the accessory drive belt(s) Check tension of accessory drive belt (versions without automatic tensioner) (or every 2...
  • Page 150 “Engine” paragraph in the "Technical Specifications" section); strictly comply with the replacement intervals in the Service Schedule; you are advised to contact a Fiat Dealership to have plugs replaced. (4) The maximum mileage is 120,000 km. The belt must be replaced every 6 years, regardless of distance travelled. If the vehicle is used in heavy conditions (dusty areas, especially severe weather conditions, very low or very high temperatures for extended periods, urban driving, long periods of idling), the maximum mileage is 60,000 km.
  • Page 151 DIESEL VERSIONS WITHOUT DPF (1.3 MultiJet - 1.6 MultiJet) WARNING Once you have carried out the last intervention in the table, continue with the scheduled servicing, maintaining the frequency indicated in the plan by marking each operation with a dot or dedicated note. Warning: simply restarting the maintenance from the start of the plan may cause the allowed interval to be exceeded for some operations!  ...
  • Page 152 Thousands of miles Thousands of kilometres Years Check handbrake lever travel and adjust, if necessary Check condition and wear of front disc brake pads and operation of pad wear indicator Check rear drum brake lining condition and wear Visually inspect condition of the accessory drive belt(s) Check tension of accessory drive belt (versions without automatic tensioner) Change engine oil and replace oil filter (or every 24 months) Replace timing belt (1.6 Multijet version) (2)
  • Page 153 DIESEL VERSIONS WITH DPF (1.3 MultiJet - 1.6 MultiJet - 2.0 MultiJet) WARNING Once you have carried out the last intervention in the table, continue with the scheduled servicing, maintaining the frequency indicated in the plan by marking each operation with a dot or dedicated note. Warning: simply restarting the maintenance from the start of the plan may cause the allowed interval to be exceeded for some operations!  ...
  • Page 154 Thousands of miles Thousands of kilometres Years Check cleanliness of bonnet locks, and cleanliness and lubrication of linkages Check cleanliness of sliding side door lower guides (or every 6 months) Check handbrake lever travel and adjust, if necessary Check condition and wear of front disc brake pads and operation of pad wear indicator Check rear drum brake lining condition and wear Visually inspect condition of the accessory drive belt(s) Check tension of accessory drive belt (versions without automatic tensioner)
  • Page 155 Thousands of miles Thousands of kilometres Years Replace passenger compartment filter (or every 24 months) (1) Only ever use the fluids shown in the handbook for topping up, and only after checking that the system is intact. (2) Consumption of additive for emissions (urea) depends on the condition of use of the vehicle and is indicated by a warning light and message on the instrument panel.

  • Page 156: Regular Checks

    REGULAR CHECKS DEMANDING versions/markets, where applicable), when the warning light comes on or VEHICLE USE Every 1,000 km or before long the message on the instrument panel journeys, check and, if necessary, top If the vehicle is mostly used in one of appears;...

  • Page 157: Engine Compartment

    ENGINE COMPARTMENT 1.4 95 HP versions F0V0076 A. Engine oil filter nozzle – B. Engine oil level dipstick – C. Engine coolant – D. Windscreen washer fluid – E. Brake fluid – F. Battery – G. Power steering fluid 133)
  • Page 158 1.4 T-JET versions F0V0390 A. Engine oil filter nozzle – B. Engine oil level dipstick – C. Engine coolant – D. Windscreen washer fluid – E. Brake fluid – F. Battery – G. Power steering fluid 133)
  • Page 159 1.3 MultiJet versions without DPF F0V0187 A. Engine oil filter nozzle – B. Engine oil level dipstick – C. Engine coolant – D. Windscreen washer fluid – E. Brake fluid – F. Battery – G. Power steering fluid 133)
  • Page 160 1.3 MultiJet versions with DPF F0V0189 A. Engine oil filter nozzle – B. Engine oil level dipstick – C. Engine coolant – D. Windscreen washer fluid – E. Brake fluid – F. Battery – G. Power steering fluid 133)
  • Page 161 1.3 Multijet Euro 6 versions F0V0630 A. Engine oil filter nozzle – B. Engine oil level dipstick – C. Engine coolant – D. Windscreen washer fluid – E. Brake fluid – F. Battery – G. Power steering fluid 133)
  • Page 162 1.6 MultiJet versions F0V0190 A. Engine oil filter nozzle – B. Engine oil level dipstick – C. Engine coolant – D. Windscreen washer fluid – E. Brake fluid – F. Battery – G. Power steering fluid 133)
  • Page 163 1.6 Multijet Euro 6 versions F0V0615 A. Engine oil filter nozzle – B. Engine oil level dipstick – C. Engine coolant – D. Windscreen washer fluid – E. Brake fluid – F. Battery – G. Power steering fluid 133)
  • Page 164 2.0 MultiJet versions F0V0160 A. Engine oil filter nozzle – B. Engine oil level dipstick – C. Engine coolant – D. Windscreen washer fluid – E. Brake fluid – F. Battery – G. Power steering fluid 133)
  • Page 165 1.4 T-JET Natural Power versions F0V0247 A. Engine oil filter nozzle – B. Engine oil level dipstick – C. Engine coolant – D. Windscreen washer fluid – E. Brake fluid – F. Battery – G. Power steering fluid 133) WARNING 133) Never smoke while working in the engine compartment: gas and inflammable vapours may be present, with the risk of fire.
  • Page 166 IMPORTANT 46) When topping up, take care not to mix up the various types of fluids: they are not compatible with each other and could seriously damage the vehicle.

  • Page 167: Engine Oil

    WARNING After adding or changing WINDSCREEN/REAR ENGINE OIL the oil, let the engine turn over for a few WINDOW WASHING Check the oil level a few minutes after FLUID seconds and wait a few minutes after stopping the engine (about 5 minutes) turning it off before you check the level.

  • Page 168: Power Steering Fluid

    If this occurs, do If necessary, only replace the plug with Check that the fluid level, with the not start the engine and contact your Fiat another original or the operation of the vehicle level and engine cold, is Dealership immediately.

  • Page 169: Recharging The Battery

    ; if another top-up is required 24 hours. Charging for a longer time after only a short period of time, have may damage the battery. the system checked for leaks at a Fiat WARNING If a "quick-type" battery Dealership. charger is used with the battery...

  • Page 170: Rear Window

    Versions without dummy pole WARNING fig. 214 140) Battery fluid is poisonous and corrosive: avoid contact with your skin and eyes. The battery should be charged in a well ventilated place, away from naked flames or possible sources of sparks: danger of explosion and fire.

  • Page 171: Wheels And Tyres

    143) Remember that the road holding swelling or irregular tyre tread wear. Go qualities of your vehicle also depend on to a Fiat Dealership if required; the correct inflation pressure of the tyres. avoid overloading the car when 144) If tyre pressure is too low, the tyre...
  • Page 172 146) Do not repaint alloy wheel rims at temperatures higher than 150°C. The mechanical features of the wheels could be compromised. 147) Keep the vehicle's speed down when snow chains are fitted; never exceed 50 km/h. Avoid potholes, do not drive over steps or pavements, and do not drive long distances over roads without snow, to avoid damaging both your vehicle and the...

  • Page 173: Technical Specifications

    TECHNICAL SPECIFICATIONS Everything you may find useful for IDENTIFICATION DATA ....172 understanding how your vehicle is ENGINE ........174 made and works is contained in this WHEELS........177 chapter and illustrated with data, tables DIMENSIONS ......185 and graphics. For the enthusiasts and WEIGHTS AND LOADS....
  • Page 174 IDENTIFICATION E Maximum permitted weight of vehicle when fully laden plus trailer DATA F Maximum permitted weight on first It is advisable to take note of the axle (front) identification codes. The following G Maximum permitted weight on identification codes are printed and second axle (rear) shown on the plates: H Engine type...

  • Page 175: System Inspection

    A Paint manufacturer on the passenger compartment floor B Colour name panel, near the right front seat; open C Fiat colour code the flap to access (A) fig. 220 D Respray and touch up code on the lower part of the windscreen This plate is fitted inside the bonnet (B) fig.
  • Page 176 Maximum torque (EEC) (kgm) 12.95 corresponding engine speed (rpm) 4500 3000 3000 Spark plugs NGK DCPR7E NGK IKR9F8 FIAT 55210685 - NGK IKR9F8 Unleaded petrol Unleaded petrol Unleaded petrol Fuel 95 R.O.N. (EN228 95 R.O.N. (EN228 Methane 95 R.O.N. (EN228...
  • Page 177   1.3 MultiJet without Versions 1.3 MultiJet with DPF 1.3 Multijet Euro 6 Engine code 199A3000 263A2000 / 263A6000 330A1000/225A2000 Cycle Diesel Diesel Diesel Number and position of cylinders 4 in line 4 in line 4 in line Piston bore and stroke (mm) 69.6x82 69.6x82 69.6x82...
  • Page 178   1.6 Multijet Euro 4 / Versions 1.6 Multijet Euro 6 2.0 Multijet Euro 5 / Euro 5+ 198A3000 / 263A3000 / 940C1000 / 263A8000 / Engine code 263A1000 263A4000 / 263A5000 263A7000 / 263A9000 Cycle Diesel Diesel Diesel Number and position of cylinders 4 in line 4 in line 4 in line...

  • Page 179: Rims And Tyres

    WHEELS RIMS AND TYRES Pressed steel or alloy rims. Tubeless radial carcass tyres. All approved tyres are listed in the registration document. WARNING If there are any discrepancies between the Owner Handbook and the registration document, take the information from the latter.
  • Page 180 RIMS AND TYRES PROVIDED   Spare wheel (for Tyres versions/markets, where provided) Versions Wheels Standard snow type Tyre equipment 195/60 R16 C 195/60 R16 C 195/60 R16 C All models 6Jx16 ET36.5 6Jx16 ET36.5 99Q (M+S) 195/60 R16 C 195/60 R16 C 195/60 R16 C 1.4 T-JET All models...
  • Page 181   Spare wheel (for Tyres versions/markets, where provided) Versions Wheels Standard snow type Tyre equipment 185/65 R15 92Q 6JX15 ET39 6Jx15 ET39 Light 185/65 R15 92T 185/65 R15 92T (M+S) Light 195/65 R15 95T 195/65 R15 95Q 6JX15 ET39 Cargo 6Jx15 ET39 Heavy 195/65 R15 95T (M+S)
  • Page 182   Spare wheel (for Tyres versions/markets, where provided) Versions Wheels Standard snow type Tyre equipment 195/60 R16 C 195/60 R16 C 195/60 R16 C 7-seater (M1) 6JX16 ET36.5 6JX16 ET36.5 99Q (M+S) 1.3 Multijet 195/65 R15 95Q 6JX15 ET39 6JX15 ET39 Heavy 195/65 R15 95T 195/65 R15 95T (M+S)
  • Page 183   Spare wheel (for versions/markets, Tyres where provided) Versions Wheels Standard snow type Tyre equipment 185/65 R15 88Q 6JX15 ET39 Light 185/65 R15 88T 6Jx15 ET39 Light 185/65 R15 88T (M+S) 195/65 R15 95T 195/65 R15 95Q 6JX15 ET39 5-seater (M1) 6Jx15 ET39 Heavy 195/65 R15 95T (M+S)
  • Page 184 Spare wheel (for versions/markets, Tyres where provided) Versions Wheels Standard snow type Tyre equipment 195/60 R16 C 195/60 R16 C 2.0 Multijet All models 6Jx16 ET36.5 6Jx16 ET36.5 195/60 R16 C 99T 99Q (M+S) (*) Alternative...
  • Page 185 COLD TYRE INFLATION PRESSURE (bar)   Medium load Full load Measurement Front Rear Front Rear 185/65 R15 88T 185/65 R15 92T 2.4 Doblò (M1) 2.6 Doblò (M1) 195/65 R15 95T 2.4 Doblò Cargo 2.7 Doblò Cargo 3.0 Doblò Combi (N1) 3.2 Doblò...
  • Page 186 With snow tyres, add +0.2 bar to the pressure value prescribed for standard tyres. When running at speeds over 160 km/h, inflate tyres at full-load pressures.
  • Page 187 DIMENSIONS Short wheelbase versions Dimensions are expressed in mm and refer to the vehicle fitted with standard tyres. Height is measured with vehicle unladen. F0V0555   4406 2755 1832 / 1905(*) 1510 1832 1530 (*) With roof bars (for versions/markets where provided) Small variations in size are possible depending on the dimensions of the rims.
  • Page 188 Long wheelbase versions Dimensions are expressed in mm and refer to the vehicle fitted with standard tyres. Height is measured with vehicle unladen. F0V0556   Long 1880 / Wheelbase 4756 3105 1510 1832 1530 1927(*) versions Long 1857 / Wheelbase 4756 3105 1510...
  • Page 189 High roof versions Dimensions are expressed in mm and refer to the vehicle fitted with standard tyres. Height is measured with vehicle unladen. F0V0557   High Roof 2115(*) / 4406 2755 1510 1832 1530 versions 2125(**) (*) Doblò versions (*) Doblò Cargo versions Small variations in size are possible depending on the dimensions of the rims.
  • Page 190 Trekking versions Dimensions are expressed in mm and refer to the vehicle fitted with standard tyres. Height is measured with vehicle unladen. F0V0555   Trekking 1855 / 1905 4410 2755 1510 1832 1530 versions (*) With roof bars (for versions/markets where provided) Small variations in size are possible depending on the dimensions of the rims.
  • Page 191 Flatbed short wheelbase versions Dimensions are expressed in mm and refer to the vehicle fitted with standard tyres. Height is measured with vehicle unladen. F0V0572   4906 4427 2755 1510 1845 1530 1789 1870 2405 1045 1240 Small variations in size are possible depending on the dimensions of the rims.
  • Page 192 Flatbed long wheelbase versions Dimensions are expressed in mm and refer to the vehicle fitted with standard tyres. Height is measured with vehicle unladen. F0V0573   5416 4577 3105 1510 1845 1530 1789 1870 2405 1395 1400 Small variations in size are possible depending on the dimensions of the rims.
  • Page 193 WEIGHTS AND between values (E) and (D) shown on H Maximum permitted weight on the plate. second rear axle. LOADS E.g.: E=6000 kg - D=3500 kg To calculate the towable weight with To identify the weights and loads Braked trailer=2500 kg a braked trailer, take the difference for your vehicle, refer to the plate between values F and E shown on the...
  • Page 194 TOWABLE WEIGHTS (kg) Key: A = TOWABLE WEIGHT B = UNBRAKED TRAILER C = LOAD ON TOW HOOK D = LOAD ON ROOF   VERSION GVW ENGINE 1000 1.4 T-JET 1000 1.4 T-JET Natural DOBLÒ / COMBI (M1) 1000 Power 1.6 MultiJet 1300 2.0 Multijet...
  • Page 195 VERSION GVW ENGINE 1.4 T-JET Natural 1000 Power 1.3 Multijet 1000 COMBI 1.6 MultiJet 1300 2.0 Multijet 1500 1000 1.3 Multijet 1000 1.3 Multijet Euro 6 1000 PLATFORM TYPE 1.6 MultiJet 1300 1.6 Multijet Euro 6 1300 2.0 Multijet 1300 M1 = people carrier NOTE For vehicles with tow hook: the vertical static load on the tow hook must be within the maximum permitted weight declared for the vehicle.
  • Page 196 REFUELLING   1.4 T-JET Natural Prescribed fuels and 1.4 T-JET Power original lubricants Fuel tank: 60 litres 60 litres 22 litres Unleaded petrol not less than 95 RON (EN 228 specification) including a reserve of: 8–10 litres 8–10 litres 5.5 litres Long wheelbase 16.15 kg (approx.)
  • Page 197 1.4 T-JET Natural Prescribed fuels and 1.4 T-JET Power original lubricants Hydraulic power steering: 0.900 kg 0.900 kg 0.900 kg TUTELA TRANSMISSION GI/E Windscreen/rear window washer Mixture of water and 2.2 (***) / 6 (****) litres 2.2 (***) / 6 (****) litres 6.0 litres (°) fluid reservoir: PETRONAS DURANCE SC35...
  • Page 198   Prescribed fuels and original 1.3 Multijet 1.6 MultiJet 2.0 Multijet lubricants Fuel tank: 60 litres 60 litres 60 litres Diesel for motor vehicles (EN590 Specification) including a reserve of: 8–10 litres 8–10 litres 8–10 litres 50% mixture of distilled water Engine cooling system: 5.2 litres 6.7/6.3 litres (****)
  • Page 199 Prescribed fuels and original 1.3 Multijet 1.6 MultiJet 2.0 Multijet lubricants AdBlue (water — UREA solution) UREA tank (for versions/markets, – – where provided) approximate DIN 70 070 and ISO 22241-1 capacity (litres): 148) 149) (*) For Doblò versions without headlight washer. (**) For Doblò/Doblò...

  • Page 200: Fluids And Lubricants

    FLUIDS AND LUBRICANTS Your vehicle is equipped with an engine oil that has been thoroughly developed and tested in order to meet the requirements of the Scheduled Servicing Plan. Constant use of the prescribed lubricants guarantees the fuel consumption and emission specifications. Lubricant quality is crucial for engine operation and duration. RECOMMENDED PRODUCTS AND THEIR SPECIFICATIONS Original fluids and Features...
  • Page 201   Original fluids and Features Specification Applications lubricants TUTELA TRANSMISSION SAE 75W API GL4 grade 9.55550-MZ6 or Manual gearbox and GEARFORCE synthetic lubricant. MS.90030–M1 differential Contractual Technical Reference N° F002.F10 TUTELA TRANSMISSION Mechanical transmissions SAE 75W- 85 grade 9.55550-MX3 TECHNYX and differentials (1.4 T-JET synthetic lubricant.
  • Page 202 Original fluids and Features Specification Applications lubricants Synthetic fluid for braking and clutch systems TUTELA TOP 4/S Hydraulic brakes and Brake fluid Exceeds specifications: 9.55597 or MS.90039. Contractual Technical clutch controls FMVSS n° 116 DOT 4, Reference N° F005.F15 ISO 4925, SAE J 1704 Red protective with antifreeze action, based Cooling circuits.
  • Page 203 FUEL CONSUMPTION AND CO 2 EMISSIONS The fuel consumption and CO 2 emission figures declared by the manufacturer are determined on the basis of the type-approval tests laid down by the applicable standards in the country where the vehicle is registered. The type of route, traffic situations, weather conditions, driving style, general conditions of the vehicle, trim level/equipment/accessories, climate control system, vehicle load, roof rack, other situations that affect aerodynamics or air drag may lead to different fuel consumption levels than those measured.
  • Page 204 European Directive 2000/53/EC governing vehicles at the end of their life, Fiat is offering their customers the opportunity of handing over their vehicle (*) at the end of its life without incurring any additional costs.
  • Page 205 MULTIMEDIA TIPS, CONTROLS AND GENERAL INFORMATION ... 204 This chapter describes the main functions of the Uconnect™ Radio, Uconnect™ RADIO ....206 Uconnect™ 5" LIVE, Uconnect™ 5" OPERATION ......211 Nav LIVE infotainment systems which Uconnect™ 5" LIVE – can be fitted on the vehicle. Uconnect™...

  • Page 206: Road Safety

    In the case of loss of the radio code is requested, the display will show contact with pointed or rigid objects passport, contact the Fiat Dealership, "Please enter Anti-Theft Code" followed which could damage its surface; use a taking an ID document and the vehicle...
  • Page 207 Immediately stop using the system in the event of a fault. Otherwise the system might be damaged. Contact a Fiat Dealership as soon as possible to have the system repaired. WARNING 150) Follow the safety rules here below:...
  • Page 208 Uconnect™ RADIO CONTROLS ON FRONT PANEL F0N0890...
  • Page 209 FRONT CONTROL PANEL SUMMARY TABLE   Button Functions Mode Ignition Short button press Switching off Short button press Volume adjustment Turning the knob clockwise/anticlockwise Volume activation/deactivation (Mute/Pause) Short button press Exit the selection/return to previous screen Short button press Scrolling the list or tuning to a radio station or select Turning the knob clockwise/anticlockwise BROWSE previous/next track...
  • Page 210 Button Functions Mode Search for previous radio station or selection of USB Short button press previous track Scan of lower frequencies until released/Fast rewind of Long button press USB track Search for next radio station or selection of USB next track Short button press Scan of higher frequencies until released/Fast forward of Long button press...
  • Page 211 CONTROLS ON THE STEERING WHEEL (for versions/markets, where provided) The controls for the main system functions are present on the steering wheel to make control easier. The activation of the function selected is controlled, in some cases, by how long the button is pressed (short or long press) as described in the table below.
  • Page 212   Button Interaction (pressure/rotation) Acceptance of incoming call Answering the second incoming call and putting the active call on hold Rejection of incoming call Ending of call in progress Deactivation/reactivation of the microphone during a phone conversation Activation/deactivation of the USB source Pause Activation/deactivation of the Mute function on the Radio/AUX source (for versions/markets where provided) Turning left wheel upwards or downwards: audio volume adjustment +/–...
  • Page 213 OPERATION the radio text information (if any) are released the previous or next radio highlighted. station is displayed. SWITCHING THE SYSTEM When searching forwards, if the system FM station list ON/OFF reaches the end of the band, it will Press the BROWSE ENTER The system is switched on/off by automatically stop on the station where button/knob to display the complete list...
  • Page 214 Audio source selection Track selection (browse) Track information display Press the MEDIA button to select the Use this function to scroll through and To select the information displayed desired audio source from those select the tracks on the active device. while playing (Artist, Album, Genre, available: USB/AUX SYSTEM (for Name, Folder, File name).
  • Page 215 AUX SOURCE PHONE MODE activate the Bluetooth® function on the mobile phone; (AUX system only) Phone mode activation press the PHONE button on the Press the PHONE button on the front To activate AUX mode, use a suitable front panel; panel to activate the Phone mode.
  • Page 216 audio of the call is played over your pairing also from the list of Bluetooth® vehicle's sound system. devices on the phone and make a new pairing. Making a phone call SETTINGS The operations described below can Press the MENU button on the front only be accessed if supported by the panel to display the "Settings"...
  • Page 217 Uconnect™ 5" LIVE – Uconnect™ 5" NAV LIVE CONTROLS ON FRONT PANEL F0V0715...
  • Page 218 FRONT CONTROL PANEL SUMMARY TABLE   Button Functions Mode Ignition Short button press Switching off Short button press Volume adjustment Left/right rotation of knob Volume activation/deactivation (Mute/Pause) Short button press Display on/off Short button press Settings Short button press Exit the selection/return to previous screen Short button press Scrolling the list or tuning to a radio station Left/right rotation of knob...
  • Page 219 Button Functions Mode Support selection: USB, AUX socket (for 10- MEDIA Short button press versions/markets, where provided) Bluetooth® 11- RADIO Access to the Radio mode Short button press...
  • Page 220 CONTROLS ON THE STEERING WHEEL The controls for the main system functions are present on the steering wheel to make control easier. The activation of the function selected is controlled, in some cases, by how long the button is pressed (short or long press) as described in the table below.
  • Page 221 STEERING WHEEL CONTROL SUMMARY TABLE   Button Interaction (pressure/rotation) Acceptance of incoming call Answering the second incoming call and putting the active call on hold A list of the last 10 calls is displayed on the instrument panel (available in versions and markets where present) Rejection of incoming call Ending of call in progress The last calls are viewed on the instrument panel only with call browsing active (available for versions and markets...
  • Page 222 OPERATION "Tune" : manual radio station tuning Applications used on portable devices (not available for DAB radios); may be not compatible with the SWITCHING THE SYSTEM "Info": additional information on the Uconnect™ system. ON/OFF source being listened to; Track selection (browse) The system is switched on/off by "Audio": access to the "Audio Use this function to scroll through and...
  • Page 223 Bluetooth® SOURCE an audio device can also be starts reproducing the AUX source connected, if it is already being played. paired by pressing the button This mode is activated by pairing a on the front panel and selecting Adjust the volume using the Bluetooth®...
  • Page 224 previous system pairing also from the pair up to 10 phones/audio device phone (if "No" is selected, the Phone list of Bluetooth® devices on the to make access and connection easier main screen is displayed); and quicker; when prompted by the mobile phone and make a new pairing.
  • Page 225 available, the SMS notification option (*) Only use the numbers listed, problems related to the above, contact on the phone must be enabled; this otherwise the system will not take the your telephone service provider. option is usually available on the phone, message.
  • Page 226 Uconnect™ on www.driveuconnect.eu or on paragraph. LIVE experience. www.fiat.it; start the Uconnect™ LIVE Uconnect™ LIVE services setup The App can by downloaded from app on the smartphone and enter your using the radio "App Store"...
  • Page 227 as consumption and emissions are Recording and transferring trip The menu includes the following items: concerned. data Language; In addition, the data can be saved The trip data can be stored in the Display; on a USB flash drive, and the data system memory and transferred using Units;...
  • Page 228 Recent calls charge for 3 years from the start of the Increase zoom Calls made warranty on the vehicle. Decrease zoom Missed calls The navigation system can also be 2D mode Calls received updated at the Fiat Dealership.
  • Page 229 154) In the interest of safety and to reduce distractions while you are driving, you should always plan a route before you start driving. OFFICIAL TYPE APPROVALS All radio equipment supplied with the vehicle complies with the 2014/53/EU directive. For further information visit the www.mopar.eu/owner or http://aftersales.fiat.com/elum/ websites.
  • Page 230   IMPORTANT INTERIOR FITTINGS Never travel with the glove compartment open: it could injure the passenger in the event of a crash. The cigar lighter becomes very hot. Handle it carefully and make sure that children don't touch it: risk of fire and/or burning. Do not use the ashtray as a waste paper basket: it may catch fire in contact with cigarette stubs.
  • Page 231 Incorrect installation of electric and electronic devices may cause severe damage to your vehicle. After purchasing your vehicle, if you wish to install any accessories (anti-theft, radio phone, etc.), go to a Fiat Dealership, which will suggest the most suitable devices and advise you whether a higher capacity battery needs to be installed.
  • Page 232 BATTERY Batteries contain substances that are very hazardous for the environment. You are recommended to go to a Fiat Dealership to have the battery replaced where the old battery will be disposed of respecting both the environment and the laws in force.
  • Page 237 MAINTAIN YOUR VEHICLE IN TIP TOP CONDITIONS WITH Mopar Vehicle Protection offers a series of service contracts that are designed to give all our customers the pleasure of driving their vehicle without any hitch's and concerns. Our product portfolio consists of a wide and flexible range of extended warranty and maintenance plans endorsed by FCA.
  • Page 238 NOTES...
  • Page 239 Interior lights ....30 Cylinder marking ... . 172 Fiat CODE system ... . 12 Interior mirror .
  • Page 240 Luggage compartment ..42 Rear light clusters ... 126 Spark plugs (type) ... 174 Rear window washer .
  • Page 241 ehicle summary identification and paintwork plate ... 172 Version with methane system (Natural Power) ... . 47 VIN plate ....172 arming up the engine just after it has started .
  • Page 242 FCA Italy S.p.A. - MOPAR - Technical Service Operations - Service Engineering Largo Senatore G. Agnelli, 3 - 10040 Volvera - Torino (Italy) Print no. 603.91.802 - 09/2018 - 1st edition...
  • Page 243 At Fiat Service authorised workshops you can find technicians directly trained by us, offering quality and professionalism for all service operations. Fiat workshops are always close to you for the regular servicing operations, season checks and practical recommendations by our experts.
  • Page 244 The data contained in this publication is intended merely as a guide. FCA Italy S.p.A. reserves the right to modify the models and versions described in this booklet at any time for technical and commercial reasons. If you have any further questions please consult your FIAT dealer. Printed in recycled paper without chlorine.

Table of Contents

Save PDF
