- Page 1 Customer operation SolvisMax For gas or oil burners and residential district heating systems with SolvisMax Wärme. Leben. Zukunft...
-
Page 2: Table Of Contents
Hot water standby times ..........................17 7.2.3 Auxiliary hot water heating button ......................17 7.2.4 Hot water pump ............................17 7.3 Circulation ................................17 7.3.1 Time control ..............................17 7.3.2 Pulse control ..............................18 SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN SOLVIS... - Page 3 10.1 Maintenance interval ............................... 33 10.2 General care ................................33 10.3 Switching the heat generator on and off ......................... 33 11 Decommissioning ..............................34 12 Appendix ................................35 12.1 Time programs overview ............................35 SOLVIS SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN...
-
Page 4: Information About These Instructions
This especially applies to copying, translating, microfilming and storing and editing in electronic formats. © SOLVIS GmbH, Braunschweig. Using these instructions... -
Page 5: Notes
Solvis in advance. • Observe the safety notes. Exclusion of liability DANGER Solvis accepts no responsibility for damage to the unit or What to do if there is a risk of fire resulting damages if: • Immediately switch off the heating emergency •... -
Page 6: Product Description
Oil condensing heat generator Flange cover insert WELCOME Fig. 3: SolvisControl system controller Operation You can operate the SolvisControl directly via a touch- sensitive display (touch screen), which has menus in which SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN SOLVIS... -
Page 7: Room Controller (Optional)
Fig. 4: Room controller BE-SC-2 Operating modes can be activated in the central controller only Operating modes can be activated with the “F” button SOLVIS SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN... -
Page 8: Operating The Solviscontrol
Activate the leave function. (pages) here. Activate the ECO function. Press for approx. 3 seconds: settings. Help button. Displays help text. Back button. Used to cancel entry or return to the previ- ous menu. SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN SOLVIS... -
Page 9: Changing Numeric Values
The SolvisControl constantly monitors the entire system. If malfunctions arise, these are displayed with messages in plain text. There are two different categories of messages. In addition to the simple message about the system status SOLVIS SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN... - Page 10 1. Improper circulation in the solar circuit 2. Heat exchanger output reduced If this happens again, inform your installer. End with << button FAULT: Burner Burner malfunction, to unlock press “Reset” on the display. Reset SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN SOLVIS...
-
Page 11: Starting Up The System
SolvisMax Gas and Öl Open the gas or oil valve on the supply line to the burner. Switch on the system 1. Switch on the heating emergency switch, if necessary. SOLVIS SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN... -
Page 12: Simple Operation
± 5 °C (based on the target value). If the wa- ter at the tap is too cold, briefly press “+” and if it is too warm, press “–”. SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN SOLVIS... -
Page 13: Expert Operation
The time windows for all heating circuits are displayed. 3. Select the navigation button: This scrolls through the days of the week. Three different time windows are SOLVIS SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN... -
Page 14: Operating Mode: Day Mode
You always select between a leave at – “Home” and a leave “Away”. Proceed as follows: 1. Select the heating circuit if you have more than one heating circuit. 2. Briefly press the “Leave” button. SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN SOLVIS... -
Page 15: Eco Function
1. Briefly press the “ECO” button. A corresponding message is also displayed in the respec- tive menu items. 2. Answer the query with “Yes”. SOLVIS SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN... -
Page 16: Water
(showering only) are sufficient when the lines are 06:30-22:30 |00:00-00:00 |00:00-00:00 also well-insulated. 8. Select the button with the day(s) of the week: Selec- tion of the day of the week to which the time window SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN SOLVIS... -
Page 17: Hot Water Standby Times
The heating phase lasts for around 30 minutes. play for informational purposes. 4. Select a time window to enter an individual time peri- SOLVIS SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN... -
Page 18: Pulse Control
“Pulse control”. To activate the pulse and time function at the same time, proceed as follows: 1. Select the “Pulse” button. The button must be activat- ed (dark background). SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN SOLVIS... -
Page 19: Chimney Sweep
The chimney sweep The Solvis Customer Service Department can also analyse can now carry out all required measurements. this data. The installation firm must e-mail the data to This operating mode ends after the specified time has Solvis. - Page 20 Day temp. time wind. 3 20°C Low-mode temp 16°C All corrections require a certain amount of time to take effect. For this reason, wait at least one day before making any further adjustments. SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN SOLVIS...
- Page 21 19 °C. In lowering mode, the circuit switches off if the medium outdoor temperature rises above 10 °C + 2 K = 12 °C. The SOLVIS SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN...
-
Page 22: System Status
S11 sensor and A1 pump. 3. Select “System information”. 5. Read the status values in the second menu (heating circuits and heat generators). 6. Use the navigation button to switch to the next menu. SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN SOLVIS... -
Page 23: Change User
• If the installer answered the query about Simple 2. Select “Next”. operation with “yes” during initialisation. 7.5.7 Counter function Querying counter readings 1. Go to the “Other” menu. 2. Select “Next”. SOLVIS SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN... -
Page 24: Load Basic Settings
4. Select your required language. If required, choose 2. Select “Next” twice. “next” to switch to additional languages. Sprache/Language/Lingua/Idioma/Langue Back System information Change user Deutsch Español Counter function English Italiano Continue Français next > 3. Select “Load basic settings”. SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN SOLVIS... -
Page 25: Display
2. Follow the instructions on the screen. 3. To save, select “Screen has been adjusted successful- ly” – “O.K.”. To cancel, press the “Back” button when you see the closing message “!! Screen is not correctly adjusted!!”. SOLVIS SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN... -
Page 26: Functional Description Of Solviscontrol
The SolvisControl takes over the temperature-controlled temperature sensors. The solar pump in the primary circuit regulation of the load pump of the solid fuel boiler to be is controlled using the collector sensor (S8) and the solar SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN SOLVIS... -
Page 27: 3Rd Mixed Heating Circuit
CESS 2 / 2” menu. off when the target temperature (“Day temp. time wind.1”) is reached. 8.3.3 Activation Activate the solar excess function 1. Access the “Other” menu. SOLVIS SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN... -
Page 28: Settings
Chimney sweep* peratures below 5 °C. Memory card Heating circuits System status Continue *For district heating: “–––” 3. Select the heating circuit that is to be operated with the solar excess function. SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN SOLVIS... -
Page 29: Troubleshooting
The maximum temperatures at the storage tank at the top (S1, factory “Solar buffer full” the storage tank temperature drops below 87 °C (at S1) setting 90 °C) or the bottom (S3, 80 °C) have been exceeded. or 77 °C (at S3). SOLVIS SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN... -
Page 30: Malfunction Messages
SolvisLino or with on-site heat generators is de- firing system on the burner before you can unlock the scribed in the operating instructions for the heat message. generator. Please contact the relevant manufactur- SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN SOLVIS... -
Page 31: Malfunctions With Heating And Hot Water
If it is still too cold in one of the rooms despite having fully opened the heating valves, we recommend that you move the room controller into this room (new reference room). SOLVIS SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN... - Page 32 Example: The room temperature is approx. 4°C too low in autumn and spring, but adequate in winter. You must increase the target room temperature in the heating time programs by this amount and reduce the slope by 0.1. SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN SOLVIS...
-
Page 33: Maintenance And Care
In the summer, the storage tank may be overly heated by the solar collectors. – – Standby User 2. Select “Chimney sweep”. 3. Continue with the section “Start the burner”. SOLVIS SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN... -
Page 34: Decommissioning
Consult the specialised dealer responsible or us regarding proper decommissioning, disassembly and disposal of the system. All Solvis components sent back to our factory at no cost to us will be disposed of according to regulations at no cost to you. -
Page 35: Appendix
08:00 16:00 Factory 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 Customized settings SOLVIS SolvisMax Subject to technical changes 12.15 BAL-MAX-7-K-EN... - Page 36 SOLVIS GmbH Grotrian-Steinweg-Straße 12 D-38122 Braunschweig +49 (0) 531 28904-0 +49 (0) 531 28904-100 info@solvis.de www.solvis.com...
