POL 55
SAFETY & OPERATING
INSTRUCTION MANUAL
Electric polishing machine
220V-900W 700-2500RPM
The values shown are based on a nominal voltage of 230V/50Hz. In the case of
voltages and frequencies of different power, values may vary. Refer to the label
technical specifications to the nominal values of the tool.
GENERAL WARNINGS
The safety and accident prevention instructions are reported in the "SAFETY INSTRUCTION" booklet
which forms an integral part of these documents. This OPERATING INSTRUCTIONS MANUAL indicates
the additional information required specifically for use of the tool.
CORRECT USAGE
This tool is designed to be used as a polisher. Read all the warnings, instructions, indications provided
on drawings and specifications supplied with this tool. Failure to comply with all the instructions provided
below may cause electrical shocks, fire and/or serious injuries. This tool is not intended to be used for
smoothing, metal brushing and cutting operations. The use of this tool for unintended applications may
cause hazards and injuries to people.
The tool must be used with accessories that have been specifically designed or recommended by the
manufacturer. The fixing of the accessory to the tool does not guarantee a safe operation. The rated speed
of the accessories must be at least equivalent to the maximum speed specified on the tool. Using the
accessories at speeds above the rated maximum, may cause them to break or be projected into the air.
The external diameter and thickness of the accessories must match the specifications of the tool.
Accessories with incorrect dimensions cannot be adequately protected or controlled. The configuration of
accessories must match the tool. The use of accessories that cannot be perfectly fitted on the tool may
result in imbalance, excessive vibrations and in the impossibility of controlling the tool.
Do not use damaged accessories. Before use, inspect all the accessories. Inspect the supporting pads and
verify there are no cracks, tears or excessive wear. If the tool or accessory has been dropped, verify that
it is not damaged or install a new accessory. After inspecting or installing an accessory, test the operation
of the tool at maximum speed and without load for one minute, keeping at a safety distance. If the
accessories are damaged, they will break during this test.
SAFETY WARNING APPLICABLE TO
POLISHING OPERATIONS
Verify that no loosened part of the polishing tool shroud or the locking ties can rotate freely. Safely
position or cut all the loosened fixing wires. Loosened or revolving fixing wires may twist around the
operator's fingers or get caught by the work piece being machined.
Chemicar Europe NV - Baarbeek 2 - 2070 Zwijndrecht - België/Belgium
Chemicar Europe NV - Baarbeek 2 - 2070 Zwijndrecht - België/Belgium
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Finixa POL 55
Summary of Contents for Finixa POL 55
- Page 1 POL 55 SAFETY & OPERATING INSTRUCTION MANUAL Electric polishing machine 220V-900W 700-2500RPM The values shown are based on a nominal voltage of 230V/50Hz. In the case of voltages and frequencies of different power, values may vary. Refer to the label technical specifications to the nominal values of the tool.
- Page 2 Chemicar Europe NV - Baarbeek 2 - 2070 Zwijndrecht - België/Belgium...
- Page 3 Chemicar Europe NV - Baarbeek 2 - 2070 Zwijndrecht - België/Belgium...
- Page 4 STARTING UP Before starting-up the tool ensure that • The packaging is complete and does not show signs of having been damaged during storage or transport; • The tool is complete; check that the number and type of components comply with that reported in this instruction booklet;...
- Page 5 TOOL IDENTIFICATION PLATE POSITION AND MAENING OF INFORMATION 1. Type of tool. 2. Nominal working voltage in volts(V). 3. Working frequency in hertz(HZ). 4. Absorbed current in Amperes (A). Ensure that the power supply to which the tool is connected can easily tolerate the indicated current as a minimum.
- Page 6 TOOL USE AND CARE • Do not force the power tool. Use the correct tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. • Do not use the tool if the switch does not turn it on or off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
- Page 7 WARRANTY When purchasing a new machine Chemicar Europe provides a 1-year manufacturer warranty, beginning on the day of the sale of the machine to the end user. The warranty covers only damages that can be traced back to material and/or manufacturing faults as well as the non-compliance of promised features. In case of assertion of claims from this warranty the original sales receipt that shows the purchase date has to be submitted.
