HawkEye Electronics DepthTrax 1BX Installation And Operation Manual

Boat mount digital depth finder with temperature
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
D10D
Model No.
BOAT MOUNT DIGITAL DEPTH FINDER WITH TEMPERATURE
INSTALLATION AND OPERATION MANUAL
This manual covers the installation and operation of both temperature and non-
temperature depth finder displays. Refer to the instructions supplied with the
transducer for transducer testing and installation.
available at support.norcrossmarine.com. To ensure safety and many years of
trouble-free operation of your product, please read this manual carefully before
using this product.
SAFETY INFORM ATION:
•
Periodically wipe the face with a dry cloth. Do not use abrasives or solvents on
this device.
•
Only qualified personnel should perform repairs or servicing not covered in this
manual.
•
The LCD used in the product is made of glass. Therefore, it can break when the
product is dropped or impacted.
•
Keep this product away from heat sources such as radiators, heaters, stoves and
other heat generating sources. Do not store in extreme temperatures above 150°
F (65° C).
•
Shade the LCD during storage.
extended periods of time.
NOTES, NOTICES, AND CAUTIONS
WARNING: Indicates a potential for property damage, personal injury or
death.
IMPORTANT: Indicates potential damage to the device and tells you how to
avoid it.
NOTICE: Indicates important information that helps you make better use of
the device and tells you how to correct a performance problem.
INFORMATION: Indicates resources to obtain the proper information to help
you make the most of your device.
Read this manual completely before attempting to use or install your
device.
advanced troubleshooting and technical support.
This depth sounder should not be used as a navigational aid to prevent
grounding, boat damage, or personal injury. Always operate the boat
at slow speeds in unfamiliar water, or if you suspect shallow water or
submerged objects.
w w w . h a w k e y e e l e c t r o n i c s . c o m
I
NFORMATION
Visit our Customer Service Center on our website for
W
Do not expose LCD to direct sunlight for
:
:
ARNING
Additional resources are

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DepthTrax 1BX and is the answer not in the manual?

Questions and answers

Summary of Contents for HawkEye Electronics DepthTrax 1BX

  • Page 1 D10D Model No. BOAT MOUNT DIGITAL DEPTH FINDER WITH TEMPERATURE INSTALLATION AND OPERATION MANUAL This manual covers the installation and operation of both temperature and non- temperature depth finder displays. Refer to the instructions supplied with the transducer for transducer testing and installation. Additional resources are available at support.norcrossmarine.com.

  • Page 2: Installing The Display

    PARTS SUPPLIED IN PACKAGING The following parts should be included with the display: • Digital Depth Sounder Display • White and Black Faces and Bezels (optional on some models, see package for details) • Thick Dash Extension Rod (optional on some models, see package for details) •...
  • Page 3 2. After finding the right location, mark a 2-inch hole. (If your boat has a pre-cut hole in the dash panel, simply remove the hole plug and proceed to Step 5.) MPORTANT Check behind the desired cutting area for wires, switches, etc. that may be damaged during cutting.
  • Page 4 STEP 3 Connecting of the Power Cable The display has no ON/OFF switch. Therefore, you will need to connect the power harness to a power source that will turn the unit on as power is applied. The key switch or an ON/OFF power switch will be suitable for powering the unit.
  • Page 5 connected to the vessel’s power source. If 12 volt power is present continue to the next step. If power is not present, return to Step 1. 4. Insert the fuse and check for 12 volt power at the end of the fuse. If 12 volt power is present continue to Step C.
  • Page 6 DISPLAY MODE SELECTION (TEMPERATURE MODELS ONLY) The Temperature Models have 3 user selectable modes: • Depth Sounder • Water Temperature • Air Temperature To Change the Mode: 1. Press the “UP” Button to change the mode to the Right (The display will change modes from Depth to Water Temperature to Air Temperature) 2.
  • Page 7 6. The indicators will now be illuminated to indicate that a shallow water alarm is set. When triggered, the alarm sounds an audible buzzer for ten seconds while flashing the warning LED and the icons on the display. After 10 seconds, the audible alarm mutes and the warning LED and the icons continue to blink until the depth increases, or the alarm is reset.

  • Page 8: Keel Offset

    continue to blink until the depth increases, or the alarm is reset. To reset the alarm repeat steps 1 thru 5. OTICE Each time the Deep Water Alarm setting is changed you must wait 5 seconds for the depth finder to return to the Normal Operation Mode in order for the setting to be saved? KEEL OFFSET The Keel Offset feature is used to...

  • Page 9: Units Of Measure

    3. Press the "UP” key to increase the Keel Offset value. Press the "DOWN" key to reduce the value. 4. The display will return to the normal operation mode after five seconds if no keys are pressed. 5. “K/O” will remain illuminated in the top left hand corner indicating that the depth readings are adjusted to the Keel Offset setting.

  • Page 10: Installing The Transducer

    INSTALLING THE TRANSDUCER IMPORTANT: Install and test the display in the desired mounting location before attempting the transducer installation. IMPORTANT: Refer to the instructions supplied with the transducer for transducer testing and installation. Additional resources are available at support.norcrossmarine.com. OTICE Any transducer supplied with our depth finders that do not have temperature readouts can be glued in-hull.

  • Page 11: Replacement Parts

    increases, the problem can not usually be completely solved by position only. Changing one of the sounders to another model that runs on a different frequency will solve the problem. Using A Non-Standard Transducer: You may be able to use a transducer that is currently installed in your watercraft or a specialized transducer.
  • Page 12 NFORMATION To aid in maintenance and service, record the following: Date of Purchase: ___________________ Place of Purchase: _____________________________________ Date of Online Warranty Registration: _____________________ Production Date Code: ________ (3 digit code located on the device housing) LEG AL NFORMATION Made in China. Tested to comply with FCC, CE & ROSH standards if applicable.
