117-0815-0021
NOVA
12" COLE JAWSET
COLE JAW EXTENSION ACCESSORY
THIS MANUAL CONTAINS IMPORTANT INFORMATION
REGARDING SAFETY, OPERATION, MAINTENANCE AND
STORAGE OF THIS PRODUCT. BEFORE USE, READ CAREFULLY
AND UNDERSTAND ALL CAUTIONS, WARNINGS, INSTRUCTIONS
AND PRODUCT LABELS. FAILURE TO DO SO COULD RESULT IN
SERIOUS PERSONAL INJURY AND/OR PROPERTY DAMAGE.THIS
ACCESSORY CAN ONLY BE USED ON NOVA CHUCKS.
Publication117-0815-002
SKU: 6039 / 6040
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Teknatool NOVA 6039
Summary of Contents for Teknatool NOVA 6039
- Page 1 NOVA 12” COLE JAWSET COLE JAW EXTENSION ACCESSORY Publication117-0815-002 SKU: 6039 / 6040 THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY, OPERATION, MAINTENANCE AND STORAGE OF THIS PRODUCT. BEFORE USE, READ CAREFULLY AND UNDERSTAND ALL CAUTIONS, WARNINGS, INSTRUCTIONS AND PRODUCT LABELS. FAILURE TO DO SO COULD RESULT IN SERIOUS PERSONAL INJURY AND/OR PROPERTY DAMAGE.THIS ACCESSORY CAN ONLY BE USED ON NOVA CHUCKS.
-
Page 2: Contact Teknatool
CONTACT TEKNATOOL: New Zealand United States Teknatool International Ltd Teknatool Service Center Phone: (+64) 9 477 5600 Phone: 727-954-3433 Fax: (+64) 9 477 5601 Free Phone: 1-866-748-3025 Email: service@teknatool.com Free Fax: 1-866-748-4193 Website: www.teknatool.com Email: service@teknatool.com Website: www.teknatool.com 117-0815-0022... -
Page 3: Table Of Contents
TABLE OF CONTENTS: CONTACT TEKNATOOL ..............2 GENERAL SAFETY RULES ..............4 12" COLE, COLE and MINI COLE JAWS ..........6 ADDING THE OPTIONAL ACCESSORY EXTENSION PIECE FOR 12” COLE JAW ..................11 WARRANTY ..................12 117-0815-0023... -
Page 4: General Safety Rules
As with any other chucking method, an extremely cautious and sensible approach is necessary. With the Teknatool chuck it is not possible to give exact directions as to the amount of tightening pressure required for work holding. Follow closely strict guidelines in this manual for different jaw types for wood blank diameters length, and turning speed. - Page 5 ALWAYS WEAR EYE PROTECTION WHICH COMPLIES WITH CURRENT ANSI STANDARD Z87.1 (USA). WE STRONGLY RECOMMEND THAT A FULL FACE SHIELD IS USED AT ALL TIMES. BEFORE USING THE TEKNATOOL CHUCK ACCESSORY JAWS BE SURE THAT: WARNING!!! EXCESSIVE SPEED IS A SERIOUS LATHE HAZARD. ALWAYS TURN AT THE LOWEST SPEED POSSIBLE.
-
Page 6: 12" Cole, Cole And Mini Cole Jaws
12" COLE, COLE and MINI COLE JAWS: Codes: 6040, JSCOLE & 6006 SAFETY Consult the safety section of this jaw manual and also read the safety section of your Chuck manual and be thoroughly familiar with the safety operation before using these jaws. - Page 7 1-4 in clockwise sequence when mounted on the chuck so that they can be put back in the same sequence each time. The standard mounting screws that come with the Teknatool chucks can be used for this purpose. Extra screws can be obtained by purchasing the “Nova Fastening Spares Kit”.
- Page 8 B. Re-Chucking Using The Cole Jaw Facility The Cole Jaw segments can be mounted onthe chuck by themselves without the use of any other jaw sets. Normal M6x10mm Countersunk screws provided with your Teknatool chuck to mount the other accessory jaw sets can be used. 117-0815-0028...
- Page 9 WARNING!!! DO NOT ATTEMPT TO USE THIS FACILITY TO GRIP BOWL BLANKS WHICH HAVE NOT BEEN FULLY TURNED INSIDE AND OUTSIDE. THE RE-CHUCKING FACILITY CANNOT BE USED AS A GRIPPING METHOD TO DO MAJOR RE-SHAPING WORK OVER THE WHOLE OUTER SURFACE BOWL.
- Page 10 WARNING!!! THE RUBBER STOPPERS ARE A CONVENIENT HOLDING METHOD BUT MUST ONLY BE USED TO RE-CHUCK SMALL, LIGHTWEIGHT BOWLS UP TO 250MM (10”) DIAMETER FOR COLE JAWS AND 200MM (8”) FOR MINI COLE JAWS. NO RESPONSIBILITY CAN BE ACCEPTED FOR USERS OWN ADAPTIONS OF THIS CUSTOM FACILITY, i.e., CUSTOM WOODEN JAW SEGMENTS (MOUNTED ON COLE JAWS).
-
Page 11: Adding The Optional Accessory Extension Piece For 12" Cole Jaw
ADDING THE OPTIONAL ACCESSORY EXTENSION PIECE FOR 12” COLE JAW: SKU 6039 New Extension Accessory for the new Cole Jaw Set (SKU6040) takes your 12” Cole Jaw up to 15”. NOTE: This accessory cannot be used on the existing Mini Cole Jaw (6006) or the Standard Cole Jaw Set (JSCOLE) Threaded holes Figure 1 –... - Page 12 Assembly: Align the Extension Accessory with the Cole Jaw, placing tabs on the Extension in the grooves on the back side of the Cole Jaw as shown in Fig. 1.Take care to ensure that all the threaded holes on the extension (indicated by arrows in Fig.
-
Page 13: Warranty
WARRANTY: Teknatool SixYear Limited Warranty This Teknatool product is backed by a warranty from the date of purchase. Teknatool International Ltd will repair or replace, at its expense and option, this Teknatool product which in normal use has proven to be defective in workmanship... - Page 14 ® © 2015 Teknatool International Ltd, Teknatool USA Inc. All Rights Reserved. Register your warranty online www.teknatool.com 117-0815-00214...
