User's Guide
Auto Retractable Keyboard Assembly
for use with Ergotron products:
25-022
60-593
CAUTION:
Product is shipped with a stop screw that MUST be removed before use.
DO NOT REMOVE STOP SCREW BEFORE ATTACHING KEYBOARD TRAY.
Failure too follow these instructions will cause equipment damage.
www.ergotron.com |
|
|
|
USA: 1-800-888-8458
Europe: +31 (0)33-45 45 600
China: 400-120-3051
Japan: japansupport@ergotron.com
1 of 7
888-97-057-W-00 rev. C • 08/19
Advertisement
Table of Contents
Summary of Contents for Ergotron 97-487-800
- Page 1 User's Guide Auto Retractable Keyboard Assembly for use with Ergotron products: 25-022 60-593 CAUTION: Product is shipped with a stop screw that MUST be removed before use. DO NOT REMOVE STOP SCREW BEFORE ATTACHING KEYBOARD TRAY. Failure too follow these instructions will cause equipment damage.
- Page 2 Max Weight Capacity Max Keyboard Depth 2.5 lbs (1.14 kg) <7" (178 mm) Minimizing Vertical Lift Storage Profile For keyboard to fit under the monitor when in storage position, follow these guidelines: Dimension “A” must be no greater than 7-7/8" (200 mm). NOTE: Keyboard needs to attach to the lowest set of holes as shown in Step 3 Centerline of Four-Hole VESA FDMI Pattern...
- Page 3 Depending on the design of your VL, you may need 2.5mm 3/32" any one or combination of these 4 tools to remove your keyboard tray and pivot. 3/8" Save these screws for use in steps 3a and 3c. Attach pivot screws to middle set of holes (third up from the bottom set) so pivot attaches at...
- Page 4 M4 x 12mm REMOVE STOP SCREW BEFORE USE. CAUTION: Product is shipped with a stop screw that MUST be removed before use. DO NOT REMOVE STOP SCREW BEFORE ATTACHING KEYBOARD TRAY. Failure too follow these instructions will cause equipment damage. 4 of 7 888-97-057-W-00 rev.
- Page 5 Remove and discard. 8-32 x 1/4" 3/32" Top tray must be removed for pivot to function properly. Attach the loop (soft) side of the velcro to the bottom of the mouse tray to eliminate rattle 3/32" when the tray is stowed upright. 3/32"...
- Page 6 Remove Auto-rise NOTE: If you would like to remove the auto-rise feature: 1. Mount all Equipment (keyboard, wrist rest, mouse pad, mouse, ect.). 2. Loosen screw to decrease the tension (turn counter clockwise) until the tray no longer auto-rises. Minimum Weight Capacity >...
- Page 7 For the latest User Installation Guide please visit: www.ergotron.com For Warranty visit: www.ergotron.com/warranty For Service visit: www.ergotron.com For local customer care phone numbers visit: http://contact.ergotron.com www.ergotron.com | USA: 1-800-888-8458 Europe: +31 (0)33-45 45 600 China: 400-120-3051 Japan: japansupport@ergotron.com © 2011 Ergotron, Inc. All rights reserved.
