SoundMAGIC E11BT User Manual

Bluetooth earphone
Hide thumbs

Advertisement

Table of Contents

E11BT
蓝牙运动耳机
Bluetooth Earphone
User manual
使用说明书

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E11BT and is the answer not in the manual?

Questions and answers

Related Manuals for SoundMAGIC E11BT

Summary of Contents for SoundMAGIC E11BT

  • Page 1 E11BT 蓝牙运动耳机 Bluetooth Earphone User manual 使用说明书...
  • Page 2 SoundMAGIC Group Marketing Hongkong SoundMAGIC Technology Development Co.,LTD Shenzhen SoundMAGIC Technology Development Co.,LTD R & D and Manufacture Dongguan Nianrui Electronic Technology Co.,LTD Fulong Industry Road 8,Fulong Community Shipai Town,Dongguan,China Tel: 086-769-81270118/89633128 Fax:086-769-81270128 Email: support@soundmagic.com www.soundmagic.com 1613# Building A,Weidonglong Business Building,Meilong Road No 2125,...

  • Page 3: Packing List

    I.Packing List ③ ② E11BT 蓝牙运动耳机 Wireless In-Ear Headphone with Mic ⑤ ④ E11BT Bluetooth Earphone ① Bowl-shaped silicone eartips S/L ② (Middle size on the Headphone) USB charging cable ③ Carry pouch ④ User manual ⑤ ①...

  • Page 4: Technical Specifications

    II.Technical specifications Bluetooth...................Bluetooth V5.0 Driver..............Dynamics,10mm,Neodymium Transmission Range.................Up to13m Impedance..................42±10%Ω MIC Sensitivity..................-42±3dB Continuous Playback music..............48~60H Continuous Talk Time................20~24H Standby Time...................280H Weight......................24.7g Ambient Temperature..............-20°C~60°C...
  • Page 5 III.Function buttons/USB Multifunction Volume - Volume + Micro USB E11BT has a built-in noise cancelling microphone,which can make/reject the phone calls crisply and reliably. And you can stop/start play the music directly via the microphone control.

  • Page 6: Basic Functions And Operations

    3.Pairing 1)With your E11BT off, press and hold the “Multifunction” button for about 5 seconds until the red-blue LED is flashing rapidly (keep the button held down for another 2 seconds past the 'power on' prompt).

  • Page 7: Automatic Connection

    If your smartphone has been paired successfully with your E11BT, they will connect automatically if they’re within the effective distance (10m) and effective time period (5 minutes). If your E11BT is outside the effective distance, it will disconnect. But if it comes back to being within the effective distance again within 5 minutes, it will connect back to your smartphone automatically.

  • Page 8: Call Waiting

    E11BT, using the provided USB cable. A red light indicates that your E11BT is being charged. The red light will go out and the blue light will come on once your E11BT is fully charged (charge time is about 2 hours).

  • Page 9: Maintenance And Precautions

    4.Do not store your E11BT near toxic chemicals. 5.Do not store your E11BT near magnets. 6.Do not leave your E11BT with a fully drained battery for long periods. 7.If your E11BT is out of use for a long time, please charge it periodically to protect the battery.

  • Page 10: Common Problems And Solutions

    -phone Smartphone is too far away from Move closer to smartphone Noise/stuttering E11BT or there is interference in or move to a different place the surrounding environment. Increase the smartphone's The volume on the smar tphone is The audio is still quiet after...

  • Page 11: Customer Service And Support

    Please contact us directly for service and support. Our service team is ready to help you. E-Mail: support@soundmagic.com Phone: +86 769 81270118 Fax: +86 769 81270128 Factory address: Fulong Industry Road 8, Fulong Community Shipai Town, Dongguan, China For more information about SoundMAGIC please visit our website: www.soundmagic.com...
  • Page 12 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 13 一、装箱清单 ③ ② E11BT 蓝牙运动耳机 Wireless In-Ear Headphone with Mic ⑤ ④ E11BT 蓝牙运动耳机 ① 大/小号耳塞(中号在耳机上) ② 数据线 ③ 收纳袋 ④ 说明书 ⑤ ①...
  • Page 14 二、技术参数 技术标准…………………..…………………........….Bluetooth V5.0 单元…………………………..........……………10mm钕铁硼磁动圈 传输距离………………................……Up to 13m 阻抗……………………............……………………….42±10%Ω MIC灵敏度……………………...............………..-42±3dB 连续播放音乐时间…………..............……..48~60H 持续通话时间…………………..............……..20~24H 待机时间……………………………..............……..280H 重量……………………………………………..............24.7g 环境温度......................-20℃~60℃...
  • Page 15 三、功能展示 多功能键 “-”键 “+”键 Micro充电接口 耳机线控内置降噪麦克风，一键接挂电话，通话过程流畅清晰； 在音乐播放模式下，可暂停或播放...
  • Page 16 四、基本功能与操作 1.开机 长按“多功能”键约3秒：开机，耳机提示音“power on” 2.关机 长按“多功能”键约3秒：关机，耳机提示音“power off” 3.配对 1)关机状态下，长按“多功能”键约5秒（3秒左右会开机，此时不要放开） LED红蓝指示灯交替快速闪烁，进入自动搜索配对状态 2)打开播放设备蓝牙连接功能搜索蓝牙设备，将会搜索到的蓝牙耳机型号E11BT, 点击即可完成配对...
  • Page 17 4.自动连接 手机与耳机如果已经配对成功，耳机和手机蓝牙功能都处于开启状态，在有效距离 和有效时间内，二者可自动建立连接；在使用的过程中耳机超出有效距离断开连接 后，5分钟内回到有效距离，耳机将与手机自动建立连接，超过5分钟耳机将启动省 电模式自动关机 5.音乐播放 点按“多功能”键：开始播放音乐；再次点按：暂停播放音乐 双击“+”键：播放下一曲 双击“-”键：播放上一曲 按住“+”键不放：快进 6.来电 来电时点按“多功能”键：接通电话；通话时点按“多功能”键：结束通话；来电时 长按“多功能”键2秒：拒接来电...
  • Page 18 7.第三方通话 通话时有新来电，长按“多功能”键3秒：当前通话保持，接通第三方来电。（此 功能需电话运营商开通支持此项功能。） 8.音量调节 点按“+”键：增加音量 点按“-”键：降低音量 9.末号重播 双击“多功能”键：最后一次拨打号码重播 10.充电 请使用电脑或者输出电压为5V±0.2V的设备和USB数据线充电数据线充电 当红色灯亮时，表示正在充电 充电结束时，红色灯灭蓝色灯亮起（充电时间约为2H）...
  • Page 19 五、维护和注意事项 1.任何由于个人使用不当或者非专业人士的维修对耳机造成的破坏被列入保修范围 2.不可使用尖锐的物体接触耳机 3.不可使耳机一直处于充电状态 4.不可存放在有化学腐蚀性环境中使用 5.不可将产品防止于强磁的环境中 6.不可让耳机长期处于无电状态 7.长时间不使用，请隔一段时间进行充电，保护电池...
  • Page 20 六、常见问题与解决方案 常见问题 常见原因 解决方案 不能开机 电量不足 进行充电 其他电磁波干扰 无法连接 换个环境重新匹配连接 打开设置 手机蓝牙功能媒体音频未打开 配对连接后媒体声音外放 手机接听方式设置为听筒 打电话时声音仍然为听筒 设置为蓝牙接听 手机里耳机太远或周围环 拉近距离更换环境 有杂音 境有干扰 耳机声音调大后声音 调大手机音量 手机播放的声音太小 依然小 通话时对方听到声音小 麦克风通话孔被灰尘堵塞 保持耳机清洁及时清洁 无法保持当前通话接听 运营商未开通此功能 联系运营商开通解决 第三方...
  • Page 21 七、服务与支持 在需要提供服务时，请直接联系我们，专业的客服人员第一时间为您服务： 邮箱：support@soundmagic.com 电话：0769-81270118 传真：0769-81270128 厂址：广东省东莞市石排镇福隆工业区8路年瑞电子科技有限公司 您需要了解购买SoundMAGIC更多产品信息请登录 官方网址：www.soundmagic.com...
