Summary of Contents for Ilshim Global Windoro WCR-I001
-
Page 2: Table Of Contents
Content WINDORO User Manual (ver. GB) 4~17 WINDORO User Manual (ver. DE) 18~31 Manuale d’uso di WINDORO (ver. IT) 32~45 Note International Certification Content 4~17p Warranty Product Strengths Safety Instructions - Main power - Before using the product - While using the product - Product Maintenance Part Names and Functions 8~10... - Page 3 Contenuti 32~45P Garanzia Content 18~31p Punti di forza del prodotto Warranty Istruzioni di sicurezza 34~35 - Potenza Principale Product Strengths - Prima di utilizzare il prodotto - Durante l'utilizzo del prodotto Safety Instructions 20~21 - Manutenzione del prodotto - Main power - Before using the product Nomi dei componenti e funzioni 36~38...
-
Page 4: Warranty
According to the notice from the Fair Trade Commission on consumer disputes resolutions by product, ILSHIM GLOBAL Co., LTD guarantees the product as follows : ILSHIM GLOBAL Co., LTD or other partners will provide services when you apply for services during the warranty period. -
Page 5: Product Strengths
Product Strengths Windoro, the window cleaning robot is operated in tandem with two modules : the inner and the outside portions. The inside module works as the navigation unit and the outside module cleans using the spinning microfiber pads. The outside module attached to the outside window pane cleans as the inside navigator module navigates itself around the window. -
Page 6: Safety Instructions
Safety Instructions This page is to prevent injury and property damage to the user. Read this page carefully and use the product safely. The product contains strong permanent magnets and if you do not read these directions properly, you could be seriously injured or the product could be damaged. Do not touch the product or detach it from the window. -
Page 7: Safety Instructions
Safety Instructions This page is to prevent injury and property damage to the user. Read this page carefully and use the product safely. The product contains strong permanent magnets and if you do not read these directions properly, you could be seriously injured or the product could be damaged. Warning If you ignore the warnings, you can be seriously injured or die. -
Page 8: Part Names And Functions
Part Names and Functions Inside Navigation Bottom – strong permanent magnet. Area to receive signals from the remote control. Magnetic force controller Turn the controller left or right to set the optimum magnetic force, while checking if the LED light shows the force is strong or weak. Power POWER/STOP : ON/OFF button Magnetic force is maintained regardless of whether the power is on or off. -
Page 9: Part Names And Functions
Part Names and Functions Outside Cleaning Tool Bottom – spinning plates for microfiber pads, and detergent nozzles. WINDORO Detergent Inlet Be careful not to overfill. The proper volume is 40 ml. Power POWER : ON/OFF button Magnetic force is maintained regardless of whether the power is on or off. Press the button for more than 2 seconds, and the product will power on with a beeping sound. -
Page 10: Remote Controller
Part Names and Functions Remote Controller START STOP PAUSE Note for remote controller usage. It can work only within 3 meters of the unit. HOME It can send a signal only to the inside device in which a receiver is embedded. The outside device does not have a receiver. -
Page 11: Product Features And Components
Product Features and Components Please be aware of the features and components of this product. Since this product contains strong permanent magnets, if you are not aware of the information below, you can be seriously injured or the product can be damaged. WINDORO for Single Panes WINDORO for Double Panes Size... -
Page 12: Usage
Usage (The Vertical and Horizontal Initialization of the product) Since this product contains strong permanent magnets, if you do not follow the directions below, you can be seriously injured or the product can be damaged. The Vertical and Horizontal initialization of WINDORO. WINDORO has a sensor to detect its position vertically and horizontally by measuring where to locate itself for correct operation. -
Page 13: Usage
Usage (How to equip Edge Cleaning Kit) Since this product contains strong permanent magnets, if you do not follow the directions below, you can be seriously injured or the product can be damaged. Components. • Edge Cleaning kit : Edge pad+Fix plate •... -
Page 14: Before Using The Product
Usage Since this product contains strong permanent magnets, if you do not follow the directions below, you can be seriously injured or the product can be damaged. Check the inside and outside devices of WINDORO before using the product. Clean the wheels of the inside and outside devices. Dust and foreign substances formed on the wheels cause the product to slip or not to operate properly. Check the bottoms of the inside and outside devices. -
Page 15: Remote Controller
Usage Since this product contains strong permanent magnets, if you do not follow the directions below, you can be seriously injured or the product can be damaged. Cleaning, Starting and Pausing POWER/ START/ STOP PAUSE Control State START STOP PAUSE Charge Charge (IN) - Page 16 Frequently Asked Questions The questions below are often asked. When the product is malfunctioning, check the questions below for solutions. What should be done if the product does not work? POWER/ START/ Check the LED display. When none of the lamps on the display are lit, check if the power is turned on. STOP PAUSE Control...
- Page 17 Frequently Asked Questions The questions below are often asked. When the product is malfunctioning, check the questions below for solutions. Troubleshooting Check Lists WINDORO does not work. • Check the display status. (communication/magnetic force/power supply) Check if the power is turned on. •...
