Nextav NX-D100 Manual

Wifi drive
Hide thumbs

Advertisement

Quick Links

Download this manual
NX-D100 Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the NX-D100 and is the answer not in the manual?

Questions and answers

Related Manuals for Nextav NX-D100

Summary of Contents for Nextav NX-D100

  • Page 1 NX-D100 Manual...

  • Page 2: Product Overview

    PRODUCT OVERVIEW...
  • Page 3 The portable NEXTAV Data Drive (code name: NX-D100) device allows you to convert any SD memory cards and USB external storage devices into a Wi-Fi accessible media. Sim- ply insert your SD memory card into the SD slot or connect your USB external storage into the built-in USB port.
  • Page 4 • Built-in micro USB port for charging and data sync function • Up to 7 Hours of continuous battery life* • Supports Hot-Plug • Search function to locate and access your file much faster • Internet access capability via wireless, supporting 802.11 b/g/n speeds •...
  • Page 5 The Wi-Fi SD/USB works as SD memory card reader and charges the internal battery B. Wireless Mode. Wirelessly connect the Wi-Fi SD/USB to your existing wireless router to function as a wireless Internet pass- through to have access to the internet as illustrated below.
  • Page 6 Wi-Fi: Standard: 802.11 b/g/n, Frequency: 2.4 GHZ Speed: 72Mbps at 20MHz / 150Mbps at 40MHz USB Interface: Micro USB 2.0 for data transfer and charging Battery: Capacity: 3000mAh. Charging current: supports 500mA, 800mA and 1.5A Power consumption: A) SD Card Read/Write* 2W B) Stand-by (HDD Sleep Mode): 1.5W Emission (EMI) Safety and Other Certifications: FCC (Class B) and CE *Varies on SD card type.
  • Page 7 PC Web Browser Windows: Supports Internet Explorer 7.0 and higher version Mac: Supports Safari 3.0 and higher version Others: Firefox 3.5 and higher version • iOS: 4.0 and above • Android: 2.3 and above • Router or Switch 4. Product View 5.
  • Page 8 directly into the computer’s USB port or wall chargers. 5.2 USB Host Interface: The built-in USB 2.0 Host Interface for connecting any USB Mass Storage device and for charg- ing mobile devices such as smartphones, MP3 Players, and tablets. 5.3 SD Slot: Available SD slot to support SD, SDHC, and SDHC.
  • Page 9 Steady Light: Initialization process completed Ready to use Wi-Fi signal is normal LED Off: The device is switched-off or no power Internet LED: Blue Color: Good signal No LED: No connection established SD Read/Write LED: Blue Color: Flashing: Reading/Writing Data Steady Light: Initialization process completed Ready to use 6.
  • Page 10 Press the power button to switch on the device. Wait for few seconds to complete the initialization process and your USB external storage is ready to use. 7. PC Client Software Installation DOWNLOAD OUR SOFTWARE Directly from http://www. NEXTAV.ca...
  • Page 11 Wi-Fi SD/USB that is connected from your home network. 1. Copy the “NEXTAV WIFI Drive” executable file on your PC and follow the on-screen instructions. 2. Once the copy is complete, double-click on the “NEXTAV WIFI Drive”...
  • Page 12 8.2. PC Client Login Utility Double-click the “NEXTAV WIFI Drive” icon on your desktop. The software utility will search all the connected devices in your network as seen on the screenshot below. If you do not find the WiFiSD on the list of devices connected in your network, click on the “Refresh”...
  • Page 13 Wi-Fi SD/USB onto your desktop 8.3. Wi-Fi SD/USB Configuration using PC Once your Wi-Fi enabled-PC is successfully connect to the Wi-Fi SD/USB, using the “NEXTAV WIFI Drive” will allow you to access our built-in Web Management Interface and configure your device.
  • Page 14 wireless device to have the internet access. Selecting the Wireless Access 1. SSID. Enter the SSID name or click on the “Rescan” button to automatically search for the available wireless network connections. 2. Password. Enter the correct password to join the wireless network connection selected.
  • Page 15 3. Click on the “Next” button. The next step is to configure the Wi-Fi Disk. C) SSID: Enter the combination of letters and numbers only. 32 characters is the maximum allowable SSID length D) Channel: The default setting is set to Auto. There are 14 available channels to choose from.
  • Page 16 9.1. iOS Client App Installation DOWNLOAD OUR APP Directly from http://www.NEXTAV.ca 1. Click on the “App Store” icon on the desktop as seen on the image below. Search and locate the free “NEXTAV WIFI Drive” app and follow the on-screen installation instructions.
  • Page 17 2. Once the installation process has been completed, the “NEXTAV WIFI Drive” app can be found on the desktop as seen on the image above. 9.2. Wirelessly connecting your iPhone/ iPad 1. Turn-on the Wi-Fi SD/USB. Wait for few minutes to com- plete the initialization process.
  • Page 18 9.3. iOS User Login 1. Click on the “NEXTAV WIFI Drive” icon to launch the app as seen on the image below. 2. Enter admin as the user name and the password that you assigned during the configuration process.
  • Page 19 9.4. Android Client App Installation DOWNLOAD OUR APP Directly from http://www.NEXTAV.ca 1. Click on the “Play Store” icon on the desktop as seen on the image below. Search and locate the free “NEXTAV WIFI Drive” app and follow the on-screen installation instructions.
  • Page 20 2. Once the installation process has been completed, the “NEXTAV WIFI Drive” app can be found on the desktop as seen on the image. 9.5. Wirelessly connecting your Android devices 1. Turn-on the Wi-Fi SD/USB. Wait for few minutes to com- plete the initialization process.
  • Page 21 Android Device is con- nected to the Wi-Fi SD/USB. 9.6. Android User Login 1. Click on the “NEXTAV WIFI Drive” icon to launch the app as seen on the image below. 2. Enter the Admin password that you assigned during the configuration process.
  • Page 22 3. Once the password has been entered correctly, you will be automatically connected into the “My WiDisk”. The “My WiDisk” is the Wi-Fi SD/USB Storage. As seen on the screenshot below, the SD Memory Card and the USB Flash Disk are both mounted on the desktop. 10.
  • Page 23 My WiDisk Main Screen View – the WiFiSD_Volume1 and USBDisk_Volume1 can be seen on the desktop. Home Button – back to the main screen. View Button – change to List or Thumbnail view. Setting Button – change the Wi-Fi SD/USB configuration.
  • Page 24 10.2. Android Device Client Once you have successfully connected to the Wi-Fi SD/ USB, by default, you will be inside the “My WiDisk”. The “My WiDisk” is the Wi-Fi SD/USB and the “My Device” is the device that you are using to access the Wi-Fi SD/USB. Few buttons that can be found inside the Main Screen as listed below.
  • Page 25 Home Button – back to the main screen. View Button – change to List or Thumbnail view. Setting Button – change the Wi-Fi SD/USB configuration. Back Button – back to previous screen File Manager Button – to share, copy, delete, download, upload file functions Search Box –...
  • Page 26 or “My Device” Simply locate the music or audio file that you would like to play. Click on the file name and your music will automatically play. Note: Please consult your device manual to check whether it will support the music/audio files that you would like to play.
  • Page 27 be played randomly. - Play current list: the music or the audio files will be played sequentially. - Repeat All songs: the music or the audio files will be played in sequence, and it will only stop playing when button is clicked. Tip: You can click and hold, then slide the music progress button to fast-forward or rewind the music.
  • Page 28 Note: Please consult your device manual to check whether it will support the movie or video files that you would like to play. By default, the video playback is in the landscape mode. See the button functionalities below. - When clicked, the movie that is currently playing will stop and will exit the Movie Player Interface.
  • Page 29 where to copy all your movie files into the Wi-Fi SD/USB for ease of use and file organization. The movie or video files can be played regardless if you are inside the “My WiDisk” or “My Device”. Simply locate the movie or video file that you would like to play.
  • Page 30 list as seen on the screenshot below. Any photos that are not supported can be viewed as a generic thumbnail or icon. Thumbnail View List View To view a photo, simply click on the photo icon or file name as seen on the screenshot below. You can swipe your finger across the screen to manually view the photos or click the button, to automatically play the photos as slideshow.
  • Page 31 There are few available functions to control the slideshow. • Click the button to pause the slideshow from playing and press again to continue playing • Click the button to restart or to replay the slideshow. • Click the button to play the slideshow once and it will stop at the last image or photo.
  • Page 32 • Repeat button – the background music will continue play- ing the same music when it is switched-on. By default, this option is switched-off. 10.7. Viewing/playing photos (Android only) Tip: It is highly recommended to create a folder or folders where to copy all your photos into the Wi-Fi SD/USB for ease of use and file organization.
  • Page 33 Thumbnail View List View To view a photo, simply click on the photo icon or file name as seen on the screenshot below. You can swipe your finger across the screen to manually view the photos or click the button, to automatically play the photos as slideshow. There are few functions that are available to control the slideshow.
  • Page 34 10.8. Sharing photos/images (iOS only) There are few available options to share photos to your friends and family; by email, saving to the device Photo Album and upload to Facebook. Note: Internet connection is required to share photos/images via email or accessing any social media network.
  • Page 35 2) Add to photo – when clicked, the selected photo will be saved into the Photo Album of the device. 3) Upload to Facebook – when clicked, you will be directed to the Facebook login screen. The Facebook app must be installed on your device.
  • Page 36 Click the button to return from the previous screen or to exit. Click the button located at the top right of the screen to show the three available options to share your photos. 1) Share button – when clicked, a list of app installed on your Android will appear as seen on the screenshot below.
  • Page 37 To open or view any documents, simply click on the file name or the icon. This will automatically open the sup- ported file. Click the button to return from the previous screen or click the button to send the file via email as seen on the screenshot below.
  • Page 38 “Mail Canceled” message will appear on the lower-left corner of the screen when the email is canceled. 10.11. Opening/viewing documents (Android only) To open/view a document using your Android device, simply click on the file name or icon that you wish to open/view. This will automatically open the file using the default viewer or the installed app on your Android device as seen on the...
  • Page 39 “Send”. Once the “Send” button is clicked, a list of installed app will appear on your screen. You may select from the list of app that you wish to use to send or share the selected document. 10.12. Copy, Delete, Download, Upload functions (iOS and Android) You may click on the button at anytime to share, copy,...
  • Page 40 - Click once again, all files will be unselected. The check marks will no longer visible. Tip: You may select a single or multiple files by clicking on the thumbnail. As well, you may click and hold on the thumbnail for few seconds and drag it to button to download, or icon to upload or to...
  • Page 41 10.13. Copying/transferring file to the My Device (iOS and Android) Once you get connected into the Wi-Fi SD/USB, you can copy/transfer a single or multiple files into the local storage (My Device). 1. Click on the 2. Use your index finger to select a single or multiple files or you may use the to select all files to be copied/ transferred as seen on screenshot below.
  • Page 42 • A new folder may be created to copy/ transfer the selected file or files. To create a new folder, simply click on the “Create Folder” button. Enter the new folder name inside the box and click the “Done” button as seen on the screenshot below.
  • Page 43 10.14. Copying/transferring file to My WiDisk (iOS and Android) Note: Make sure you switch to the “My Device”. 1. Click on the button. 2. Use your index finger to select a single or multiple files or you may use the button to select all files to be copied/ transferred.
  • Page 44 characters and up to maximum of 26 characters in length. Click the “Cancel” button to exit. 5. Click on the “Select” button to start copying/transferring files as seen on the screenshot below into the “My WiDisk”. 6. Click anywhere on the screen and you will return to the previous screen.
  • Page 45 10.18. Exiting NEXTAV WIFI Drive App (iOS) To exit from using the NEXTAV WIFI Drive on iPhone/ iPad devices, simply press the Home key on your Apple Device. To reset the app, click on the Home key twice and the list of app will appear at the bottom of your device.
  • Page 46 10.19. Exiting NEXTAV WIFI Drive App (Android) To exit from using the NEXTAV WIFI DRIVE Android mobile devices, simply click on the and select the “Exit” button. A warning “Are you sure you want to exit this applet?”...
  • Page 47 10.21. Uninstall NEXTAV WIFI Drive App (Android) To uninstall the NEXTAV WIFI Drive app from your Android mobile devices, see the instructions below. Note: Uninstalling app on the Android devices will vary. Please consult your mobile device manual prior to removing any application.
  • Page 48 Simply launch our “NEXTAV WIFI Drive” client app or open your web browser and enter the 10.10.10.254 IP address. Allows the user to make changes on the admin password. Provides information of the Internal hard disk drive.
  • Page 49 11.1. Explorer Function Our user-friendly web based utility allows the user to upload files to the device, create folders, copy, cut, delete and rename folders and file names. We provide similar functionalities as the windows explorer of which makes our interface much easier to use.
  • Page 50 11.2. Context Menu 1. On the file level, you can right-click using your mouse and a pop-menu will appear. You may Copy, Cut, Delete, Rename or Download as seen on the screenshot below. 2. On the folder level, you can right-click using your mouse and a pop-up menu will appear.
  • Page 51 • Open Command – Select a folder and right-click. Inside the pop-up menu, select “Open” to view the contents or open the folder. • Copy Command - Select a folder or a file and then right- click. Inside the pop-up menu, select “Copy” to make a copy of the entire folder or a file and paste into another location or folder.
  • Page 52 location. • Download Command – Select and right-click on the file to be downloaded. From the pop-up menu, select “Down- load”. The file will automatically open if any of the software installed on the computer supports this file type otherwise, it will ask you to download the file into a specific location.
  • Page 53 Number, Manufacturer Name, Model Number and CPU utiliza- tion as seen on the screenshot below. 11.5.2. Storage Information Provides information regarding the internal storage such as the total capacity, hard drive manu- facturer and available storage as seen on the screenshot below. 11.5.3.
  • Page 54 button the password has been changed. The default User Name is admin and no password is as- signed. Click on the “X” to cancel and exit. 11.6.2. Disk Click on the “Disk” button. This window provides information regarding the internal hard drive as seen on the screenshot below.
  • Page 55 11.7. Network Settings 11.7.1 Hostname The Host Name is a name that is assigned to certain device that is connected to a computer network. The Host Name can be modified to whatever name that will fit your needs. It must begin with a letter and followed by a combination of letters and numbers.
  • Page 56 1. SSID: Enter the combination of letters and numbers only. 32 characters is the maximum allowable SSID length 2. Channel: The default setting is set to Auto. There are 14 available channels to choose from. 3. Modes: The default setting is 11b/g/n. You can also manually set the modes to 11Mbps (802.11b), 54MBPS (802.11G), and 150Mbps (802.11n).
  • Page 57 Click on the “Save” button after making any changes. Click on the “X” to exit and cancel. Click on the “DHCP List” button and it will provide a list of all the computers and devices connected to your Wi-Fi SD/USB Device. Please see the screenshot below.
  • Page 58 3. IP Address. Select either DHCP or Manually assign an IP address a. By selecting DHCP, the host will provide an automatic IP address to connect to the internet b. By selecting Manual, you have to manually assign an IP address to connect to the internet 11.8 Network Services Windows sharing and network services are available to...
  • Page 59 Click on the “OK” button to continue on rebooting the device. 11.9. System Settings 11.9.1 Time Settings The time settings can be changed based on the region where you are located. You can choose to synchronize time with the Internet or the time on your PC.
  • Page 60 will automatically adjust the time and date based on the PC time. See the image below. Click on the “X” button to exit and cancel the Time Settings. 11.9.2. Backup Settings Creating a backup as seen on the screenshot below can save the Wi-Fi SD/USB system configuration.
  • Page 61 A warning message will appear. The device will reboot automatically once the restore pro- cess has been completed and will return to login screen. 11.9.3. Firmware Upgrade The device firmware can be upgraded by following the simple steps below. 1. Download and save the latest firmware version on your computer.
  • Page 62 “Save” button to continue updating the firmware. 4. Once the firmware has been installed, the warn- ing message as seen on the screenshot below will appear and the device will automatically reboot and will go back into the login screen. 11.9.4.
  • Page 63 Wi-Fi SD/USB production. 13. Warranty NEXTAV offers a 1 year limited warranty on this product for Canada and US. For warranty elsewhere check the store where you purchased your item and visit us at...
