Summary of Contents for DUTCH 9D-58-A
- Page 1 02/03/16 - AC - Rev.1 INSTRUCTIONS USE AND MAINTENANCE PORTABLE FIRE EXTINGUISHERS WATER+ADDITIVE PERMANENT PRESSURE Models: 9D-58-A (Class A) 9D-58-A (Classes A – F) 9D-58-AB 9D-34-A (Class A) 9D-34-A (Classes A – F) 9D-34-AB The total or partial reproduction of this document is prohibited.
-
Page 2: Table Of Contents
02/03/16 - AC - Rev.1 INDEX 1. INSTALLATION............................……... 3 2. WORKING ..............................…….. 3 3. USE AND WORKING ………......……………..………………..........………………………. 3 3.1. WARNINGS ..………........................……….. 3 3.2. INSTRUCTIONS FOR USE .………....................………….. 4 4. INSPECTION MADE BY THE USER .....……................………………… 4 5. MAINTENANCE MADE BY QUALIFIED OPERATOR .............…………………….…… 5 5.1. -
Page 3: Installation
02/03/16 - AC - Rev.1 1. INSTALLATION This model, delivered ready for use, is designed to be installed on the wall bracket supplied. It can be used in vehicles and boats (optional). Its location must be reported in the manner prescribed by the current regulations. 2. -
Page 4: Instructions For Use
02/03/16 - AC - Rev.1 Fires from cooking oil and fat as well as other kitchen cooking material, which are of the greasy kind. 3.2 INSTRUCTIONS FOR USE 1. Use upright pull out clip 2. Aim at base of fire 3. -
Page 5: Maintenance Made By Qualified Operator
02/03/16 - AC - Rev.1 5. MAINTENANCE MADE BY QUALIFIED OPERATOR 5.1 SCHEME OF THE FIRE EXTINGUISHERS Models : 9D-58-A (Class A) / 9D-58-A (Classes A F ) / 9D-58-AB N. Description Safety seal Safety pin Wall bracket Ceck valve... -
Page 6: General Information
02/03/16 - AC - Rev.1 5.2 GENERAL INFORMATION The user must always ensure that portable fire extinguishers are checked and maintained in the manner specified in paragraph 5.8.1. The qualified maintenance operator must perform the work at the frequency established by the current regulations. This frequency may be increased because of environmental concerns, risks or specific regulatory requirements. -
Page 7: Tag Of Maintenance
02/03/16 - AC - Rev.1 5.5 TAG OF MAINTENANCE The maintenance data must be recorded on a tag that does not conceal any marking the manufacturer SAE. The tag contains the following data: - Verified / audited; - The recharge date specifying the nature of the extinguisher if necessary; - The date of additional maintenance and thorough;... -
Page 8: Maintenance Procedures
02/03/16 - AC - Rev.1 5.8 MAINTENANCE PROCEDURES These procedures are the responsibility of maintenance operator or company authorized to conduct any revision. CAUTION: according to the current regulations in the country where they are used fire extinguishers, some maintenance procedures may not be applicable. 5.8.1 Details of maintenance procedures adopted in accordance with the regulations in force Phase or element checked Istructions... - Page 9 02/03/16 - AC - Rev.1 Phase or element checked Istructions Fill in the tag maintenance Fill in the tag maintenance, as it appears in paragraph 5.5. extinguisher NOTE: Only use wrenches certified. The safety valve is screwed with the force torque of 12/17 Nm. The valve with thread M34 is screwed with the force torque of 20/70 Nm.
-
Page 10: Safety Precautions For The User
ASX= 1,35 L; BSX233=0,09 L; water=7,56L Models: 9D-58-A (class A); 9D-34-A (class A) SAE-Aplus= 9 L Models: 9D-58-A (class A F); 9D-34-A (class A F) SAE-Aplus= 8,91 L; BSX233=0,09 L 6. SAFETY PRECAUTIONS FOR THE USER 6.1 During the suppression of the fire... -
Page 11: Warranty
02/03/16 - AC - Rev.1 PHASE EVENT RISK PREVENTIVE CORRECTIVE ACTIONS MEASURES conductive Please observe consult doctor instructions of use given hospital. in section 3.1, and in After inhalation Accidental particular: case difficulty contact with the INHALATION - Keep the hose provided breathing, give oxygen.
