Gremo
1250F/1450F
Workshop manual
Release
Workshop manual in
original
1450F 4.1EN
©Gremo 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1250F and is the answer not in the manual?

Questions and answers

Summary of Contents for GREMO 1250F

  • Page 1 Gremo 1250F/1450F Workshop manual Gremo AB 311 51 Ätran Sweden Release Tel. +46 346–60515 Workshop manual in Fax. +46 346–60342 original www.gremo.com 1450F 4.1EN info@gremo.se ©Gremo 2019...

  • Page 3: Table Of Contents

    ......... 9 filter ..........68 4.5 Replacing drive belts....... 70 2 Safety regulations ........13 2.1 General ........... 13 5 Transmission 1250F/1450F ....73 2.2 Clothing ........... 16 5.1 Transmission, gearbox....73 2.3 Seat belt .......... 16 5.2 Bogie axles........74 2.4 Emergency stop ......

  • Page 5: Introduction

    1.1 Introduction 1 Introduction 1.1 Introduction For you to get the most out of your Gremo machine as an owner or an operator, it is very important that you maintain and handle the machine correctly. It is also very important that you familiarise yourself with the performance and the restrictions of the machine.

  • Page 6: About The Documentation Kit

    1.2 About the documentation kit 1.2.1 About the Instruction Manual The Instruction Manual contains important information about your new Gremo machine, about operating the machine, safety when working and the machine's daily checks. In addition, it offers many valuable tips that facilitate your daily work.
  • Page 7 Gremo 1250F/1450F Workshop manual 1 Introduction 1.2 About the documentation kit 1.2.5 Ordering documentation Documentation can be ordered from your service dealer or from Gremo AB. Always specify the machine number and publication number when ordering. The publication number is printed...

  • Page 8: Presentation Gremo 1250F/1450F

    1 Introduction Gremo 1250F/1450F Workshop manual 1.3 Presentation Gremo 1250F/1450F 1.3 Presentation Gremo 1250F/1450F 1.3.1 General description of the machine Fig. 1 Gremo 1250F/1450F Gremo 1250F/1450F • is a robust and versatile 12 to 14 tonne forwarder that easily navigates all types of terrain. The forwarder is...

  • Page 9: Intended Area Of Use

    Gremo 1250F/1450F Workshop manual 1 Introduction 1.4 Intended area of use 1.4 Intended area of use The machine must only be used for what it has been designed and adapted for, i.e. forwarding forest raw materials, the weight of which does not exceed the machine's maximum load capacity, from felling site in the forest to the roadside stacking area.

  • Page 10: Operator Requirements

    Accidents are usually caused by humans, not by the machine. A well-maintained machine and a safety-aware owner/operator is a profitable and safe combination. A Gremo machine meets the requirements of the Machinery Directive and the harmonised standards, plus national requirements and provisions.

  • Page 11: Warning Symbols And Information About Risks

    Gremo 1250F/1450F Workshop manual 1 Introduction 1.7 Warning symbols and information about risks 1.7 Warning symbols and information about risks The following warning symbols and signal words are used throughout this manual and on stickers on the machine: NOTICE Read this important information carefully.

  • Page 12: Construction Of The Machine

    1 Introduction Gremo 1250F/1450F Workshop manual 1.8 Construction of the machine 1.8 Construction of the machine NOTICE This Instruction Manual is designed to be valid in several market areas and for most factory-installed equipment. Please ignore the paragraphs which are not valid for your machine.

  • Page 13: Location Of Type Plates And Serial Numbers

    Gremo 1250F/1450F Workshop manual 1 Introduction 1.11 Location of type plates and serial numbers 1.11 Location of type plates and serial numbers Fig. 2 Type plates and serial numbers Type plate for the grapple Type plate for the crane Type plate for the cab...
  • Page 14 1 Introduction Gremo 1250F/1450F Workshop manual 1.11 Location of type plates and serial numbers 1.11.2 Type plate for the machine The following details are shown on the machine's type plate: Fig. 4 Type plate for the machine Diesel engine’s serial number Country of manufacture Machine no.
  • Page 15 Gremo 1250F/1450F Workshop manual 1 Introduction 1.11 Location of type plates and serial numbers 1.11.3 Type plate for the cab The following details are shown on the cab's type plate: Fig. 5 Type plate for the cab Approved according to: Model/Type Serial no.
  • Page 16 The injection pump is itemised from Gremo AB. The following details are shown on the engine's type plate: Fig. 8 Type plate for the diesel engine...

  • Page 17: Safety Regulations

    Gremo 1250F/1450F Workshop manual 2 Safety regulations 2.1 General 2 Safety regulations 2.1 General Operators, mechanics and supervisors are obliged to study and follow the safety regulations and advice given in this chapter. The machine is equipped with signs, and you should make yourself familiar with the meaning and location of these signs.
  • Page 18 2 Safety regulations Gremo 1250F/1450F Workshop manual 2.1 General WARNING Do not leave the cab without first placing the grapple/ crane safely on the ground or in the loading platform. WARNING During all work on the machine, remember the risk of slipping.
  • Page 19 Gremo 1250F/1450F Workshop manual 2 Safety regulations 2.1 General NOTICE For your mobile phone and other portable communication equipment you should always use externally mounted aerials in order to prevent interference with the computers of the machine. NOTICE Never use the main power switch to turn off the machine...

  • Page 20: Clothing

    2.3 Seat belt Always use the seat belt. Replace a damaged or worn seat belt immediately. Order from you nearest Gremo service dealer or from Gremo AB using spare part number 92900100. Before you start operating the machine, check that there is no one standing close to it.

  • Page 21: Emergency Stop

    Gremo 1250F/1450F Workshop manual 2 Safety regulations 2.4 Emergency stop 2.4 Emergency stop Check the emergency stop function daily. The emergency stop is the red switch with the yellow plate. The external emergency stop is located on the right-hand ascent into the machine, and the cab emergency stop is on the left-hand 'B' column.

  • Page 22: Emergency Exit

    2 Safety regulations Gremo 1250F/1450F Workshop manual 2.5 Emergency exit 2.5 Emergency exit The left-hand side window acts as the emergency exit. To open the window, grip the latch handle and turn it upwards until the latch is released. The window can now be opened outwards.

  • Page 23: Boarding The Machine

    Gremo 1250F/1450F Workshop manual 2 Safety regulations 2.8 Boarding the machine joint lock is released when you ”rev” with the accelerator pedal. For settings, see GreControl in the User Manual. 2.8 Boarding the machine Use the ladder, and hold on to the handle on the bonnet, the handle on the cab column and the door handle.

  • Page 24: Inspection Of Parking Brake

    2 Safety regulations Gremo 1250F/1450F Workshop manual 2.9 Inspection of parking brake 2.9 Inspection of parking brake The parking brake is a safety detail and its working order should be checked. • Place the fully-loaded machine on a slight slope, 10-12 degrees, or a climb of 2 m per 10 m with free rolling movement with no obstacles.
  • Page 25 Gremo 1250F/1450F Workshop manual 2 Safety regulations 2.9 Inspection of parking brake 2.9.1 Manual release of parking brake WARNING Before starting the work of manually releasing the parking brake, ensure that the machine's wheels are locked to prevent it from rolling.
  • Page 26 2 Safety regulations Gremo 1250F/1450F Workshop manual 2.9 Inspection of parking brake 3. Screw the threaded stud (3) all the way in through the hole in the brake cylinder and tighten until it stops. Fig. 17 4. Fit the washer and counter-locking nut (4) and tighten the nut to release the spring force in the brake cylinder.

  • Page 27: Driving

    Driving speed A Gremo 1050F is designed to manage a maximum load of 10,500 kg, even on difficult terrain. Off-road driving causes large dynamic forces on the machine. The machine’s own weight, plus the load, increases the stress...

  • Page 28: Crane Operation

    2 Safety regulations Gremo 1250F/1450F Workshop manual 2.11 Crane operation 2.11 Crane operation Read the instructions carefully before you operate the crane for the first time. See the sub-supplier's documentation. There is a considerable risk of accidents if you start without being sufficiently familiar with the design, function and use of the crane.
  • Page 29 Gremo 1250F/1450F Workshop manual 2 Safety regulations 2.11 Crane operation NOTICE Observe the lifting capacity limits on the load sign. Never overload. NOTICE Never run the hydraulic cylinders towards the end stops at full speed! Risk of damage to the machine...

  • Page 30: Parking/Storage

    2 Safety regulations Gremo 1250F/1450F Workshop manual 2.12 Parking/storage 2.12 Parking/storage • For safety reasons, park the machine on a level surface when it is not to be used. • Let the machine idle for a minute or so before turning off the engine.

  • Page 31: Trailer Transport

    Gremo 1250F/1450F Workshop manual 2 Safety regulations 2.13 Trailer transport 2.13 Trailer transport DANGER Major demands are placed on lifting and transport equipment, e.g. lifting chains, hooks, etc. Danger! Check the equipment and its capacity, the lifting straps on the machine and the lashing points on the transport vehicle and machine.

  • Page 32: Service

    Gremo AB. Rebuilding and/or modifying the machine (mechanically or electrically) is done at your own risk, and Gremo takes no responsibility for the consequences. Be aware that the safety system may become disabled! It is the rebuilder’s responsibility by law to document and...
  • Page 33 Gremo 1250F/1450F Workshop manual 2 Safety regulations 2.14 Service WARNING You are not allowed to service the machine unless you have the correct knowledge to do the work. CAUTION Avoid breathing in exhaust gases! The exhaust gases contain, inter alia, carcinogenic substances, aldehydes...
  • Page 34 Waste oils and fluids should always be disposed of as hazardous waste at designated waste facilities or handled by an authorised company. NOTICE In case of hose breakage: connect the vacuum pump (additional equipment) so that unnecessary oil does not leak out! NOTICE Always use Gremo original spare parts.

  • Page 35: Oil Leaks

    2 Safety regulations 2.15 Oil leaks 2.15 Oil leaks If you cannot rectify the oil leakage yourself, please contact an authorised service dealer or Gremo AB immediately. 2.16 Oils CAUTION All work where you may get into contact with oil involves a risk of skin trouble, e.g.

  • Page 36: Batteries

    Gremo 1250F/1450F Workshop manual 2.17 Batteries 2.17 Batteries A Gremo can be equipped with wet cell or dry cell batteries. When a dry cell battery is depleted, a diode will illuminate red on the screen, or not illuminate at all. Wet cell batteries must be checked so that the fluid level is above the cells.

  • Page 37: If By Accident The Machine Tips Over

    Gremo 1250F/1450F Workshop manual 2 Safety regulations 2.19 If by accident the machine tips over NOTICE Never carry out any welding repairs on frames, articulated joint or crane without first contacting an authorised service dealer or the service department at Gremo AB.
  • Page 38 If the machine has tipped over onto one side, you should immediately let a Gremo-authorised workshop check the operator’s cab. The protection provided by the cab is impaired if the cab becomes distorted.

  • Page 39: In The Event Of Fire

    For more information, see 9.1 Fire extinguishing system, page 101. NOTICE Contact an authorised Gremo service workshop, or a service workshop authorised by Fogmaker International AB, for refilling and inspection of the fire extinguishing system.

  • Page 40: Warning Signs

    2 Safety regulations Gremo 1250F/1450F Workshop manual 2.21 Warning signs 2.21 Warning signs CAUTION Ensure that warning and information signs on the machine and its components are always visible and readable. Clean dirty signs and replace signs that are damaged, are unclear or painted over.
  • Page 41 Gremo 1250F/1450F Workshop manual 2 Safety regulations 2.21 Warning signs Fig. 25 Warning sign in the event of fire Fig. 26 Warning sign for high pressure Fig. 27 Operator information for Fogmaker extinguishing system...
  • Page 42 2 Safety regulations Gremo 1250F/1450F Workshop manual 2.21 Warning signs Fig. 28 Operator information hand-held fire extinguisher 2.21.2 On the machine Fig. 29 The following warning signs for crushing injuries can be found on the right and left sides of the machine:...
  • Page 43 Gremo 1250F/1450F Workshop manual 2 Safety regulations 2.21 Warning signs Fig. 30 Warning sign for crushing injuries, moving gate Fig. 31 Warning sign for crushing injuries, moving mid- section...
  • Page 44 2 Safety regulations Gremo 1250F/1450F Workshop manual 2.21 Warning signs Fig. 32 Protective cover for controlling cab tilt The following warning signs can be found on the protective cover for controlling cab tilt on the left side of the machine:...
  • Page 45 Gremo 1250F/1450F Workshop manual 2 Safety regulations 2.21 Warning signs 2.21.3 In the engine compartment The following warning signs can be found in the engine compartment: Fig. 34 Engine compartment, left side Warning for rotating objects Warning sign for crushing injuries under cab Fig.
  • Page 46 2 Safety regulations Gremo 1250F/1450F Workshop manual 2.21 Warning signs Fig. 36 Warning for rotating objects Fig. 37 Warning for air conditioning system Type of refrigerant Max. pressure NOTICE Special authorisation is required by the person refilling the refrigerant in the air conditioning system (observe...
  • Page 47 Gremo 1250F/1450F Workshop manual 2 Safety regulations 2.21 Warning signs Fig. 38 Information sign for air conditioning system Year of manufacture Type of refrigerant Amount of refrigerant Type of oil Pressure in bar 2.21.4 On the crane The following warning signs can be found on the crane: Fig.

  • Page 48: Recovery And Towing

    If the machine has capsized, pull it up using wires/straps attached to the anti-skid chains, bogie cases or bunks. NOTICE If the engine has been submerged in water, an authorised service dealer or the Gremo AB service department must be contacted before the engine is started.
  • Page 49 Gremo 1250F/1450F Workshop manual 2 Safety regulations 2.22 Recovery and towing NOTICE In order for towing to take place, the brakes must first be disengaged, see 2.9.1 Manual release of parking brake, page 21, and the hydrostatic motor disassembled, see 2.22.1 Disassembling the hydrostatic motor, page 46.
  • Page 50 2 Safety regulations Gremo 1250F/1450F Workshop manual 2.22 Recovery and towing 2.22.1 Disassembling the hydrostatic motor WARNING Before starting the work of removing the hydrostatic motor, ensure that the machine's wheels are locked to prevent it from rolling. 1. Remove the screws holding the hydrostatic motor in place on the gearbox.

  • Page 51: Winch

    Gremo 1250F/1450F Workshop manual 2 Safety regulations 2.23 Winch 2.23 Winch DANGER The winch (optional equipment) is not approved for suspended loads. If a load is hoisted, e.g. by means of a pulley, it is dangerous to stand under the load.

  • Page 52: Bogie Tracks

    The A-weighted sound pressure level at the working location does not exceed 70 dB(A). The reading is based on measurements taken in conjunction with the type approval of Gremo 1050F/1450F. Meets requirements as per VVFS 2003:17 (max 80 dBA in cab).

  • Page 53: Service, Maintenance And Technical Information

    Gremo 1250F/1450F Workshop manual 3 Service, maintenance and technical information 3.1 Safety rules during service Service, maintenance and technical information 3.1 Safety rules during service NOTICE Read all signs and instructions on the machine and in the safety regulations in the Instruction Manual before you start servicing the machine.
  • Page 54 3 Service, maintenance and technical Gremo 1250F/1450F Workshop manual information 3.1 Safety rules during service WARNING During all work on the machine, remember the risk of slipping. You should always use a safety helmet, safety goggles, gloves, safety boots, breathing protection and other necessary protective equipment when required.

  • Page 55: Service And Maintenance

    Gremo 1250F/1450F Workshop manual 3 Service, maintenance and technical information 3.2 Service and maintenance 3.2 Service and maintenance Preventive maintenance measures are divided into time intervals: daily checks (every 8-10 operating hours), weekly checks every 50 operating hours and checks every 500, 1,000, 2,000 and 5,000 operating hours.

  • Page 56: Volume Specifications

    3 Service, maintenance and technical Gremo 1250F/1450F Workshop manual information 3.3 Volume specifications 3.3 Volume specifications Part Total volume Replacement volume Engine 16 litres (including filter replacement) Cooling system approx. 25 litres 20 litres Differential 12 litres x 2 Bogie cases...
  • Page 57 Gremo 1250F/1450F Workshop manual 3 Service, maintenance and technical information 3.4 Working with oils • Use protective gloves! Wash your hands before putting the gloves on. A protective cream on your hands will make it easier to clean them later.

  • Page 58: Oil, Requirement Specification

    3 Service, maintenance and technical Gremo 1250F/1450F Workshop manual information 3.5 Oil, requirement specification 3.5 Oil, requirement specification As the viscosity of lubricating oil is dependent on Temperature ºF temperature, the choice of viscosity grade (SAE grade) should be governed by the ambient temperature prevailing...

  • Page 59: Antifreeze, Requirement Specification

    Gremo 1250F/1450F Workshop manual 3 Service, maintenance and technical information 3.6 Antifreeze, requirement specification 3.6 Antifreeze, requirement specification Approved antifreeze is propylene glycol. NOTICE Do not mix ethylene glycol and propylene glycol. If you have the slightest doubt, pour out, clean and refill with a...

  • Page 60: Fuel, Requirement Specification

    3 Service, maintenance and technical Gremo 1250F/1450F Workshop manual information 3.7 Fuel, requirement specification 3.7 Fuel, requirement specification Engines should be run on commercial diesel fuel which meets the manufacturer's specifications, see sub- supplier's documentation for diesel engine. NOTICE It is important to only use fuel that meets the standards specified.

  • Page 61: Cleaning Of Safety Glass Windows

    Gremo 1250F/1450F Workshop manual 3 Service, maintenance and technical information 3.8 Cleaning of Safety Glass Windows 3.8 Cleaning of Safety Glass Windows 3.8.1 Cleaning Wash the window with lukewarm water and a mild neutral detergent. Use washing-up detergent or a similar soap- based detergent.

  • Page 62: Welding Repairs

    3 Service, maintenance and technical Gremo 1250F/1450F Workshop manual information 3.9 Welding Repairs 3.9 Welding Repairs NOTICE Prior to beginning any welding, read this chapter carefully! 3.9.1 Prior to welding, the following measures must be taken • Turn off the main power switch.
  • Page 63 Gremo 1250F/1450F Workshop manual 3 Service, maintenance and technical information 3.9 Welding Repairs NOTICE Remember that welding close to the fire extinguishing system’s detector coil may cause it to burn off and release the contents of the fire extinguisher tank! In order to ensure that the fire extinguisher tank is not accidentally deployed, fit the safety screw.

  • Page 64: Tyres - Air Pressure: Manufacturer's Recommendations

    If there is a change to a different version of tyre or wheel rim, a different tyre pressure may apply — contact Gremo. Danger! To avoid serious accidents, always follow directions for inflating tyres.
  • Page 65 500 kPa 2 20 100 kPa = 1 bar All tyres are from the factory (Gremo) and inflated to 450 kPa. The minimum pressure is approximately 50 kPa below the stated values and the maximum pressure is around 50 kPa above the stated values.
  • Page 66 3.10.1 Filling of fluid in forestry tyres The tyres can be filled with fluid to increase the machine’s stability and traction Gremo recommends filling 50% of the tyres’ volume. Maximum permitted is 75%. The fluid should consist of water. At temperatures below Fig.
  • Page 67 Calcium chloride increases the fluid’s density by up to 1.2 kg/litre in a 35% blend. Fluid-filled tyres are less elastic owing to their smaller air volume and are therefore more vulnerable to spot loads. Rolling resistance and the dynamic forces acting on the wheel rims and suspension components are also higher.

  • Page 69: Engine

    Gremo 1250F/1450F Workshop manual 4 Engine 4.1 Fuel system Engine For further information regarding the diesel engine and its system and for information that is missing from this manual, please refer to the sub-supplier's documentation from the engine manufacturer. 4.1 Fuel system...
  • Page 70 4 Engine Gremo 1250F/1450F Workshop manual 4.1 Fuel system Fuel tank Drain plug Diesel filling line Fuel level sensor Return valves (2 of) Condense filter CAUTION The high pressure fuel lines from the fuel pump and the fuel distributor on the engine contain fuel at very high pressure.

  • Page 71: Cooling System

    Gremo 1250F/1450F Workshop manual 4 Engine 4.2 Cooling system 4.2 Cooling system Fig. 46 Cooling system Coolant inlet Coolant, bypass Coolant pump impeller Coolant flow back to the water cooler Coolant flow lubricating oil cooler Bypass open Coolant flow through the cylinders...

  • Page 72: Intercooler

    4 Engine Gremo 1250F/1450F Workshop manual 4.3 Intercooler 4.3 Intercooler G0666 Fig. 47 Intercooler 4.4 Exhaust system with particulate filter Fig. 48 DPF particulate filter 4.4.1 General The engine installed in this machine is a 3B engine that complies with the requirements outlined in the 97/68/EG directive concerning exhaust emission limits.
  • Page 73 Gremo 1250F/1450F Workshop manual 4 Engine 4.4 Exhaust system with particulate filter The filter is made of a ceramic material with small channels with an irregular surface. By restricting the exhaust flow through the exhaust system the pressure is increased and the combustion temperature raised. First...

  • Page 74: Replacing Drive Belts

    4 Engine Gremo 1250F/1450F Workshop manual 4.5 Replacing drive belts regeneration process, which takes about 45 minutes. Park the machine by engaging the parking brake but keep the engine running. Do not operate the crane during an ongoing regeneration process. Start the process in Gre- Control by pressing F4.
  • Page 75 Gremo 1250F/1450F Workshop manual 4 Engine 4.5 Replacing drive belts 4.5.2 Replacing drive belt, alternator/AC compressor and water pump 1. Release the belt tensioner and lift off the drive belt. 2. Lift the belt tensioner, fit on the drive belt and let the tensioner return to its normal position.

  • Page 77: Transmission 1250F/1450F

    5 Transmission 1250F/1450F 5.1 Transmission, gearbox 5.1.1 General The gearbox in the Gremo 1250F/1450F is a mechanical transmission dropbox with two speed registers as standard. The gearbox has two gears and develops a variable torque that is easily controlled using the potentiometer in the left panel.

  • Page 78: Bogie Axles

    5 Transmission 1250F/1450F Gremo 1250F/1450F Workshop manual 5.2 Bogie axles 5.2 Bogie axles 5.2.1 Bogie axle, component position Fig. 54 Bogie axle, component position Differential housing drain Differential housing level plug Differential housing filling Differential housing dipstick Manual release of parking brake in the event of loss of pressure...
  • Page 79 Gremo 1250F/1450F Workshop manual 5 Transmission 1250F/1450F 5.2 Bogie axles Bogie housing, component position Fig. 55 Bogie housing Bogie housing drain plug Oil level for bogie housing Oil filling for bogie housing 5.2.2 Oil change Each bogie axle has three separate compartments containing oil, whose level must be changed individually.

  • Page 80: Parking Brake

    5 Transmission 1250F/1450F Gremo 1250F/1450F Workshop manual 5.3 Parking brake • Test-drive the machine for a short distance without any load and then recheck the oil level, topping up if necessary. • Check for leaks. Bogie housing • Switch off the engine and cut the main power supply.
  • Page 81 Gremo 1250F/1450F Workshop manual 5 Transmission 1250F/1450F 5.3 Parking brake 5.3.3 Parking brake, adjustment Fig. 58 Brake cylinder NOTICE When removing the brake cylinder, the parking brake must first be released, see 2.9.1 Manual release of parking brake, page 21 The machine’s parking brake can be adjusted individually...

  • Page 83: Electrical System

    Gremo 1250F/1450F Workshop manual 6 Electrical system 7.1 Structure of wiring diagram, wire numbering, revision state Electrical system 7.1 Structure of wiring diagram, wire numbering, revision state 1.1 Structure of wiring diagram The wiring diagrams are structured to simplify troubleshooting and service. The different wiring diagrams are divided into circuits with work lighting separate, heating and ventilation separate and so forth.

  • Page 84: Component Position Of Fuse Groups And Relays

    6 Electrical system Gremo 1250F/1450F Workshop manual 6.2 Component position of fuse groups and relays 6.2 Component position of fuse groups and relays Fig. 59 Position of distribution boxes Pos. Location Fuses Relay Right engine F51-F60, F99-F101 K30–31 compartment K60 (at rear)
  • Page 85 Gremo 1250F/1450F Workshop manual 6 Electrical system 6.2 Component position of fuse groups and relays 6.2.1 Fuse list, right engine compartment Fig. 60 Fuse list: right engine compartment Fuse Nominal current [A] Function Main fuse for fuses F12, F24, F46, F49, F50...
  • Page 86 6 Electrical system Gremo 1250F/1450F Workshop manual 6.2 Component position of fuse groups and relays Fuse Nominal current [A] Function Main fuse for power relay K31, starter motor F100 Main fuse for power relay K60, pre-heating F101 Main fuse for cab card 6.2.2 Fuse and relay list, distribution box in cab...
  • Page 87 Gremo 1250F/1450F Workshop manual 6 Electrical system 6.2 Component position of fuse groups and relays Fuse Nominal current Function Driving lights, main beam Driving lights, dipped beam Armrest panels, crane levers, digital keys for IQAN, seat position, pedals, lever control,...
  • Page 88 6 Electrical system Gremo 1250F/1450F Workshop manual 6.2 Component position of fuse groups and relays Fuse Nominal current Function Back-up, after ignition lock, tilt sensor Back-up, before ignition lock, PC-ECU socket Extra box A8:18, A14:16 Working lights roof, front Working lights roof, left side...

  • Page 89: Relay List

    Gremo 1250F/1450F Workshop manual 6 Electrical system 7.3 Relay list Fuse Nominal current Function Fire Heater setting, Climate system 7.3 Relay list 3.1 Table Relay Function Overload protection relay for ignition lock Overload protection relay for ignition lock Overload protection relay for...

  • Page 90: Connector List

    6 Electrical system Gremo 1250F/1450F Workshop manual 7.4 Connector list Relay Function Brake lights Back-up supply F47 Back-up supply F48 DASA Bogie lift tractor/carriage Bogie lift tractor/carriage Bogie lift tractor/carriage Bogie lift tractor/carriage Float mode Float mode Start barrier, relay...
  • Page 91 Gremo 1250F/1450F Workshop manual 6 Electrical system 7.4 Connector list Name Location/connection Connector type between Distribution box Cab card JPT 15 pin Distribution box Cab card – JPT 12 pin Driver’s seat cable harness Distribution box Cab card JPT 15 pin...
  • Page 92 6 Electrical system Gremo 1250F/1450F Workshop manual 7.4 Connector list Name Location/connection Connector type between Power circuit board Battery JPT 4 pin cutout Power circuit board Feeds G-H 8 pin Power circuit board Operation JPT 18 pin Distribution box Floor – front...
  • Page 93 Gremo 1250F/1450F Workshop manual 6 Electrical system 7.4 Connector list Name Location/connection Connector type between X30B IQAN-MD4 Deutsch 12 pin IQAN-XA2-A0 MT 42 pin IQAN-XA2-A0 MT 42 pin IQAN-XA2-A1 MT 42 pin IQAN-XA2-A2 MT 42 pin Driver’s seat cable harness –...
  • Page 94 6 Electrical system Gremo 1250F/1450F Workshop manual 7.4 Connector list Name Location/connection Connector type between Radio loudspeaker 8 pin Radio 8 pin Washer MNL 3 pin Trailer socket 7 pin X74A Wiper left FF 2 pin X74B Wiper left FF 3 pin...

  • Page 95: Hydraulic System

    Gremo 1250F/1450F Workshop manual 7 Hydraulic system 7.1 Hydraulic system, component position Hydraulic system 7.1 Hydraulic system, component position Fig. 62 Hydraulic system "Rexroth", component position Working hydraulics pump Hydraulic oil cooler Hydrostatic pump Hydraulic tank Valve bank working hydraulics...

  • Page 96: Breather Filter Hydraulic Oil Tank

    7 Hydraulic system Gremo 1250F/1450F Workshop manual 7.3 Breather filter hydraulic oil tank 7.3 Breather filter hydraulic oil tank 7.3.1 Breather filter, general There is a breather filter (H according to picture) on the hydraulic oil tank which protects the tank from dirt.

  • Page 97: Pressure Check Working Hydraulics

    Gremo 1250F/1450F Workshop manual 7 Hydraulic system 7.5 Pressure check working hydraulics 7.5 Pressure check working hydraulics Fig. 64 Pressure check working hydraulics with manometer PX Max. pressure PL Signal pressure 7.5.1 General The working hydraulics pressure can be checked in the...
  • Page 98 7 Hydraulic system Gremo 1250F/1450F Workshop manual 7.5 Pressure check working hydraulics Table 4 Hydraulic pressure check: normal pressure Measured value Normal Normal pressure: Crane pressure: Crane with single with double boom extension boom extension PX Max. 240 bar 245 bar...
  • Page 99 NOTICE Contact Gremo service if the max. pressure needs to be adjusted on a machine with hydraulic pumps of the "Rexroth" make. On a machine with hydraulic pumps of the "Linde"...
  • Page 100 NOTICE Contact Gremo service if the max. pressure needs to be adjusted on a machine with hydraulic pumps of the "Rexroth" make. On a machine with hydraulic pumps of the "Linde"...

  • Page 101: Pressure Check, Transmission

    40°C. The feed pressure to the transmission pump is checked in GreControl and it should be between: 25 and 30 bar, if an incorrect feed pressure is noted, contact Gremo service.

  • Page 103: Pressurised Air System

    Gremo 1250F/1450F Workshop manual 8 Pressurised air system 8.1 General Pressurised air system 8.1 General The machine is equipped with a pressurised air system that provides air to the operator's seat, and a socket where, for example, the compressed air gun can be connected.
  • Page 104 8 Pressurised air system Gremo 1250F/1450F Workshop manual 8.2 Pressurised air diagram Air filter Pneumatic operator's seat Compressor Quick connection Pressure regulator Accumulator tank...

  • Page 105: Other Equipment And Optional Equipment

    Gremo 1250F/1450F Workshop manual 9 Other equipment and optional equipment 9.1 Fire extinguishing system Other equipment and optional equipment 9.1 Fire extinguishing system 9.1.1 How the Fogmaker fire extinguishing system works 1. In the event of a fire in the engine compartment, the detector coil will burn off.
  • Page 106 9 Other equipment and optional equipment Gremo 1250F/1450F Workshop manual 9.1 Fire extinguishing system alarm signal (diode + buzzer in the alarm panel (2) and a flashing "WARNING" lamp (7) in the cab roof). • Stop the machine’s engine with the emergency stop (5 or 6) or by switching off the ignition (1).
  • Page 107 Gremo 1250F/1450F Workshop manual 9 Other equipment and optional equipment 9.1 Fire extinguishing system 9.1.4 Actions after the fire • Check that the fire has been properly extinguished. Use additional extinguishers if necessary. • Disable main fuse F49 to switch off the alarm.

  • Page 109: Wiring Diagram

    Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply 10 Wiring diagram 10.1 Power supply...
  • Page 111 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply Fig. 75 Power supply, main feeds...
  • Page 113 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply Fig. 76 Power supply Cab card...
  • Page 115 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply 54 000 54 000 01 001 BLAD 1. 54 004 28 000 BLAD 0. 54 000 09 971 CABIN 54 000 X30A 09 960 BOARD 54 013 IQAN 54 015...
  • Page 117 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply Fig. 78 Driving lights...
  • Page 119 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply RATT OMKOPPLARE VARNINGSBLINKERS S 533193 LED 12-135ARME 12 000 i-LS 16-ILS.02 17 026 BRUN = POSLJUS 3. 17 000 SVART =JORD 17 002 RÖD = STOPP 2. 17 003 BLÅ = BLINKERS LAMPA 17 001 GUL = BLINKERS 1.
  • Page 121 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply Fig. 80 Working lights...
  • Page 123 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply Fig. 81 Windshield wipers...
  • Page 125 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply Fig. 82 Windshield wipers with side wipers...
  • Page 127 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply VINDRUTETORKARE VÄNSTER SIDA VINDRUTETORKARE HÖGER SIDA SIDOTORKARE OCH SPOLNING 120509 S 533232 S 533232 11 710 16 000 TAS BORT OCH ISOLERAS 11 710 11 710 FLYTTAS FRÅN 6. TILL 2.
  • Page 129 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply Fig. 84 Heating, ventilation and AC Lokab...
  • Page 131 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply Fig. 85 Cab and Mech. lighting, Chair heater, tilt and chair brake, Rotation light...
  • Page 133 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply MATVÄRMARE MATVÄRMARE S 533025 20 002 20 002 20 000 56 000 BLAD 14. 23 000 22 001 22 001 CABIN RADIO A12:4 BOARD A12:8 A12:2 A12:5 A12:1 22 001 BLAD 1.
  • Page 135 160119 61404 Skala KRETSSCHEMA Ej skalenlig Cummins QSB 120509 1450F HASTIGHET OCH Ritn.-nr MED PCB VARVTALSREGLERING BLAD 12. Ändring och/eller medd.-nr Sign. Datum Inf-rd Fig. 87 Speed and engine speed regulation, applies to Gremo 1450F machine number up to 81405...
  • Page 137 KRETSSCHEMA Ej skalenlig Cummins QSB 120509 1450F HASTIGHET OCH Ritn.-nr VARVTALSREGLERING MED PCB BLAD 12. Ändring och/eller medd.-nr Datum Inf-rd Sign. Fig. 88 Speed and engine speed regulation, applies to Gremo 1450F with Caldaro pedals machine number up to 81406...
  • Page 139 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply MV.LÅS URKOPPLING IQAN IQAN 08 515 08 515 XA2-A0 XA2-A1 FRAM 10 205 10 205 08 516 08 516 08 515 BACK 08 517 08 517 08 515 21 501...
  • Page 141 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply AIR VALVE OIL FILLING TANK BOARD SW42 55 001 611163 S 533215 1 Amp X1:16 BLAD 1. IQAN 1K ohm 5% 1W 56 002 56 002 XA2-A5 1K ohm 5% 1W...
  • Page 143 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply SPAKSTYRNING S 533025 08 310 08 000 CABIN BOARD A17:9 08 000 BLAD 1. A18:3 08 310 SPAKSTYRNING AKTIV 08 310 08 310 A16:2 IQAN 08 310 08 310 A8:13...
  • Page 145 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply ALLHJULS ALLHJULSVAKT DRIFT 04 003 04 000 04 000 09 723 09 723 IQAN XA2-A5 04 003 04 003 04 003 DIFFSPÄRR FRAM 09 726 09 726 DIFFSPÄRR 09 727...
  • Page 147 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply 08 514 A9:13 08 514 CABIN IQAN 08 513 A9:16 08 513 BOARD XA2-A2 08 511 A9:10 08 511 08 510 A9:17 08 510 A8.4 08 509 BOGGILYFT VÄNSTER 08 509...
  • Page 149 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply 10 522 10 522 CABIN IQAN KRAN SVÄNG BOARD 10 523 10 523 10 522 XA2-A0 HÖGER 10 524 10 524 10 522 KRAN SVÄNG VÄNSTER 10 525 10 525...
  • Page 151 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply A6:1 08 000 08 000 08 000 08 000 CABIN VÄNSTER JORD JORD BOARD PALETT A6:11 09 951 09 951 09 951 09 951 BLAD 1. A6:12 09 940 09 940...
  • Page 153 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply A1:7 08 115 08 115 A4:3 08 012 08 012 IQAN 08 117 08 117 A4:12 08 011 08 011 CABIN XA2-A5 08 118 08 118 BOARD 08 144 08 144...
  • Page 155 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply EJ SIGNAL IN PÅ NR:6 SVART TÄNDER GUL DIOD (FEL) SLÄCKMEDELSBEHÅLLARE EJ SIGNAL IN PÅ NR:2 GUL TÄNDER RÖD DIOD (LARM LJUS, LJUD) CABIN TRYCKBRYTARE (NO om P<85BAR) BOARD SLUTNING MELLAN GRÅ OCH BLÅ VID BRAND KAN ANVÄNDAS TILL MOTORAVSTÄNING...
  • Page 157 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply CABIN BOARD K3 TÄNDNING 00 004 A14:13 41 000 41 000 41 000 A14:14 BLAD 1. 42 000 A14:7 42 000 A14:8 42 000 K2 TÄNDNING 00 004 A14:3 43 000...
  • Page 159 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply CABIN BOARD A6:11 09 951 BLAD 19. A6:12 09 940 BLAD 19. X30A DISPLAY A4:13 09 951 CAN-H 09 951 A4:11 09 940 CAN-L 09 940 A15:9 09 951 A15:8...
  • Page 161 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply 03 001 03 011 24 001 BLAD 9. 03 000 09 000 24 000 Styrenhet ECC 8002414 J1-1 Blå (3A) J1-11 Röd (10mA) J1-2 Gul (10mA) J1-12 Svart (3A) Aggregatlåda...
  • Page 163 Ersatt av 120509 Skala KRETSSCHEMA Ej skalenlig Cummins QSB 120509 1450F BROMSAR OCH Ritn.-nr MED PCB FLÄKTSTYRNING BLAD 25. Ändring och/eller medd.-nr Sign. Datum Inf-rd Fig. 101 Brakes and fan control, applies to Gremo 1450F machine number up to 81405...
  • Page 165 Skala KRETSSCHEMA Ej skalenlig Cummins QSB 120509 1450F BROMSAR OCH Ritn.-nr MED PCB FLÄKTSTYRNING BLAD 25. Ändring och/eller medd.-nr Sign. Datum Inf-rd Fig. 102 Speed and fan control, applies to Gremo 1450F with Caldaro pedals machine number up to 81406...
  • Page 167 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply Can-kort Can-kort K4-1 K2-1 TGT 1 Extra TGT 10 Intervalltorkare K4-2 K2-2 TGT 2 Extra TGT 11 Grind upp K4-3 K2-3 TGT 3 Vinsch ut TGT 12 Grind ner K4-4...
  • Page 169 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply Can-kort Can-kort K5-1 K2-1 TGT 13 Krankörning framåt TGT 19 Parkeringsbroms K5-2 K2-2 TGT 14 Midjelås TGT 20 Stolsbroms K5-3 K2-3 TGT 15 Vagnsdrift TGT 21 Farthållare K5-8 K2-8 + 24V...
  • Page 171 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply Mod.-nr Ämne Det.-nr Ant. Benämning Material Anm. Dimension Ant. Material Mod.-nr Ämne Dimension Anm. EP2006 Knappsats kmpl Gremo skotare v2 S6908-09 Konstr. Ritad Dat. Status Stand. enl. Godk. Dat. Ersätter...
  • Page 173 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply Fig. 106 Active bogie...
  • Page 175 Gremo 1250F/1450F Workshop manual 10 Wiring diagram 10.1 Power supply Fig. 107 Active bogie...

  • Page 177: Hydraulic Diagram

    Gremo 1250F/1450F Workshop manual 11 Hydraulic diagram 11.1 Hydraulic diagram list 11 Hydraulic diagram 11.1 Hydraulic diagram list Sheet Function Hydraulic diagram 1450F, complete Crane functions Steering and Gate Wheel brakes Working pump and LS Activation Bogie lift and mid-section stabilisation...
  • Page 179 Gremo 1250F/1450F Workshop manual 11 Hydraulic diagram 11.1 Hydraulic diagram list Approved 120411 Hydraulikschema 1450F GrArtNo Fig. 108 Hydraulic diagram 1450F 4Gen Cranab with options...
  • Page 181 Gremo 1250F/1450F Workshop manual 11 Hydraulic diagram 11.1 Hydraulic diagram list Approved 120411 Kranfunktioner 1450F GrArtNo Fig. 109 Crane unit...
  • Page 183 Gremo 1250F/1450F Workshop manual 11 Hydraulic diagram 11.1 Hydraulic diagram list Approved 120411 Styrning & Grind 1450F GrArtNo Fig. 110 Steering and Gate...
  • Page 185 Gremo 1250F/1450F Workshop manual 11 Hydraulic diagram 11.1 Hydraulic diagram list Approved 120411 Färdbromsreglering 1450F GrArtNo Fig. 111 Wheel brakes...
  • Page 187 Gremo 1250F/1450F Workshop manual 11 Hydraulic diagram 11.1 Hydraulic diagram list Approved 120411 Arbetspump & LS Aktivering 1450F GrArtNo Fig. 112 Working pump...
  • Page 189 Gremo 1250F/1450F Workshop manual 11 Hydraulic diagram 11.1 Hydraulic diagram list Approved 120411 Boggilyft & Midjestabilisering 1450F GrArtNo Fig. 113 Bogie and Mid-section stabilisation...
  • Page 191 Gremo 1250F/1450F Workshop manual 11 Hydraulic diagram 11.1 Hydraulic diagram list Aktiv Boggie Fram & Midjestab Approved 120411 1450F GrArtNo Fig. 114 Active bogie front and mid-section...
  • Page 193 Gremo 1250F/1450F Workshop manual 11 Hydraulic diagram 11.1 Hydraulic diagram list Approved 120411 Hydrostatpump 1450F GrArtNo Fig. 115 Hydrostatic pump...
  • Page 195 Gremo 1250F/1450F Workshop manual 11 Hydraulic diagram 11.1 Hydraulic diagram list Approved 120411 Hydrostatmotorer 1450F GrArtNo Fig. 116 Hydrostatic motors...
  • Page 197 Gremo 1250F/1450F Workshop manual 11 Hydraulic diagram 11.1 Hydraulic diagram list Approved 120411 Fläkt, Retur, Filtrering & Påfyllning 1450F GrArtNo Fig. 117 Fan, Return, Filtration and Filling.
  • Page 199 Gremo 1250F/1450F Workshop manual 11 Hydraulic diagram 11.1 Hydraulic diagram list Approved 120411 Stege,Parkeringsbroms,Diffspärr & Vangsdrift 1450F GrArtNo Fig. 118 Ladder Parking brake Diff. lock, Carriage drive...
  • Page 201 Gremo 1250F/1450F Workshop manual 11 Hydraulic diagram 11.1 Hydraulic diagram list Approved 120411 Elhydraulisk Hyttipp & Krandämp 1450F GrArtNo Fig. 119 Electrical hydraulic cab tilt and crane damper...
  • Page 203 Gremo 1250F/1450F Workshop manual 11 Hydraulic diagram 11.1 Hydraulic diagram list Planeringsblad( Tillval) Approved 120411 1450F GrArtNo Fig. 120 Dozer blade...
  • Page 205 Gremo 1250F/1450F Workshop manual 11 Hydraulic diagram 11.1 Hydraulic diagram list Aktiv Boggie Vagn Approved 120411 1450F GrArtNo Fig. 121 Active bogie carriage...
  • Page 206 last page ©2019...

This manual is also suitable for:

1450f

Table of Contents
