Summary of Contents for STOKVIS ENERGY SYSTEMS ECONOPLATE E3 Series
Page 1
ECONOPLATE E3 SERIES HOT WATER SERVICE PACKAGED PLATE HEAT EXCHANGER INSTALLATION OPERATION & MAINTENANCE DOCUMENTATION STOKVIS ENERGY SYSTEMS 96R WALTON ROAD EAST MOLESEY SURREY KT8 0DL TEL: 08707 707 747 FAX: 08707 707 767 E-MAIL:info@stokvisboilers.com WEBSITE:www.stokvisboilers.com E3 SERIESIO&M2007...
Page 3
Plate Heat Exchangers have low water content and low thermal inertia making them ideal for use in systems with varying heat loads. The Econoplate E3 series units are supplied with fast acting 3 port motorised control valves fitted to the primary circuit.
Page 15
PERFORMANCE GUIDE FOR E3C RANGE(PRIMARY TEMPERATURE 82 C , COLD FEED 10 ECONOPLATE MODEL E3C22 E3C26 E3C30 E3C34 E3C38 E3C42 E3C46 E3C50 E3C54 E3C58 E3C62 E3C66 E3C70 SECONDARY FLOW RATE 163.2 207.6 228.6 244.8 259.8 286.8 295.8 307.8 317.4 325.2 332.4 AT 60 C l/min...
Page 16
The “Typical installation schematic” shows an ideal example. TYPICAL INSTALLATION OF ECONOPLATE E3 SERIES PLATE HEAT EXCHANGER ON A COMBINED HEATING AND HOT WATER SYSTEM ( SHOWN WITH HWS PRIORITY).
INSTANTANEOUS HOT WATER APPLICATIONS. When water is being drawn directly from the Econoplate into the distribution system to the taps this is termed instantaneous hot water generation. The cold water feed connection is made into the bottom horizontal bronze connection on the rear of the Econoplate.
Page 18
SECONDARY INSTALLATION DETAILS. Instantaneous Application. LEGEND SAFETY VALVE DOUBLE NRV SINGLE NRV HWS DRAW OFF ISOLATION VALVE PRESSURE REG VALVE AUTO AIR VALVE DRAIN VALVE PLATE HEAT EXCHANGER EXPANSION VESSEL RECIRC PUMP MAINTENANCE LOCKSHIELD VALVE (PROHIBITED BY U.K. REGULATIONS) COLD WATER SERVICE N.B.
ELECTRICAL DETAILS FOR +1R MODELS. E3A100 Range: 240V - Single phase - 375 Watt E3A300 Range: 240V - Single phase - 595 Watt E3C Range 415V - 3 phase - 915 Watt E3C Range 240V - Single phase - 915 Watt When a transfer pump is fitted the power consumption will be greater.
OPERATION. Prior to switching the Econoplate on it must be ensured that the unit is filled with water and that all pipework and pumps are vented. Once this is complete and the unit is on, the Econoplate Controller should be set up as described in the Econotrol 2100 Controller Manual to suit the particular requirements of the client.
Page 21
AVM124 actuators also have a switch coding for valve speed inside the actuator cover, which can be seen through the clear lid, and these should be set as below. There is also a single green LED just below the switch box which gives indication of the following functions of the actuator.
Page 22
AVM234 actuators also have switch coding for the actuator/valve speed and characteristics (which are on the inside the actuator terminal box) should be as below. AVM234 actuators have the following indicators on the outside of the actuator assembly whilst in operation.
MAINTENANCE. If the installation is set up as per the above instructions, and if the pre-set factory values are unchanged, the Stokvis Econoplate Unit should not need dismantling for service for many years. Any clogging, may be detected as follows: - A high pressure drop between inlet and outlet of the secondary hot water circuit.
Page 24
A visual check on the correct assembly can be made by looking at the edge of the plates. A pattern resembling a honeycomb should always be seen. Plates can be identified in the following way. G30 all have gaskets on one side of each plate facing the fixed chassis. G30 have octagonal gaskets around the ports and the corner of the plate is cropped at 45 GL13 have round gaskets around the ports and have the corner of the plate is...
FAULT FINDING. E SERIES PLATE HEAT EXCHANGER FLUCTUATING TEMPERATURES AT OUTLET. Check that the secondary pump is operating correctly and that good circulation exists - feel the temperature of the return pipe, if it is cool then there is no circulation. Check that a non-return valve is fitted on the HWS return and that it is not letting by and so allowing the cold feed to pass up the HWS return - feel for a cool return pipe.
Page 26
Check to ensure correct connection of valve and actuator as described previously in the Operation section. Check that the valve motor is operating - raise and lower the set point on the controller and observe. - If the motor does not work, perform the procedure above for the temporary hot water supply.
Page 27
Ensure that there is an electrical supply to a primary pump and link the start/stop terminals for that pump if not already made. Reduce the boiler flow temperature to a maximum of 65°C to prevent excess secondary temperatures. Set the high temperature alarm to automatic - refer to “Econotrol 2100 manual” for procedure.
PARTS LIST. Description E3A PARTS LIST. Description Econotrol 2100 controller exc. Enclosure Temperature Sensor 1/8” BSP 65mm 3 port valve Sauter type BUE040F304 for E3A 3 port valve Sauter type BUE050F300 for E3C only Sauter actuator type AVM124F130 for BUE valve E3A100 Primary Pump Motor UPS40-80 1 Phase E3A300 Primary Pump Motor UPS40-120/2 1 Phase E3A300 Primary Pump Terminal Box 96405865...
Page 29
Guide pins TIL/M/033/A 150mm Guide pins TIL/M/034/A 250mm Guide pins TIL/M/035/A 350mm M20 Hex Set Screws x 180mm M20 Hex Set Screws x 280mm M20 Hex Set Screws x 380mm HEAT EXCHANGER PLATES G30H EPDM End Blanking Plate G30H EPDM Intermediate Plate G30H EPDM 4 Hole First Plate GL13H First 4 Hole Plate GL13H LH Intermediate Plate...
Page 30
STOKVIS ENERGY SYSTEMS 96R WALTON ROAD EAST MOLESEY SURREY KT8 0DL TEL: 08707 707 747 FAX: 08707 707 767 E-MAIL:info@stokvisboilers.com WEBSITE:www.stokvisboilers.com...
