Summary of Contents for Geovent Power Box III
- Page 1 I N S T R U C T I O N M A N U A L P O W E R B O X I l I on/off control of airflow dampers and fans www.geovent.com Version 1.0 26.01.16...
- Page 2 1.0 Installation of Powerbox FV5OX for on/ After start: off control of airflow dampers • Connect 230V power supply to terminal L and N as • The installation is controlled by activating the shown in diagram and photo FV40X. This is done by either pressing the switch on the front cover or by short-circuiting terminal 8 •...
- Page 3 230VAC Supply L N PE Power Coil A Damper motor 24VDC Power Coil B To CTS outlet Power Coil C To ON/OFF switch Power Coil A Trim Power Coil B Trim Power Coil C Trim Timer for Off function TIME Maintenance: •...
- Page 4 HOVEDGADEN 86 • DK-8831 LØGSTRUP (+45) 8664 2211 • salg@geovent.dk...
