Digitech Audio Visual CW-2864 User Manual

Max. VESA 400X500
20kg(44lbs) max.
23" - 55"(58-140cm)
CW-2864
The wall structure must be capable of supporting at
least a maximum weight of 20kg (44lbs) for 23"-55"
televisions. If not, the wall must be reinforced. Proper
installation procedure by a qualified service technician,
as outlined in the installation instructions, must be
adhered to. Failure to do so could result in serious
personal injury, or even death.
Safety measures must be practiced at all times during
the installation of this product. Use proper safety gear
and tools for the installation procedure to prevent
personal injury.
Prior to the installation of this product, the installation
instructions should be read and
understood. The installation instructions must be read
to prevent personal injury and property damage. Keep
these installation instructions in an easily accessible
location for future reference.
A secure structure must support the weight or load
of the display, When mounting to a wall that
contains wooden studs, dead center of the wooden
stud must be confirmed prior to installation.
Do not install on a structure that is prone to
vibration, movement or chance of impact. Failure
to do so could result in damage to the display
and/or damage to the mounting surface.
Do not install near heater, fireplace, direct sunlight,
air conditioning or any other source of direct heat
energy. Failure to do so may result in damage to
the display and could increase the risk of fire.
At least two qualified people should perform the
installation procedure. Injury and/or damage can
result from dropping or mishandling the display.
Recommended mounting surfaces: wooden studs
and solid-flat concrete. If the mount is to be
installed on any surface other than wooden studs,
use suitable hardware (which is commercially
available).
completely
A
B
C
D
E
F
?
18X8X20(x4)
