User information
EWE-FLEXORIPP Water Meter Pit
Edition 01/2017
Verpackung
•
Die einzelnen Armaturen sind entsprechend den zu erwartenden Transportbedingun-
...thoroughly tried and tested!
gen verpackt. Für die Verpackung wurden umweltfreundliche Materialien verwendet.
Die Verpackung soll die einzelnen Bauteile bis zur Montage vor Transportschäden,
Korrosion und anderen Beschädigungen schützen. Entfernen Sie die Verpackung erst
kurz vor der Montage der Armatur.
EWE-FLEXORIPP
Entsorgung
•
Trennen Sie die vorhandenen Rohstoffe nach Entsorgungstyp und Werkstoff. Die Ent-
sorgung der Rohstoffe muss nach den jeweils gültigen gesetzlichen Bestimmungen
Water Meter Pit
und örtlichen Vorschriften erfolgen. Führen Sie wiederverwertbare Verpackungsma-
terialien dem Recycling zu.
Verwendung von Abkürzungen:
WZ: Wasserzähler
Art.: Artikelnummer
KMR: Kegelmembran-Rückflussverhinderer WZA: Wasserzähler-Anlage
Current information at: www.ewe-armaturen.de
Installation and Operating Instructions
Qn: Nenngröße Wasserzähler
PN: Nenndruck
www.ewe-armaturen.de
1
Advertisement
Table of Contents
Summary of Contents for EWE EWE-FLEXORIPP
- Page 1 User information EWE-FLEXORIPP Water Meter Pit Edition 01/2017 Verpackung • Die einzelnen Armaturen sind entsprechend den zu erwartenden Transportbedingun- …thoroughly tried and tested! gen verpackt. Für die Verpackung wurden umweltfreundliche Materialien verwendet. Die Verpackung soll die einzelnen Bauteile bis zur Montage vor Transportschäden, Korrosion und anderen Beschädigungen schützen. Entfernen Sie die Verpackung erst kurz vor der Montage der Armatur. EWE-FLEXORIPP Entsorgung • Trennen Sie die vorhandenen Rohstoffe nach Entsorgungstyp und Werkstoff. Die Ent- sorgung der Rohstoffe muss nach den jeweils gültigen gesetzlichen Bestimmungen Water Meter Pit und örtlichen Vorschriften erfolgen. Führen Sie wiederverwertbare Verpackungsma- terialien dem Recycling zu. Installation and Operating Instructions Verwendung von Abkürzungen: WZ: Wasserzähler Qn: Nenngröße Wasserzähler Art.: Artikelnummer...
-
Page 2: General Information
• The current version of these installation and operating instructions can be found on our website: www.ewe-armaturen.de. • Check the delivery for transport damage and to make sure it is complete immedia- tely after receiving it. • Keep the user information available should any questions occur. • Only trained and qualified personnel are permitted to install, operate or maintain the fittings and valves. • Our team is happy to provide you with more information by telephone during business hours. Manufacturer‘s address Wilhelm EWE GmbH & Co. KG Volkmaroder Straße 19 D- 38104 Braunschweig Phone: +49 531 37005-0 Fax: +49 531 37005-55 E-mail: info@ewe-armaturen.de General safety instructions CAUTION • The necessary activities must be carried out in accordance with the statutory regulations, accident prevention regulations and applicable standards including the recognised rules of engineering. • Technical and unauthorised modifications to the product are not permitted. The product may only be used for its intended purpose. Disclaimer •... - Page 3 User information EWE-FLEXORIPP Water Meter Pit Edition 01/2017 Packaging • The individual fittings and valves are packed in accordance with the anticipated transport conditions. Only environmentally friendly materials have been used for the packaging. The packaging should protect the individual components from transport damage, corrosion and other damage until they are installed. Remove the packaging just before the fitting is installed. Disposal • Separate the existing raw materials according to disposal type and material. Raw materials must be disposed of in accordance with the applicable statutory provisions and local regulations. Send recyclable packaging materials for recycling. Explanation of the symbols, warning symbols and signal words used Symbol Description General danger area (danger/warning/caution) DANGER: Hazard with a high degree of risk which, if not avoided, will result in death or serious injury. WARNING: Hazard with an average degree of risk which, if not avoided, may result in death or serious injury. CAUTION: Hazard with a low degree of risk which, if not avoided, may result in minor or moderate injury.
-
Page 4: Information About The Product
User information EWE-FLEXORIPP Water Meter Pit Edition 01/2017 Information about the product Scope This user information applies to EWE-FLEXORIPP water meter pits, article number: 0396XXX, consisting of a: – • Pit body, water meter system with flexible hoses and lifting device, pit ducts and insulating cover. Pit covers must be ordered separately. EWE-FLEXORIPP-pit covers (not supplied with the pit!): – • FLEXORIPP cover cap, max. 200 KG, article number 0396000 • FLEXORIPP A15 pit cover, consisting of a cover frame with cover seal, cover and locking screws, article number 0396001 • FLEXORIPP B125 pit cover, consisting of a cover frame with cover seal, cover and locking screws, article number 0396002 Other applicable documents • The operating instructions of the respective contracting body or contracting company must be followed • DVGW (German Technical and Scientific Association for Gas and Water) and statutory accident insurance institution regulations In particular: •... - Page 5 User information EWE-FLEXORIPP Water Meter Pit Edition 01/2017 • DIN 18196 ”Earthworks and foundations - Soil classification for civil engineering purposes” • KTW (plastics in drinking water) and elastomer guidelines issued by the Federal Environ- ment Agency • List of ”Metallic materials suitable for contact with drinking water” issued by the Federal Environment Agency • DVGW worksheet W 270 ”Propagation of microorganisms on materials used in drinking water systems” • DVGW worksheet W 400 ”Technical rules for water distribution plants” • DVGW worksheet W 543 ”Pressure-resistant hose pipes and compensators” • DVGW worksheet W 570 ”Valves for drinking water installation” • RSA 95 ”Guidelines for safeguarding work sites on roads” Areas of use/medium • Cold drinking water in accordance with DIN 2000 Permissible operating pressure of components (PFA) • PN 10 Material/dimensions/performance 1.5.1 Pit body...
- Page 6 User information EWE-FLEXORIPP Water Meter Pit Edition 01/2017 Drawing: Dimensions of EWE-FLEXORIPP water meter pit External Ø with A15/ B125 pit cover installed External Ø without pit Internal Ø Largest external Ø See table on page 5 for detailed information about these dimensions! Current information at: www.ewe-armaturen.de...
- Page 7 User information EWE-FLEXORIPP Water Meter Pit Edition 01/2017 1.5.3 Water meter systems and hoses Materials: • Bracket made of A2 stainless steel • Water meter screw fittings made of lead-free silicon brass in accordance with the list of “Metallic materials suitable for contact with drinking water”. • Plastics and elastomers in accordance with the KTW and elastomer guidelines issued by the Federal Environment Agency and the DVGW worksheet W270. • Valves made of lead-free silicon brass in accordance with the list of “Metallic materi- als suitable for contact with drinking water”. • Hoses made of silicone with braiding made of A2 stainless steel and fabric covering made of thermoplastic material • Pressure regulator made of stainless steel Versions: • • Ball valve-ball valve Ball valve-pressure regulator-ball valve • • Ball valve-CAC-valve Ball valve-pressure regulator-CAC-valve •...
- Page 8 User information EWE-FLEXORIPP Water Meter Pit Edition 01/2017 Water meter system variants – water meter dimensions: Water meter dimensions MID (Measurement Instrument Directive) Thread T (d ) × Length mm (l 2 ) [m³/h] [m³/h] 3/4" × 165* 3/4" × 165* 1" × 190 2.5 or 4 1" × 190 2.5 or 4 1" × 190 2.5 or 4 1 1 " × 175 4 or 10 1 1 " × 175...
- Page 9 User information EWE-FLEXORIPP Water Meter Pit Edition 01/2017 The water meter pit system is factory fitted with a PE adapter. The PE adapter is only used as a substitute for the water meter and is not suitable for operation. Information about the installation site The water meter pit should be located at an elevated position on the site or protrude a few centimetres above ground level if possible. The choice of pit size should be compatible with the frost-free installation depth of the pipe and is the sole responsibility of the user. The water meter pit demonstrates favourable behaviour against buoyancy because of its external shape. An essential requirement is that it is installed properly with gravel backfill and compaction in layers. The pit body has a waterproof design and the connection to the cover is impermeable to surface water. A soil engineering specialist should be consulted in areas where there is a risk of temporary flooding. Should there be flat-lying supply pipes (so-called summer pipes) downstream of the water meter pit, which have to be emptied before the start of the frost season, we recommend installing a special fitting in the pipe routing between the pit exit and the tapping point, e.g. an EWE garden valve in combination with an installation set. An EWE garden hydrant provides the same convenience in the case of an outdoor tapping point. The emptying of the downstream supply pipe in the pit body requires special care from a hygienic point of view. The water from the pipe must be pumped away immediately during the emptying phase and then the drain opening must be closed to prevent any possible contamination in the pipe network. Excavation and backfilling The water meter pit is delivered ready for installation and can be used in prepared ditches. The work required is the responsibility of the user.
-
Page 10: Installation
User information EWE-FLEXORIPP Water Meter Pit Edition 01/2017 Installation • Level out and compact the bottom of the trench evenly throughout. • Position the pit so that it is vertical and level. • Arrange for the foundations for the footprint of the pit to be dug in accordance with load class A15 or B125. • Arrow - Observe the flow direction when aligning the pit. • Flush the pipe before establishing the connections. • Establish connections between the connection sleeves of the pit and the pipe. • Observe the guidelines of the connection fittings manufacturer. Perform a leak test in accordance with the regulations. • Backfill the trench in the area of the water meter pit. • Support the connection pipes (inlet and outlet side) before the compac- ting. - Page 11 User information EWE-FLEXORIPP Water Meter Pit Edition 01/2017 • Install the water meter in accordance with section 4 “Maintenance and servicing”. • Install the pit cover in accordance with section 5 “Pit covers”. The pit may not be operated without a pit cover in accordance with section 5. The insulating cover is non load-bearing. The installation site and pit opening must be secured against unintentional CAUTION access during the installation period. Current information at: www.ewe-armaturen.de...
- Page 12 User information EWE-FLEXORIPP Water Meter Pit Edition 01/2017 Shortening the pit pipe The cylindrical, rib-shaped part of the pit can be shortened in 2.5 cm sections. At least 3 ribs need to remain to mount the cover frame and its seal. Frost protection through the planned installation depth must be taken into consideration. If shortened by more than 20 cm, the length of the lifting line must be reduced or the latter must be replaced. • Remove the cover if one is fitted. • Loosen and also remove the cover frame (if applicable). • Remove the cover frame seal (if applicable). • Remove the insulating cover. Current information at: www.ewe-armaturen.de...
-
Page 13: Operation And Use
User information EWE-FLEXORIPP Water Meter Pit Edition 01/2017 • Take the measurement to the surface. • When using the cover cap, makesure that the pit together with the cap prot- rude approx. 7 cm above the ground. • When using the A15/B125 pit cover, add its height of 7 cm from the first rib. • The pit pipe can be shortened in sections of 2.5 cm at the deepest point of the rib using a suitable tool (e.g. EWE- FLEXORIPP cutter). • A minimum of three ribs must remain. • Deburr the cut edge. • Deburr the first rib at its deepest point. • Install the pit cover in accordance with section 5 “Pit covers”. Operation and use A visual inspection of the water meter pit, the water meter pit fittings and the entire system must be made prior to putting it into operation. Functional check and leak test The entire system must be checked to ensure that it is working and has no leaks. -
Page 14: Maintenance And Servicing
User information EWE-FLEXORIPP Water Meter Pit Edition 01/2017 Pit security The pit must not be operated without a pit cover in accordance with section 5. The insulating cover is non load-bearing. The installation site and pit opening must be secured against unintentional CAUTION access during the installation period and during operation of the pit. A15/B125 pit covers must be locked with the enclosed screws. Frost protection The insulating cover fastened to the lifting line must be used. Frost protection must be ensured through the local installation, in particular by the right choice of installation depth. It is therefore the sole responsibility of the planning and contracting body to ensure the frost-free conditions in the pipe and pit. Maintenance and servicing The (ball) shut-off valves in the water meter systems are generally defined as maintenance fittings; they should therefore be actuated slowly in the case of maintenance (during opening and closing) when the tapping devices are closed. The fittings must be opened as far as they will go, i.e. by setting them to the fully open position. It is not permitted to restrict them. It is recommended that the shut-off valves on the water meter system are normally actuated at least once a year to ensure that they work and move freely. As a general rule, an annual functional check should be performed on the non-return flow valve. It is not necessary for plug-in non-return flow valves to be inspected annual- ly. These fittings must be changed with the regular replacement of the water meter, but within 10 years at the latest (EN806). The non-return flow valves are wear parts. A functional check can be carried out on models with a control screw that are already installed. - Page 15 User information EWE-FLEXORIPP Water Meter Pit Edition 01/2017 Meter reading and meter replacement • Remove the cover and insulating cover. • Pull out the water meter pit system with the aid of the lifting line. • Place the water meter pit system next to the pit opening. • Alternatively, the pit system can be fixed with the plinth on the pit frame. • Install and replace the meter taking account of the installation instructions of the water meter manufacturer. • Lower the water meter pit system slowly on the lifting line. • Close the insulating cover. • Fit the pit cover. Current information at: www.ewe-armaturen.de...
- Page 16 User information EWE-FLEXORIPP Water Meter Pit Edition 01/2017 Pit covers • FLEXORIPP cover cap - 200 kg • FLEXORIPP A15 pit cover, EN124 • FLEXORIPP B125 pit cover, EN124 Material/dimensions/performance Material: • Cover cap made of lamellar graphite cast iron • A15/B125 pit covers with cover frame made of lamellar graphite cast iron with integrated cover sealing ring made of NBR. Screws made of stainless steel. Dimensions: • 535 mm external diameter of cover cap • 548 mm external diameter of cover frame for the A15/B125 cover Description The load of the pit is restricted accordingly depending on the pit cover selected. The cover cap is only suitable for load-free installation situations (front gardens, small gardens). The A15 pit frame is suitable and certified for traffic areas used by pedestrians and cyclists in accordance with DIN EN 124 Class A15, Group 1. The B125 pit frame is suitable and certified for traffic areas used by pedestrians or in pedestrian zones and similar areas, car parking lots or decks in accordance with Class B125, Group 2. Current information at: www.ewe-armaturen.de...
- Page 17 User information EWE-FLEXORIPP Water Meter Pit Edition 01/2017 Installation instructions for cover cap • The cover cap must be installed approx. 7 cm above ground level. • The cover cap can only be lifted from the edge of the cover. • Precipitation or any surface water that occurs must be drained because of the elevated installation situation. Installation instructions for A15/B125 pit covers The pit covers can be fitted flush with the surface; countersinking should be avoided. • Clean the deepest point of the top rib, remove burr if necessary. • Place the sealing ring in the deepest point of the top rib. The top rib is used to support the cover frame and must not be damaged!
- Page 18 User information EWE-FLEXORIPP Water Meter Pit Edition 01/2017 5.2.1 Operation of the A15/B125 pit cover Opening the cover • Remove the sealing plugs. • Unscrew the hexagon head screws SW 15. • Remove the pit cover via the recesses with a suitable lifting tool. Current information at: www.ewe-armaturen.de...
- Page 19 User information EWE-FLEXORIPP Water Meter Pit Edition 01/2017 Closing the cover • Insert the insulating cover. • Clean the seal in the cover frame. • Check the threaded screw holes for dirt and clean if necessary. • Insert the cover in the cover frame with the aid of the positioning lugs. • Tighten the screws alternately. • Recommended torque: 35-45 Nm. • Insert the sealing plugs in both openings. • Check that they are locked firmly by lifting the cover. Current information at: www.ewe-armaturen.de...
- Page 20 Braunschweig WILHELM EWE GmbH & Co. KG Volkmaroder Straße 19 38104 Braunschweig Phone.:+49 531 37005-0 Fax: +49 531 37005-55 E-mail: info@ewe-armaturen.de www.ewe-armaturen.de...
