1.0 Introduction
1.1 About This Document
This document contains the information necessary to properly
receive, assemble, install, operate, and maintain the SAAF
PORTA-Scrubber filtration system. The purchaser, installer, and/or
operator of the filtration system MUST read and comply with this
document in its entirety prior to installation of the equipment and its
operation. Failure to comply with the requirements of this manual
may void the product warranty.
CAUTION: These instructions are specific to the SAAF PORTA-
Scrubber and SAAF Chemical Filtration Media. All ancillary tasks
including, but not limited to, electrical and mechanical work,
equipment handling, and safety procedures must be performed in
accordance with industry accepted practice and all relevant local,
state, and federal government codes, laws, and policies.
TM
Advertisement
Table of Contents
Related Manuals for AAF SAAF PORTA-Scrubber PS-200
Summary of Contents for AAF SAAF PORTA-Scrubber PS-200
-
Page 1: Table Of Contents
Better Air is Our Business ® SAAF PORTA-Scrubber ™ Installation, Operation, and Maintenance Instructions Table of Contents 5.0 Maintenance 1.0 Introduction 5.1 PolyKlean Blue filter 1.1 About this document 5.2 Gas phase chemical media monitoring 1.2 Packaging and shipping, receiving and inspection, 5.3 Removal and replacement of particulate and gas phase handling and storage chemical media... -
Page 2: Packaging And Shipping, Receiving And Inspection, Handling And Storage
FOB the mounted on a pallet for protection during shipping and handling. AAF factory. The method of shipment will be as specified in the It is recommended that it remain on its pallet until it has been customer’s purchase order to AAF. - Page 3 S removal, Mercaptan Figure 1.3.2.1: Typical carton box SAAFCarb , amines 12" high x 12" wide x 12" deep SAAFCarb MC * , HCl * PORTA-Scrubbers designed for chlorine applications require special corrosion resistant materials. Contact your AAF representative for details.
-
Page 4: Product Model Designations
Copies of the appropriate drawings should have been supplied as AAF PolyKlean Blue pads. Depending on the size of the PORTA- part of the AAF submittals in response to the purchase order. Obtain Scrubber ordered, a round 24" diameter x 2" deep or a round 37"... -
Page 5: Related System Equipment
• Inlet and outlet ducts, or other sheet metal parts, as required of chemical storage tanks. These items will not be supplied by AAF unless noted specifically in the AAF quotation and in the accepted customer purchase order. WARNING: Chemical tank on other high concentration applications may require constant airflow and other special operating instructions. -
Page 6: Installation Instructions
3.0 Installation Instructions 3.3 Typical PORTA-Scrubber Details Consult the product drawing(s) submitted on this order before proceeding. Cast Aluminum Wire Outlet Guard 3.1 Space Requirements Pressure Blower A minimum of 24" clear space must be available around the PORTA-Scrubber to perform routine maintenance. Additionally, it is recommended that 36"... -
Page 7: General Filter System Installation
Provision for the anchoring hardware, support cradles, or any other supporting component will be the responsibility of the installer or others. These items will not be supplied by AAF unless noted specifically in the AAF quotation and in the accepted customer purchase order. -
Page 8: Preparation For Filter Installation
Install the prefilters as shown in the sequence shown below. For best results AAF recommends the use of the 2" thick PolyKlean Blue filter media. Circular PolyKlean Blue pads will be cut with a 2" overlap. -
Page 9: Fans
Sometimes the PORTA-Scrubber may be supplied with an externally injury, and even death. Disconnect all power whenever working on mounted blower. See the AAF drawing for information and details. the system. Only qualified electrical personnel should work on the Blowers can be fitted with an optional power cord with a 115-volt plug. -
Page 10: Start-Up Instructions
Remove all contamination, clean and returning it to AAF for analysis. Consult with your AAF representative sterilize as necessary. regarding active and passive monitoring systems and media sampling 5.6.3 Filter System Integrity: Ensure that the unit contains the... -
Page 11: Troubleshooting
6.0 Troubleshooting Potential problems and causes listed are in no order of importance or priority. The causes are only a list of the most common items to check to correct a problem. If you find the cause of a problem, DO NOT assume it is the only cause of that problem. -
Page 12: Spare Parts List
It is recommended that the following spare parts be stored at the installation site for routine maintenance purposes. The quantities required will depend on the size of the system. Consult with your AAF representative to determine actual quantities required. Minimum recommended quantities are provided in the table below.
