dobar 50130 Quick Start Manual

Quick Start Guide
50130 Automatic Pet Feeder (for Cats & Small Pets)
Control Panel Keys
CLOCK – current time
•
• TIMER – switches between preset feeding times
• VOLUME – sets the feeding volume/portion-size
• SET – SET mode, confirms any feeding times you enter
and advances to the next setting. Also used with
VOLUME key to perform manual feedings
START – starts the feeding schedule, confirms clock
•
and feeding-time settings
• DAY – sets the number of days to feed
• REC – records your personal voice message
• PLAY – plays back your personal voice message
Getting Started
1. Open the battery door (bottom side)
2. Keep the ON/OFF switch set to OFF
3. Insert 4 C-size alkaline batteries into the battery tray
4. Slide the ON/OFF switch to ON
5. The feeder will cycle once until (12:00) is flashing on
the LCD display
6. You now have 90 seconds to set the current-time.
After that (1 07) will be displayed on the LCD. If you
did not get to set the time correctly, simply slide the
switch to OFF, wait 1 minute, then repeat from step-4
Setting the Current Time
1. All digits should now be flashing
2. Press the CLOCK key to set HOUR
3. Press the TIMER key to set MINUTE
4. Press the SET key once to confirm time
The display will show either 12 or 24 to indicate the
display mode
12h-Format
nachmittags
Ziffer 2
Ziffer 1 Ziffer 3
5. Press the CLOCK key to change between 12- or 24-hour
display mode
6. Press the START key to CONFIRM clock setup
7. (1 07) will be flashing and you must now set the
feeding times
Setting the Feed Time and Number of Feedings
per Day
1. (1 07) should now be flashing. Digit-1 is the feeding
number (times per day), Digits-3 & 4 are the feeding
time (in hours)
12h-Format
nachmittags
Ziffer 2
Ziffer 1 Ziffer 3
2. The display shows the 1st feeding time (1 07)=(1st
feeding at 7 am)
3. With (1 07) Flashing, Press and HOLD (for 2 seconds)
the SET key until Digit-3 & 4 start flashing (07)
4. Press the TIMER key to set the desired hour for fee-
ding. Note the (P) in the top left corner stands for PM
when using 12 hour time
5. Press the SET key to confirm your setting and proceed
to the 2nd feeding time
6. Repeat step-4 to set the desired hour for feeding the
SECOND feeding time
7. At this point if you want to only feed 2 times per day
press the START key and you're finished
8. If you wish to feed a 3rd or 4th time each day do NOT
press the START key and repeat from step-4
Tip: If you pressed the SET key a 3rd time, but you did not want to feed 3
times per day, press the TIMER key then Press and Hold the SET key (for 2
seconds) to start over, not press the SET key after the Second feeding time,
press the START key to end your number of feedings per day.
Setting the Volume/Portion-Size
1. Press the VOLUME key to display feed-volume/porti-
on-size
2. Press and hold (for 2 seconds) the SET key until Digit-4
blinks
3. Press the VOLUME key to set the desired volume
Note: A Feed-volume of 1 equals 0.05cups (12cc) of food, 2 means
0.10cups (24cc) of food, 3=0.15cups (36cc) and so on.
4. Press the START key to confirm the volume/portion
size
Sanduhr
Uhrzeit-
Symbol
Ziffer 4
Sanduhr
Ziffer 4
1
