Operating instructions BA 30/800 Automatic Banding Machine HIMA 06/11 Harald Hinderer Maschinenbau...
Page 2
9. GSGV (German ordinance on machinery safety) A complete technical documentation exists in accordance with the directives and guidelines. The operating instructions belonging to the machine are available. Rudersberg (Harald Hinderer) Owner of HIMA-Harald Hinderer Maschinenbau Information about the signatory...
HIMA Harald Hinderer Maschinenbau Contents Description of features Technical specifications Power supply General instructions Setting up/ place of operation Loading the paper Adjusting product stops Setting length of band loop Putting into operation Hand-operated single stroke mode Foot-operated single stroke mode...
HIMA Harald Hinderer Maschinenbau Description of features BA 30/800 The banding machine applies paper BA 30/800 HIMA bands automatically where the paper is unwinded from a paper roll. When the paper roll is loaded and the start button is pressed a band is pulled tight around the product to be banded, sealed and cut off.
HIMA Harald Hinderer Maschinenbau General instructions The banding machine of the type manufactured BA 30/800 is easy to operate but nevertheless requires pru- HIMA dence. The persons operating the machine shall be familiar with its operation and limits. The following instructions must be observed:...
Setting up/ place of operation Caution Please observe the following in order to ensure a proper functioning of the machine: 1. Place the banding machine BA 30/800 HIMA on a secure and sturdy stand which is secured against tilting. The stand must be non-combustible.
HIMA Harald Hinderer Maschinenbau Adjusting product stops Loosen the knurled screws of the band guides and set (7 + 8) the desired loop width (approx. 1/3 longer than the product width). Fix the guides by tightening the knurled screws (11) again.
HIMA Harald Hinderer Maschinenbau Adjusting the band tension Turn the knob into the direction to reduce the band (20) (–) tension and into the direction to increase it. Automatic operation mode Turn on the main switch at the back of the machine.
Page 9
HIMA Harald Hinderer Maschinenbau Banding machine cannot be switched on at the control panel Check whether the light of the main switch at the back is on. If so, the control panel is faulty (please contact customer ser- vice). Banding machine can be switched on but does not start Check whether the front door protective contact is engaged properly.
HIMA Harald Hinderer Maschinenbau Setting up the banding machine with floor rack – Fasten the castor break at the front of the floor rack. – Remove existing transport locks. – Place the banding machine on the floor rack so that the legs of the banding machine fit into the recesses of the rack.
HIMA Harald Hinderer Maschinenbau Loading paper when operated with floor rack – Place the paper roll on the roll mount (see figure for running direction). – Feed the paper around the guiding rolls at the control lever as shown in the figure.
HIMA Harald Hinderer Maschinenbau Lubricating intervals In order to ensure a long service life of the machine, it is necessary to lubricate some parts. Please use commercial white or fine oil for lubricating. Please observe the following lubricating intervals: = monthly...
Page 13
Warranty issues a six month warranty for the machine. The HIMA – Harald Hinderer Maschinenbau warranty covers material or manufacturing faults which occur during normal load. The war- ranty does not cover damages of parts caused by improper use, wrong operation or wilful intervention into the machine.
