Product Specifications

Temperature
• Thermistor: 10,000 ohm @ 77 ºF (25 ºC)
• Accuracy: +/- 0.36 ºF from 32 - 158 ºF (+/- 0.2 ºC from 0 - 70 ºC)
• Stability: 0.24 ºF over 5 years (0.13 ºC)
Connectors
• Screw-type terminal connectors (located on the backplate)
• Optional RJ-11 Service Port jack (6 wire)
Wiring
• 2 for optional BACnet MS/TP service port connection (100-120 ohm balanced TSP
cable, 16 PF/FT or lower)
• 2 for optional service port power
• 2 for temperature
• 1 each for optional pushbutton and or setpoint adjustment
Wiring Class
• Class 2
Power
• 24 VAC 50/60Hz 3VA (necessary only for the optional service port)
Ambient
• 32º to 131º F (0º to 55º C)
• 10 to 90% RH (non-condensing)
Size
• 4 7/8" x 3 1/4"x 1" (11.4 cm x 7 cm x 2.54 cm)
Weight
• 0.16 lb. (71 g.)
