Slime Smart Repair CRK-0305IN Instructions Manual

Emergency flat tyre repair
Hide thumbs
Table of Contents
  • Installation Instructions
  • Troubleshooting
  • Problembehebung
  • Instructions D'installation
  • Dépannage
  • Istruzioni D'installazione
  • Risoluzione Dei Problemi
  • Instrucciones de Instalación
  • Resolución de Problemas

Advertisement

Available languages
  • EN

Available languages

  • ENGLISH, page 1

Quick Links

KIT INCLUDES:
• 473 ml (16oz.) bottle of Slime Tyre Sealant with filler hose
• Tyre inflator with built-in pressure gauge
• Valve core removal tool and air adapters for inflatables
LIGHT
• Bright LED for
night-time
emergencies
DIAL GAUGE
• Measures PSI/BAR
ON/OFF
SWITCH
POWER SOURCE
• Plugs into 12V
power outlet
ATTENTION! READ ALL INSTRUCTIONS CAREFULLY
FAILURE TO FOLLOW WARNING INSTRUCTIONS CAN RESULT IN FIRE,
Slime® provides a quick emergency repair. Treated tyres should be repaired by a qualified
tyre professional at the earliest opportunity to ensure safety and proper cleaning of tyre
pressure sensor, if so equipped. We recommend treated tyre be repaired within 3 days or
160 Km after use of Slime Tyre Sealant, whichever comes first. Advise tyre professional
of product use.
SMART REPAIR
EMERGENCY FLAT TYRE REPAIR
PERSONAL INJURY OR PROPERTY DAMAGE.
QUICK CONNECT
AIR HOSE
PART# CRK-0305IN INSTRUCTIONS | REV082218ART

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Smart Repair CRK-0305IN and is the answer not in the manual?

Questions and answers

Alec Kinane
January 21, 2025

how much slime should be inserted into a tire?

0
1 comments:
Mr. Anderson
February 4, 2025

473 ml (16 oz.) of Slime Tyre Sealant should be inserted into a tire using part number Smart Repair CRK-0305IN.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Summary of Contents for Slime Smart Repair CRK-0305IN

  • Page 1 FAILURE TO FOLLOW WARNING INSTRUCTIONS CAN RESULT IN FIRE, PERSONAL INJURY OR PROPERTY DAMAGE. Slime® provides a quick emergency repair. Treated tyres should be repaired by a qualified tyre professional at the earliest opportunity to ensure safety and proper cleaning of tyre pressure sensor, if so equipped.
  • Page 2 SEALANT REMOVAL INSTRUCTIONS (FOR THE TYRE REPAIR PROFESSIONAL) Slime Tyre Sealant is non-flammable and water based so clean up is simple. The sealant should be rinsed or wiped out of the tyre prior to making a permanent repair. Should any sealant fall on the shop floor, simply wipe it up with a rag and rinse off the area with water.

  • Page 3: Installation Instructions

    4. Remove the puncturing object if possible. 5. Place white cap on sealant bottle. Attach filler tube to the bottle tip and tyre valve stem and squeeze in recommended amount of Slime Tyre Sealant. 6. Replace the valve core. 7. Inflate the tyre.

  • Page 4: Troubleshooting

    125 Venture Drive, Suite 210, San Luis Obispo, CA 93401 USA • ITW Global Tire Repair Europe, Carl-Benz Str. 10, 88696 Owingen, Deutschland. Tel.: (+49) 7551-9200-0. Slime® is a trademark of Illinois Tool Works, Inc., registered in the U.S. and other countries.
  • Page 5 Reifenfachmann repariert werden, um die Sicherheit und ordnungsgemäße Reinigung des Reifendrucksensors zu gewährleisten. Wir empfehlen, den behandelten Reifen innerhalb von 3 Tagen oder 160 Km nach der Verwendung von Slime Tyre Sealant zu reparieren, je nachdem, was zuerst eintritt. Informieren Sie den Reifenprofi...
  • Page 6 ANLEITUNG ZUR ENTFERNUNG VOM DICHTMITTEL (FÜR DEN REIFENDIESNT MONTEUR) Slime Reifendichtmittel ist nicht entzündbar und wasserbasierend, daher einfach zu säubern. Das Dichtmittel sollte ausgespült oder ausgeputzt werden bevor die Reifenreparatur vorgenommen wird. Sollte etwas vom Dichtmittel auf dem Boden fallen, wischen Sie es einfach auf und waschen sie die Stelle mit Wasser aus.
  • Page 7 4. Wenn möglich, den Fremdkörper entfernen. 5. Den weißen Aufsatz auf die Flasche aufschrauben. Verbinden Sie den Einfüllschlauch an die Flasche und an das Ventil und füllen Sie die empfohlene Menge Slime Reifendichtmittel ein. 6. Setzten Sie den Ventilkern wieder ein.

  • Page 8: Problembehebung

    FRAGEN ODER KOMMENTARE: Rufen Sie an unter (+1) 888-457-5463 oder besuchen Sie www. slime.com. ITW Global Tire Repair • 125 Venture Drive, Suite 210, San Luis Obispo, CA 93401 USA • ITW Global Tire Repair Europe, Carl-Benz Str. 10, 88696 Owingen, Deutschland. Tel.: (+49) 7551-9200-0.
  • Page 9 Nous recommandons que le pneu traité soit réparé dans les 3 jours ou 160 km après l’utilisation de Slime Tyre Sealant. Informez le professionnel du pneu de l’utilisation du produit.
  • Page 10 INSTRUCTIONS POUR L’ENLÈVEMENT DU GEL D’ÉTANCHÉITÉ SLIME (MESSAGE À L’INTENTION DES RÉPARATEURS DE PNEUS PROFESSIONNELS) Le gel d’étanchéité Slime est ininflammable et à base d’eau, donc le nettoyage est simple. Le produit d’étanchéité doit être rincé ou essuyé avant d’effectuer une réparation permanente du pneu.

  • Page 11: Instructions D'installation

    5. Vissez le capuchon blanc sur la bouteille. Fixez le tube de remplissage sur l’extrémité du capuchon d’un côté et sur la tige de la valve de l’autre, puis faites entrer la quantité recommandée de liquide d’étanchéité Slime dans le pneu. 6. Replacez l’obus de valve.

  • Page 12: Dépannage

    Pour plus d’informations sur la garantie limitée offerte, consultez la page : www.slime.com/warranty QUESTIONS OU COMMENTAIRES : appeler le (+1) 888-457-5463 ou visiter www.slime.com. ITW Global Tire Repair • 125 Venture Drive, Suite 210, San Luis Obispo, CA 93401, USA • ITW Global Tire Repair Europe, Carl-Benz Str. 10, 88696 Owingen, Deutschland.
  • Page 13 Si consiglia di riparare il pneumatico trattato entro 3 giorni o 160 km dall’uso di Slime Tyre Sealant, a seconda della condizione che si verifica per prima. Informare i professionisti dell’uso dei pneu-...
  • Page 14 ISTRUZIONI PER ESTARRE IL SIGILLANTE (PER IL GOMMISTA) Il sigillante Slime non è infiammabile ed è a base d’acqua, quindi la pulizia di esso è semplice. Il sigillante deve essere rimosso e bisogna risciacquare la gomma prima di effettuare la riparazione permanente. In caso che il sigillante cada sul pavimento dell’officina, basta pulirlo con uno straccio bagnato e risciacquare l’area con acqua.

  • Page 15: Istruzioni D'installazione

    ISTRUZIONI D’INSTALLAZIONE Riparare una gomma forata con il Kit Smart Spair è semplice e impiega solamente 15 minuti. 0.2 MI/0.32 KM BAR/KPA 1. Fate girare la ruota in modo da portare lo spillo della valvola nella parte superiore della gomma. 2.

  • Page 16: Risoluzione Dei Problemi

    ITW Global Tire Repair (Riparazione delle gomme globale ITW) • 125 Venture Drive, Suite 210, San Luis Obispo, CA, USA • ITW Global Tire Repair Europe, Carl-Benz Str. 10, 88696 Owingen, Deutschland. Tel.: (+49) 7551-9200-0. Slime è un marchio della Illinois tool Works, Inc. registrata nelli Stati Uniti di America e altri paesi.
  • Page 17 él. Recomendamos que la rueda tratada sea reparada dentro de 3 días o 160 km después del uso de Slime Tyre Sealant, lo que ocurra primero. Informe al técnico del taller sobre el uso del producto.
  • Page 18 INSTRUCCIONES PARA RETIRAR EL SELLANTE (NOTA PARA PROFESIONALES EN LA REPARACIÓN DE NEUMÁTICOS) El sellante Slime para neumáticos no es inflamable, está formulado con una base de agua, por lo que su limpieza es sencilla. Antes de realizar una reparación permanente, enjuague y limpie el sellador del neumático.

  • Page 19: Instrucciones De Instalación

    4. Si es posible, retire el objeto que ha causado el pinchazo. 5. Enroscar el tapón blanco a la botella de sellante. Conecte la punta de la manguera a la botella y a la válvula del neumático e introduzca la cantidad recomendada de sellante Slime para neumáticos.

  • Page 20: Resolución De Problemas

    Repair • 125 Venture Drive, Suite 210, San Luis Obispo, CA 93401 USA • ITW Global Tire Repair Europe, Carl-Benz Str. 10, 88696 Owingen, Deutschland. Tel.: (+49) 7551-9200-0. Slime® es una marca comercial de Illinois Tool Works Inc., registrada en los EE. UU. y en otros países.
