General Information - Favero Electronics Console-700 User Manual

ENGLISH
ENGLISH
Console-700
Table of contents
1. General information........................................ 2
2. Operation........................................................ 5
1. G
ENERAL INFORMATION
1.1. Purpose
This manual provides the necessary information for the correct use of Console-700 (art.308-01), also called
"product" in this document. We also suggest you keep the manual for the duration of the product's life.
1.2. Product description
The product consists of a portable console with touchscreen display which enables control of the FC, FS, FW,
FOS and TM series scoreboards. Communication between the console and the scoreboards can be wireless
or through a connection cable.
1.3. Symbols used in the manual
Portions of the text which are of particular importance in regards to the safety or proper use of the product are
indicated by the following symbols.
Warning: risk of danger or injury to persons if instructions or the necessary precautions are not
followed.
Caution: situations that could cause damage to your device or other equipment
Note: important information on product use.
1.4. Technical features
Relative humidity (without condensation) of storage:
00308-M01-03-ML - Console-700 User Manual
(art.308-01)
Supply: AC Adapter - Battery charger
Temperature of storage: -10 ... +70°C (Console)
operating: 0 ... 45°C (Console),
operating:
Altitude of storage:
operating:
Battery: for the power supply: lithium polymer battery, 37Wh (typical),
Size (Width x Height x Depth): 240 x 82 x 168mm
Weight: 1.1kg
Enclosure material: ABS
3. Software update.............................................. 8
4. Problem solving.............................................. 8
Input: 90-264V, 47-63Hz, 0.5A (100VAC)
Output: 9.0VDC ± 5%, 0-2.0A, 18W
-20 ... +85°C (Power supply - Battery charger)
0 ... 50°C (Power supply - Battery charger)
5 ... 95%
10 ... 90%
12000m
200m
for the internal clock: button type, lithium battery, CR2032,
2 / 44
10Ah (typical), 14-hour average life (level
7 display brightness).
230mAh, 3V, 7-year
expectancy
F
AVERO
average life
E
LECTRONICS SRL
