- Page 1 I I I I C C C C R R R R O O O O Use and installation manual Garden/Tower-MICRO Rev. 2 - 03/2015 – MITECH srl reserves the right to change the information in this document without warning.
-
Page 2: Table Of Contents
Index Anti-intrusion column Main components Additional components General installation instructions Mounting options Wall mounting Ground mounting Fixing the column to the base Inserting the cover and closing the column Mounting the lamp Examples of installation Example of how to protect an independent building Column supply Microwave Barrier Detection System Introduction... -
Page 3: Anti-Intrusion Column
Anti-intrusion column IMPORTANT - Power the device using the 13.8 Vdc stabilised voltage only. - In order for the column to work correctly, ensure the power voltage never falls below 12 Vdc. - It is imperative you switch on the temperature control system for both internal and external installations (power –supply 24Vac). -
Page 4: Main Components
Main components Part Part Part Part Quantity Quantity Quantity Quantity Description Description Description Description Aluminum profile IR polycarbonate cover Upper cover Lower cover Receiver or transmitter microwave device Tamper Garden/Tower-MICRO Use and installation manual Page 4 of 20... -
Page 5: Additional Components
Additional components Components included Components included Components included Components included (TW = Tower – GAR = Garden) Part Part Part Part Quantity Quantity Quantity Quantity Description Description Description Description Ground fixing base (TW e GAR) Wall fixing base (TW e GAR) Bracket (TW e GAR) Screws with... -
Page 6: General Installation Instructions
General installation instructions 1. After installing the column, make sure that it is perfectly closed with the watertight covers supplied. 2. Make sure that the path between the sensors is free and that there are no obstacles that could affect the communication between the optical assemblies of the transmitters and receivers that could interfere with the beams (i.e. -
Page 7: Ground Mounting
Ground mounting Ground mounting Ground mounting Ground mounting with clamps, fixing the base to a plinth This fixing method is the most secure. It requires a cement base in which to anchor the clamps provided. Ø33 Ensure the plinth contains a tube (Ø 20 mm) through which to thread the cables. -
Page 8: Fixing The Column To The Base
Fixing the column to the base Insert the lower cover into the base guide. Insert the aluminium profile into the base guide and into the relevant slot in the lower cover. squadretta Insert the connecting bracket between the lower cover and the aluminium profile. M6x25 Screw 2 TE M6x20 screws through the bracket and the base and 2 TE M6x25 screws... -
Page 9: Inserting The Cover And Closing The Column
Inserting the cover and closing the column Insert the polycarbonate cover from above, making it slide down as far as the column base and inserting it into the lower cover. Place the upper cover and screw it to the column by means of 2 O-ring screws (supplied). Garden/Tower-MICRO Use and installation manual Page 9 of 20... -
Page 10: Mounting The Lamp
Mounting the lamp Place the specific upper cover that connects to the lamp holder, ensuring the power cables are properly threaded. Screw the cover to the column by means of 2 O-ring screws (supplied). Connect the wires to the lamp holder terminal. Fix the lamp holder to the cover using the 2 Allen screws found at the sides (5 mm spanner). -
Page 11: Examples Of Installation
Examples of installation 4 sides perimeter check 4 sides perimeter check 4 sides perimeter check 4 sides perimeter check solution 1: 8 terminal columns (each column has only one TX or RX device). PROTECTED AREA 4 sides perimeter check 4 sides perimeter check 4 sides perimeter check 4 sides perimeter check solution 2: 4 complete bidirectional columns (each column has a TX + one RX device). -
Page 12: Example Of How To Protect An Independent Building
Example of how to protect an independent building Example of how to protect an independent building Example of how to protect an independent building Example of how to protect an independent building The electromagnetic waves transmitted are high frequency to guarantee maximum protection. columns high frequency electromagnetic waves... -
Page 13: Column Supply
Column supply Example of supply of RX terminal column using the GAR POW dual power supply unit. 220 Vac GARPOW 6 5 4 3 2 1 MICROWAVE WARNINGS To function correctly the column needs 230 Vac filtered and stabilized voltage supply. Therefore check the electrical system before powering up. -
Page 14: Microwave Barrier Detection System
Microwave Barrier Detection System Introduction Introduction Introduction Introduction The current manual uses the following abbreviations: DZ - detection zone TU - transmitting unit RU - receiving unit TU and RU are placed at the opposite ends of the guarded area. TU emits electromagnetic waves in the direction of RU. -
Page 15: Technical Specifications And Connections
Technical specifications and connections Parametro Valore Lobo dimensions: height max 2,50 m opening max 1,0 m Operating temperature da -40°C a +65°C DZ length da 1 a 200 m Range of detection speeds da 0,1 a 10,0 m/s Range of working supply voltage da 12 a 36 Vdc Maximum current required at the working supply voltage of 24V 80 mA... -
Page 16: Warnings And General Characteristics
WARNINGS 1. When carrying out the work for preparing the detector for use as well as in using it, the current rules on technical safety have to be observed in the use of electric installations. 2. The emission level of the TU of the detector, in accordance with the effective norms for personal safety of those, who are professionally, allows non-stop working. -
Page 17: Notes
NOTES: ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. Garden/Tower-MICRO Use and installation manual Page 17 of 20... - Page 18 ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. Garden/Tower-MICRO Use and installation manual Page 18 of 20...
- Page 19 ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. ………………………………………………………………………………………………………….. Garden/Tower-MICRO Use and installation manual Page 19 of 20...
- Page 20 MITECH S.r.l. Main Office: Via Roncaglia, 14 - 20146 Milano -Italy Telefono: +39 02.48006383 Fax: +39 02.48025620 Production site: Via Ramazzone, 23 43010 - Fontevivo (Parma) - Italy Email: tech@mitech-security.com www.mitech-security.com Garden/Tower-MICRO Use and installation manual Page 20 of 20...
