OPERATING MANUAL
MHS-5200A Series
dual-channel DDS signal generator
Zhengzhou Ming Wo Electronic Technology Co., Ltd.
Investor Road, New District, Zhengzhou City,
Henan Province No. 96
Tel: 0371-86106382
Fax: 0371-86106382
Website: www.mhinstek.com
E-mail: sales@mhinstek.com
All rights reserved
May 2015
.
1
Advertisement
Table of Contents
Summary of Contents for MH Instek MHS-5200A Series
- Page 1 OPERATING MANUAL MHS-5200A Series dual-channel DDS signal generator Zhengzhou Ming Wo Electronic Technology Co., Ltd. Investor Road, New District, Zhengzhou City, Henan Province No. 96 Tel: 0371-86106382 Fax: 0371-86106382 Website: www.mhinstek.com E-mail: sales@mhinstek.com All rights reserved May 2015...
-
Page 2: Table Of Contents
Contents 1 Unpacking 2 Overview 2.1 Instrument introduction ..... 2.2 Model description ......2.3 Instrument characteristics . -
Page 3: Unpacking
Unpacking When you get a new MHS-5200A Series dual-channel DDS signal generator, it is recommended that you follow these steps to inspect the instrument. 1. Check for transportation damage to the shipping box and packing ma- terials. If there is serious damage, keep them until the machine and accessories have passed the acceptance test. -
Page 4: Model Description
Model description This series of instruments includes four models, differentiated by the maxi- mum frequency of the output sine wave: MHS-5200-06M sinusoidal signals at frequencies up to 6MHz MHS-5200-12M sinusoidal signals at frequencies up to 12MHz MHS-5200-20M sinusoidal signals at frequencies up to 20MHz MHS-5200-25M sinusoidal signals at frequencies up to 25MHz Instrument characteristics •... - Page 5 • All parametric EQ calibration can be performed by internal procedures; • Powerful communications features. Completely open communications protocol allows development of third-party applications • When connected to the PC, the computer can be used to control the instrument. The user can edit arbitrary output waveforms, and down- load it to the instrument •...
-
Page 6: Technical Specifications
Technical specifications 2.4.1 Key parameters Sine wave MHS-5200-06M 0Hz..6MHz MHS-5200-12M 0Hz..12MHz MHS-5200-20M 0Hz..20MHz Frequency Range MHS-5200-25M 0Hz..25MHz Square wave 0Hz..6MHz Triangle wave 0Hz..6MHz Sawtooth 0Hz..6MHz Arbitrary waveform 0Hz..6MHz TTL digital signal 0Hz..6MHz Output modulation Frequency sweep Waveform types Sine, square, triangle, sawtooth, TTL digital signal wave, Arbitrary Waveform Length... -
Page 7: Detailed Specifications
2.4.2 Detailed specifications Sine wave Harmonic content 40dBc (below 1MHz), 35dBc (1MHz .. 20MHz) Distortion <0.8% (20Hz .. 20KHz) Rise time ≤20ns Square Overshoot ≤10% wave Duty cycle adjustment 0% .. 99.9% range Rise time ≤20ns Low level <0.3V High level 1V ..7.5V Arbitrary No. -
Page 8: Instrument Description
Instrument Description External description MHS-5200A external appearance and user interface is described in Figure 1. LCD1602 LCD CH2 output connector Status Indicator Power switch Operation buttons 5VDC power input Rotary knob selector USB connector Ext.In input connector TTL input / output connector CH1 output connector Figure 1: MHS-5200A external layout... -
Page 9: Front Panel Keys
Front panel keys The instrument front panel keys are described in Figure 2. There are six physical membrane keys: five function keys, and a shift key that introduces a secondary operation for the other keys. Move the cursor left, or change the current parameter value Move the cursor right, or change the current parameter value... -
Page 10: Operating Instructions
Frequency display Selected menu operation / parameter display Figure 3: Front panel display symbol indicates which values will be modified by they arrow keys and the adjustment knob. In multi-digit parameter values, the current selected digit is indicated by an underline. Operating Instructions Startup sequence 1. -
Page 11: Selecting Ch1 Waveform
The primary functions, signal waveform and amplitude (Sec. 4.2.1 and 4.2.2), have their own key selectors; other functions are selected by moving through the menu selections by the PgUp and PgDn keys, in the following ✗ ✔ order: WAVE → AMPL → OFFS → DUTY → PHASE → TRACE → FREQ-UNIT →... -
Page 12: Setting Ch1 Voltage Offset
In the default range setting function mode, the maximum amplitude is 15V, and the minimum amplitude is 0.15V; the incremental step value is 0.01V (10mV). The -20dB output attenuator may be selected by pressing the button. With attenuation, the output signal has a maximum value of 1.500V, the minimum value of 0.015V, and the minimum step is 0.001V (1mV). -
Page 13: Setting The Display Unit Of Frequency
4.2.7 Setting the display unit of frequency Change the mode to adjust the frequency units of the display, and then select the frequency units of Hz, kHz, or MHz. 4.2.8 Tracking function Tracking function is used to synchronize the frequency of CH2 to CH1. The amplitude and duty cycle can also be tracked. -
Page 14: Measurement Function
4.2.10 Measurement function Several parameters of the input signal can be measured. • Choose the measurement mode selection, and then turn the knob or click the button to switch the measured quantity: FREQ F= frequency COUNTR C= count POS-PW H= positive (logical high) period NEG-PW L= negative (logical low) period PERIOD T= time period DUTY DUTY= duty cycle (percent) -
Page 15: Parameter Storage And Loading
• Next, select the sweep time setting mode, and rotate "ADJUST" knob to adjust the sweep time between 1s and 600s, e.g. to 10s as shown below: • Next, enter the sweep mode selection screen, and choose between LINE (linear frequency sweep) and LOG (logarithmic sweep). •... -
Page 16: Care And Maintenance
Care and maintenance 1. Make sure to use the provided DC5V power adapter; 2. The instrument display LCD module is fragile and needs to be pro- tected from mechanical and chemical damage. Clean by gently wiping with a soft cloth. 3. - Page 17 Warranty conditions: Instrument is warrantied for a period of one year from the shipment date. During the warranty period, the company will repair or replace equipment selected according to the situation. For service, please send the product to the company. The following conditions are not covered under warranty: •...
-
Page 18: A Instrument Internals
Instrument internals 1. LCMX02-1200HC lattice FPGA 2. STM8S00 controller 3. R-2R resistor ladder DAC 4. LM358 opamps 5. AD603AR variable gain output amplifiers 6. 74HC140 TTL driver 7. CH340G USB-serial interface Figure 4: MHS-5200A main circuit board MHS-5200A serial protocol This is a copy of Al Williams’... - Page 19 • baud rate 57600 • data formatting 8/n/1 • hardware handshake Manufacturer-provided software initiates the communication with the device with the following commands (presumably to probe different device types in the future): : clear any pending command :r1c returns :r1c323 (current observed firmware 3.23) :r2c returns :r2c015 (last digits of P/N?) :r0c returns :r0c52A (model #? 5200A?) If you get an echo of <CRLF>### that probably is an error indication...
- Page 20 :rXa Read amplitude for chan X :rXaNNNN :sXb Set chan X on or off 1=on,0=off :rXb Read chan X on or off :rXbN :s3b Set trace on or off 1=on 0=off :r3b Read trace on or off status :r3b :s4b Select ext in or ttl 0=ext 1=ttl :r4b...
- Page 21 :s6bN 0=stop, 1=run only affects counter mode :r6b Read run state :r6bN :s5b1 Reset counter :r5b Read reset status :r5bN Functions still unknown: • Reading back arbitrary storage (if even possible) • Setting or loading stored setups • Sweep time setting (not sure why I missed this)
