Summary of Contents for DVS DS100S Series
- Page 1 DS100S AC Servo Manual DS100S AC SERVO DRIVE MANUAL...
- Page 2 DS100S AC Servo Manual DS Series AC Servo Systems Features Strong Overload Capability Because it adopts industrial intelligent power module IPM, it has advantages of strong overload capacity and high starting torque. Moreover the load that it withstands are three times stronger than the rated torque.
- Page 3 DS100S AC Servo Manual DS Servo System Configuration...
- Page 4 DS100S AC Servo Manual Notes: “SET” Button: Enter the parameter settings or set the values to the selected parameter and exit. UP Button: Increase the selected value by 1. DOWN Button: Decrease the selected value by 1. BACK Button: Press this to come back to before data. Wiring Example in Position Mode DN series Motor Connecting(15-Line Encoder) DN series 15-line Motor Connecting(60mm、80mm、90mm)
- Page 5 DS100S AC Servo Manual Notes: 1. If use 3 phase AC220V main power supply, please connect with terminal L1,L2,L3. 2. If use 1 phase AC220V main power supply, please connect with terminal L1,L3. 3. Terminal CN2 please connect with the signal terminal of encoder. 4.
- Page 6 DS100S AC Servo Manual Parameters In Position Mode The following parameters need to be set when in position mode: Parameter Introduction Value Default Value Controlling Method Command pulses if 10000 PA11 the motor runs one Set by yourself roll. To select position PA14 Set by yourself command pulse mode...
- Page 7 DS100S AC Servo Manual Pic 1. Operating display layer Monitoring In the first layer, please select “DP--” and press the SET button to enter into monitoring mode. There are 16 displays in total. Users select the desired display mode with ↑or ↓key, and then press the SET key to enter into the specific states.
- Page 8 DS100S AC Servo Manual Terminals CN1 Connector CN2 Connector...
- Page 9 DS100S AC Servo Manual CN3 And CN3B Connector Can be connected to the PC machine or controller through special serial cable, don’t plug it with RS485 electric. Twisted pair shielded wires are suggested and less than 2 meters in length Terminal CN3A Name...
- Page 10 DS100S AC Servo Manual Parameter Function Introduction Parameter Default Name Function Range Value 1.User password is 315 to set or change parameters. Password 0-9999 2.Motor type code is 385. 1. Corresponding to different drives and motors with different power in the same series. 2.
- Page 11 DS100S AC Servo Manual stronger. The parameter value is set according to your exact servo driving system model and the load. Generally, the greater the load inertia, the bigger the value. 3.Please set a little high value if the system condition does not generate oscillation.
- Page 12 DS100S AC Servo Manual The filter does not lose the input pulse, but the delay of the instruction occurs. 3.The filter applies in (1. PC controller without acceleration and deceleration function. (2. The electronic gear frequency is a little big(>10). (3.The command frequency is a little low.
- Page 13 DS100S AC Servo Manual Fault Code indication Code No. Fault Name Indication Normal Over Speed Motor speed over than the setting values. Main Circuit Over Voltage The voltage of main circuit is too high Main Circuit Under Voltage The voltage of main circuit is too low The value of position deviation counter is over than the Position Error setting value.
- Page 14 DS100S AC Servo Manual DS Series AC Servo Drives Module Part Number 1 0 0 □□□ ① ② ③ ④ Number Description ① DS Series AC Servo Drive ② 100：under 0.75KW , 200: under2.2KW, 300:under 3.4KW S ： standard ac servo drive compatible with 2500-line encoder ③...
- Page 15 DS100S AC Servo Manual Specifications Parameters DS100S-40 DS100S-75 Output Power 50W-400W 400W-1000W 1 phase/3 phase Main Supply AC220V-240V 50/60Hz Power Supply for 1 phase 220VAC Control Circuit 0: position control 1: velocity control Control Method 2: test trial control 3: JOG control 4: torque control over speed/under voltage/over voltage/over current/over load/encoder Protect Function...
- Page 16 DS100S AC Servo Manual Dimension DS100S-40(50W~400W) DS100S-75(400W~750W) Installation Notes: DS200S(1KW~2.2KW) NOTE: 1. Install the drives indoors, where the drives are not subjected to rain or direct sun beams.The drives are not waterproof. 2. Install the drives where the products are not subjected to corrosive atmospheres,and free from splash of inflammable gas, grinding oil, oil mist,iron powder or chips etc.
