Summary of Contents for Heinner VMGB002
- Page 1 Instructions Instrucțiuni de utilizare - RO Eredeti használati utasítás - HU Ръководство за употреба - BG www.heinner.com VMGB002...
- Page 2 GASOLINE LAWN MOWER CAUTION: For your safety, please read this instruction manual carefully before using the tool! Thank you for choosing HEINNER! Safety instructions TRAINING Read the instruction carefully. Be familiar with the controls and the proper use of the equipment.
- Page 3 GASOLINE LAWN MOWER and or grass catchers, in place. 12) Do not change the engine governor settings or over speed the engine. 13) Disengage all blade(s) and drive and drive clutches before starting the engine. 14) Start the engine or switch on the motor carefully according to instructions and with feet well away from the blade(s).
- Page 4 This appliance is not intended for use by persons with lack of experience or knowledge, unless they have been given instruction concerning the use of the appliance. PRODUCT SPECIFICATIONS MODEL VMGB002 Displacement: 123 CC Engine Power: 1.7 KW/2.3 HP Engine type: 4 strokes...
-
Page 5: Table Of Contents
GASOLINE LAWN MOWER SUMMARY: 1. DESCRIPTION ........................4 2. ASSEMBLY OF GRASS CATCHER/DEFLECTOR ..............4 3. HANDLE ASSEMBLY ......................5 4. ADJUSTMENT OF CUTTING HEIGHT ................... 5 5. SAFETY PRECAUTIONS ....................... 6 6. OPERATION ........................6 7. GEAR BOX ......................... 7 8. -
Page 6: Handle Assembly
GASOLINE LAWN MOWER e) Put the guide grass board when use the side discharge (Figure A4). 3. ASSEMBLY OF THE HANDLE Open out the handle and screw the handles parts with the two screws and plastic nuts. Put the recoil starter on the right of the handle and fix the cable with the plastic collar. -
Page 7: Safety Precautions
GASOLINE LAWN MOWER 5. SAFETY PRECAUTIONS a) Always use the lawnmower with the grass catcher or/ and the deflector in position. b) Stop the engine before emptying the grass catcher or before you change the cutting height. c) While the engine is running, never introduce your hands or feet under the lawnmower or under the grass ejection area (figure E). -
Page 8: Gear Box
GASOLINE LAWN MOWER Blade is in action as soon as engine started. While the machine is working maintain the security handle (3) in working position. The engine will stop as soon as you release the engine control bar. 7. GEAR BOX Polish the gear in the wheels and put grease on them. - Page 9 GASOLINE LAWN MOWER - After hitting a foreign object, stop the engine and check thoroughly the mower in order to see if it is damage. Bring the mower in an agreed service station to do the repairing if necessary. - WARNING: After you stopped the engine the blade is still in motion during a few seconds. - If the mower vibrates in an abnormal way, find the reasons why, and take your mower to an agreed service station.
-
Page 10: Maintenance
GASOLINE LAWN MOWER 9. MAINTENANCE WARNING: Stop the engine and unplug the spark plug before each repairing or maintenance operation. - For four strokes engine read carefully the maintenance engine manual. Check regularly the oil level and add some oil or replace it if necessary. - Frequently check the lawnmower and ensure that all grass deposits are removed from beneath the deck. - Page 11 GASOLINE LAWN MOWER RECYCLING Recycling and disposal of petrol engine powered tools, fuel and oil • Tools powered by petrol-based internal combustion engines must not be disposed of with household waste. Such tools should be taken to your local recycling centre and disposed of according to current environmental protection requirements in your country.
