Gefen EXT-PACS User Manual

Professional automation control system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Professional
Automation
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
ontrol System
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w.gefen.com
EXT-PACS
User Manual
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EXT-PACS and is the answer not in the manual?

Questions and answers

Summary of Contents for Gefen EXT-PACS

  • Page 1 ® Professional Automation ontrol System EXT-PACS User Manual w.gefen.com...
  • Page 3 Notice Gefen, LLC reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. Professional Automation Control System is a trademark of Gefen, LLC All trademarks are the property of their respective companies.

  • Page 4: Table Of Contents

    CONTENTS Introduction Operation Notes Features Front Panel Layout Front Panel Descriptions Back Panel Layout Back Panel Descriptions Connecting the PACS Wiring Diagram Confi guring the PACS 14 Web Interface The Built-in Web Server RS-232 Menu RS-232 Settings TCP / UDP Bridge Settings IR Emitters Menu Adding a new IR device Adding a new IR device from a Template...

  • Page 5: Introduction

    IR commands of different manufacturers’ remotes. The 12V DC triggers are highly confi gurable to work with the different requirements of various devices. Use with the new Gefen A/V Automation System Processor to create a complete control system. How It Works Connect the serial-controlled devices to the PACS RS-232 ports.

  • Page 6: Operation Notes

    OPERATION NOTES READ THESE NOTES BEFORE INSTALLING OR OPERATING THE PROFESSIONAL AUTOMATION CONTROL SYSTEM • The PACS is shipped with a static IP address of 192.168.1.72. This address may need to be changed before the PACS will work on your Local Area Network.

  • Page 7: Features

    RS-232 devices. Supports baud rates up to 115200. • Firmware can be upgraded via Web interface. • Rack-mountable using the 1U Rack Tray (Gefen part no. EXT-RACK-1U). Package Includes (1) Professional Automation Control System (4) Single IR emitters (1) 6 ft. DB-9 cable (M - F)

  • Page 8: Front Panel Layout

    FRONT PANEL LAYOUT...

  • Page 9: Front Panel Descriptions

    FRONT PANEL DESCRIPTIONS The IR receiver is provided for the PACS to learn new IR commands. Use the Web Interface or Telnet for this procedure. See pages 17 - 23 for more information. Status This LED indicator is normally OFF. It glows bright blue when the PACS is ready to receive a new IR command via the IR receiver.

  • Page 10: Back Panel Layout

    BACK PANEL LAYOUT...

  • Page 11: Back Panel Descriptions

    RS-232). IR Emitters Connect up to eight (8) single or dual 12V IR emitters (Gefen part no. EXT-IREMIT or other Xantech-compatible emitters) to these ports to control A/V or other devices using one-way IR control. These outputs are capable of transmitting IR signals with 30 - 60 kHz carrier frequencies.

  • Page 12: Connecting The Pacs

    PACS. Connect the AC power cord to an available electrical outlet. Wiring Diagram for the PACS IR PORT 12V/GND TRIGGERS RS-232 IP / RJ-45 HDMI I N S V I C A / V 4 x 1 - 2 3 T - G EXT-PACS...
  • Page 13 CONFIGURING THE IP ADDRESS Setting the IP Address The PACS is designed to control devices over a network using a built-in Web server or via Telnet. Before using Telnet control or the built-in Web Server, the network settings for the PACS must be confi gured via IP. Before connecting the PACS to a network, locate the label on the bottom of the PACS.
  • Page 14 CONFIGURING THE IP ADDRESS If you computer has an IP address of 192.168.1.(x), and 192.168.1.72 is an available address, you can access the PACS by entering 192.168.1.72 in your Web browser. Otherwise use the following procedure to change the PACS IP address to match your network: Access the Network Setting control panel in Windows and locate your LAN connection.
  • Page 15 CONFIGURING THE IP ADDRESS Click on the Properties button to display the Local Area Connection Properties dialog. Click on Internet Protocol Version 4 (TCP/IPv4). Internet Protocol Version 4 (TCP/IPv4) Click to highlight this Network protocol. Click the Properties button to display the Internet Protocol Version 4 (TCP/ IPv4) Properties dialog.
  • Page 16 CONFIGURING THE IP ADDRESS STOP: Write down the current IP settings before making changes, since you will need to restore the old settings later. If the Properties are set to “Obtain an IP address automatically” and “Obtain DNS server address automatically”, you do not need the actual address settings.
  • Page 17 CONFIGURING THE IP ADDRESS Click the OK button, then close all Control Panel windows. Refresh your Web browser and go to http://192.168.1.72 to open the PACS Web Server. Go to the Confi guration Menu (see page 35) and change the PACS IP address to an appropriate address for your network.

  • Page 18: Web Interface

    WEB INTERFACE The Built-in Web Server The PACS includes a built-in Web server which provides an intuitive Web interface. If TCP/IP is not confi gured on the PACS, then see page 9 for details on confi guring the PACS. If the PACS is already confi gured for use on a network, then open a Web browser and type in the IP address of the PACS.

  • Page 19: Rs-232 Menu

    WEB INTERFACE RS-232 Menu The PACS has three (3) RS-232 ports. The RS-232 Menu allows you to change the RS-232 port settings on the PACS. Description Provide a name to the device connected to this port (e.g. “SonyTV”, “Samsung”, etc.)

  • Page 20: Rs-232 Settings

    WEB INTERFACE RS-232 Settings Some RS-232 settings use a drop-down menu for selecting different options. For example, to select the Baud Rate, click the arrow icon then click on the required port speed: Arrow Icon Indicates a drop- down list. Click to list the available baud rates.

  • Page 21: Tcp / Udp Bridge Settings

    When using UDP you can broadcast the message by using the IP address: 255.255.255.255. Use TCP unless otherwise instructed by your Control System User Manual, or by Gefen Technical Support. See page 58 for a full explanation of these settings.
  • Page 22 For example, 0D0A is CR + LF (Carriage Return + Line Feed). The delimiters are used by some control systems to fi lter incoming data. Contact Gefen Technical Support for details if you need to use them. TCP Port #...

  • Page 23: Ir Emitters Menu

    WEB INTERFACE IR Emitters Menu The PACS has eight (8) IR Emitter (IR back-channel) ports. The PACS can use any one of these IR Emitter ports to send IR commands to the source device. Up to 64 IR commands can be stored per device. IR confi guration fi les can be saved, downloaded, uploaded, edited, and deleted.
  • Page 24 WEB INTERFACE Test Command Name Press the Test button to Used to enter / edit the name of each validate the learned IR IR command. This is a required fi eld. command. One or more Up to sixty-four (64) IR commands can be outputs must be selected and stored per device.
  • Page 25 WEB INTERFACE Learn All Performs a “step- through” when learning IR commands from a template (see page 28). Rename Advanced View Click the Rename Click the Advanced View link button to rename to display additional options the IR command. for learning or deleting IR commands. Learn Delete Click the Learn button to learn a...
  • Page 26 WEB INTERFACE Model No. (optional This is the device model number (e.g. KDL40EX729, etc.) This fi eld is used by the GAVA to sort the IR library. Max. Length: 15 characters (letters, numbers, and underscores only). Manufacturer (optional) This is the device manufacturer’s name (e.g. Sony, Yamaha, etc).
  • Page 27 WEB INTERFACE Brow wse... Click this button to open a list of fi les on your computer to Upload. It will open the last selected folder on your computer with a default selection of All Files (*.*). Download IR File to PC Press this button to save the currently-displayed Device IR commands to an XML fi...

  • Page 28: Adding A New Ir Device

    WEB INTERFACE Adding a new IR Device The PACS can hold up to 20 IR devices in memory. Each device may have up to 64 Commands. If you are building a library, you may need to delete some devices from the PACS once they are learned and saved, to make room for more devices.
  • Page 29 WEB INTERFACE 10. Find the IR remote for the new device. Make sure the batteries are fresh! Hold the remote so it is pointing at the IR window on the PACS, and is about 6” away from the window. 11. Click the “Learn” button for the fi rst named Command. 12.
  • Page 30 WEB INTERFACE 14. If the commands match, the PACS will return to the main screen, and the new command will now be green. 15. If a code is learned incorrectly, you may overwrite it by repeating steps 11 - 13. The PACS will warn you that the command is already in memory, and ask you to confi...
  • Page 31 WEB INTERFACE <?xml version=”1.0” encoding=”UTF-8”?> <ir_emitter> <dn>Bedroom_DVD</dn> <class>Disc</class> <manufacturer>Sony</manufacturer> <model>BDPS580</model> <cs> <c> <cn>power_toggle</cn> <freq>1175</freq> <p_len>64</p_len> <p_dat>564 149 279 ... 149 137 5149 0</p_dat> <p_rep>1</p_rep> </c> <c> <cn>power_off</cn> <freq>1200</freq> <p_len>64</p_len> <p_dat>564 148 280 ... 136 5007 0</p_dat> <p_rep>1</p_rep> </c> <c> <cn>volume_up</cn> <freq>1200</freq>...

  • Page 32: Adding A New Ir Device From A Template

    Gefen’s GAVA Control System requires that IR commands have specifi c name conventions that are matched to the GAVA User Interface buttons, so Templates provide an easy way to ensure that new devices have the proper names.
  • Page 33 WEB INTERFACE Since this is a template fi le, the Command Names will be yellow, rather than green. This means that only the names, and not the IR data, have been stored. Click on the “Advanced View” button above the Command Name list. This adds the “Learn”...
  • Page 34 WEB INTERFACE 12. If the commands match, the PACS will prompt you for the next Command in the list. 13. If you are prompted for a command that does not exist on your remote, you can press the “SKIP Command” button, and you will be prompted for the next button on the list, or you can press “EXIT IR Learning”...
  • Page 35 WEB INTERFACE 18. You can delete any commands that are not available for that specifi c remote by clicking the “Delete” button for those commands. Deleted buttons will be removed when changes are saved. Un-learned template commands will be saved for later learning. 19.

  • Page 36: Triggers Menu

    WEB INTERFACE Triggers Menu The PACS provides ten (10) 12V triggers which can be used for controlling lighting system, curtains, motorized screens, or various automation devices. Each trigger can be confi gured separately. Trigger Buttons Click one of these buttons to name and confi...
  • Page 37 WEB INTERFACE Delete Save Changes Deletes the trigger Saves the trigger name and resets event. settings to default. Mode* Pulse Duration (ms) Sets the voltage mode Required when Trigger Type Options: Open Collector, is set to Pulse. Push/Pull. Range: 0 -10000. (1000 = 1 sec.) Default State Sets the default state...

  • Page 38: Testing Triggers

    WEB INTERFACE Testing Triggers Press the “Set High” or “Set Low” buttons to manually change the state of a trigger. If the “Type” is set to “Pulse”, the trigger output will revert to its default state after the Pulse Duration period has expired. Trigger State Trigger ID Indicates the current state of the trigger.

  • Page 39: Confi Guration Menu

    WEB INTERFACE Confi guration Menu The Confi guration Menu allows management of TCP/IP confi guration, login credentials, fi rmware upgrades, and system resets. IP Confi guration IP Address Sets the IP address. This must be a valid and unused address on your local network.
  • Page 40 WEB INTERFACE Subnet Gateway Sets the subnet mask. Sets the IP address of The default settings is your router (IP gateway). 255.255.255.0 Maximum value for each number is 255. Web UI Port Sets the HTTP listening port. The default setting Telnet Port is 80.

  • Page 41: Telnet Login Settings

    WEB INTERFACE Telnet Login Settings Force Password on Connect Display Welcome Message on Connect Forces password prompt when Displays a “Welcome to PACS Telnet connecting via Telnet. Server” message when Telnet connection opens. Save Changes Saves the current changes to the Telnet Login Settings. Password Sets the password.

  • Page 42: Firmware Update

    WEB INTERFACE Firmware Update Get Firmware Checks the Gefen Web site for the latest fi rmware. The current version of fi rmware is displayed above this button. Browse... Update Click the Browse... button to select the Click the Update button fi...

  • Page 43: System Reset

    WEB INTERFACE System Reset Yes To All Check this box to perform a System-Wide Reset during a reset procedure. Set Triggers To default Place a check mark in this box to set triggers to default settings when resetting the PACS. ATTENTION: A System-Wide Reset will delete all Commands and Device data, reset the IP address, and reset the PACS to factory (default) settings.
  • Page 44 WEB INTERFACE Delete IR Commands Place a check mark in the box to delete all learned IR commands during a reset. Delete IR Devices & Commands Place a check mark in the box to delete all IR devices and learned IR commands during a reset.

  • Page 45: System Settings

    WEB INTERFACE System Settings The System Settings section allows you to upload or restore a fi le containing all of the IP settings, RS-232 settings, trigger settings, and all IR fi les, devices, and commands. The default name of this XML fi le is “Settings_xml.gfn”. This fi...
  • Page 46 WEB INTERFACE It is important to understand that this XML fi le does not actually exist in the PACS. Rather, it is created “on-the-fl y” by the Web GUI when it is downloaded. When a new settings fi le is presented for an update, it is parsed by the PACS fi...

  • Page 47: Ip (Telnet) Control Setup

    IP (TELNET) CONTROL SETUP The PACS may be manually operated using the Web server Graphical User Interface (GUI), or by an automation system (such as the Gefen GAVA System) that is capable of sending Telnet serial commands to the PACS via IP.
  • Page 48 IP (TELNET) CONTROL SETUP Click “Save Settings”. Open HyperTerminal or another Terminal Emulation program on your computer. Open a new session with a Host Address that matches the IP address of the PACS, and set the Port Number to 49200. Type “help ?”...
  • Page 49 RS-232 / TELNET COMMANDS IP Confi guration Command Description #change_trig_state Changes the current trigger state #display_telnet_welcome Set Telnet welcome message on login #load_trig_params Loads trigger parameters from memory #save_trig_params Saves trigger parameters to memory #sgateway Sets the IP gateway address #set_http_port Sets the Web server listening port #sipadd...

  • Page 50: Change_Trig_State

    RS-232 / TELNET COMMANDS #change_trig_state Command The #change_trig_state command changes the current trigger state. Specify the trigger number and then the initial state (low or high) of the trigger. Syntax #change_trig_state param1 param2 Parameters: param1 Trigger [1 - 10] param2 State [0 - 1] State...

  • Page 51: Rs-232 / Telnet Commands

    RS-232 / TELNET COMMANDS #load_trig_params Command The #load_trig_params command loads trigger settings from the memory. Syntax #load_trig_params Parameters: None #save_trig_params Command The #save_trig_params command saves trigger settings to the memory. Syntax #save_trig_params Parameters: None #sgateway Command The #sgateway sets the IP gateway (router) address. Dot-decimal notation must be used when specifying the IP address.

  • Page 52: Set_Http_Port

    RS-232 / TELNET COMMANDS #set_http_port Command The #set_http_port command sets the Web server listening port. Syntax #set_http_port param1 Parameters: param1 Port [0 - 65535] Default: #sipadd Command The #sipadd command sets the IP address for the PACS. Dot-decimal nota- tion must be used when specifying the IP address. The default IP address is 192.168.1.72.

  • Page 53: Set_Pass

    RS-232 / TELNET COMMANDS #snetmask Command The #snetmask command sets the IP network mask. Dot-decimal notation must be used when specifying the IP network mask. The default network mask is 255.255.255.0 Syntax #snetmask param1 Parameters: param1 Network mask Default: 255.255.255.0 #set_pass Command The #set_pass command sets Telnet password.

  • Page 54: Set_Serial_Mode

    RS-232 / TELNET COMMANDS #set_serial_mode Command The #set_serial_mode command sets the specifi ed serial port mode. Syntax #set_serial_mode param1 param2 Parameters: param1 Serial port [1 - 3] param2 Mode [1 - 3] Mode Meaning Terminal* TCP Bridge UDP Bridge Example: #set_serial_mode 1 2 Default: Default is all ports in “TCP Bridge”...

  • Page 55: Set_Serial_Params

    RS-232 / TELNET COMMANDS #set_serial_params Command The #set_serial_params command sets the serial port parameters. Syntax #set_serial_params param1 param2 param3 param4 param5 param6 Parameters: param1 Serial port [1 - 3] param2 Word length [5 - 8] param3 Stop bits [1 - 2] param4 Parity Parity...

  • Page 56: Set_Telnet_Port

    RS-232 / TELNET COMMANDS #set_telnet_port Command The #set_telnet_port command sets the Telnet listening port. The default port value is 23. Syntax #set_telnet_port param1 Parameters: param1 Port [0 - 65535] #set_trig_params Command The #set_trig_params command sets the input trigger parameters. Syntax #set_trig_params param1 param2 param3 param4 Parameters: param1...

  • Page 57: Set_User_Name

    RS-232 / TELNET COMMANDS #set_user_name Command The #set_user_name command sets the Telnet user name. The maximum length of param1 is 20 characters. The user name is case-sensitive. Syntax #set_user_name param1 Parameters: param1 User name Default: Admin #show_pass Command The #show_pass command shows the Telnet password for login (if required). Syntax #show_pass Default:...
  • Page 58 RS-232 / TELNET COMMANDS #show_serial_connect Command The #show_serial_connect command displays the serial port connection status. Syntax #show_serial_connect Parameters: None Example: #show_serial_connect You are connected to Serial Port 3 Note: If you are connected via TCP, it will display: You are not connected to a Serial Port. #show_serial_mode Command The #show_serial_mode command displays the current serial port modes.

  • Page 59: Show_Serial_Params

    RS-232 / TELNET COMMANDS #show_serial_params Command The #show_serial_params command displays the specifi ed serial port parameters. Syntax #show_serial_params param1 Parameters: param1 Serial port [1 - 3] Example: #show_serial_params 1 Serial Port 1 parameters: Word length = 8 bits Stop bits = 1 bit Parity = No Baud rate = 19200 bps Line delay = 0 ms...

  • Page 60: Show_Trig_Params

    RS-232 / TELNET COMMANDS #show_trig_params Command The #show_trig_params command displays the current trigger parameters. param1 specifi es the trigger (1 - 10) to query. Set param1 to 0 to display the parameters for each of the 10 triggers. Syntax #show_trig_params param1 Parameters: param1 Trigger...

  • Page 61: System_Wide_Reset

    RS-232 / TELNET COMMANDS #system_wide_reset Command The #system_wide_reset command performs a system-wide reset. Each param- eter specifi es the hardware to reset. Syntax #system_wide_reset param1 Parameters: param1 Setting [0 - 6] Parity Meaning Reboot only Delete IP settings Delete Serial settings Delete IR devices and commands Delete IR commands...

  • Page 62: Bridging Settings

    RS-232 / TELNET COMMANDS Bridging Settings RS-232 Feedback and Delimiters One advantage of RS-232 serial control over IR control is that RS-232 offers 2-way communications between a device and the control system. This allows the controlled device to provide feedback to confi rm that its operating state matches the control system’s assumptions.
  • Page 63 RS-232 / TELNET COMMANDS Command Description #set_adddel Sets add delimiter mode #set_end_del Sets end-delimiter mode and value #set_send_byte_cnt Sets the end-delimiter mode and value #set_send_time_out Sets the time-out value for sending data collected from a device #set_start_del Sets start-delimiter mode and value #set_tcp_br_port Sets the TCP Bridge server listening port #set_udp_br_port...
  • Page 64 RS-232 / TELNET COMMANDS #set_end_del Command The #set_end_del command sets the end-delimiter mode and value. Syntax #set_end_del param1 param2 param3 Parameters: param1 Serial port [1 - 3] param2 On / Off [0 - 1] param3 Delimiter value [00 - FF] Example: #set_end_del 1 1 B0 Notes:...
  • Page 65 RS-232 / TELNET COMMANDS #set_send_time_out Command The #set_send_time_out command sets the timeout value for sending data collected from a device to the control system in Bridging Mode when a Start Delimiter and End Delimiter have been set. If no data has been collected for the specifi...
  • Page 66 RS-232 / TELNET COMMANDS #set_start_del Command The #set_start_del command sets the start-delimiter mode and value. Syntax #set_start_del param1 param2 param3 Parameters: param1 Serial port [1 - 3] param2 On / Off [0 - 1] param3 Delimiter value [00 - FF] Examples: #set_start_del 1 1 A0 #set_start_del 1 0...
  • Page 67 #set_tcp_br_port 49201 Default: TCP Bridge to Serial Port 1: 49200 TCP Bridge to Serial Port 2: 49201 TCP Bridge to Serial Port 3: 49202 Notes: Do not change the TCP Bridge server port values unless instructed by Gefen Technical Support.
  • Page 68 RS-232 / TELNET COMMANDS #set_udp_br_port Command The #set_udp_br_port command sets the UDP server listening port. Syntax #set_udp_br_port param1 param2 Parameters: param1 Port [1 - 3] param2 Port number [0 - 65535] Example: #set_udp_br_port 1 50200 Default: UDP Bridge to Serial Port 1: 50200 UDP Bridge to Serial Port 2: 50201 UDP Bridge to Serial Port 3: 50202 #set_udp_remote_br Command...

  • Page 69: Ir Device Setup

    RS-232 / TELNET COMMANDS IR Device Setup Command Description #add_class Specifi es the Class of the device #add_device Adds a new device #add_manufacturer Specifi es the Manufacturer for the device #add_mod_num Specifi es the Model Number for the device #delete_device Deletes a device from the PACS #delete_ir_cmd Deletes a device by removing it from the IR list...
  • Page 70 RS-232 / TELNET COMMANDS #add_device Command (required) The #add_device command adds a new device. The ADD_DEVICE command must be excuted before learning a new device. The Device Name must be alphanumeric characters and spaces, and is limited to 20 characters in length. (Note that spaces will be replaced with underscores (_) in the XML fi...
  • Page 71 RS-232 / TELNET COMMANDS #add_mod_num Command (optional) The #add_mod_num command adds or updates the “Model No.” tag for the specifi ed device. The “Model No.” tag is used by GAVA to identify devices, and along with the “Manufacturer” tags, may be helpful for users to identify their IR library fi...
  • Page 72 RS-232 / TELNET COMMANDS #delete_ir_cmd Command The #delete_ir_cmd command deletes the IR command from the specifi ed device. Syntax #delete_ir_cmd param1 param2 Parameters: param1 Command Name param2 Device Name Example: #delete_ir_cmd play SamsungTV IR Command play for device SamsungTV was removed from FLASH!
  • Page 73 RS-232 / TELNET COMMANDS #learn_ir_cmd Command The #learn_ir_cmd command initializes the learning of a new IR command. Syntax #learn_ir_cmd param1 param2 Parameters: param1 Command Name param2 Device Name Example: #learn_ir_cmd mute tv IR RMT Learning mode Press the desired RMT command mute for device tv Captured timing array 1 Cap timing array 1 end Press again the same RMT command...
  • Page 74 RS-232 / TELNET COMMANDS #play_ir_cmd Command The #play_ir_cmd command plays an IR command stored in memory. Syntax #play_ir_cmd param1 param2 param3 Parameters: param1 Command Name param2 Device Name param3 Emitter Port [0 - 8] Notes: Emitter Port 0 is all Ports. Multiple Emitter Port Numbers may be entered.
  • Page 75 RS-232 / TELNET COMMANDS #ren_cmd_name Command The #ren_cmd_name command renames the specifi ed IR command name. The IR command name must be alphanumeric characters and is limited to 20 characters in length. Spaces are not permitted when creating command names. Use the underscore character (“_”) if a space is required.
  • Page 76 RS-232 / TELNET COMMANDS #show_device_tags Command The #show_device_tags command shows the existing tags (Class, Manufacturer and Model Number) for a specifi ed Device. The Device Name is actually used by PACS to send an IR command. The additional tags are not required by PACS, but are used by GAVA, and may be helpful for users to keep their IR fi...
  • Page 77 RS-232 / TELNET COMMANDS #show_devices Command The #show_devices command displays all devices in the IR list. Syntax #show_devices Parameters: None Example: #show_devices Devices listed in system: Device #01: SamsungTV Device #02: panasonic Device #03: SonyDVD Device #04: Panasonic_Blu_ray Device #05: apple_ipod Device #06: dish_network Device #07: DirecTV...
  • Page 78 RS-232 / TELNET COMMANDS #show_ir_cmds Command The #show_ir_cmds command displays all IR commands for a stored device. Syntax #show_ir_cmds param1 Parameters: param1 Device Name Example: #show_ir_cmds tv Display IR commands for device tv: Command #01, power_toggle Command #02, channel_up Command #03, channel_down Command #04, volume_up Command #05, volume_down Command #06, mute...
  • Page 79 RS-232 / TELNET COMMANDS #show_ir_data Command The #show_ir_data command displays raw data from the memory. Syntax #show_ir_cmd param1 param2 Parameters: param1 Command Name param2 Device Name Example: #show_ir_data pwr tv Command: pwr for Device: tv Carrier frequency = 40.000 Khz Carrier value = 1200 Clock frequency = 48000000Hz Timer prescaler = 200...
  • Page 80 RS-232 / TELNET COMMANDS For remotes with toggle bits there will be additional data: Command: 9 for Device: tv Carrier frequency = 40.000 Khz Carrier value = 1200 Clock frequency = 48000000Hz Timer prescaler = 200 Timing Size = 52 Repeat Command = 1 Toggle Bits Data table:...

  • Page 81: General Query

    RS-232 / TELNET COMMANDS General Query Command Description #help Displays a complete list of commands #ipconfi g Displays all TCP/IP settings #show_ver_data Displays the PACS version information #help Command The #help command displays help on the specifi ed command. If param1 is not included, then the full list of commands is displayed.
  • Page 82 RS-232 / TELNET COMMANDS #ipconfi g Command The #ipconfi g displays all TCP/IP settings. Syntax #ipconfi g Parameters: None Example: #ipconfi g ------------- PACS TCP/IP settings ------------- MAC addr = 00:1C:91:02:20:00 IP addr = 192.168.1.72 Net Mask = 255.255.255.0 Gateway = 0.0.0.0 Web Server Port = 80 Telnet Server Port = 23...
  • Page 83 RS-232 / TELNET COMMANDS #show_ver_data Command The #show_ver_data command displays the PACS version information. Syntax #show_ver_data Parameters: None Example: #show_ver_data Hardware version 0 Firmware version 1.66 Release date Mar 29 2012 Release time 16:11:03...

  • Page 84: Appendix

    APPENDIX Controlling the PACS via RS-232 The PACS is generally intended to be controlled via IP, in order to control RS-232, IR, and trigger-operated devices that are connected to it. Under some circumstances, it may be useful to control the Mini PACS via an RS-232 port, such as to use the Mini PACS as an RS-232-to-IR or RS-232-to-trigger converter or if it is more convenient to use an RS-232 connection than an IP connection for confi...

  • Page 85: Learning Ir Commands Via Telnet

    APPENDIX Learning IR Commands via Telnet The PACS has eight (8) IR Emitter outputs. Each of these IR Emitters can be connected to device. The PACS can learn new IR commands and then send the learned IR command to any or all of the devices at once. The PACS can store commands for up to 20 devices.
  • Page 86 APPENDIX NOTE: If the PACS is unable to validate the IR command, the PACS will prompt you to repeat steps 4 and 5. If the IR command data is valid, then the IR command will be saved to memory. The PACS will ignore IR data that cannot be validated.

  • Page 87: Specifi Cations

    SPECIFICATIONS Output triggers......(10) Phoenix connectors (+12V DC, 100 mA max.) RS-232 serial ports................(3) DB-9, male IR ports............... (8) 3.5 mm mini-mono jacks Ethernet Port....................RJ-45 Power Supply....................12V DC Power Consumption..........20 W (max.)* / 2 W (standby) Operating Temperature................

  • Page 88: Warranty

    Gefen warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen is notifi ed within two (2) years from the date of shipment, Gefen will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifi...
  • Page 92 Rev A3 1.66 20600 Nordhoff St., Chatsworth CA 91311 1-800-545-6900 818-772-9100 fax: 818-772-9120 www.gefen.com support@gefen.com This product uses UL or CE listed power supplies.
