NOTE TO INSTALLER:
This manual should be left with the equip-
ment owner.
FOR YOUR SAFETY
Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
WARNING: Improper installation, ad-
justment, alteration, service or mainte-
nance can cause injury or property dam-
age. Refer to this manual. For assistance
or additional information, consult a quali-
fied installer, service agency, or the gas
supplier.
user's information manual
SINGLE PACKAGE GAS HEATING/
ELECTRIC COOLING UNITS
Cancels: New
FOR YOUR SAFETY
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
• If you cannot reach your gas supplier, call
the fire department.
WARNING: Before performing recom-
mended maintenance, be sure gas supply
and main power switch to unit are turned
off. Electrical shock could cause personal
injury.
Model PY1P
PY1P
Sizes 018-060
OM10-14
2/1/98
Advertisement
Table of Contents
Summary of Contents for Payne PY1P
- Page 1 Refer to this manual. For assistance mended maintenance, be sure gas supply or additional information, consult a quali- and main power switch to unit are turned fied installer, service agency, or the gas off. Electrical shock could cause personal supplier. injury. Model PY1P...
-
Page 2: To Light Unit
Your combination heating/cooling unit is equipped with an WARNING: automatic direct spark ignition and power combustion blower. 1. If the main burners fail to light, or the blower fails WARNING: Do not attempt to light by hand; per- to start, shut down gas heating section and call your sonal injury may result. -
Page 3: Routine Maintenance
Table 1 — Indoor-Air Filter Data BURNERS UNIT SIZE 018-024 030-036 048-060 PY1P Filter Size 20 x 20 20 x 24 24 x 24 24 x 30 Fig. 2 — Gas Heating/Electric Cooling Unit WARNING: Never operate your unit without filters Step 6 in place. - Page 4 STEP 3 STEP 1 STEP 2 STEP 5 STEP 4 STEP 6 STEP 7 STEP 10 STEP 9 STEP 8 Fig. 3 — To Light Unit —4—...
- Page 5 STEP 1 STEP 3 STEP 2 STEP 4 STEP 5 STEP 6 STEP 7 Fig. 4 — To Shut Unit Off —5—...
-
Page 6: Regular Dealer Maintenance
WARNING: Components in heat section may be hot after unit has been started up. When observing flame, be careful not to get close to or touch heating compo- nents or serious personal injury may result. Watch the burner flame to see if it is bright blue. If you observe a suspected malfunction or if the burner flames are not bright blue, call your dealer. -
Page 7: Before You Call For Service, Check For Several Easily-Solved Problems
BEFORE YOU CALL FOR SERVICE, CHECK FOR SEVERAL NOTE: Before proceeding with the next check, turn OFF the EASILY-SOLVED PROBLEMS gas supply, then the electrical power supply to the unit. Re- move the control access door. If insufficient heating or cooling is suspected: ( ) During the heating season, check the control dial on the internal gas valve. - Page 9 —9—...
