DOGIPARK DOGIFOUNTAIN 7751 Installation & Operation Manual

7751 DOGIPARK
PEDESTAL DOG DRINKING FOUNTAIN
Recommended Specifications
The 7751 DOGIPARK
®
drinking fountain is a single-level, vandal resistant drinking
fountain with Type 304 stainless steel 10" Schedule-10 main
column and 7 GA. flange.
Fountain shall have high-polished, 18 GA. stainless steel
bowl with anti-rotation, anti-squirt, solid stainless steel bub-
bler. Bubbler shall be activated by pedestal mounted solid
stainless steel foot-operated push button assembly, which
controls a lead-free, self-closing valve.
Standard Features
• Heavy duty Type 304 stainless steel 10" Schedule-10 main column and 7 GA. flange
• High polished stainless steel bowl
• Solid stainless steel, anti-rotation bubbler
• Serviceable mesh strainer on inlet water supply
• Resistant to sunlight, heat and vandalism
• Stainless steel adjustable push button
• Integral slow drain
1/2018
DOGIFOUNTAIN
®
DOGIFOUNTAIN pedestal dog
7751 COMES IN BLACK OR GREEN. CUSTOM COLORS MAY BE ORDERED
(SILVER, RED, BLUE, ORANGE, VIOLET, YELLOW, BROWN, BEIGE, WHITE).
CUSTOM ORDERS TAKE APPROXIMATELY 8-10 WEEKS.
www.DOGIPOT.com
2100 Principal Row • Suite 405 • Orlando, Florida 32837
407.888.4627 • Fax: 407.888.8526 • 800.364.7681
Push button shall require less than 5 lbs. of force to oper-
ate. Push button shall be adjustable to ensure adequate flow
without being wasteful. 7751 DOGIPARK
TAIN shall be lead-free, adhering to ANSI/NSF 61, Section
9, ANSI A117.1.
www.DOGIPARK.com
DOGIFOUN-
®
