Summary of Contents for TOUGH-WORKS SSA16V
- Page 1 SSA16V 16 IN. SCROLL SAW WITH PINLESS BLADE HOLDER IMPORTANT: INSTRUCTION For your own safety, read and follow all of the Safety Guidelines and Operating Instructions before operating MANUAL this product.
- Page 2 SSA16V BD4603 TABLE OF CONTENTS TABLE OF CONTENTS ....................SPECIFICATIONS ....................... SAFETY GUIDELINES ....................ELECTRICAL SAFETY ....................PACKAGE CONTENTS ....................KEY PARTS DIAGRAN....................A S S E M B L Y / M O U N T I N G ..................
- Page 3 SSA16V BD4603 serious injury. SAFETY GUIDELINES CAUTION WARNING Indicates a potentially hazardous situation Your power tool and its Instruction Manual which, if not avoided,may result in minor or may contain “WARNING ICONS”(a picture） moderate injury. symbol intended to alert you to and/or instruct...
- Page 4 SSA16V GENERAL SAFETY INSTRUCTIONS ALWAYS wear Safety Goggles (not BEFORE USING THIS POWER TOOL glasses) that comply with ANSI Safety Safety is a combination of common sense, standard Z87.1. Everyday eyeglasses staying alert and knowing how to use your have only impact–resistant lenses. They power tool.
-
Page 5: Specific Safety Rules
SSA16V 4. MAKE SURE THE WORK AREA HAS carefully checked to determine that it AMPLE LIGHTING will operate properly and perform its to see the work and that no obstructions will int- intended function– check for alignment erfere with safe operation BEFORE performing of moving parts, binding of moving parts, any work using the saw. - Page 6 SSA16V of power and the motor will overheat. If the EXTENSION CORDS saw does not operate when plugged into an Use only 3-wire extension cords that have 3-prong outlet, double check the power supply. grounding plugs and 3-pole receptacles that accept SPEED AND WIRING the tool's plug.
- Page 7 SSA16V Ground fault outlet Grounding pin Figure1...
- Page 8 SSA16V No. Description Qty. Scroll saw Blade(s) T-handle hex key...
- Page 9 SSA16V BD4603 H - Switch and switch key A - Blade tension knob I - Sawdust exhaust B - Drop foot lock knob J - Bevel lock knob C - Saw dust blower K - Bevel scale D - Saw blade...
- Page 10 SSA16V mped to a workbench or other supporting surface. The mounting board should be of sufficient size to avoid tipping of saw while in use. Any good grade Do not use this product if any parts on plywood or chipboard with a 3/4 in. thickness is re- the Loose Parts List are already asse- commended.
- Page 11 SSA16V DROP FOOT (In Figure 3） To prevent workpiece from lifting, the drop foot should be adjusted so it just rests on the 1. Bevel top of the workpiece. The drop foot should scale not be adjusted so that the workpiece drags.
- Page 12 SSA16V NOTE: Adjustments to blade tension can be made at any time.Check tension by the sound the blade makes when plucked like a guitar string. This method of adding tension to the blade can be developed with practice and requires knowing the scroll saw.
- Page 13 SSA16V BD4603 The blade teeth cut material only on the down ● stroke. Use gentle pressure and both hands when Do not allow familiarity with products to make ● feeding the work into the blade. Do not force you careless. Remember that a careless fra- the work.
- Page 14 SSA16V AVOIDING INJURY use and adjust the saw. Blades generally stay sharp for 1/2 hour to 2 hours of cutting, dep- Make sure saw is level and does not rock. Saw ● ending on the type of material and speed of...
- Page 15 SSA16V BD4603 Blades wear faster when: Turn the blade tension knob clockwise until the ● ● 1）Cutting plywood, hardwood, and other la- blade has the desired amount of tension. minates. Replace the throat plate. ● 2）Cutting material thicker than 3/4 in.
- Page 16 SSA16V BD4603 engaged in the blade without pushing it – the acked on top and secured to each other before workpiece could bind or twist the blade. cutting. The wood pieces may be joined to- gether by placing double sided tape between INTERIOR SCROLL CUTTING(In Figure 10）...
- Page 17 SSA16V BD4603 ARM BEARINGS(In Figure 12） Lubricate the arm bearings after the first 10 hours of use. Oil after every 50 hours of use When servicing, use only identical replace- or whenever there is a squeak coming from ment parts. Use of any other parts can create the bearings.
- Page 18 SSA16V Problem Possible Causes Likely Solutions Likely Solutions Problem Have worn parts replaced before using scroll saw Problem with ON-OFF switch, again. Have the proper outlet installed by a qualified Motor will not run power cord, or outlet. electrician. Do not attempt any repair. Have repaired by a Motor defective.
- Page 19 SSA16V BD4603...
- Page 20 SSA16V BD4603 Item Description Specification Qty Item Description 1 Philips Screw M5X8 41 Eccentric connector p 2 Handle 42 Philps screw 3 Side Cover Q235 43 Small spacer 4 Hex nut, I type 44 Hex screw+spring wa 5 Spring washer...
- Page 21 SSA16V BD4603 Specification Q235 Item Description Specification 23 Bellow Cover ST4.2X9.5 24 Philips Screw+spring washe 34 Blade holde Q235 Powder metal 25 Locking knob 35 Blade ( with pin) 15 TPI M5X16 26 Switch box cover 36 Hex screw M5X25...
- Page 22 SSA16V Item Description Specification 63 Work Table ZL105 5X28 64 Table insert 65 Variable speed Knob 66 Hex screw M5x6 i l i t a l 69 Hex screw M8X12 M6X20 70 Eccentric counter wheel Powder metal Washer 4 72 Switch Box...
- Page 23 SSA16V BD4603 ONE-YEAR LIMITED WARRANTY Having Problems ? Give us a chance to help you before returning this product info@toolots.com Email : After the phone：(844) 866-5687...
