Operating Instructions • Warning Information
Some dust created by power sanding, sawing, grinding, drilling, and
other construction activities contains chemicals known to cause
cancer, birth defects or other reproductive harm. Some examples of
these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement and other masonry
products, and
• arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you
do this type of work. To reduce your exposure to these chemicals:
work in a well ventilated area, and work with approved safety
equipment, such as those dust masks that are specially designed
to filter out microscopic particles.
SPECIFICATIONS
Free Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22,000 RPM
Horse Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0.45
Air Inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1/4" NPT
Collet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1/4"
Minimum Hose Size. . . . . . . . . . . . . . . . . . . . . . . . . . . 3/8" I.D.
Recommended Air Pressure . . . . . . . . . . . . . . . . . . . . . 90 psig
Average Air Consumption . . . . . . . . . . . . . . . . . . . . . . . . 3 CFM
Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7"
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.3 Lbs
CAT530
• Parts Breakdown
WARNING
WARNING
• MaxiMuM RPM of 22,000
• Max. aiR PRESSuRE:
90 PSIg, 6.2 bAR
ALWAYS ReAD
INSTRuCTIoNS beFoRe
uSINg PoWeR TooLS
ALWAYS WeAR
SAFeTY goggLeS
ALWAYS WeAR HeARINg
PRoTeCTIoN
AvoID PRoLoNgeD
exPoSuRe To vIbRATIoN
RATeD RPM oF THe
ACCeSSoRY MuST
RPM
RPM
RPM
exCeeD THe MAxIMuM
TooL RPM SHoWN
CAT530
Heavy Duty
Straight Die Grinder
Copyright © Professional Tool Products, 2014
All rights reserved
Rev. 10/2/14
Advertisement
Related Manuals for Cornwell Tools CAT530
Summary of Contents for Cornwell Tools CAT530
-
Page 1: Parts Breakdown
Horse Power........0.45 CAT530 Air Inlet ........1/4" NPT Collet . - Page 2 • use accessories rated at 22,000 RPM or more. sup p ly, drain hose of air pres s ure and de t ach tool from • use accessories recommended by Cornwell Tools. air sup p ly be f ore in s tall i ng, re m ov i ng or ad j ust i ng any • Never mount a grinding wheel, cut-off wheel, router...
- Page 3 PARTS BREAKDOWN - CAT530 Ref. # Item # DeSCRIPTIoN Ref. # Item # DeSCRIPTIoN RS31501 Screw 18 RS31518 Pin (2.5 x 6L) RS31502 O-Ring (P12) 19 RS288320 Rotor Blde RS31503 O-Ring (P8) 20 RS288321 Rotor RS31504 Air Regulator 21 RS31521 Cylinder RS31505 Spring 22 RS31522 Cone Muffler RS31506...
-
Page 4: Air Supply
THIS WARRANTY AND THE REMEDIES SET FORTH ABOVE ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, REMEDIES AND CONDITIONS, WHETHER ORAL OR WRITTEN, EXPRESS OR IMPLIED. CORNWELL SPECIFICALLY DISCLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUDING, TO THE EXTENT PERMITTED BY APPLICABLE LAW, ANY WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. IF CORNWELL CANNOT LAWFULLY DISCLAIM IMPLIED WARRANTIES UNDER THIS LIMITED WARRANTY, ALL SUCH IMPLIED WARRANTIES ARE LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY. IN NO EVENT SHALL CORNWELL BE LIABLE TO THE PURCHASER OR TO THE USER OF A CORNWELL PRODUCT FOR ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES BASED UPON BREACH OF WARRANTY, BREACH OF CONTRACT, NEGLIGENCE, TORT, OR ANY OTHER LEGAL THEORY. SUCH DAMAGES INCLUDE, WITHOUT LIMITATION, EXPENSES, LOST REVENUES, LOST SAVINGS, LOST PROFITS, OR ANY OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING FROM THE PURCHASE, USE OR INABILITY TO USE THE CORNWELL PRODUCT. Some states do not allow the exclusion or limitation of incidental or consequential damages or exclusions or limitation on the duration of implied warranties or conditions, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other rights that vary by state. Repair kits and replacement parts are available for many Cornwell products, regardless of whether or not the product is still covered by a warranty plan. CAT530 Rev. 10/2/14...
