- Page 1 USER / INSTALLER INSTRUCTION BOOKLET Please read the instructions before using the appliance MODEL: MAXI 60 GSF...
-
Page 2: Table Of Contents
CONTENTS Introduction..............Page 3 Service………..............Page 3 Safety (General) ............Page 4 & 5 Using the Oven…………………………………………………………Page 6 Using the Hotplate Burners………………………………………Page 7 Using the Grill…………………………………………………………..Page 7 Cleaning……………………………………………………………………Page 8 Installation……………………………………………………..Page 9 -11 LPG Conversion…………………………………………..………..Page 12 Technical Data………………………………………………..……Page 14 Specification……………………………………………………..…….Page 15... -
Page 3: Introduction
INTRODUCTION Thank you for choosing a STATESMAN appliance. IMPORTANT; before using your appliance, please read this manual carefully to assist safe and successful operation. I N S T A L L A T I O N ( S e e P a g e 9 ) This appliance is adjusted for use as stated on the data badge. -
Page 4: Safety (General)
This appliance must be installed and commissioned by a qualified person as • Statesman will not take any responsibility for damage caused by incorrect installation. Before installing this appliance, make sure that the gas and electricity supplies •... - Page 5 SAFETY CONTINUED When using the grill, the oven door should be kept open. • Never use steam cleaners for cleaning the appliance. • IF A REPAIR IS REQUIRED, ONLY GENUINE PARTS SHOULD BE USED AND ANY • WORK MUST BE CARRIED OUT BY A QUALIFIED ENGINEER. The installer of this appliance should read the installation instructions and should •...
-
Page 6: Using The Oven
USING THE OVEN O P E R A T I O N Open the door fully, push in and turn the oven control knob to max. Hold the control knob in and press the ignition button. Keep the oven control knob pressed in for a further 5 - 10 seconds before slowly releasing and turning to the desired temperature. -
Page 7: Using The Hotplate Burners
USING THE HOTPLATE BURNERS I G N I T I O N Push in and turn the selected control knob anticlockwise to the ‘full on’ position (as indicated by the flame symbols), whilst pressing the ignition button until the burner lights. -
Page 8: Cleaning
CLEANING I M P O R T A N T - Before any maintenance or cleaning can be carried out, the cooker must be un-plugged from the electricity supply. HOTPLATE BURNERS AND SPILLAGE TRAY AREA The hotplate tray is best cleaned when it is still warm as it is easier to remove spillages before it has cooled. -
Page 9: Installation
INSTALLATION I M P O R T A N T - Installation of this cooker must be carried out by qualified personnel. CLEARANCES COOKER HOOD Min.650mm with hood Min.700mm Min.110mm without hood Min.420mm O O O O O O Min. 2 mm This cooker may be fitted flush to the base units. - Page 10 VENTILATION REQUIREMENTS This appliance needs 2m /h of air per kw input. This appliance must not be installed in a bed sitting room of less than 20m or in a bathroom or shower room. If there are other fuel burning appliances in the same room, BS5440; Part2; 1989 should be consulted to determine the air vent requirements.
- Page 11 LEVELLING Place a spirit level on an oven pan or shelf and adjust the feet accordingly. Make sure that the appliance is stable and does not rock. GAS CONNECTION • Always grip the appliance inlet fitting firmly when fitting the hose to prevent any damage occurring. •...
-
Page 12: Lpg Conversion
The instructions must be followed, otherwise the guarantee is invalid. LPG CONVERSION This cooker has been pre-set for use on Natural Gas. A conversion kit is included for converting the appliance for use on LP Gas. This should only be carried out by a suitably qualified engineer. - Page 13 OVEN; the by-pass/simmer rate needs to be adjusted to ensure a sufficient maintenance rate to the burner once the oven temperature has been reached. Proceed as follows: 1. Light the oven and select 180 C. After a few minutes the oven will have reached the required temperature and the flame size will have decreased.
-
Page 14: Technical Data
TE CHN I CA L DA TA N a t G a s @ 2 0 m b a r G A S T Y P E - L P G - P r o p a n e @ 3 7 m b a r L P G - B u t a n e @ 2 8 . -
Page 15: Specification
SPE C IF I CA T ION INJECTOR DIAMETERS GAS TYPE Small Medium Large Oven Grill Burner Burner Burner Burner Burner G20 20mbar 0.72 0.97 1.15 G25 25mbar 0.72 0.94 1.25 G30 30mbar 0.65 0.85 0.76 0.68 G31 37mbar 0.65 0.85 0.76 0.68...
