AVR
Industrial-Grade High Efficiency A.C Voltage Regulator
USER'S MANUAL
OPTI-UPS International Corporation reserves the right to make engineering changes on all its products. Such
refinements may affect information given in the instructions. Therefore, USE ONLY THE INSTRUCTIONS THAT
ARE PACKED WITH THE PRODUCT.
WARNING: High voltages are present inside this unit during operation. Do not operate this unit unless all covers
are in place. Installation and servicing should only be done by qualified personnel.
- 1-
Advertisement
Table of Contents
Related Manuals for OPTI-UPS AVR
Summary of Contents for OPTI-UPS AVR
- Page 1 Industrial-Grade High Efficiency A.C Voltage Regulator USER’S MANUAL OPTI-UPS International Corporation reserves the right to make engineering changes on all its products. Such refinements may affect information given in the instructions. Therefore, USE ONLY THE INSTRUCTIONS THAT ARE PACKED WITH THE PRODUCT.
-
Page 2: Table Of Contents
CONTENTS 1- The Protection and Maintenance of AVR 2- Safety warnings 3- Description of the symbols used in this manual 4- Introduction 5- Functions Introduction 6- Preliminary warnings to use the AVR 7- Operating procedures 8- The Operation Procedures of Maintenance By Pass Switch 9- Maintenance &... -
Page 3: 1- The Protection And Maintenance Of Avr
The Protection and Maintenance of AVR 1. Please clean and maintain the AVR periodically to keep from dust for lasting machine life. 2. Please use soft cloth for wiping, and please don’t use sandpaper as detergent. 3.Please check every kind of connection wires every month periodically to prevent the loosing or abrasion. -
Page 4: 2- Safety Warnings
- Read the instructions carefully in the “The Operation Procedures of Maintenance By Pass Switch” & “Cleaning” section when cleaning the AVR. - Leave at least a distance of 45 cm between the AVR and the walls in order to maintain adequate air-flow . -
Page 5: 3- Description Of The Symbols Used In This Manual
The following symbols have been used in this manual. This symbol gives information regarding points important for user’s own health and safety, AVR operation and the safety of your data. This symbol gives information, warnings, and other suggestions. This symbol shows the operations that need to be executed. -
Page 6: 4- Introduction
4- Introduction Input power is applied across the motor driven variable transformer which has a “center tap” that divides the variable transformer into bucking and boosting voltage areas.The buck-boost transformer is a fixed ratio isolation transformer capable of high amperes at low voltage. The ratio of the buck-boost transformer is determined by the amount of voltage needed to buck or boost the input line voltage to maintain the specified output level. -
Page 7: 5- Functions Introduction
Related points for human health are mentioned in “Safety Warnings” part of this manual. In this part, these points will repeated to give information about the connections of AVR and the load. -
Page 8: 7- Operating Procedures 8~9
4. The utmost importance to install a three phase AVR is to mark sure of the right phase order. 5. For safely consideration, it is strictly forbidden to install with AC power “On” status. - Page 9 Before switch on(initial start) In order to perfect the AVR normal function, please check the followings in advance: make sure MCCB(1)、MCCB(2) Mold cast circuit breaker is in “Off” status. make sure all of the load’s Mold cast circuit breaker are in “Off” status.
-
Page 10: 8- The Operation Procedures Of Maintenance By Pass Switch
Check the area surrounding the AVR. Ensure the area is not cluttered, allowing free access to the unit. Ensure the air intakes (vents on the front doors) and exhaust opening (on rear of the AVR cabinet sections) are not blocked. -
Page 11: 10- Trouble Shooting Guide
Adjust and tighten as needed. -Lubrication of the AVR is not required since it has been lubricated at the factory for its lifetime. 10- Trouble shooting Guide... -
Page 12: 12- Technical Specifications
12. Technical specifications Input Characteristics Capacity: 30 KVA Voltage Range: 380Y/220 Volt, +15% to - 15% at 50 Hz for regulation. Phases: Three phases-4 wire ,Wye connection(R,S,T,N,G) Frequency Range: 47-53Hz for 50Hz models +/-3Hz Termination terminal block terminal board Output Characteristics Voltage: 380Y/220 Volt Phases:... - Page 13 [Front view] [Right side view] [Three-D view] Page 1...
- Page 14 Lifting lugs Variable transformer Push botton Buck-boost transformer Main MCCB Control board Bypass MCCB Magnetic contact Fuse Mold cast circuit Input/Output breaker (MCCB) terminal board Conduit entrance Enclose mounting holes Page2...
- Page 15 Input Output Input/Output terminal board Cable Cable Output Input conduit entrance conduit entrance Page 3...
- Page 16 Main MCCB On Main MCCB Off Bypass MCCB On Bypass MCCB Off Page 4...
- Page 17 Fuse Page 5...
- Page 18 AVR control board U PHASE V PHASE W PHASE Output voltage adjust Page 6...
- Page 19 Min 450mm Min 450mm Page 7...
