PRODUCT OVERVIEW: FRONT
IR LED
During is poor light or night, the IR LED will improve the environmental brightness
LIGHT SENSOR
This sensor enables the infrared light when the illumina on is below 2 Lux
MICROPHONE
The Mic captures voice and sounds
PUSH BUTTON
When this bu on is pressed, the doorbell rings, the internal chime sounds and a push
no fica on is sent to your phone.
PIR
This sensor detects movement and will send a push no fica on to your phone.
LENS
This captures all imagery. Please keep it clean.
INDICATOR
Flashing RED slowly: Wai ng for Wi-Fi Configura on
LIGHT
Flashing BLUE slowly: The doorbell is working
Flashing RED/BLUE off and on: Wi-Fi Connec on Fail
SPEAKER
Emits sounds and voice via Intercom func on.
PRODUCT OVERVIEW: BACK
Smart Wireless Video Doorbell Model SH343
Installa on Guide
Advertisement
Summary of Contents for EZView SH343
- Page 1 Installa on Guide Smart Wireless Video Doorbell Model SH343 PRODUCT OVERVIEW: FRONT IR LED During is poor light or night, the IR LED will improve the environmental brightness LIGHT SENSOR This sensor enables the infrared light when the illumina on is below 2 Lux...
- Page 2 Installa on Guide Smart Wireless Video Doorbell SH343 Use this USB port to charge the ba eries in your device AC INPUT Use these connec ons to power your device if your have permanent power available RESET BUTTON Press this bu on during original setup, or press and hold for 5 sec to restore default BATTERY Ba ery compartment.
- Page 3 Installa on Guide Smart Wireless Video Doorbell SH343 PREPARE THE DOORBELL FOR USE—Con nued Inser ng your TF card into the TF card slot. Flip the doorbell upside down so the back is facing you. Remove the 4 x small screws in each corner on the back of the doorbell.
- Page 4 Installa on Guide Smart Wireless Video Doorbell SH343 PREPARE THE DOORBELL FOR USE—Con nued Locate the TF card slot which is under the bo om le corner of the circuit board. Insert your TF card into the TF card slot with the TF card connectors facing up and slide the TF card in slowly un l it “clicks”...
- Page 5 Installa on Guide Smart Wireless Video Doorbell SH343 INSTALL AND CONNECT THE MOBILE APP—Con nued Now you will see the Connec on Screen on your phone. Select the ENTER THE CONFIGURATION INTERFACE icon You will now see the list of Wi-Fi devices within range of your phone.
- Page 6 Installa on Guide Smart Wireless Video Doorbell SH343 INSTALL AND CONNECT THE MOBILE APP—Con nued CONGRATULATIONS. You have completed the doorbell / phone App setup. Give the doorbell a relevant name such as “Front of House” or “Back door” Then press CONFIRM.
- Page 7 Installa on Guide Smart Wireless Video Doorbell SH343 MOUNTING THE DOORBELL Using the back plate as a template, mark the 4 x holes on your wall. Posi on the doorbell in such a loca on such that the lens is facing the average visitor’s face.
- Page 8 Installa on Guide Smart Wireless Video Doorbell SH343 ACTUAL PHOTOS OF THE SMART WIRELESS DOORBELL—SH346...
- Page 9 Installa on Guide Smart Wireless Video Doorbell SH343 Q: The device cannot connect to WiFi. 1. Please confirm that the wireless network to be connected is 2.4G protocol. This device is NOT compa ble with 5G. 2. Make sure that the LED on the front of the doorbell is in the “red light flashing slowly state”.
