PTW20 Degas
Freestanding 20 - Bottles Thermoelectric Winecellar
REMINDER:
This unit is best suited to
be used in an environment
temperature of 25-27
Please refer to the instruction manual
℃
KEEP IN A SAFETY PLACE
Before operating this winecellar,
Please read the instruction carefully
℃
25
to
℃
27
environment
Advertisement
Table of Contents
Related Manuals for Pacifica Degas PTW20
Summary of Contents for Pacifica Degas PTW20
- Page 1 PTW20 Degas Freestanding 20 - Bottles Thermoelectric Winecellar REMINDER: ℃ This unit is best suited to be used in an environment ℃ ℃ temperature of 25-27 environment Please refer to the instruction manual KEEP IN A SAFETY PLACE Before operating this winecellar, Please read the instruction carefully...
- Page 2 Index Congratulations! Your purchase of a PACIFICA® product attests to the importance you place upon the quality and performance of the major appliances you use. With minimal care, as outlined in this guide, your product is designed to provide you with years of reliable service. Please take a few minutes to learn about its proper and efficient use and care.
-
Page 3: Table Of Contents
Content Structure ………………………………………………. Technical Data …….……………………………………. Important Safety Instructions ……………...……..Installation Instructions ………………………………… Electrical Connection ….………………………………. Built-in Measurements ………………………………….. Operating Instructions …….…………………………… Care and Maintenance ………………………………… Troubleshooting ……..…………………………………. -
Page 4: Structure
Structure 1. Hinge 7. Adjustable stand 2. Light 8. Air chamber 3. Temperature controller 9. Door frame 4. Temperature display 10. Glass 5. Fan grille 11. Door handle 6. Shelf Technical Data Electric Circuit Diagram:... -
Page 5: Important Safety Instructions
PTW20 Model no. Capacity Voltage 220-240V Current 1A (25℃/77℉) SN;N;T Climate class 140W Input power Power Consumption 1.2(15℃/59°F) (KW.h/24h) ﹥18℃(64°F) Max Temperature Difference Temperature Control Range 12-18℃/15-18℃ 21.4kg Net weight 23.5kg Gross weight 34.0×84.0×51.5 CM Product size(W×H×D) 38.2×87.0×55.0 CM Packing size(W×H×D) Important Safety Instructions To reduce the risk of fire, electrical shock, or injury when using your appliance, please... -
Page 6: Installation Instructions
Installation Instructions Before using this wine cellar, ensure the followings is take care of: • Remove the exterior and interior packing • Check the following parts are properly fixed: 5 Sliding shelves. Instruction manual is provided. • Before connecting the appliance to the power source, after 2 hours upright position. This will reduce the possibility of a malfunction in the cooling system after the fluctuating transportation and installation phase. -
Page 7: Built-In Measurements
Built Under Installation for Thermoelectric Cellar Please provide sufficient spacing gap between left & right 40mm (4cm), height 870mm (87cm), behind 50mm (5cm) from the wall. -
Page 8: Operating Instructions
Operating Instructions It is recommended that you installed the wine cellar in a place best with ambient temperature is between 25 C - 27 C (77 F - 80.6 • If the ambient temperature is above recommended temperature, the performance of the unit may be able to reach below 16 C. -
Page 9: Troubleshooting
Troubleshooting PROBLEM POSSIBLE CAUSE REMEDIES The plug is not plugged in. Insert the plug into the socket. Wine cellar The local power supply is different from the Call the customer service for futher advice. does not operate. appliance’s requirement. The circuit breaker Call the customer service for repairing appointment. - Page 10 Menara Lien Hoe (HQ) Lot 18.2, 18th Floor, Menara Lien Hoe, 8, Persiaran Tropicana, 47410 Petaling Jaya, Selango...
