Page 1 Gremo 1050 Service and maintenance manual Applies to serial numbers 41101, 51102, 61101– Gremo AB 311 51 Ätran Sweden Release Tel. +46 346–60515 Service and maintenance Fax. +46 346–60342 manual in original www.gremo.com 1050F 04EN info@gremo.se ©Gremo 2019...
Page 3: Table Of Contents
Contents Gremo1050F4 Service and maintenance manual 1 Service and maintenance ......1 2.12 Fault report 500 h Copy Customer's Copies..........65 1.1 Safety rules during service ....1 2.13 Report, service during the 1.2 Service and maintenance ....3 warranty period after 1,000 hours of 1.3 Volume specifications .......
Page 4 Contents Gremo1050F4 Service and maintenance manual 2.33 Fault report 2,500 h....... 88 2.44 Report, service during the warranty 2.34 Report, service during the period after 3,500 hours of operation warranty period after 2,500 hours of (cont'd.) .......... 99 operation Copy Customer's 2.45 Fault report 3,500 h.....
Page 5: Service And Maintenance
Gremo1050F4 Service and maintenance manual 1 Service and maintenance 1.1 Safety rules during service 1 Service and maintenance 1.1 Safety rules during service NOTICE Read all signs and instructions on the machine and in the safety regulations in the Instruction Manual before you start servicing the machine.
Page 6 1 Service and maintenance Gremo1050F4 Service and maintenance 1.1 Safety rules during service manual WARNING During all work on the machine, remember the risk of slipping. You should always use a safety helmet, safety goggles, gloves, safety boots, breathing protection and other necessary protective equipment when required.
Page 7: Service And Maintenance
Gremo1050F4 Service and maintenance manual 1 Service and maintenance 1.2 Service and maintenance 1.2 Service and maintenance Preventive maintenance measures are divided into time intervals: daily checks (every 8-10 operating hours), weekly checks every 50 operating hours and checks every 500, 1,000, 2,000 and 5,000 operating hours.
Page 8: Volume Specifications
1 Service and maintenance Gremo1050F4 Service and maintenance 1.3 Volume specifications manual 1.3 Volume specifications Part Total volume Replacement volume Engine 11 litres (including filter 10 litres (without filter replacement) *) replacement) Cooling system approx. 20 litres 15 litres Hub reductions 2.4 litres x 8 2.4 litres x 8 Differential...
Page 9: Oil, Requirement Specification
Gremo1050F4 Service and maintenance manual 1 Service and maintenance 1.5 Oil, requirement specification • Use protective gloves! Wash your hands before putting the gloves on. A protective cream on your hands will make it easier to clean them later. • Don’t keep any oil-stained rags in your pockets! •...
Page 10 1 Service and maintenance Gremo1050F4 Service and maintenance 1.5 Oil, requirement specification manual Part Oil/lubricant Differential cases, Bogie cases Gearbox Crane base Hydraulic system MOTOREX COREX HV 46 Cab tilt pump TEXACO Rando Ashless 8401 Articulated joint For maximum bearing life, use LGHB204 grease for all articulated joints.
Page 11: Antifreeze, Requirement Specification
Gremo1050F4 Service and maintenance manual 1 Service and maintenance 1.6 Antifreeze, requirement specification 1.6 Antifreeze, requirement specification Approved antifreeze is propylene glycol. NOTICE Do not mix ethylene glycol and propylene glycol. If you have the slightest doubt, pour out, clean and refill with a new mixture.
Page 12: Fuel, Requirement Specification
1 Service and maintenance Gremo1050F4 Service and maintenance 1.7 Fuel, requirement specification manual 1.7 Fuel, requirement specification Engines should be run on commercial diesel fuel which meets the manufacturer's specifications, see sub- supplier's documentation for diesel engine. NOTICE It is important to only use fuel that meets the standards specified.
Page 13: Cleaning Of Safety Glass Windows
Gremo1050F4 Service and maintenance manual 1 Service and maintenance 1.8 Cleaning of Safety Glass Windows 1.8 Cleaning of Safety Glass Windows 1.8.1 Cleaning Wash the window with lukewarm water and a mild neutral detergent. Use washing-up detergent or a similar soap- based detergent.
Page 14: Welding Repairs
Never carry out any welding repairs on frames, articulated joint or crane without first contacting an authorised service dealer or the service department at Gremo AB. NOTICE Always bear in mind the danger of fire. Always keep a hand-held fire extinguisher within reach!
Page 15 Gremo1050F4 Service and maintenance manual 1 Service and maintenance 1.9 Welding Repairs NOTICE Remember that welding close to the fire extinguishing system’s detector coil may cause it to burn off and release the contents of the fire extinguisher tank! In order to ensure that the fire extinguisher tank is not accidentally deployed, fit the safety screw.
Page 16: Tyres - Air Pressure: Manufacturer's Recommendations
If there is a change to a different version of tyre or wheel rim, a different tyre pressure may apply — contact Gremo. Danger! To avoid serious accidents, always follow directions for inflating tyres.
Page 17 500 kPa 2 16 100 kPa = 1 bar All tyres are from the factory (Gremo) and inflated to 450 kPa. The minimum pressure is approximately 50 kPa below the stated values and the maximum pressure is around 50 kPa above the stated values.
Page 18 1.10.1 Filling of fluid in forestry tyres The tyres can be filled with fluid to increase the machine’s stability and traction Gremo recommends filling 50% of the tyres’ volume. Maximum permitted is 75%. The fluid should consist of water. At temperatures below Fig.
Page 19 Gremo1050F4 Service and maintenance manual 1 Service and maintenance 1.10 Tyres — Air pressure: Manufacturer’s recommendations By turning the wheel and pressing in the valve needle, it is easily possible to determine whether the tyre is filled to 75% or 50% fluid. Calcium chloride increases the fluid’s density by up to 1.2 kg/litre in a 35% blend.
Page 20: Daily Maintenance (Every 8-10 Operating Hours)
1 Service and maintenance Gremo1050F4 Service and maintenance 1.11 Daily maintenance (every 8-10 operating manual hours) 1.11 Daily maintenance (every 8-10 operating hours) 1.11.1 Lubrication Fig. 3 L = Lubricate= Lubricate Pos. Lubrication point Nipples Comments/reference Support bearing, propeller Drawn out to the left-hand lubrication point shaft at the side.
Page 21 Gremo1050F4 Service and maintenance manual 1 Service and maintenance 1.11 Daily maintenance (every 8-10 operating hours) 1.11.2 Check Fig. 4 C = Check Component Reference Diesel engine: lubricating oil level with dipstick. Coolant level in radiator. Diesel engine’s crankcase ventilation. Check that it is free from dirt and ice, free exit of air! Drain the fuel prefilter when indicated in...
Page 22 1 Service and maintenance Gremo1050F4 Service and maintenance 1.11 Daily maintenance (every 8-10 operating manual hours) Component Reference Tyres, general condition, visual check See 1.10 Tyres — Air pressure: Manufacturer’s recommendations, page 12. The machine’s various fluid sub-systems See Driving instructions, checks before with regard to leakage.
Page 23: Inspection Every 50 Hours Of Operation Or Every Week
Gremo1050F4 Service and maintenance manual 1 Service and maintenance 1.12 Inspection every 50 hours of operation or every week 1.12 Inspection every 50 hours of operation or every week 1.12.1 Lubrication Fig. 5 L = Lubricate Pos. Lubrication point Nipples Comments/reference Bogie, bearings front and back.
Page 24 1 Service and maintenance Gremo1050F4 Service and maintenance 1.12 Inspection every 50 hours of operation or manual every week Pos. Lubrication point Nipples Comments/reference Universal joint (front) Universal joint (rear) Universal joint (rear), intermediate axle Universal joint (front), intermediate axle Bogie cylinder, Piston rod Bogie cylinder, cylinder housing ear...
Page 25 Gremo1050F4 Service and maintenance manual 1 Service and maintenance 1.12 Inspection every 50 hours of operation or every week Pos. Lubrication point Nipples Comments/reference See also sub-supplier documentation for each crane. Grapple Cranab CR280 See also sub-supplier documentation for each grapple. Grapple Hultdins SPG260 Grapple Hassela 028 Claw coupling, winch...
Page 26 1 Service and maintenance Gremo1050F4 Service and maintenance 1.12 Inspection every 50 hours of operation or manual every week 1.12.2 Check Fig. 6 C = Check Pos. Component Reference/Measure Drive belt, (wear etc.) Wheel bolts Torque for M22 920 Nm Oil level in the crane base See also sub-supplier documentation for each crane.
Page 27 Gremo1050F4 Service and maintenance manual 1 Service and maintenance 1.12 Inspection every 50 hours of operation or every week Pos. Component Reference/Measure - and that detector pressure is at least 15 bar (green area). Oil level in the winch gearbox, in continual See 1.13.15 Winch, page 52.
Page 28: Inspection Every 500 Hours Of Operation Or Every Three Months
1 Service and maintenance Gremo1050F4 Service and maintenance 1.13 Inspection every 500 hours of operation or manual every three months 1.13 Inspection every 500 hours of operation or every three months 1.13.1 Lubrication Fig. 7 L = Lubricate Pos. Lubrication point Nipples Comments/reference Gate cylinder rear articulated...
Page 29 Gremo1050F4 Service and maintenance manual 1 Service and maintenance 1.13 Inspection every 500 hours of operation or every three months 1.13.2 Change Oil — Filters Fig. 8 R = Replace Pos. System Part Action Reference Engine Lubrication system Engine oil 11 litres See 1.13.4 Replacing (including...
Page 30 1 Service and maintenance Gremo1050F4 Service and maintenance 1.13 Inspection every 500 hours of operation or manual every three months Pos. System Part Action Reference clogged with dirt or every alternate air filter replacement. Crankcase ventilation Every 2,000th hour of operation. See sub-supplier documentation for Replacement of crankcase filters...
Page 31 Gremo1050F4 Service and maintenance manual 1 Service and maintenance 1.13 Inspection every 500 hours of operation or every three months Pos. System Part Action Reference Crane control levers Pilot filter Replace- See Replacing pilot ment filter crane control, page 44. Every 1,000th hour of...
Page 32 1 Service and maintenance Gremo1050F4 Service and maintenance 1.13 Inspection every 500 hours of operation or manual every three months 1.13.3 Check/adjust/replace Fig. 9 C = Check Pos. System Action Reference Hub reductions Checking oil level See Hub reduction, page 51. Differentials Checking oil level See The differential, page 51.
Page 33 Gremo1050F4 Service and maintenance manual 1 Service and maintenance 1.13 Inspection every 500 hours of operation or every three months Pos. System Action Reference Hydraulic oil Check condition of see Sampling and analysis of condition of hydraulic oil/Replace hydraulic oil, page 41 hydraulic oil and Changing hydraulic oil, page 42.
Page 34 1 Service and maintenance Gremo1050F4 Service and maintenance 1.13 Inspection every 500 hours of operation or manual every three months 1.13.4 Replacing oil 1. Warm the engine until the coolant temperature is 60°C. 2. Park the machine on a level surface. 3.
Page 35 Gremo1050F4 Service and maintenance manual 1 Service and maintenance 1.13 Inspection every 500 hours of operation or every three months Fig. 13 Oil dipstick Oil level too high Correct engine oil level Oil level too low 10. Start the engine, let it run at idling speed and check the oil plug and oil filter for any leaks.
Page 36 1 Service and maintenance Gremo1050F4 Service and maintenance 1.13 Inspection every 500 hours of operation or manual every three months 6. Lightly lubricate the O-ring and sealing surface of the new oil filter with clean oil. 7. Screw in the filter by hand until the O-ring comes into contact with the filter head.
Page 37 Gremo1050F4 Service and maintenance manual 1 Service and maintenance 1.13 Inspection every 500 hours of operation or every three months 1.13.7 Replacing fuel prefilters 1. Stop the engine. G0645 2. Put a container under the filter to collect the fuel. 3.
Page 38 1 Service and maintenance Gremo1050F4 Service and maintenance 1.13 Inspection every 500 hours of operation or manual every three months 1.13.9 Cooling system Coolant, draining 1. Switch off the engine and cut the main power supply. 2. Remove the filler cap from the cooling system’s expansion tank.
Page 39 Gremo1050F4 Service and maintenance manual 1 Service and maintenance 1.13 Inspection every 500 hours of operation or every three months 6. Pour the coolant into the expansion tank’s filling opening so that the level reaches the middle of the sight glass. The engine must not be started until the system has been bled and is completely filled.
Page 40 1 Service and maintenance Gremo1050F4 Service and maintenance 1.13 Inspection every 500 hours of operation or manual every three months Coolant, filling NOTICE It is vital that the system is filled with the right concentration and volume of coolant. Mix it in a separate clean container before filling the cooling system.
Page 41 Gremo1050F4 Service and maintenance manual 1 Service and maintenance 1.13 Inspection every 500 hours of operation or every three months 1.13.10 Air conditioning system Replacing fresh air filter The air conditioning system's fresh air filter is located on the left-hand side of the cab, behind the rear side hatch. Fold down the rear side hatch (1) and open the cover (2) protecting the fresh air filter.
Page 42 1 Service and maintenance Gremo1050F4 Service and maintenance 1.13 Inspection every 500 hours of operation or manual every three months 1.13.11 Air filtration system Replacing filter cartridges and safety filters Fig. 28 Air filtration system Air filter indicator Outer air filter, filter cartridge Air filter holder Filter cover...
Page 43 Gremo1050F4 Service and maintenance manual 1 Service and maintenance 1.13 Inspection every 500 hours of operation or every three months air and cause damage. Remove and clean parts if necessary.
Page 44 1 Service and maintenance Gremo1050F4 Service and maintenance 1.13 Inspection every 500 hours of operation or manual every three months 1.13.12 Intercooler Intercooler, inspection Check that the intercooler’s cooling fins are not blocked by dust or rubbish, and clean if necessary with compressed air.
Page 45 Hydraulic system Hydraulic oil Sampling and analysis of condition of hydraulic Gremo recommends that the condition of the hydraulic oil is checked by means of oil sampling every 1,000 operating hours during the entire lifetime of the machine. This is to minimise the number of oil changes, maximise performance and minimise maintenance costs.
Page 46 1 Service and maintenance Gremo1050F4 Service and maintenance 1.13 Inspection every 500 hours of operation or manual every three months Changing hydraulic oil 1. Loosen the left-hand side guard under the hydraulic tank. 2. In the chassis there is a 1/2" hydraulic hose connected to the bottom of the hydraulic tank and plugged into the free end.
Page 47 Gremo1050F4 Service and maintenance manual 1 Service and maintenance 1.13 Inspection every 500 hours of operation or every three months Breather filter hydraulic oil tank Replacement of breather filters Replacing breather filter (H), hydraulic oil tank 1. Switch off the engine and cut the main power supply. 2.
Page 48 1 Service and maintenance Gremo1050F4 Service and maintenance 1.13 Inspection every 500 hours of operation or manual every three months Replacing pilot filter crane control 1. The engine and main power switch must be turned off. 2. Place a container under the filter. 3.
Page 49 1.13.14 Transmission system and gearbox General Component position The gearbox in Gremo 1050F4 is a mechanical transmission dropbox with two speed registers. The gearbox has two gears and develops a variable torque that is easily controlled using the potentiometer in the left panel.
Page 50 1 Service and maintenance Gremo1050F4 Service and maintenance 1.13 Inspection every 500 hours of operation or manual every three months Transmission oil, change and level check NOTICE The transmission should never be overfilled! See Fig. 37 Gearbox, page 45. 1. Run the engine until the transmission oil is hot. 2.
Page 51 Gremo1050F4 Service and maintenance manual 1 Service and maintenance 1.13 Inspection every 500 hours of operation or every three months Bogie axle Component position Fig. 39 Bogie axle, component position Drain and level control plug Bleeding Drain plug...
Page 52 1 Service and maintenance Gremo1050F4 Service and maintenance 1.13 Inspection every 500 hours of operation or manual every three months Fig. 40 Bogie axle, component position Drain and level control plug Connection for hydraulically operated differential lock (working pressure 15-30 Bleeding bar) Grease nipple...
Page 53 Gremo1050F4 Service and maintenance manual 1 Service and maintenance 1.13 Inspection every 500 hours of operation or every three months Fig. 42 Bogie axle, component position Sensor, all-wheel drive Release pressure all-wheel drive (10-30 bar) Filling and level control plug Connection pressure all-wheel drive (10- Hydraulic engine 30 bar)
Page 54 1 Service and maintenance Gremo1050F4 Service and maintenance 1.13 Inspection every 500 hours of operation or manual every three months Fig. 43 Bogie axle, component position Connection for hydraulic gear 1 (requires Sensors, gear indication pressure of 12-35 bar) Manual control of neutral position Connection for hydraulic gear 2 (requires Drain plug pressure of 12-35 bar)
Page 55 Gremo1050F4 Service and maintenance manual 1 Service and maintenance 1.13 Inspection every 500 hours of operation or every three months Oil level check in bogie axles Level check Each bogie axle has seven separate sections containing oil where the oil level must be checked separately. (4 hub reductions, 2 bogie housings and the differential) See Fig.
Page 56 1 Service and maintenance Gremo1050F4 Service and maintenance 1.13 Inspection every 500 hours of operation or manual every three months 1.13.15 Winch Winch gearbox, level check of gear oil The oil level in the winch gearbox is checked by means of the plug (1).
Page 57: Service And Maintenance During The Warranty Period
Service and maintenance during the warranty period This chapter contains: 1. Service and maintenance during the warranty period 2. Warranty service reports and Error report forms...
Page 58: Report, Service During The Warranty Period After 100 Hours Of Operation
2.1 Report, service during the warranty period after 100 hours of operation Machine information Telephone number Machine number: Machine: _____________________________ _____________________________ Operator: Machine owner Replacement Check Oil level, diesel engine, see 1.11 Daily maintenance Fuel filter (every 8-10 operating hours), page 16 Coolant level, see 1.11 Daily maintenance (every 8- Fuel prefilter 10 operating hours), page 16...
Page 59: Report, Service During The Warranty Period After 100 Hours Of Operation (Cont'd.)
Tightening the screw joints Service performed date: ____________________________ Sign-off for Warranty Service 100 h in GreControl Service performed by: ________________________________ The report must be submitted to: Authorised service dealer Gremo AB, FAO: SERVICE Service approved: _________________________ Box 51 Customer signature 311 51 ÄTRAN...
Page 60: Fault Report 100 H
2 Service and maintenance during the Gremo1050F4 Service and maintenance warranty period manual 2.3 Fault report 100 h 2.3 Fault report 100 h Machine information Machine number: ________________________________ Machine owner Electrical system: Hydraulics: Hoses: Tyres: Chassis: Miscellaneous:...
Page 61: Report, Service During The Warranty Period After 100 Hours Of Operation Copy Customer's Copies
2.4 Report, service during the warranty period after 100 hours of operation Copy Customer's Copies Machine information Telephone number Machine number: Machine: _____________________________ _____________________________ Operator: Machine owner Replacement Check Oil level, diesel engine, see 1.11 Daily maintenance Fuel filter (every 8-10 operating hours), page 16 Coolant level, see 1.11 Daily maintenance (every 8- Fuel prefilter 10 operating hours), page 16...
Page 62: Report, Service During The Warranty Period After 100 Hours Of Operation (Cont'd.) Copy Customer's Copies
Tightening the screw joints Service performed date: ____________________________ Sign-off for Warranty Service 100 h in GreControl Service performed by: ________________________________ The report must be submitted to: Authorised service dealer Gremo AB, FAO: SERVICE Service approved: _________________________ Box 51 Customer signature 311 51 ÄTRAN...
Page 63: Fault Report 100 H Copy Customer's Copies
Gremo1050F4 Service and maintenance manual 2 Service and maintenance during the warranty period 2.6 Fault report 100 h Copy Customer's Copies 2.6 Fault report 100 h Copy Customer's Copies Machine information Machine number: ________________________________ Machine owner Electrical system: Hydraulics: Hoses: Tyres: Chassis: Miscellaneous:...
Page 64: Report, Service During The Warranty Period After 500 Hours Of Operation
2.7 Report, service during the warranty period after 500 hours of operation Machine information Telephone number Machine number: _____________________________________ Machine: ________________________________________ Machine owner Operator: __________________________________________ Replacement Check Crankcase ventilation, diesel engine, see 1.11 Daily Engine oil and filter maintenance (every 8-10 operating hours), page 16 Air inlet hoses, diesel engine, see 1.11 Daily Fuel filter maintenance (every 8-10 operating hours), page 16...
Page 65: Report, Service During The Warranty Period After 500 Hours Of Operation (Cont'd.)
Pressure setting for crane Machine owner/Authorised service dealer Brake function, traffic brake The report must be submitted to Brake function, working brake Gremo AB, FAO: SERVICE Brake function, parking brake Box 44 311 51 ÄTRAN Inspection of crane Check function of air conditioning system.
Page 66: Fault Report 500 H
2 Service and maintenance during the Gremo1050F4 Service and maintenance warranty period manual 2.9 Fault report 500 h 2.9 Fault report 500 h Machine information Machine number: ________________________________ Machine owner Electrical system: Hydraulics: Hoses: Tyres: Chassis: Miscellaneous:...
Page 67: Report, Service During The Warranty Period After 500 Hours Of Operation Copy Customer's Copies
2.10 Report, service during the warranty period after 500 hours of operation Copy Customer's Copies Machine information Telephone number Machine number: _____________________________________ Machine: ________________________________________ Machine owner Operator: __________________________________________ Replacement Check Crankcase ventilation, diesel engine, see 1.11 Daily Engine oil and filter maintenance (every 8-10 operating hours), page 16 Air inlet hoses, diesel engine, see 1.11 Daily Fuel filter...
Page 68: Report, Service During The Warranty Period After 500 Hours Of Operation (Cont'd.) Copy Customer's Copies
Pressure setting for crane Machine owner/Authorised service dealer Brake function, traffic brake The report must be submitted to Brake function, working brake Gremo AB, FAO: SERVICE Brake function, parking brake Box 44 311 51 ÄTRAN Inspection of crane Check function of air conditioning system.
Page 69: Fault Report 500 H Copy Customer's Copies
Gremo1050F4 Service and maintenance manual 2 Service and maintenance during the warranty period 2.12 Fault report 500 h Copy Customer's Copies 2.12 Fault report 500 h Copy Customer's Copies Machine information Machine number: ________________________________ Machine owner Electrical system: Hydraulics: Hoses: Tyres: Chassis: Miscellaneous:...
Page 70: Report, Service During The Warranty Period After 1,000 Hours Of Operation
2.13 Report, service during the warranty period after 1,000 hours of operation Machine information Telephone number Machine number: _____________________________________ Machine: ________________________________________ Machine owner Operator: __________________________________________ Replacement Lubricated Engine oil and oil filter All lubrication points Fuel filter Cleaned Fuel prefilter Air filter (only in the event of an alarm being Vibration damper, brake lining triggered)
Page 72: Report, Service During The Warranty Period After 1,000 Hours Of Operation (Cont'd.)
Play in articulated steering joint Wear plate bogie housings Authorised service dealer Tightening the screw joints Service approved: Sign-off for Warranty Service 1,000 h in GreControl The report must be submitted to: Gremo AB, Att Service Box 44 Customer signature 311 51 ÄTRAN...
Page 73: Fault Report 1,000 H
Gremo1050F4 Service and maintenance manual 2 Service and maintenance during the warranty period 2.15 Fault report 1,000 h 2.15 Fault report 1,000 h Machine information Machine number: ________________________________ Machine owner Electrical system: Hydraulics: Hoses: Tyres: Chassis: Miscellaneous:...
Page 74: Report, Service During The Warranty Period After 1,000 Hours Of Operation Copy Customer's Copies
2.16 Report, service during the warranty period after 1,000 hours of operation Copy Customer's Copies Machine information Telephone number Machine number: _____________________________________ Machine: ________________________________________ Machine owner Operator: __________________________________________ Replacement Lubricated Engine oil and oil filter All lubrication points Fuel filter Cleaned Fuel prefilter Air filter (only in the event of an alarm being...
Page 76: Report, Service During The Warranty Period After 1,000 Hours Of Operation (Cont'd.) Copy Customer's Copies
Play in articulated steering joint Wear plate bogie housings Authorised service dealer Tightening the screw joints Service approved: Sign-off for Warranty Service 1,000 h in GreControl The report must be submitted to: Gremo AB, Att Service Box 44 Customer signature 311 51 ÄTRAN...
Page 77: Fault Report 1,000 H Copy Customer's Copies
2.18 Fault report 1,000 h Copy Customer's Copies Machine information Machine number: ________________________________ Machine owner Electrical system: Hydraulics: Hoses: Tyres: Chassis: Miscellaneous:...
Page 78: Report, Service During The Warranty Period After 1,500 Hours Of Operation
2.19 Report, service during the warranty period after 1,500 hours of operation Machine information Telephone number Machine number: _____________________________________ Machine: ________________________________________ Machine owner Operator: __________________________________________ Replacement Check Crankcase ventilation, diesel engine, see 1.11 Daily Engine oil and filter maintenance (every 8-10 operating hours), page 16 Air inlet hoses, diesel engine, see 1.11 Daily Fuel filter maintenance (every 8-10 operating hours), page 16...
Page 79: Report, Service During The Warranty Period After 1,500 Hours Of Operation (Cont'd.)
Brake function, traffic brake Machine owner/Authorised service dealer Brake function, working brake The report must be submitted to Brake function, parking brake Gremo AB, FAO: SERVICE Inspection of forestry crane Box 44 Check function of air conditioning system. 311 51 ÄTRAN...
Page 80: Fault Report 1,500 H
2 Service and maintenance during the Gremo1050F4 Service and maintenance warranty period manual 2.21 Fault report 1,500 h 2.21 Fault report 1,500 h Machine information Machine number: ________________________________ Machine owner Electrical system: Hydraulics: Hoses: Tyres: Chassis: Miscellaneous:...
Page 81: Report, Service During The Warranty Period After 1,500 Hours Of Operation Copy Customer's Copies
2.22 Report, service during the warranty period after 1,500 hours of operation Copy Customer's Copies Machine information Telephone number Machine number: _____________________________________ Machine: ________________________________________ Machine owner Operator: __________________________________________ Replacement Check Crankcase ventilation, diesel engine, see 1.11 Daily Engine oil and filter maintenance (every 8-10 operating hours), page 16 Air inlet hoses, diesel engine, see 1.11 Daily Fuel filter...
Page 82: Report, Service During The Warranty Period After 1,500 Hours Of Operation (Cont'd.) Copy Customer's Copies
Brake function, traffic brake Machine owner/Authorised service dealer Brake function, working brake The report must be submitted to Brake function, parking brake Gremo AB, FAO: SERVICE Inspection of forestry crane Box 44 Check function of air conditioning system. 311 51 ÄTRAN...
Page 83: Fault Report 1,500 H Copy Customer's Copies
2.24 Fault report 1,500 h Copy Customer's Copies Machine information Machine number: ________________________________ Machine owner Electrical system: Hydraulics: Hoses: Tyres: Chassis: Miscellaneous:...
Page 84: Report, Service During The Warranty Period After 2,000 Hours Of Operation
2.25 Report, service during the warranty period after 2,000 hours of operation Machine information Telephone number Machine number: _____________________________________ Machine: ________________________________________ Machine owner Operator: __________________________________________ Replacement Replacement Air conditioning system's fresh air filter Engine oil and oil filter Air conditioning system, recirculation filter Fuel filter Fuel prefilter Lubricated...
Page 85: Report, Service During The Warranty Period After 2,000 Hours Of Operation (Cont'd.)
Play in articulated steering joint Wear plate bogie housings Authorised service dealer Tightening the screw joints Service approved: Sign-off for Warranty Service 2,000 h in GreControl The report must be submitted to: Gremo AB, Att Service Box 44 Customer signature 311 51 ÄTRAN...
Page 86: Fault Report 2,000 H
2 Service and maintenance during the Gremo1050F4 Service and maintenance warranty period manual 2.27 Fault report 2,000 h 2.27 Fault report 2,000 h Machine information Machine number: ________________________________ Machine owner Electrical system: Hydraulics: Hoses: Tyres: Chassis: Miscellaneous:...
Page 87: Report, Service During The Warranty Period After 2,000 Hours Of Operation Copy Customer's Copies
2.28 Report, service during the warranty period after 2,000 hours of operation Copy Customer's Copies Machine information Telephone number Machine number: _____________________________________ Machine: ________________________________________ Machine owner Operator: __________________________________________ Replacement Replacement Air conditioning system's fresh air filter Engine oil and oil filter Air conditioning system, recirculation filter Fuel filter Fuel prefilter...
Page 88: Report, Service During The Warranty Period After 2,000 Hours Of Operation (Cont'd.) Copy Customer's Copies
Play in articulated steering joint Wear plate bogie housings Authorised service dealer Tightening the screw joints Service approved: Sign-off for Warranty Service 2,000 h in GreControl The report must be submitted to: Gremo AB, Att Service Box 44 Customer signature 311 51 ÄTRAN...
Page 89: Fault Report 2,000 H Copy Customer's Copies
2.30 Fault report 2,000 h Copy Customer's Copies Machine information Machine number: ________________________________ Machine owner Electrical system: Hydraulics: Hoses: Tyres: Chassis: Miscellaneous:...
Page 90: Report, Service During The Warranty Period After 2,500 Hours Of Operation
2.31 Report, service during the warranty period after 2,500 hours of operation Machine information Telephone number Machine number: _____________________________________ Machine: ________________________________________ Machine owner Operator: __________________________________________ Replacement Check Crankcase ventilation, diesel engine, see 1.11 Daily Engine oil and filter maintenance (every 8-10 operating hours), page 16 Air inlet hoses, diesel engine, see 1.11 Daily Fuel filter maintenance (every 8-10 operating hours), page 16...
Page 91: Report, Service During The Warranty Period After 2,500 Hours Of Operation (Cont'd.)
Brake function, traffic brake Machine owner/Authorised service dealer Brake function, working brake The report must be submitted to Brake function, parking brake Gremo AB, FAO: SERVICE Inspection of forestry crane Box 44 Check function of air conditioning system. 311 51 ÄTRAN...
Page 92: Fault Report 2,500 H
2 Service and maintenance during the Gremo1050F4 Service and maintenance warranty period manual 2.33 Fault report 2,500 h 2.33 Fault report 2,500 h Machine information Machine number: ________________________________ Machine owner Electrical system: Hydraulics: Hoses: Tyres: Chassis: Miscellaneous:...
Page 93: Report, Service During The Warranty Period After 2,500 Hours Of Operation Copy Customer's Copy
2.34 Report, service during the warranty period after 2,500 hours of operation Copy Customer's Copy Machine information Telephone number Machine number: _____________________________________ Machine: ________________________________________ Machine owner Operator: __________________________________________ Replacement Check Crankcase ventilation, diesel engine, see 1.11 Daily Engine oil and filter maintenance (every 8-10 operating hours), page 16 Air inlet hoses, diesel engine, see 1.11 Daily Fuel filter...
Page 94: Report, Service During The Warranty Period After 2,500 Hours Of Operation (Cont'd.) Copy Customer's Copy
Brake function, traffic brake Machine owner/Authorised service dealer Brake function, working brake The report must be submitted to Brake function, parking brake Gremo AB, FAO: SERVICE Inspection of forestry crane Box 44 Check function of air conditioning system. 311 51 ÄTRAN...
Page 95: Fault Report 2,500 H Copy Customer's Copy
Gremo1050F4 Service and maintenance manual 2 Service and maintenance during the warranty period 2.36 Fault report 2,500 h Copy Customer's Copy 2.36 Fault report 2,500 h Copy Customer's Copy Machine information Machine number: ________________________________ Machine owner Electrical system: Hydraulics: Hoses: Tyres: Chassis: Miscellaneous:...
Page 96: Report, Service During The Warranty Period After 3,000 Hours Of Operation
2.37 Report, service during the warranty period after 3,000 hours of operation Machine information Telephone number Machine number: _____________________________________ Machine: ________________________________________ Machine owner Operator: __________________________________________ Replacement Replacement Air conditioning system's fresh air filter Engine oil and oil filter Air conditioning system, recirculation filter Fuel filter Fuel prefilter Lubricated...
Page 97: Report, Service During The Warranty Period After 3,000 Hours Of Operation (Cont'd.)
Play in articulated steering joint Wear plate bogie housings Authorised service dealer Tightening the screw joints Service approved: Sign-off for Warranty Service 2,000 h in GreControl The report must be submitted to: Gremo AB, Att Service Box 44 Customer signature 311 51 ÄTRAN...
Page 98: Fault Report 3,000 H
2 Service and maintenance during the Gremo1050F4 Service and maintenance warranty period manual 2.39 Fault report 3,000 h 2.39 Fault report 3,000 h Machine information Machine number: ________________________________ Machine owner Electrical system: Hydraulics: Hoses: Tyres: Chassis: Miscellaneous:...
Page 99: Report, Service During The Warranty Period After 3,000 Hours Of Operation Copy Customer's Copy
2.40 Report, service during the warranty period after 3,000 hours of operation Copy Customer's Copy Machine information Telephone number Machine number: _____________________________________ Machine: ________________________________________ Machine owner Operator: __________________________________________ Replacement Replacement Air conditioning system's fresh air filter Engine oil and oil filter Air conditioning system, recirculation filter Fuel filter Fuel prefilter...
Page 100: Report, Service During The Warranty Period After 3,000 Hours Of Operation (Cont'd.) Copy Customer's Copy
Play in articulated steering joint Wear plate bogie housings Authorised service dealer Tightening the screw joints Service approved: Sign-off for Warranty Service 2,000 h in GreControl The report must be submitted to: Gremo AB, Att Service Box 44 Customer signature 311 51 ÄTRAN...
Page 101: Fault Report 3,000 H Copy Customer's Copy
Gremo1050F4 Service and maintenance manual 2 Service and maintenance during the warranty period 2.42 Fault report 3,000 h Copy Customer's Copy 2.42 Fault report 3,000 h Copy Customer's Copy Machine information Machine number: ________________________________ Machine owner Electrical system: Hydraulics: Hoses: Tyres: Chassis: Miscellaneous:...
Page 102: Report, Service During The Warranty Period After 3,500 Hours Of Operation
2.43 Report, service during the warranty period after 3,500 hours of operation Machine information Telephone number Machine number: _____________________________________ Machine: ________________________________________ Machine owner Operator: __________________________________________ Replacement Check Crankcase ventilation, diesel engine, see 1.11 Daily Engine oil and filter maintenance (every 8-10 operating hours), page 16 Air inlet hoses, diesel engine, see 1.11 Daily Fuel filter maintenance (every 8-10 operating hours), page 16...
Page 103: Report, Service During The Warranty Period After 3,500 Hours Of Operation (Cont'd.)
Brake function, traffic brake Machine owner/Authorised service dealer Brake function, working brake The report must be submitted to Brake function, parking brake Gremo AB, FAO: SERVICE Inspection of forestry crane Box 44 Check function of air conditioning system. 311 51 ÄTRAN...
Page 104: Fault Report 3,500 H
2 Service and maintenance during the Gremo1050F4 Service and maintenance warranty period manual 2.45 Fault report 3,500 h 2.45 Fault report 3,500 h Machine information Machine number: ________________________________ Machine owner Electrical system: Hydraulics: Hoses: Tyres: Chassis: Miscellaneous:...
Page 105: Report, Service During The Warranty Period After 3,500 Hours Of Operation Copy Customer's Copy
2.46 Report, service during the warranty period after 3,500 hours of operation Copy Customer's Copy Machine information Telephone number Machine number: _____________________________________ Machine: ________________________________________ Machine owner Operator: __________________________________________ Replacement Check Crankcase ventilation, diesel engine, see 1.11 Daily Engine oil and filter maintenance (every 8-10 operating hours), page 16 Air inlet hoses, diesel engine, see 1.11 Daily Fuel filter...
Page 106: Report, Service During The Warranty Period After 3,500 Hours Of Operation (Cont'd.) Copy Customer's Copy
Brake function, traffic brake Machine owner/Authorised service dealer Brake function, working brake The report must be submitted to Brake function, parking brake Gremo AB, FAO: SERVICE Inspection of forestry crane Box 44 Check function of air conditioning system. 311 51 ÄTRAN...
Page 107: Fault Report 3,500 H Copy Customer's Copy
Gremo1050F4 Service and maintenance manual 2 Service and maintenance during the warranty period 2.48 Fault report 3,500 h Copy Customer's Copy 2.48 Fault report 3,500 h Copy Customer's Copy Machine information Machine number: ________________________________ Machine owner Electrical system: Hydraulics: Hoses: Tyres: Chassis: Miscellaneous:...
Page 108: Report, Service During The Warranty Period After 4,000 Hours Of Operation
2.49 Report, service during the warranty period after 4,000 hours of operation Machine information Telephone number Machine number: _____________________________________ Machine: ________________________________________ Machine owner Operator: __________________________________________ Replacement Replacement Air conditioning system's fresh air filter Engine oil and oil filter Air conditioning system, recirculation filter Fuel filter Fuel prefilter Lubricated...
Page 109: Report, Service During The Warranty Period After 4,000 Hours Of Operation (Cont'd.)
Play in articulated steering joint Wear plate bogie housings Authorised service dealer Tightening the screw joints Service approved: Sign-off for Warranty Service 2,000 h in GreControl The report must be submitted to: Gremo AB, Att Service Box 44 Customer signature 311 51 ÄTRAN...
Page 110: Fault Report 4,000 H
2 Service and maintenance during the Gremo1050F4 Service and maintenance warranty period manual 2.51 Fault report 4,000 h 2.51 Fault report 4,000 h Machine information Machine number: ________________________________ Machine owner Electrical system: Hydraulics: Hoses: Tyres: Chassis: Miscellaneous:...
Page 111: Report, Service During The Warranty Period After 4,000 Hours Of Operation Copy Customer's Copy
2.52 Report, service during the warranty period after 4,000 hours of operation Copy Customer's Copy Machine information Telephone number Machine number: _____________________________________ Machine: ________________________________________ Machine owner Operator: __________________________________________ Replacement Replacement Air conditioning system's fresh air filter Engine oil and oil filter Air conditioning system, recirculation filter Fuel filter Fuel prefilter...
Page 112: Report, Service During The Warranty Period After 4,000 Hours Of Operation (Cont'd.) Copy Customer's Copy
Play in articulated steering joint Wear plate bogie housings Authorised service dealer Tightening the screw joints Service approved: Sign-off for Warranty Service 2,000 h in GreControl The report must be submitted to: Gremo AB, Att Service Box 44 Customer signature 311 51 ÄTRAN...
Page 113: Fault Report 4,000 H Copy Customer's Copy
Gremo1050F4 Service and maintenance manual 2 Service and maintenance during the warranty period 2.54 Fault report 4,000 h Copy Customer's Copy 2.54 Fault report 4,000 h Copy Customer's Copy Machine information Machine number: ________________________________ Machine owner Electrical system: Hydraulics: Hoses: Tyres: Chassis: Miscellaneous:...

GREMO 1050F4 Service And Maintenance Manual

1 Service and Maintenance

2 Service and Maintenance During the Warranty Period

Quick Links

Need help?

Questions and answers

Related Manuals for GREMO 1050F4

Summary of Contents for GREMO 1050F4

Table of Contents
