Summary of Contents for Axema UDR-Plus
- Page 1 Manual Updated 2018-11-17 UDR-Plus Universal door alarm Axema Access Control AB | Box 90215 | 120 23 Stockholm, Sweden | 08-722 34 40 | info@axema.se | www.axema.se...
-
Page 2: Table Of Contents
The alarm is set of by a closing magnet contact and is reset when the door is shut. NC relay when the door is closed NO relay when the door is closed UDR-plus with code lock and electric lock VAKA with UDR-plus UDR with extended flash. UDR-plus with ASSA evacuation lock... -
Page 3: Description
Description UDR-plus is a compact door alarm for all types of doors. UDR-plus can signal when a valid pass is made (optional function) and activates the internal siren when an invalid pass is made. The functions are programmed using a DIP switches and duration times are programmed using the P1 and P2 buttons. -
Page 4: Terminals
Terminals 1, 2 Alarm trigger Controlled by connection or voltage (10-30 V DC). Delay 0-5 sec. Activates siren, 1 sec. - 60 min. and flash. Volume, 65-90 dB. 0, deactivates sound signal. 3, 4 Reset Resets the alarm if the door is closed 5, 6 Bypass Allows the door to be open 1 sec. -
Page 5: Jumpers For Alarm Trigger
Jumpers for alarm trigger DL 12 LED Status Flashes during operation. Rapid flash during trigger or delay. Programming Press and hold P1 for approximately 2 seconds. The status LED should shut of and configuration LED 1 should turn on. The display will show the preset delay before the alarm is activated. - Page 6 2. Siren duration Configuration LED 2 is lit up. 1 sec. to 60 min., factory set to 30 sec. 3. Alarm bypass Configuration LED 2 and 3 are lit. 1 sec. to 5 min., factory set to 30 sec 4. Siren volume Configuration LED 1 is lit.
-
Page 7: Installation Examples
Installation examples 7 (17) Manual UDR Plus... -
Page 8: The Alarm Is Set Of By A Closing Magnet Contact And Is Reset When The Door Is Shut
Duration of siren and any delay has to be set. See Programming. NC relay when the door is closed Terminal on UDR-Plus Connects to Terminal 3 on UDR-Plus. C on magnet contact +10 - 30 VDC 8 (17) Manual UDR Plus... -
Page 9: No Relay When The Door Is Closed
NO relay when the door is closed Terminal on UDR-Plus Connects to NO on magnet contact C on magnet contact NC on magnet contact +10 - 30 VDC 9 (17) Manual UDR Plus... -
Page 10: Udr-Plus With Code Lock And Electric Lock
UDR-plus with code lock and electric lock The example shows a door where the code lock allows an entry duration equal to the sum of the relay time on the code lock and alarm bypass time. If possible, use only the relay time on the code lock to prevent bypassing the alarm when the door has been closed again. - Page 11 Terminal on UDR-Plus Connects to NO on magnet contact C on magnet contact Terminal 15 on UDR-Plus NO on code lock C on code lock +10 - 30 VDC GND (Also connects to electric lock) Electric lock +10 - 30 VDC...
-
Page 12: Vaka With Udr-Plus
If the door is forced open, the alarm will be set off. The alarm is reset when a valid pass is made, The lock is connected to UDR. If B16 or 17 is used, connect the door monitoring directly to UDR-Plus according to the top example. Terminal on the door controller... - Page 13 Terminal on UDR-Plus Electric lock 13 (17) Manual UDR Plus...
-
Page 14: Udr With Extended Flash
UDR with extended flash. Requires switching door contact. The alarm is set off immediately with sound and flash if an invalid pass is made. After the door has been closed, the flash continues for the set siren duration. Reset by connecting terminal 5 and 6. 1. - Page 15 Terminal on UDR-Plus Connects to C on magnet contact NC on magnet contact Reset Reset NO on magnet contact +10 - 30 VDC 15 (17) Manual UDR Plus...
-
Page 16: Udr-Plus With Assa Evacuation Lock
UDR-plus with ASSA evacuation lock When the evacuation handle is pulled, a connection is made that triggers the alarm. If the evacuation handle is reset, (the connection between terminal 1 and 2 disappears) and the lock bolt is extended (connection between terminal 3 and 4), the alarm will be reset. -
Page 17: Accessories
Accessories Green, 1-9033-7 Black, 1-9033-8 Technical Data Attributes UDR Plus Power Supply 10 - 30 V DC IP classification IP40 IK classification IK07 Temperature -20° to + 50°C 17 (17) Manual UDR Plus...
