- Page 1 Quick setup and operation guide ONEbox.micro ONEbox.mini ONEbox.cube Version 1.3 May 2019...
-
Page 2: Key Operation
ONEbox quick guide Key operation Front panel key operation when ONEbox is in standby mode Hold right key can change input connection, press again will switch to next input. Press left key to confirm and make connection. If your speakers are turned on, you will hear voice guidance. ... - Page 3 Connect your smartphone to ONEbox Smartphone direct WiFi connect to your ONEbox (AP mode) Your ONEbox can work as WiFi base station (Access Point mode), your smartphone can connect to ONEbox directly as a client, no router is needed. If your smartphone connect to ONEbox directly, the smartphone will loss data service or no internet access. 1.
- Page 4 Setup ONEbox router connection Smartphone access ONEbox via home router (Client mode) 1. Go to setting to connect your 2. Add your home router, either router 1 or ONEbox to your home router router 2, input your router password and connect 3.
- Page 5 ONEbox web page control manual Homepage Web page connection IP address Direct WiFi : SSID = ONEbox****, IP = 192.168.101.1 Client mode : SSID = router, IP = assigned by router Select input Playing audio information Master volume & Mute audio Press [-] or [+] to change 1dB level, or touch and slide volume bar to change volume Touch the volume level will mute audio, the volume level in...
-
Page 6: Internet Radio
Local music server Plug-in a USB RAM to USB host port. USB ram size is 4~32GB with FAT32 format. Song files storage at root directory or second layer sub-directory. Touch button to refresh song list in the USB RAM Shuffle play Single loop Loop playback Single play... - Page 7 Sound setting sub-page Individual audio mode sound setting, total 9 audio mode : DLNA, AirPlay, Surround 5.1, optical LPCM (CD), TV 3.1, USB, music server, internet radio, Bluetooth Touch here to go back to home page Individual audio mode sound setting : DLNA stereo mode Treble level of all speakers Subwoofer level of subwoofers Select speaker sound character...
- Page 8 Individual audio mode sound setting : AirPlay stereo mode AirPlay up-sampling sound enhancer Play buffer size Longer buffer can reduce audio glitch, but create longer delay Tips : Sound character - Speaker sound setting, change speaker DSP to reproduce different character of sound Warm : Warm sound like tube amplifier behaviors Natural :...
- Page 9 Speaker setting sub-page Speakers in the system Lighted speaker icon indicate speaker is ON Dimmed speaker icon indicate speaker is OFF Touch icon to get more speaker inforamtion Touch button to add new speakers Add new speaker into the system / Test speakers Stereo mode, 3 zones speaker pair play ON/OFF TV mode, switch 3.1 center ON/OFF, or center speaker only Paralleled subwoofer, select individual ON/OFF...
- Page 10 Set the rear speaker 1. Set listening area (time delay for rear speaker : Small 0.6m, Medium 1.6m, Large 3.3m, Open 10m) 2. 3D effect (ONEmicro as rear speaker) 3. Pseudo center : switch rear speaker to play center channel in TV3.1 mode (switch 4.1 mode to TV 3.1 mode) Switch rear speaker to play center channel in TV 3.1 mode Set listen area size Subwoofer group volume...
- Page 11 ONEbox system setting Change the spare time to auto standby Change ONEbox host name (special character is not allowed) Change password for ONEbox direct WiFi connection (SSID = ONEbox****) Connect ONEbox to your home router (refer to Quick setup guide) Firmware upgrade for ONEbox’s WiFi module EU DECT channel 1-10 US DECT channel 1-5...
-
Page 12: Visual Indication
Visual Indication Operation mode State LED indication Standby mode Standby with smart input scanning Short flash BLUE LED every 4 second Sleep (WiFi remote function enable) No LED Power off (WiFi remote function stop No LED Play mode Ready to Play or Playing BLUE LED stay on Receive command... - Page 13 Connect your play device to ONEbox A. iPhone AirPlay connect to ONEbox Your iPhone and ONEbox is connected to your home network, or your iPhone is connect to ONEbox WiFi SSID : ONEbox**** Switch ONEbox input mode to AirPlay or Standby ...
-
Page 14: Troubleshooting
Troubleshooting Reset ONEbox to factory default (reset password and host name) 1. Unplug ONEbox from power supply 2. Press and hold the L+R key, at the same time, power up ONEbox 3. Keep pressing both L+R key for 5 seconds, and you will see both Red and Blue LED blink 4.
