1080P Dual Camera DVR Instructional Manual
DVR HUB
3
4
1
5
6
2
7
1. Power button
2. Memory card slot
3. Down button
4. Up button
5. REC/OK button
6. Menu button
7. Mode button
MotoProCam
DESCRIPTION OF BUTTONS:
POWER CONVERTER
8
9
10
11
8. CAM 1 connection
9. Cam 2 connection
11. Power connection
12. MIC
13. Speaker
14. Reset button
CAM 1
CAM 2
SOS BUTTON
12
13 14
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TD Electronics MotoProCam
Summary of Contents for TD Electronics MotoProCam
- Page 1 MotoProCam 1080P Dual Camera DVR Instructional Manual DESCRIPTION OF BUTTONS: CAM 1 CAM 2 SOS BUTTON DVR HUB POWER CONVERTER 13 14 1. Power button 8. CAM 1 connection 2. Memory card slot 9. Cam 2 connection 3. Down button 10.
- Page 2 Buttons on DVR function description Power button：SHORT press to POWER ON; LONG press to TURN OFF; NOTE: when DVR has power turned on (connected), it will automatically turn on and start recording; when power is turned off (disconnected), the DVR will have a delayed shutdown button：Mute audio key function (while on live view screen);...
- Page 3 3. The power supply system of this product is designed for the DC12V ~ 24v. Connect the red power cord to the red connector from DVR HOST. Please confirm that the positive and negative poles are connected correctly (general body paint may have bad grounding). (The best ground connection position is the battery negative electrode.) Note: Try to avoid being connected to the same power line with other electronic products if possible, and avoid the abnormal operation of the machine because of the power grabbing.
- Page 4 ( F ) Date Stamp：Off；On ( G ) G-Sensor：Off；High；Medium；Low (recommend low) 6. Photograph menu setting Press the mode key to enter the photograph mode after booting, press the menu button enter into the menu setting ( A ) Photograph Mode：Single; 2S timing; 5S timing; 10S timing ( B ) Resolution：12M 4032*3024;...
- Page 5 ( C ) APP IN MARKET STORE(ANDROID/IPHONE) NAME : CRUISE CAM – Please download after connected to WIFI on phone. ( D ) Return to app to use with MotoProCam Spartan 1080 ( E ) Save and edit video and pictures with app to send from phone to various destinations 9.
- Page 6 working voltage DC5V Display 3.5 inches Storage temperature -20℃~70℃ working temperature -10℃~60℃ Operating humidity 15-65%RH 10. Accessories details ( A ) DVR*1pcs ( B ) LENS*2pcs ( C ) Drive-by-wire*1pc ( D ) Multiple mounts available (bar mounts, etc.) Safety requirement ●...
- Page 7 MANUFACTURER Limited Warranty What warranty covers: Manufacturer warrants to the original purchaser that the product furnished hereunder shall be free from defects in material and workmanship under normal use and service. In the event of any defect in material or workmanship, the Manufacturer will for twelve (12) months from the date of delivery of the product to purchaser, F.O.B.
