  • Page 2: Safety Warning

    - in any service procedure or operations session. The D-10h Locomotive features the following DIE-CAST parts: boiler, boiler support, tender chassis, leading truck centre weight, gear housing and internal fluid retainer casting.
  • Page 5 Operators Service Manual - PROCEDURE FOR SMOKE OPERATION. You can choose to operate the smoke unit, but first you will need to fill the fluid reservoir with fluid. A cross section of the locomotive shows that the reservoir is located underneath the smoke stack.
  • Page 6 Operators Service Manual - PROCEDURE FOR GREASE AND LUBRICATION. - REQUIRED - #0 Phillips screw driver, lite oil, lite grease, work station On the bottom of your locomotive, there are a se- ries of 6 (six) screws that secure the gear cover on. Placing the locomotive on a secure work station, such as a foam cradle, remove these screws.
  • Page 7 CONT’D To remove the boiler, you will need to remove the 2 (two) screws as highlighted in the rendering to the left. Place these screws in a safe, secure location Tilting the boiler from the BACK forward (as depicted in the illustration) slide the boiler off. This will leave exposed the motor, universal, worm gear cover, and flywheel.
  • Page 8 With the chassis exposed, you can put lite GREASE in the service hole of the drive mechanism. Not much grease is needed, and be carefull NOT to over pack the drive with grease. There is a CAM located on the front axle that will not function cor- rectly if coared in grease.
  • Page 9 DCC / DC / SOUND: Your model features a DUAL MODE decoder. Able to switch from DC to DCC automatically. Sounds are from actual D-10 recordings and have been digitally re-created to bring you these authentic sounds. While we have worked very hard with DIGISIGHT Technologies to make our custom decoder, you can use any 21 pin decoder.

  • Page 10: Warranty

    CONTACT INFORMATION: HEAD OFFICE SERVICE DEPT Email: support@shiratrains.ca Website: www.shiratrains.ca Your locomitve has been designed in CANADA by SHIRA TRAINS and assembled with pride in Dongguang City, Guangdong province at the YIHE ARTS AND CRAFTS CO., LTD.
