Instruction Manual
SweetSpot10™ Inventory:
• SweetSpot10™ dual-band transmitter – broadcasts on 2.4ghz and 5.8ghz
concurrently (includes 1 Gigabit Internet port and 1 Gigabit LAN port)
• Short Ethernet data cable
• Smart PoE injector and 50-foot Cat 5e cable
• Stainless mounting hardware
• Preconfiguration
• SweetSpot10™ infographic and invoice
SweetSpot10
Your partner in wireless networking
TM
™
Advertisement
Table of Contents
Related Manuals for Omni-WiFi SweetSpot10
Summary of Contents for Omni-WiFi SweetSpot10
- Page 1 SweetSpot10 Instruction Manual SweetSpot10™ Inventory: • SweetSpot10™ dual-band transmitter – broadcasts on 2.4ghz and 5.8ghz concurrently (includes 1 Gigabit Internet port and 1 Gigabit LAN port) • Short Ethernet data cable • Smart PoE injector and 50-foot Cat 5e cable • Stainless mounting hardware • Preconfiguration • SweetSpot10™ infographic and invoice ™ Your partner in wireless networking...
- Page 2 OMNI-WiFi™ SweetSpot10™ Instruction Manual © OMNI-WiFi, LLC, 2005, 2018 All rights reserved. This manual or parts thereof may not be reproduced in any form, stored in any retrieval system, or transmitted in any form by any means—electronic, mechanical, photocopy, recording, or otherwise—with- out prior written permission of the publisher, except as provided by United States of America copyright law.
-
Page 3: General Mounting Considerations
Take care to mount the SweetSpot10™ close enough to your power source and to your cable or broadband modem. Mounting hardware is included for pole-mounting or 90-degree surface mounting. If 90 degrees is too much or too little, the mount can be bent more or less to suit the environment. You can point the SweetSpot10™ in any direction but its mounting polarity should be observed. Mounting Outdoors To service a building from across the street, remember that the SweetSpot10™... -
Page 4: Installation Considerations
OMNI-WiFi™ SweetSpot10™ Instruction Manual Mounting Indoors To service a building from inside that same building, you can mount the SweetSpot10 ™ on the first floor toward the ceiling, in the ceiling, or on an upper floor, tilting down. The best place to mount the SweetSpot10™ is in an attic, screwed onto a roof rafter or a truss and tilting downward toward the back of the house. - Page 5 Do not mount directly behind a chimney or an air conditioning duct. If mounted outdoors, the mounting hardware packed with your SweetSpot10™ must be used for safety. When mounted properly, the SweetSpot10™ will remain secure even in winds of over 100 mph. Secure the antenna tightly so that wind does not move it!
- Page 6 OMNI-WiFi™ SweetSpot10™ Instruction Manual...
-
Page 7: Wireless Clients
MAC address information and force the cable modem to get a new MAC address from your ‘new’ SweetSpot10™. This is true if you have previously used the cable modem with a direct connection into a computer. -
Page 8: Performance Testing
The simple demonstration: Do not plug in the SweetSpot10™ yet. First establish baseline performance of your previous access point. Place it up high on a desk or shelf. Connect to the existing AP, a non-OMNI-WiFi AP. Note the channel of the existing AP. Then after establishing a connection, run the speed test from Speakeasy (www.speakeasy.net/speedtest) while walking away from the AP. Continue to run the speed test until the connection is lost, while at the same time slowly walking away from the AP. Mark the spot where the signal is lost. Now unplug the original AP and plug in the OMNI-WiFi AP and place it in the same location as the original AP was placed, but up as high as possible per the mounting suggestions given on pp. 3-4. Put the SweetSpot10™ on the same channel as the old AP to create a fair comparison. Connect to the... -
Page 9: How It Works
APs, but the combination of the super sensitive radio, custom antenna, and special noise elimination circuit give it the highest quality. Therefore, the client computer will usually connect a good deal farther away from the SweetSpot10™ than from any other AP, regardless of how many bars are showing in the wireless signal strength icon at the bottom of the screen. With other APs, up to one-half of the signal strength bars represent noise or a distorted signal. -
Page 10: Interference Statement
OMNI-WiFi™ SweetSpot10™ Instruction Manual Appendix Federal Communications Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,... -
Page 11: Technical Support
| Technical Support 1-800-610-6711 Technical Support: Email: engr@omni-wifi.com Phone: 1-800-610-6711 x 7 SPECIAL NOTE regarding interference and coverage: Aim the SweetSpot10™ slightly downward instead of straight ahead to ensure coverage into dips and valleys. Avoid transmitting into or close to appliances, radios, cordless phones, baby monitors, wireless security systems or wireless cameras. OMNI-WiFi Trademark The SweetSpot10™ is a service trademark OMNI-WiFi, LLC. OMNI-WiFi™ is a federally registered trademark. Environmental Specifications: Operating Temperature: -20 to + 120 degrees F. Operating Humidity: 5% to 80%, non-condensing Enclosure: NEMA-4 rated, to withstand direct water spray, and to withstand ice formation on enclosure. - Page 12 omniwifi Wireless Password: root omniomni Administrative Username: Password: 192.168.188.253 IP address: Channel: ™ Your partner in wireless networking Phone: 800-610-6711 Email: sales@omni-wifi.com www.OMNI-WiFi.com ...
