- Page 1 INSTRUCTION MANUAL 4 Megapixel Box Camera Before installing and using the camera, please read this instructions thoroughly and keep for reference.
- Page 2 INFORMATION FOR USER CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated "dangerous voltage"...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Table of Contents Preca u tions ----- ----- ----- ----- --- - - --- 4 F eat u res --- --- --- --- --- --- --- --- --- --- 5 Accessories ------- ------ ----- ------ ---- 6 Rear Pane I Interfaces ------ ------ ---- - ---- 7 Main Men u ---- ---- ---- ---- ---- ---- ---- - 9 F oc u s ---- ---- ---- ---- ---- ---- ---- ---- -10... -
Page 4: Precautions
PRECAUTIONS Do not install the camera in extreme temperature conditions ■ ° ° Do use the camera under conditions where temperatures are within -10 C to 50 Especially be careful for ventilation under high temperatures. Do not install or use the camera in an environment where the ■... -
Page 5: Features
FEATURES BOX CAMERA This color video camera is designed to use for video monitoring systems BMH-S29Q: DC12V model • 1 /2" Sony Starvis CMOS sensor • Built-in 3.6~10mm Motorized Zoom Lens • QHD Resolution support • Day & Night (ICR) •... -
Page 6: Accessories
ACCESSORIES ACCESSORIES MANUAL CAMERA DC 12VCABLE SERVI C E VI D EO OUT BNC CABLE OPTIONAL REMOTE CONTROLLER ____ Not used ____ Tele/ Up ___ _ Far/ Right ----Menu/ ----Wi d e Down _______ _,,ear Left... -
Page 7: Rear Pane I Interfaces
REAR PANEL INTERFACES NAME OF EACH PARTS ® o·" ► HD-SDI [El (CJ [ 4 1 -----AD CVBS---tt+il- ( o□mo DC12V [ 7 ] ( 1] OSD / Zoom / Focus control (2] Power LED (3] HD-SDI Out (4] AD Key 1: GND 2: AD-key 3: GND... - Page 8 REAR PANEL INTERFACES CONNECTIONS 1. Caxial cable connecting (HD-SDI / EX-SDI) - Coaxial cable should be properly connected to a monitor, DVR. or one cable receiver unit Please use a coaxial cable and BNC connector which have 750 impedance 2. Power supply to the camera (DC12V) - Connect a DC 12V power source to the camera careful with polarity.
-
Page 9: Main Menu
MAIN MENU Camera menu is subject to change without prior notice for the functional upgrade or quality improvement. Also, we may use slip sheet for the change. Please check the camera version and the slip sheet if the camera menu and this manual's menu is not matched. -
Page 10: F Oc U
FOCUS FOCUS ZOOM/FOCUS MODEL D&N FOCUS MODE AUTO ZOOM / FOCUS SCANNING HALF EXPOSURE ONESHOT WHITE BAL SYNC TON IMAGE LENS RESET INTELLIGENCE REFOCUS SPECIAL FUNC DISPAV [EXIT] [SAVE] [DFLT] [EXIT] [SAVE] [DFLT] ♦ FOCUS MODE : Set auto focus mode ► AUTO, MANUAL ♦... -
Page 11: Exposure
EXPOSURE EXPOSURE MENU EXPOSURE MODEL D&N LENS MODE INDOOR ZOOM / FOCUS BRIGHTNESS EXPOSURE SHUT SPEED AUTO WHITE BAL IMAGE INTELLIGENCE FLICKERLESS SPECIAL FUNC WDR/BLC DISPAV DAV&NIGHT AUTOJ [EXIT] [SAVE] [DFLT] [EXIT] [SAVE] [DFLT] ♦ LENS MO DE : Select LENS modefl �... - Page 12 EXPOSURE WDR/BLC: Set WDR(Wide Dynamic Range) or BLC(Backlight compensation) ► WDRfl [> MODE : Select WDR mode. ► LINE, FRAME [> LEVEL: Set WDR level. ► LOW, MID-LOW, MIDDLE, MID-HIGH, HIGH WDR does not work at Manual Shutter Mode. ► BLCfl [>...
-
Page 13: White Ba I An
WHITE BALANCE WHITE BALANCE WHITE BAL MODEL D&N ZOOM/ FOCUS EXPOSURE WHITE BAL IMAGE INTELLIGENCE SPECIAL FUNC DISPAV [EXIT] [SAVE] [DFLT] [EXIT] [SAVE] [DFLT] ♦ AWB: Set WHITE BALANCE mode ► AUTO/ ONE PUSH�/ MANUAL/ INDOOR/ OUTDOOR AUTO : Automatically adjusts color according to the lighting condition. [>... -
Page 14: Image
IMAGE IMAGE MENU IMAGE MODEL D&N ZOOM/ FOCUS EXPOSURE MIRROR WHITE BAL SHARPNESS IMAGE INTELLIGENCE DEFOG SPECIAL FUNC FREEZE 0.55 DISPAV GAMMA E.ZOOM [EXIT] [SAVE] [DFLT] [EXIT] [SAVE] [DFLT] HLC : Set High Light Compensation. When camera is shooting extremely bright light source, camera masks the area to prevent saturation on the monitor. - Page 15 IMAGE ♦ ACE : Set Adaptive Contrast Enhancement function ► OFF/ LOW/ MIDDLE/ HIGH ♦ DEFOG : Set Defog function ► OFF/ ON+i [> MODE : AUTO/ MANUAL [> LEVEL: LOW/ MIDDLE/ HIGH You can not use DEFOG and ACE at the same time (When ACE On, DEFOG will be Off.
-
Page 16: Intelligent
INTELLIGENT INTELLIGENCE INTELLIGENCE MODEL D&N PRIVACY ZOOM/ FOCUS MOTION EXPOSURE WHITE BAL IMAGE INTELLIGENCE SPECIAL FUNC DISPAV [EXIT] [SAVE] [DFLT] [EXIT] [SAVE] [DFLT] +PRIVACY: You can hide some areas on the screen ►OFF/ ONfl [> MASK#: Select a number of mask area (1 ~ 24) [>... -
Page 17: Special Function
SPECIAL FUNCTION SPECIAL FUNC SPECIAL FU NC MODEL D&N DEFECT ZOOM/ FOCUS IMAGE RANGE FULL EXPOSURE SYSTEM NTSC WHITE BAL HD FORMAT 1440p/30fJ?S IMAGE SDI MODE EX270M (1.0) INTELLIGENCE CVBS SPECIAL FUNC COMM DISPAV [EXIT] [SAVE] [DFLT] [EXIT] [SAVE] [DFLT] + DE FECT : Compensates bad pixels on image sensor + IMAGE RANGE : Set the bit range of video image ( F ull : 100%, Compressed : 75%) -
Page 18: D Is P La
DISPLAY DISPLAY DISPLAY MODEL D&N DISP SEL ZOOM/ FOCUS SET TITLE EXPOSURE INIT SEL WHITE BAL SET TIME MSG LANGUAGE ENGLISH IMAGE INTELLIGENCE SPECIAL FUNC DISPAV [EXIT] [SAVE] [DFLT] [EXIT] [SAVE] [DFLT] ♦ DISP SEL : Select items to display on the screen ►... -
Page 19: Specifications
SPECIFICATIONS Image Sensor 1/2" Sony Starvis CMOS Sensor Total Pixels 3,096(H) x 2,094(V) = 6.48M pixels 3,089(H) x 1,744(V) = 5.39M pixels Active pixels Lens Optical 3x, Digital 32x Zoom f = 3.6mm ~ 10mm, F1 .5 (wide)~ F2.8 (tele) °... - Page 20 P/N: PRINTED IN KOREA Distributed by...
