- Page 1 TrackMan™ TMC3J Installation and Safety Instructions Issue 3, January 2019 TrackMan™ Radar Unit Installation and Safety Instruction TrackMan Baseball V2, Type: TMC3J Page 1 of 10...
-
Page 2: Table Of Contents
NSTALLATION INSTRUCTIONS System description ......................7 System specifications ....................8 3.2.1 Radar........................8 3.2.2 Junction Box......................8 TrackMan™ Radar Unit, model TMC3J ..............9 Setting up the system ....................9 ...................... 10 ARRANTY OMMENTS Page 2 of 10... -
Page 3: Introduction
This document provides instructions and warning in order to safely install and operate the TrackMan Baseball Stadium Radar TMC3J Radar Unit This document does not describe the TrackMan™ application software and how to operate it. This is provided in separate document. -
Page 4: Safety Instructions
TrackMan™ TMC3J Installation and Safety Instructions Issue 3, January 2019 2 Safety Instructions 2.1 Regulatory Notice FCC compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 5: Warning: Radiation Hazard
Never try to open or repair the device yourself. Any changes or modifications not expressly approved by TrackMan A/S could void the user’s authority to operate the device. Changes or modifications made to this equipment not expressly approved by (manufacturer name) may void the FCC authorization to operate this equipment. -
Page 6: Caution: Safety Precautions
• Only use the Junction Box supplied with the TrackMan™ Radar Unit. • Before you connect the TrackMan™ Radar Unit to an electrical outlet, check the AC adaptor voltage rating to ensure that the required voltage and frequency match the available power source. -
Page 7: Installation Instructions
TrackMan™ TMC3J Installation and Safety Instructions Issue 3, January 2019 3 Installation instructions 3.1 System description The TrackMan™ radar system is a standalone measurement system for the detection and measurement of baseballl movements. The system consists of: • TrackMan™ Radar Unit model TMC3J •... -
Page 8: System Specifications
Issue 3, January 2019 3.2 System specifications 3.2.1 Radar. The TrackMan™ radar unit is a robust construction, with chassis made of Metal back. The front of the TrackMan™ is black plastic from where behind the microwave radiation is transmitted and received. -
Page 9: Trackman™ Radar Unit, Model Tmc3J
• Antennas for transmitting and receiving • Digital camera • GPS receiver The TrackMan™ Radar Unit system is splash proof and designed to withstand rain. 3.4 Setting up the system Setting up the system will only be done by TrackMan™ personnel or 3 party personnel educated by TrackMan™... -
Page 10: Warranty Comments
TrackMan™ TMC3J Installation and Safety Instructions Issue 3, January 2019 4 Warranty Comments The TrackMan™ Radar Unit contains NO user serviceable parts inside. In case of defect or malfunctioning TrackMan™ Radar Unit, TrackMan A/S authorized personal ONLY must repair the unit.
