DIEBOLD AccuVote-OS Hardware Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

AccuVote-OS
AccuVote-OS
Hardware Guide
Revision 2.0
August 21, 2002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AccuVote-OS and is the answer not in the manual?

Questions and answers

Summary of Contents for DIEBOLD AccuVote-OS

  • Page 1 AccuVote-OS AccuVote-OS Hardware Guide Revision 2.0 August 21, 2002...
  • Page 2 AccuVote-OS Hardware Guide Copyright © Diebold Election Systems, Inc. and Diebold Election Systems Inc., 2002 This documentation contains proprietary, trade secret information and is the property of Diebold Election Systems, Inc. and/or Diebold Elections Systems Inc. The information contained herein may not be disclosed, used, transferred or copied, in whole or in part, without the express prior written consent of Diebold Election Systems, Inc.
  • Page 3 Document History Document Number Date Remarks August 21, 2002 Updated document to Diebold Election Systems Product Document Standard 1.0. © Diebold Election Systems, Inc. 2002 AccuVote-OS Hardware Guide...

  • Page 4: Table Of Contents

    1.2. Overview ........................1 1.3. Other documents....................... 1 AccuVote-OS Hardware ......................3 2.1. Product environment ....................3 2.2. Looking at the AccuVote-OS..................3 2.3. Inside the AccuVote-OS .................... 5 2.4. Ballot Reader......................5 2.5. CPU Board ........................ 6 2.6. Read Only Memory (ROM)..................6 2.7.
  • Page 5 6.9. Replacing a Full Ballot Box ..................26 Setting Up the AccuVote-OS....................28 7.1. Setting up the AccuVote-OS to Program memory cards ........28 7.2. Setting up the AccuVote-OS for Ballot Processing ..........29 7.3. Setting up the AccuVote-OS on Election Day............30 7.4.
  • Page 6 9.5.2. Programmed memory card................42 9.6. Storage ........................42 10. Equipment Maintenance and Repair ..................43 10.1. Election maintenance ....................43 10.1.1. Pre-Election Maintenance ................43 10.1.2. Election day ....................43 © Diebold Election Systems, Inc. 2002 AccuVote-OS Hardware Guide...
  • Page 7 10.28. Installing the ballot deflector cable ................61 11. Points to Remember......................62 12. Parts List..........................63 12.1. AccuVote-OS unit parts list ..................63 12.2. Ballot box unit parts list ................... 65 13. Unit Specifications ......................... 67 13.1. Mechanical ......................67 13.2.
  • Page 8 Transportation environment ..................68 13.8. Ballot cards......................68 Appendix A: Glossary........................69 Appendix B: AccuVote-OS Inventory and Maintenance Logs ............73 Appendix C: Ballot Box Inventory and Maintenance Logs............. 75 Appendix D: Modem Transmission Checklist ................77 Appendix E: ROM Labels......................79 Appendix F: RS-232 Pin Definitions....................
  • Page 9 Figure 7-3: Separating Ballots in the Ballot Box ................26 Figure 7-4: Unlocking and Opening the Ballot Box Lid ..............27 Figure 8-1. Rear View of AccuVote-OS Unit................. 28 Figure 8-2: AccuVote-OS Ballot Processing Unit ................. 29 Figure 8-3: Internal View of AccuVote-OS ..................31 Figure 9-1: AccuVote-OS Modems ....................

  • Page 11: Introduction

    AccuVote-OS and at any polling place. Memory cards may easily be set to one of three election modes, with additional supportive setup and diagnostic modes.
  • Page 12 Introduction AccuVote-HS Central Count User’s Guide AccuVote-OS Central Count User’s Guide • AccuVote-OS Precinct Count User’s Guide • AccuVote-TS R6 Hardware Guide • Ballot Station User’s Guide • Election Media Processor Hardware Guide • Election Media Processor User’s Guide •...

  • Page 13: Accuvote-Os Hardware

    The visible light card reader consists of two sets of printed circuit boards for reading both sides of the ballot card. The AccuVote-OS accepts 8½” by 11”, 14”, 17, or 18” ballots, in any one of four orientations. Detailed specifications regarding weight, dimensions, color, tolerances, positioning of control marks, etc.
  • Page 14 CPU by means of the card reader serial interface. Deflector Plug The ballot deflector plug allows the AccuVote-OS to electronically control the ballot deflector in the ballot box or, with a special adapter, to electronically control an AccuFeed.

  • Page 15: Inside The Accuvote-Os

    The Phone jack is used to attach a standard telephone to assist in manual dialing when the onsite phone system doesn’t allow automatic -this jack should be left covered, as it is not commonly used. 2.3. Inside the AccuVote-OS The AccuVote-OS ballot-processing unit consists of the following components, as illustrated in Figure 2-2: • Ballot reader •...

  • Page 16: Cpu Board

    2.5. CPU Board The AccuVote-OS is run with an NEC V-25 single chip microcomputer, which is used primarily to control the peripheral devices, analyze ballot data, update memory card totals, and print reports. Information gathered by the ballot reader is transferred to the CPU’s Direct Memory Access (DMA) channel by means of a high-speed serial input connection.

  • Page 17: Liquid Crystal Display (Lcd)

    AccuVote-OS Hardware 2.9. Liquid Crystal Display (LCD) The AccuVote-OS features a 2 by 16 character LCD unit, which is used to display messages and prompts in each of a memory card’s election modes as well as diagnostic and setup information.

  • Page 18: Modems

    CPU board, which is in turn connected to the power supply. The Line and Phone jacks at the rear of the AccuVote-OS are connected to the modem by means of RJ-11 connector cables. Line is used to connect the modem to a phone line - the Phone jack may be...

  • Page 19: How The Unit Works

    How the Unit Works This section provides a detailed look at the AccuVote-OS and its components. 3.1. Inside the AccuVote-OS Figure 3-1: The AccuVote-OS The AccuVote-OS ballot processing unit consists of the following components, as illustrated in Figure 4-1: • ballot reader •...

  • Page 20: Scanning The Timing Marks

    Even though both reader boards scan from left to right, the left side of the upper reader board is looking at the visual left © Diebold Election Systems, Inc. 2002 AccuVote-OS Hardware Guide...

  • Page 21: Ballot Reader Motor

    3.5. Power supply The AccuVote-OS is powered with a switching 5 and 14 volt power supply which also provides filtering and transient suppression to improve system performance. The AccuVote-OS is supplied with a battery to backup the power supply in the event of an AC power failure.

  • Page 22: Battery

    Figure 4-2. A battery will operate for up to two hours. An AccuVote-OS installed with a battery will reject a ballot being read at the time of the power interruption, but will allow refeeding of the ballot and continued operation under battery power.

  • Page 23: Rom Memory

    Note that the ballot reader interface is discussed in Reader DMA interface above. 3.7. ROM memory Each AccuVote-OS is operated by the program (firmware) stored on EPROM chips. ROM chips are non-volatile memory devices. Note that all information concerning your jurisdiction, election and ballots is stored on the memory card and not on the ROM chips.

  • Page 24: Lcd Module Interface

    CPU board, which is in turn connected to the power supply. The Line and Phone jacks at the rear of the AccuVote-OS are connected to the modem by means of RJ-11 © Diebold Election Systems, Inc. 2002...
  • Page 25 Each modem is pocket-sized, transmits data at a rate of 2400 baud and weighs approximately 4 oz. Modems are set by default to transmit an eight-bit character, with no parity, and one stop bit. © Diebold Election Systems, Inc. 2002 AccuVote-OS Hardware Guide...

  • Page 26: How The Software Works

    The AccuVote-OS adopts the election mode determined by the first memory card installed after the unit is powered on. In order to install a memory card with a different mode, the AccuVote-OS must be powered off and on again.

  • Page 27: Election Mode

    Once the AccuVote-OS has been electronically locked, the program exits the Count Ballots module and prints the Election Results report using the Print Totals module. You may move the ballot deflector if the AccuVote-OS is installed on a ballot box without a rear door for removing ballots.

  • Page 28: Post-Election Mode

    The unit is now set to Post-Election Mode, and may be powered off before transmitting election results to the host computer. 4.4. Post-Election Mode Once the AccuVote-OS has been electronically locked at the end of election day in Election Mode, the memory card is set to Post-Election Mode. Post-Election Mode is used to: •...
  • Page 29 How the Software Works direct communications and 2400 baud for internal modem communications. The AccuVote-OS unit displays Communications Error messages and allows a transmission retry if an incorrect response is detected in transmission. For a list of transmission error messages, see the AccuVote-OS Operator's GuidePrecinct Count User’s...

  • Page 30: Memory Cards

    A low memory card battery is indicated by the appearance of the ‡ symbol in the bottom left hand corner of the AccuVote-OS LCD. Once this symbol appears, the memory card battery should be replaced to assure continued and safe use of the memory card. Once the memory card battery is removed, all programming stored on the memory card will be lost.

  • Page 31: Sealing Memory Cards And Accuvote-Os Units

    This seal number should be verified before the AccuVote-OS is installed in the ballot box on Election Day. The memory card remains sealed in the AccuVote-OS until the election has closed, and after election results have been transmitted to the host computer if modem transmission is being used.

  • Page 32: Ballot Box

    6.3. Ballot Box Lid The retaining door at the front of the AccuVote-OS ballot box lid opens to allow installation of the AccuVote-OS ballot-processing unit. The ballot box lid has a large recessed area with metal guide rails along each side of this opening.

  • Page 33: Security Plate

    Ballot Box The AccuVote-OS power cord tube is located at the back left hand side of the ballot box lid and is used to house the AccuVote-OS power cord once the AccuVote-OS has been installed in the ballot box. At the rear of the ballot box lid is a small electrical connector. When the AccuVote-OS is secured in place, the deflector connector plugs into the back of the unit.

  • Page 34: Ballot Box Compartments

    The back door of the ballot boxes only exists in newer model ballot boxes and is designed to allow the removal of ballots at the end of Election Day or in case of an AccuVote-OS failure (where ballots are transferred to the side compartment). The back door should be kept locked at all times on Election Day.

  • Page 35: Separating Ballots In The Ballot Box

    Ballots drop into only one of the main compartments of the ballot box only if no separation of blank or write-in ballots is specified in the AccuVote-OS Options window in GEMS, or into either one of the ballot box’s two principal compartments if separation is specified. Once a ballot is determined to be blank or contain write-ins, the ballot deflector automatically rotates to cause the ballot to drop into the ballot box’s alternate main compartment.

  • Page 36: Removing Ballots From The Ballot Box

    Shaking a full ballot box may allow ballots to settle, creating more space inside the box. If an AccuVote-OS seems to be jamming on a continuous basis, verify that ballots have not become stacked up to the chute or ballots are not jammed in the chute (look up through the back door into the chute area).
  • Page 37 11. Thread the power cord through the back of the power cord tube of the empty ballot box. 12. Remove the AccuVote-OS from the full ballot box and slide it halfway onto the ballot box lid of the empty ballot box. Plug the power cord into the back of the AccuVote-OS and power the unit on.

  • Page 38: Setting Up The Accuvote-Os

    This procedure describes setting up the AccuVote-OS for direct memory card programming. The AccuVote-OS should not be installed in a ballot box. 14. Unzip the carrying case, remove the AccuVote-OS and place it on a clean work surface. 15. Unlock and remove the printer cover. Make sure the following items are installed: •...

  • Page 39: Setting Up The Accuvote-Os For Ballot Processing

    7. Slide the AccuVote-OS unit onto the guide rails in the recessed opening in the ballot box lid. Do not slide the unit all the way to the back. Note the positioning of the AccuVote-OS prior to being slid onto the ballot box lid in Figure 8.2.

  • Page 40: Setting Up The Accuvote-Os On Election Day

    Setting Up the AccuVote-OS 12. Close the retaining door at the front of the ballot box lid over the lip of the AccuVote-OS unit and lock it into place. If the retaining door is difficult to close and lock, the security plate may not have removed from the ballot entry slot.

  • Page 41: Closing The Polls On Election Day

    6. Replace and lock the printer cover. 7. Slide the AccuVote-OS unit half way out of the ballot box lid and power the unit off. 8. Unplug the power cord from the wall outlet and thread it out of the power cord tube.

  • Page 42: Modem Transmission

    Election results may be transmitted to the host computer by modem. 8.1. Programming a memory card The AccuVote-OS first signals to the host computer that it is ready to receive information. Once ports have been readied in the AccuVote-OS Server 1 console in GEMS, ballot and vote center information is programmed to memory cards at the remote site.

  • Page 43: Setting Up Host Computer Modems

    Be attached to a host computer serial port by means of an RS-232C cable. The front and backs of the typical modem used are displayed in Figure 9-2 and Figure 9-3. © Diebold Election Systems, Inc. 2002 AccuVote-OS Hardware Guide...

  • Page 44: Multiple Serial Port Cards

    The multiple serial port card will transmit data at 2400 bps (bits per second), reflecting the speed of the pocket modem inside the AccuVote-OS units. We recommend using an eight-port, multiple serial-port card, although four-port and 16-port cards are also available.

  • Page 45: Telephone Lines

    An AccuVote-OS will redial a phone number if a line is busy, rather than the cascade the call to the next free line.

  • Page 46: Poll Workers

    Modem transmission • Line jack at the back of each AccuVote-OS is connected to the designated RJ-11 phone jack with an RJ-11 cable when transmitting results • Coupler plugs and additional RJ-11 phone cords are available as required • Dummy plug is attached to the Phone jack at the back of each AccuVote-OS.

  • Page 47: Pre-Election Maintenance

    Record the serial number, date purchased, firmware, card reader type, and whether a unit is equipped with a modem for each AccuVote-OS on hand. When problems are encountered, record a description of the problem, the date the problem occurred, the initials of the person logging the problem, when the problem is resolved, a description of the repair, the date, and the initials of the person logging the repair.

  • Page 48: Installing The Paper Roll

    9.3. Printer Ribbon Ensure that the printer ribbon is adequately inked prior to Election Day. Replace the ribbon if the type is very light or illegible in spots. The AccuVote-OS should be powered off before the printer ribbon is replaced.

  • Page 49: Battery

    A weak battery may also be indicated by the continuous display of the battery low message. 1. Enter Diagnostics Mode by powering the AccuVote-OS on while pressing the YES and NO buttons. 2. Remove the AccuVote-OS power cord.

  • Page 50: Power Fail

    Even though the unit is connected to a wall power jack, it is not receiving any AC power. 1. Plug the AccuVote-OS into an alternate power source. If the unit receives AC power, the initial power source is faulty and should not be used.

  • Page 51: Removing The Battery

    Using a side-to-side tugging motion may ease removal. A pair of needle nose pliers may supply a better grip, but do not pull with too tight of a grip or the connector may become damaged. Figure 9-1: AccuVote-OS Battery Terminals 9.4.5. Installing the Battery Ensure that the unit is powered off and the power cord is disconnected from the unit before attempting to remove the battery.

  • Page 52: Replacing The Memory Card Battery

    9.5. Replacing the memory card battery A low memory card battery is indicated by the appearance of the ‡ symbol in the bottom left corner of the AccuVote-OS LCD. Replace the memory card battery when the battery low symbol appears on the LCD.

  • Page 53: Equipment Maintenance And Repair

    Contingency procedures should be developed to replace faulty AccuVote-OS units with tested replacements on election day, when timing is critical. If an AccuVote-OS fails on election day, it should be powered off and on again and the unit should be replaced if the apparent failure persists.

  • Page 54: Post-Election Maintenance

    Equipment Maintenance and Repair 10.2. Post-election Maintenance When the election is over the AccuVote-OS batteries should be recharged and the units cleaned and stored. For more information on AccuVote-OS and ballot box storage, refer to the section titled Storage in Chapter 23: Maintenance in the AccuVote-OS Operator's GuidePrecinct Count User’s...

  • Page 55: Removing The Cover

    3. With the front panel facing you, raise the AccuVote-OS cover and place it on its back immediately behind the AccuVote-OS. Ensure that there is enough slack in the card reader's ribbon cable and the three-wire power supply cable to prevent damage to connections.

  • Page 56: Removing The Card Reader Assembly

    4. Connect the ribbon cable to the reader. Press the connector on one end of the ribbon cable into the header on the AccuVote-OS base and the connector on the other end of the ribbon cable into the header on the reader. The locking eject levers on both sides of the headers should snap into place once the connectors have been installed.

  • Page 57: Removing The Cpu Board

    The modem serial port connector is located to the right hand side of the main serial port header. The modem serial cable need only be removed if a modem is installed in the AccuVote-OS. 8. Grip the two-wire modem power connector located between the modem serial cable and the ballot reader connector and remove from the CPU board.

  • Page 58: Installing The Cpu Board

    CPU board. Grip each static ground connector and pull outwards in order to remove it from the CPU board. 11. Remove the AccuVote-OS YES and NO button pads by pushing out on the button pads from the inside of the chassis, using a small, flat blade (—) screwdriver.

  • Page 59: Removing The Battery

    — turn the thumb wheel clockwise in order to feed the paper through the printer ribbon. 14. Reinstall the AccuVote-OS cover using the procedure previously described in Replacing the cover. 10.7. Removing the battery Ensure that the unit is powered off before removing the battery and the power cord is disconnected from the unit.
  • Page 60 4. Make a note of the battery’s orientation, then disconnect the spade lug connectors from the terminals on the battery and remove the battery from its housing. See Figure 11-3. Figure 10-3: Battery compartment © Diebold Election Systems, Inc. 2002 AccuVote-OS Hardware Guide...

  • Page 61: Installing The Battery

    Before attempting this procedure, ensure that all external cables have been disconnected from the unit, and the AccuVote-OS has been powered off. 1. Prepare the work surface with a thick, soft, non-abrasive layer of material such as foam, in an area large enough for the chassis.

  • Page 62: Installing The Power Supply

    Installing the power supply Before attempting this procedure, ensure that all external cables have been disconnected, and the AccuVote-OS has been powered off. 1. Prepare your work surface with a thick, soft, non-abrasive layer of material such as foam, in an area large enough for the chassis.

  • Page 63: Removing The Lcd Module

    Removing the LCD module Before attempting this procedure, ensure that all external cables are disconnected from the unit and the AccuVote-OS is powered off. 1. Remove the cover using the procedure previously described in Removing the cover. Position the chassis with its front panel facing you.

  • Page 64: Installing The Printer

    8. Replace the unit cover using the procedure previously described in Replacing the cover. 10.15. Removing the ROM chips ROM chips contain the version of firmware being used by the unit. The AccuVote-OS firmware is upgraded by replacing existing ROM chips with new ones. There are two ROM chips on the CPU board: •...

  • Page 65: Installing The Rom Chips

    1. With the cover removed, position the chassis with the front panel facing you. 2. Orient ROM A chip with the notch on the chip facing toward the rear of the AccuVote-OS unit (in the same orientation as the rest of the chips in the unit).

  • Page 66: Removing The Smartwatch Rom Chip

    5. Replace the unit cover using the procedure previously described in Replacing the cover. 10.21. Removing the modem An AccuVote-OS may be installed with a modem used to program memory cards and transmit election results. The modem is used to communicate memory card information and election results at 2400 baud over telephone lines.

  • Page 67: Installing The Modem

    6. Detach the two-wire modem power cable connector from the modem by pulling the connector outwards from the modem. 7. Firmly grip the modem and pull out of the AccuVote-OS. Alternatively, you may use a flat blade (—) screwdriver to pry the modem away from the chassis. The modem is attached to the bottom of the chassis using double-sided adhesive tape, which should be carefully peeled off from the bottom of the modem and the chassis.

  • Page 68: Removing The Ballot Deflector

    The AccuVote-OS should not be installed in the ballot box before installing the ballot deflector. After the deflector is in position, an AccuVote-OS can be installed into the ballot box in order to verify ballot deflector alignment in Diagnostics Mode.

  • Page 69: Removing The Ballot Deflector Motor

    14. Remove the lift arm from the ballot box lid and close and lock the ballot box. 10.25. Removing the ballot deflector motor The AccuVote-OS should not be installed in the ballot box while removing the ballot deflector motor. 1. Unlock and open the ballot box lid and support on the ballot box lift arm.

  • Page 70: Installing The Ballot Deflector Motor

    5. Remove the lift arm from the ballot box lid and close and lock the ballot box. 10.26. Installing the ballot deflector motor The AccuVote-OS should not be installed in the ballot box while installing the ballot deflector motor. Unlock and open the ballot box lid and support on the ballot box lift arm.

  • Page 71: Installing The Ballot Deflector Cable

    10.28. Installing the ballot deflector cable The AccuVote-OS should not be installed in the ballot box while installing the ballot deflector cable. 1. If it is in place, unlock and remove the security plate from the ballot box entry slot. Do not place in the security plate recess on the ballot box lid as it may fall off once the lid has been opened.

  • Page 72: Points To Remember

    Check each ballot box on Election Day when the ballot counter reaches 1000 • Count absentee ballots on the AccuVote-OS units after polling ballots if ballots are being counted and tallied at the precincts. © Diebold Election Systems, Inc. 2002...

  • Page 73: Parts List

    This part does not include the CPU board mounting hardware (453-1111). 421-2332 Power Supply Assembly Replacement 120 volt AC switching power supply for the AccuVote-OS Unit. This part does not include the power supply mounting hardware (453-4111). 442-1111 Infra-red Reader Assembly AccuVote-OS reader fully assembled including the reader motor.
  • Page 74 128K x 8 RAM IC 128KB Static RAM chip. 521-2111 memory card Security Plate This part mounts onto the AccuVote-OS’s enclosure. It limits access to the memory card after it has been inserted. This part does not include the mounting hardware (453-4121). 541-0111 Loopback Connector ©...

  • Page 75: Ballot Box Unit Parts List

    Demonstration Test Ballot Cards A package of 25 demonstration ballots for use in testing whether the AccuVote-OS unit is reading marks on ballot cards during a test election. These ballots can be used with a test memory card (641-1112) loaded with the demonstration ballot card data.
  • Page 76 This cable has the ballot box deflector connector and bracket on one end and the ballot box motor interface connector on the other end. This part does not include the mounting hardware (453-7121). © Diebold Election Systems, Inc. 2002 AccuVote-OS Hardware Guide...

  • Page 77: Unit Specifications

    Unit Specifications 13. Unit Specifications This chapter covers the mechanical and electrical specifications of the AccuVote-OS ballot processing unit. 13.1. Mechanical Size: 16" x 14" x 3" Weight: 15 lbs. 13.2. Electrical Power Supply Input: 120 VAC, 60/50 Hz @ 0.3 A...

  • Page 78: Storage Environment

    Width: 8.50 in. (+ 0.030 in. - 0.020 in.) Thickness: 7 point (0.007 in.) Weight: Nominal 90 lb. Index stock For more information on ballot cards, see the GEMS User’s Guide. © Diebold Election Systems, Inc. 2002 AccuVote-OS Hardware Guide...

  • Page 79: Appendix A: Glossary

    Listed below are definitions for some of the more technical terms included in this manual. They appear in alphabetical order. ABSENTEE COUNT card A special card that when inserted in the AccuVote-OS unit, signals the unit to begin reading absentee ballots. Any ballot inserted after this card will be read as an absentee ballot.
  • Page 80 A small card used in the AccuVote-OS ballot processing unit to store precinct information and to record ballot results. override To force the AccuVote-OS unit to accept a rejected ballot card, such as an overvoted card, by pressing the YES button while the card is being read. overvoting Overvoting is when a voter votes for more candidates than he/she is eligible to vote for in a race.
  • Page 81 An abbreviation for Request to Send. test cards Two test cards are available for testing the AccuVote-OS unit. The marked test card test that the ballot reader is reading all the marks that it should. The blank test card tests that the ballot reader isn't reading extraneous marks.
  • Page 82 Write-ins are the blank lines on the ballot where the voter writes the name of a candidate that was not nominated to run in this race. © Diebold Election Systems, Inc. 2002 AccuVote-OS Hardware Guide...

  • Page 83: Appendix B: Accuvote-Os Inventory And Maintenance Logs

    Appendix B: AccuVote-OS Inventory and Maintenance Logs Table 1 presents an AccuVote-OS form that can be used to log the serial number, the purchase date, the firmware release (currently) installed, the reader type (i.e. visible light, infrared), as well as whether a modem is installed for each AccuVote-OS.
  • Page 84 Unit Specifications Initials Date Solution/ Repair Initials Date Problem Table 2: AccuVote-OS Maintenance Log © Diebold Election Systems, Inc. 2002 AccuVote-OS Hardware Guide...

  • Page 85: Appendix C: Ballot Box Inventory And Maintenance Logs

    Damage Foot Locks Deflector Working Security Plate Keys Serial Number Table 3: Ballot Box Inventory Log Store this sheet in a clear plastic sleeve near the ballot box. © Diebold Election Systems, Inc. 2002 AccuVote-OS Hardware Guide...
  • Page 86 Table 4 presents a ballot box log form that can be used to record all maintenance or upgrades to the ballot box. Initials Date Solution/Repair Initials Date Problem Table 4: Ballot Box Maintenance Log © Diebold Election Systems, Inc. 2002 AccuVote-OS Hardware Guide...

  • Page 87: Appendix D: Modem Transmission Checklist

    • Telephone number to be used for performing results transmission • Whether line is tone or pulse (prefix telephone number defined on AccuVote-OS either with T or P) • Whether line used is a voice line or a fax line •...
  • Page 88 Unit Specifications Ground/Cell Line Tested Ext. Special Codes Direct/PBX Voice/Fax Tone/Pulse Phone No. Polling Place Table 5: Modem transmission checklist © Diebold Election Systems, Inc. 2002 AccuVote-OS Hardware Guide...

  • Page 89: Appendix E: Rom Labels

    Unit Specifications Appendix E: ROM Labels The ROM chips are located at the front of the AccuVote-OS between the LCD and the memory card interface. Each ROM is labeled in the following manner: Accu-Vote LL AA RRRRR ##### I-CCCC YY-MM-DD...

  • Page 90: Appendix F: Rs-232 Pin Definitions

    The following table defines the signals and corresponding pins on the rear DB9-M serial connector which is wired as a DTE. This table represents a complete definition of all the pin assignments for the connector. Note that not all of these pins are used by the AccuVote-OS ballot processing unit. DB9-M PIN NO.

  • Page 91: Adapter Cable

    SIGNAL DB9-F DB25-M FUNCTION PIN NO. PIN NO. Data Carrier Detect Receive Data Transmit Data Data Terminal Ready Signal Ground Data Set Ready Request to Send Clear to Send Ring Indicator © Diebold Election Systems, Inc. 2002 AccuVote-OS Hardware Guide...
