Summary of Contents for CSC WIZ
- Page 2 If you have any recommendations, please let us know. For more information, please contact us. Used batteries should be recycled at appropriate sites. Only use genuine CSC components and accessories on this product. CSC Motorcycles 1331 Foothill Boulevard...
- Page 3 Caution Danger 1. Observe traffic rules ride safely. 1. Please check the accessories and all informa- 2. Do not operate the motorcycle without a li- tion with the electric motorcycle after opening cense. the box. 3. Do not operate the vehicle while udner the in- 2.
-
Page 4: Table Of Contents
Contents Appearance and the Name of Components ....................4 Engine start lock, USB, Manipulation handle .................... 5 Instrument Indicators ..........................6 LHS and RHS switches ..........................7 Items to Be Checked before Operation ....................8 Starting and Operation ..........................9 Inspection and Adjustment after Break-in .................... -
Page 5: Appearance And The Name Of Components
Appearance and the name of components 1. Headlamp 2. Instrument 3. Document box 4. Charging interface 5. Seat 6. Trunk 7. Tail lamp 8. Front wheel 9. Front shock absorber 10. Front pedal 11. Side stand 12. Rear wheel... -
Page 6: Engine Start Lock, Usb, Manipulation Handle
Engine start lock, USB, manipulation handle Name Description of functions Power source On Turn the key to the position to enable starting Power source Off Turn the key to the position to disable starting Turn the key to the position to lock the steering han- Steering lock dle and the electric motorcycle is not available USB interface... -
Page 7: Instrument Indicators
Instrument indicators Name Description of function RHS turn signal RHS turn signal lamp “ ”flickers when lamp it is being used High beam High beam indicator is illuminated indicator when it is being used Display of It displays the present temperature of temperature the instrument circuit board. -
Page 8: Lhs And Rhs Switches
LHS and RHS switches Name Description of function High beam lamp is illuminated when the lighting H i g h - l o w b e a m switch is turned to“ ”.Low beam is illuminated switching button when the lighting switch is turned“ ”... -
Page 9: Items To Be Checked Before Operation
Items to be checked before operation Check the items before operation to ensure the user can drive smoothly and safely Item Check Remarks Battery Check if the power of battery is sufficient M a i n t a i n t h e m o t o r c y c l e a s specified in this manual. -
Page 10: Starting And Operation
Starting and Operation 1. Insert the key into the seat lock hole to open the seat and turn air switch to “ON” to enable the general power source. 2. Insert the key into power source lock and turn it to the on position. -
Page 11: Inspection And Adjustment After Break
Inspection and adjustment after break-in The user shall attach importance to run-in after purchasing a new motorcycle. The initial mileage of 600 miles is the break-in period. The performance of break-in has direct impact on the service life. Break-in refers to a process during which all components can better fit in well with each other and deliver better performance after having used the new motorcycle over period of time. -
Page 12: Regular Maintenance
Regular Maintenance Miles Reading on odometer Items 300 Miles 2000 Miles 4000 Miles 8000 Miles Remark Controller Check Check Check Air switch Check Check Check Manipulation Cleaning Cleaning Cleaning Cleaning Braking handle Adjustment Adjustment Adjustment Adjustment Battery The user charges based on mileage covered Braking shoe Check Check... -
Page 13: Maintenance Requirements
Maintenance requirements Components may loosen and wear during operation. It is necessary to maintain the motorcycle on a regular basis in order to extend its service life, lower repair costs and achieve safe operation. 1. Keep the motorcycle clean, fully charged, and free from rattles. 2. -
Page 14: Charger Use And Maintenance Of Charger
Charger use and maintenance The charger is an important part of the motorcycle. The performance of the charger can heavily affect the service life of the battery. A charger mainly consists of a rectifier filter, a high-voltage switch, voltage commutation, control of constant voltage and charging and others. -
Page 15: Battery Use And Maintenance
The high temperature can lead to change of parameters of the charger and even to loss of control and swelling of battery. 3. Contact CSC Motorcycles for instructions on disposal of the battery when it is nececssary to do so. -
Page 16: Lithium Battery Removal
Lithium battery removal Removal steps: 1.Turn on the electric lock 2.Open the seat 3.Turn off the air switch 4.Open the battery pressing plate 5.Plug out the charging plug 6.Plug out the discharging plut 7.Lift the battery The installation steps are the reverse of the removal steps. Note: before removing the battery, the electric lock and air switch shall be turned off to disconnect the source of power and to avoid potential danger. -
Page 17: Drive Motor Maintenance
Drive motor maintenance The motorcycle employs a brushless DC rear wheel-mounted motor, with an efficiency of higher than 85%. The motorcycle features excellent gradability, higher speed, low current consumed for operating, long full charge endurance, outstanding coasting effect and other advantages. 1. -
Page 18: Brake Inspection And Adjustment
1. At the end of adjusting brake, sgrip and release the brake handle several times while rolling to check if the wheel can spin freely. At the end of adjusting brake, check the rear stop lamp switch and adjust if necessary. 2. Use only CSC components when servicing the brakes. -
Page 19: Cleaning And Storage
Cleaning and storage 1. Cleaning (1). Do not flush the motorcycle with high pressure water so as to avoid potential risk as a result of wet electrical parts and circuits. (2).Wipe the surface of the motorcycle using a clean cotton cloth or clean towel. -
Page 20: Specifications
Specifications Dimension L×W×H 1785×655×1240mm Wheelbase 1285mm Min. ground clearance 140mm Curb weight 91kg Max. payload 150kg Tire specification/tire pressure Front3.50-10/225kpa Rear3.50-10/250kpa Max. speed 70km/h Full charge endurance 20km/h - 140km Motor type and model 72V/3KW Wheel hub motor (2.15MT×10) Electric quantity consumed ≤3kw.h per 100km Controller... -
Page 21: Electrical Schematic
Electrical schematic Black----B, White----W, Yellow----Y, Blue----L, Green----G, Red----R, Brown----Br Grey----Gr, Light blue----Lb, Light green----Lg, Orange----O, Pink----P, Purple----K... - Page 22 All rights reserved; reprinting is prohibited. Format: 140mm 102mm Print: 1st printing July 2019...
