Summary of Contents for AVANIT Smartmeter ES1
- Page 1 DVB-S2 Messgerät smartmeter ES1 User Manual Version: 11.06.2019 – Englisch...
- Page 2 Technical Details smartmeter S30...
- Page 3 Technical Details Preface Dear Customer, Thank you for purchasing the digital DVB-S/C/T meter smartmeter ES1. This user manual contains all the information required to connect, to operate, to clean, and to dispose of the device. Please read the user manual carefully before you start using the meter.
-
Page 4: Table Of Contents
Technical Details Table of Contents 1. Safety precautions 2. Main features 3. Front panel and functions 4. Operations and Management 5. Main menu operation description 5.1 Find 5.2 Spectrum 5.3 List 5.4 Edit satellite 5.5 Edit transponder 5.6 Setup System 6. -
Page 5: Safety Precautions
Technical Details 1. Safety precautions • Please read this user’s guide carefully, especially for the first time users. • Do not touch the LCD display by hand. • Do not place heavy items on the device. • Keep this unit away from the heat, direct sunlight, strong mechanical vib- ration, or dusty places. -
Page 6: Main Features
Technical Details 2. Main features 1 - Support DVB-S, DVB-S2 2 - Support Spectrum Function 3 - Support 0/22KHz., DISEqC1.0 , UASLS 4 - Support Unicable LNB 5 - Build in highlight LED light 6 - Show the Signal Quality on Nixie Tube 7 - Build in buzzer 8 - Support to check the power cable automatically 9 - Support to reset to defaults... -
Page 7: Operations And Management
Technical Details 1 Signal Input 2 DC input 3 USB port 4 Compass 5 Indicator 6 LCD 7 Nixie tube 8 LED switch 9 Buttons 10 Power Switch 4. Operations and Management Power: It lights on when the power on Change: It lights on when change the battery 22K: Indicate the 22K signal 18V: Indicate the 18V output for LNB... -
Page 8: Main Menu Operation Description
Technical Details 5. Main menu operation description When power on, the screen will display some information about software, then enter to the main menu. 5.1 Find In this menu, it is display the signal strength and quality according to the parameters that user selected or edited, help user to adjust the dish. - Page 9 Technical Details Satellite Name: Chinasat6B Local Freq: 05150 Transponder Freq: 03840 Symbol Rate: 27500 Polarity: 22K: DiSEqC1.0: LNB2 USALS: Buzzer: S: 57 % Q: 45 % Set USALS parameter “ON”, press [OK] on this parameter to enter USALS function as below: Satellite Name: Chinasat6B Local Freq: 05150...
-
Page 10: Spectrum
Technical Details 5.2 Spectrum In this menu, the strength of input signal will display in graphic mode. Press < / > to move cursor, press Up / Down to change the range of signal strength display, current frequency and signal strength is shown on top, press [OK] to pause. 5.3 List 5.3.1 Manual Check Select the desired satellite and corresponding transponder, it will show the signal... -
Page 11: Edit Satellite
Technical Details ·Press Up / Down to change satellite ·Press < / > to change transponder 5.3.2 Auto Check This function is used for finding which satellite that selected has been connected to the line quickly and easily. It will stop switch satellite and light “Lock” LED when the signal has been locked. -
Page 12: Edit Transponder
Technical Details 5.5 TP In this menu user can add, modify or delete the transponders, including transponder frequency, symbol rate and polarity. Edit Transponder Transponder Modify Transponder Delete Transponder 5.6 Setup This menu contains some auxiliary functions and user data management 5.6.1 Back up Data You can back up satellite data to U disk by this menu. - Page 13 Technical Details ① “01” means this line information is about satellite. ② The serial number of the satellite, it must be continuous, can not from “01” to “03”. ③ Satellite name. The length is ten. If the name of the satellite is sat01, the third must be “00000sat01”.
- Page 14 Technical Details 5.6.4 Calculation Angle The function can calculate antenna elevation, azimuth and LNB polarization angle according to satellite longitude, local location longitude and latitude parameter set- tings, it is useful for receiving installation. Parameter Setting Sat Longitude: 111.0 E Local Longitude: 113.0 E Local Latitude:...
-
Page 15: Update Application System
Technical Details 6. Update application system The product can update application system from USB port, if you want to update application system, insert U disk, press MENU and connect power supply until the screen display as below. Select File SF700-1.BIN Press “OK”... -
Page 16: Technique Specifications
Technical Details 8. Technical specifications Frequency range 950~2150MHz Input signal Signal Level -65 ~ -25dBm Impedance 75Ω Symbol rate 1Msps~60Msps DVB-S: QPSK Demodulation DVB-S2: 8PSK,16APSK,32APSK Signal processing 22KHz Tone Supported DiSEqC1.0 Supported USALS Supported Switching Power input AC110~240V 50Hz/60Hz Power supply Switching Power output 12V DC 2000mA 9. - Page 17 Technical Details Technical Details System Resources DDRAM 1GByte DDR FLASH 8MByte Connectors Data Connector Audio Video Output Digital HDMI Audio Video Output Analog Hosiden Power Supply Power 15 V Li-Ion Battery 3000 mAh Voltage Power Supply/Charger 175 - 250 V ~, 50/60 Hz Size and Weight Length x Wide x Heigth 11.2 cm x 17.7 cm x 4.8 cm...
- Page 18 Declaration of Conformity Declaration of Conformity The company Avanit GmbH, Am Sternbach 1, 91477 Markt Bibart hereby declares conformity with the following guidelines and standards for this product: Guideline for electromagnetic compatibility 99/5/EC and 2014/30/EU EN61326-1:2013 EN61326-2-2:2013 ...
- Page 19 Declaration of Conformity smartmeter S30...
